Philips PentaFlood User manual

Page 1of 2
© 2016 Philips Lighting Holding B.V. All rights reserved.
www.philips.com/luminaires
443561063590/5900508-000 Rev. C
INSTALLATION INSTRUCTIONS
PentaFlood - Accessories
CAUTION: The installation and servicing of these products should be performed by a qualified electrician or service
personnel.
WARNING: To avoid electrical shock, TURN POWER SUPPLY OFF before installing or servicing this unit. Wire
fixtures in accordance with the national electrical code and any applicable local code requirements.
Top / Full Visor: Fig. 1
1. Fill up the notched areas between glass and door frame with RTV silicone as shown.
2. Attach clips between glass and door frame at notches area in frame as shown, ensure clip presses into
silicone.
3. Assemble visor to clips with the screws provided.
External Louvre: Fig. 2
1. Fill up the notched areas between glass and door frame with RTV silicone as shown.
2. Attach four clips between glass and door frame at notched area in frame as shown, ensure clip presses into
silicone.
3. Assemble external louvre to clips with the four screws provided.
SILICONE
SILICONE

Page 2of 2
© 2016 Philips Lighting Holding B.V. All rights reserved.
www.philips.com/luminaires
443561063590 Rev. C
Philips Lighting North America Philips Lighting Canada Ltd.
Corporation 281 Hillmount Road,
200 Franklin Square Drive, Markham ON, Canada L6C 2S3
Somerset, NJ 08873, USA
INSTALLATION INSTRUCTIONS
PentaFlood – Accessories
Vandal Shield: Fig. 3
1. Fill up the notched areas between glass and door frame with RTV silicone as shown.
2. Attach four clips between glass and door frame at notched area in frame as shown, ensure clip presses into
silicone.
3. Remove protective covering from shield and assemble to clips with four screws provided.
Wireguard: Fig. 4
1. Fill up the notched areas between glass and door frame with RTV silicone as shown.
2. Attach four clips between glass and door frame at notched area in frame as shown, ensure clip presses into
silicone.
3. Assemble wire guard to clips with the four screws provided.
SILICONE
SILICONE
