Philips HD9240/30 User manual

YYKW: 1336
HD9240/30
HD9240/31
HD9240/32
HD9240/33
HD9240/34
HD9240/35
HD9240/36
PRODUCT INFORMATION
- This product meets requirements regarding
interference suppression on radio and TV.
-After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
OPTIONAL (Accessories)
- Baking dish 4222 459 52761
Version: A
Air Fryer
TECHNICAL INFORMATION
•Frequency : 50/60 Hz
•Power Global : 2100 W
•Voltage Global : 220-230 V
•Cord length : 0.8 meter
•Materials : Outer skin : Plastic (PP)
: Pan : Aluminized steel
: Basket : Aluminized steel
: Basket mesh : Stainless steel
: Coating : PTFE coating
-Capacity : 2.2 liter (1,2 kg)
(till max indicator)
-Coloursetting : white/black
- Temperature : 80 till 200 °C
- Fuse cut-o temp. Motor : 145 °C
TCO : 190 °C
Specifications Airfryer XL with Rapid Air technology
Low fat fryer Multicooker 1.2kg, White
Design and finishing
• Color(s): Star White
• Materials: Plastic
General specifications
• Patented Rapid Air Technology
• Digital Touch-Screen Interface: 60-minute timer,
Integrated Power-on light
On/Off switch
Preset cooking function
Time and temperature control
• Ready signal
• Cord storage
• Non-slip feet
• Automatic shut-off
Weight and dimensions
•Product dimensions (W x H x D) : 315 x 302 x 423 mm
•Weight appliance : 7.0 kg

TECHNICAL INFORMATIONS HD9240/30
HD9240/31
HD9240/32
HD9240/33
HD9240/34
HD9240/35
HD9240/36

PARTSLISTS
Pos Service code Description
1
4203 036 03161
Top
cover main black
2 4203 036 03171
Housing
top
3 4203 036 03181
LCD Unit
complete
4203 036 03951
LCD
unit US
4 4203 036 03191
UI front
printed
5 4203 036 03201
UI diffuser
6 4203 036 03211
UI
PCB assy
4203 036 03961
UI PCB
assy US
7 4203 036 03221
UI
light seperator
8 4203 036 03231
UI back
9 4203 036 03241
Basket
assy
10 4203 036 03251
Pan
assy
11 4203 036 03261
Drawer
assy white
12 4203 036 03271
Chassis
bottom / side assy
13 4203 036 03281
Housing
/Bottom (incl. Studs)
14 4203 036 03291
Cable
storage white
15 4203 036 03301
Heat
shield
16 4203 036 03311
Cooking
fan assy
17 4203 036 03321
Fan
cooling incl. Ring, adapter
18 4203 036 03331
Cooling
air cover assy
19 4203 036 03341
Chassis
top assy
20 4203 036 03351
Pan
sealing
21 4203 036 03361
Heater
assy + reflector 230V/2000 W
4203 036 03531
Heater
assy + reflector 220V/2000 W
4203 036 03541
Heater
assy + reflector 127V/1900 W
4203 036 03551
Heater
assy + reflector 120V/1700 W
4203 036 03561
Heater
assy + reflector 110V/1550 W
4203 036 03571
Heater
assy + reflector 100V/1400 W
22 4203 036 03371
Power
supply PCB assy
23 4203 036 03391
Power
PCB frame
24 4203 036 03401
Motor
230V/50 Hz
4203 036 03411
Motor
250V/60 Hz
4203 036 03421
Motor
110V/60Hz
4203 036 03581
Motor
127V/60Hz
4203 036 03591
Motor
220V/50Hz (CN)
4203 036 03601
Motor
120V/60Hz
4203 036 03611
Motor
100V/650-60Hz
25 4203 036 03431
Exhaust
black
26 4203 036 03441
Powercord
EU
4203 036 03451
Powercord
UK/DB
4203 036 03461
Powercord
CN
4203 036 03471
Powercord AU
4203 036 03481
Powercord
TW
4203 036 03621
Powercord
ID
4203 036 03631
Powercord
AR
4203 036 03641
Powercord
CH
4203 036 03651
Powercord SA
4203 036 03661
Powercord
SG (export)
4203 036 03671
Powercord
KR
4203 036 03681
Powercord
BR (HV)
4203 036 03691
Powercord
SG/MY/HK
4203 036 03701
Powercord
TH
4203 036 03711
Powercord
US
4203 036 03721
Powercord
JP
4203 036 03731
Powercord
BR (LV)
HD9240/30
HD9240/31
HD9240/32
HD9240/33
HD9240/34
HD9240/35
HD9240/36

EXPLODED VIEW
1
2
3
4
5
6 7
8
9
10
11
12
13 14
(CRP)
LCD unit
HD9240/30
HD9240/31
HD9240/32
HD9240/33
HD9240/34
HD9240/35
HD9240/36

EXPLODED VIEW
15
16
17
18
19
20
21
22 23
24
25
26
HD9240/30
HD9240/31
HD9240/32
HD9240/33
HD9240/34
HD9240/35
HD9240/36

DISSASEMBLY ADVICE
A. Top cover removal
1. open the 4 screws on the bottom
2. remove the housing
B. LCD window removal
3. remove both wires
1. remove both screws
2. Dissasemble all 5 LCD parts
C. Powercord removal
1. Cut this cable
HD9240/30
HD9240/31
HD9240/32
HD9240/33
HD9240/34
HD9240/35
HD9240/36

DISSASEMBLY ADVICE
E. PCB removal
1. open the hook and remove all crimps
D. Heating element removal
1. remove the crimps from the PCB part
HD9240/30
HD9240/31
HD9240/32
HD9240/33
HD9240/34
HD9240/35
HD9240/36

DISSASEMBLY ADVICE
F. Motor/ventilator removal
1. turn the screw into the right side, hold the ventilator
2. turn the screw into the right side
HD9240/30
HD9240/31
HD9240/32
HD9240/33
HD9240/34
HD9240/35
HD9240/36

DISSASEMBLY ADVICE
G. Basket holder removal
1. open the 2 screws
remove the basket holder
H. Bottom/Heating shield removal
1. open all 4 screws
HD9240/30
HD9240/31
HD9240/32
HD9240/33
HD9240/34
HD9240/35
HD9240/36
