Philips PDEG User manual

106 mm (4.17 in)
99 mm (3.89 in)
110 mm (4.33 in)
38 mm
(1.49 in)
RJ12
+ V
PDEG
X 4
45 mm
(1.77 in)
45 mm
(1.77 in)
1 A
B
www.lighting.philips.com/dynalite
Ethernet Gateway
Installation Instructions
Instructions d’installation
Installationsanweisungen
Instrucciones de instalación
Istruzioni per l’installazione
Installatie-instructies
インストー ル 手 順
安装指示
50° C (122° F)
-20° C (-4° F)
≤
90%
IEC Pollution Degree II
Devices must be installed by a
qualied electrician in accordance with
all national and local electrical and
construction codes and regulations.
Les appareils doivent être installés par un
électricien diplômé conformément à tous les
codes et réglementations électriques et de
construction nationaux et locaux.
Die Geräte sind von einem qualizierten Elektriker
in Übereinstimmung mit allen geltenden
Vorschriften zu installieren.
Los dispositivos deben ser instalados por un
electricista calicado y cumpliendo todas las
normas y regulaciones, tanto nacionales como
locales, sobre instalaciones eléctricas y obras.
I dispositivi devono essere installati da un
elettricista qualicato in conformità con le norme
locali e nazionali vigenti in materia di costruzioni
edilizie e installazione di impianti elettrici.
De apparaten moeten worden aangebracht
door een gekwaliceerde elektricien en in
overeenstemming met alle nationale en
plaatselijke elektriciteits- en bouwvoorschriften.
装置を取り付ける際は、資格のある電気技師に依頼し、
国および地域の電気および建設に関するすべての法令に
従 ってくだ さい 。
根据国家/地区及当地的电气与建筑规范和法规，该设
备必须由有资质的电工进行安装。
.
PDEG

12-24 V
RJ45
Ethernet
DyNet RS485
GND AUX
< 20 m
+-
ETHERNET
SUPPLY IN
12/24 VDC
SERVICE
DYNET RJ12
PDEG
SHD GND D + D - + V AUX
RS-485 DyNet
RJ12
+-
GND AUX
< 20 m
RJ45
Ethernet
ETHERNET SUPPLY IN
12/24 VDC
SERVICERJ12
DYNET
PDEG
SHD GND D + D - + V AUX
12-24 V ≤ 2 A
Philips Dynalite
www.lighting.philips.com/dynalite
© 2018 Philips Lighting. All rights reserved.
2 A 3 A
3 B2 B
RS-485 DyNet Port
-
+
SHLD
GND
D +
D -
+ V
AUX
RJ45
Ethernet
µP
RJ12
12 V 100 mA
24 V 50 mA
SELV/Class 2
RS-485 DyNet Port
-
+
SHLD
GND
D +
D -
+ V
AUX
RJ45
Ethernet
µP
RJ12
12 V 300 mA
24 V 250 mA
12 V 200 mA
24 V 200 mA
SELV/Class 2
5
IEC Overvoltage Category III
IEC Overvoltage Category III
Federal Communications Commission (FCC) Compliance Notice: Radio Frequency Notice – This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the
equipment and receiver. Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. Consult the dealer or an
experienced radio/TV technician for help. Any modications not approved by the manufacturer of this device could void the user’s authority to operate this device.
Installation of a home and building automation and control system shall comply with HD 60364-4-41. The temperature limits and current-carrying capacities for
the communication wires specied in HD 384.5.523 shall not be exceeded.
This Class B digital apparatus complies with Canadian ICES-003: CAN ICES-3(B)/NMB-3(B). Cet appareil numerique de la classe B est conforme a la norme NMB-
003 du Canada: CAN ICES-3(B)/NMB-3(B).
Do not connect inputs to mains.
DyNet RS-485
Ethernet
4
