Service
Manual
Hairclipper
series 3000
HC3510/13
HC3510/15
HC3510/85

2
HC3510/13 /15 /85
Contents
Important repair instructions
•Only skilled personnel should carry out the repair.
•After repair the appliance should function properly.
•After repair the appliance has to meet the regulatory- and safety requirements that were applicable at the
time of release of the model.
•After repair the appliance always has to be tested for electrical safety according VDE 0701-0702 and for
medical products IEC 62353.
General information 3
Specications
Production date (or serial number)
Optional (accessories)
Disassembly- and Reassembly advice 4
To remove the Cutter assy
To place the Cutter assy:
Functions/features explanation 5
Service parts 6
Version history 7

3
Specications
Cutting system
•Trim-n-Flow technology
•Cutter width: 41 mm
•Cutting element: Stainless steel blades
•Number of length settings: 13
•Precision (size of steps): By 2 mm
•Range of length settings: From 0.5 to 23 mm
Accessories
•Comb: Adjustable hair comb, Extra adjustable
beard comb
•Maintenance: Cleaning brush
Ease of use
•Cleaning: Removable cutter, Washable blades
•Operation: Corded only
•Maintenance free: No oil needed
Power
•Automatic voltage: 100 - 240 V
Nose trimmer model
•NT1150 only with the HC3510/85
Design
•Handle: Ergonomic grip & handling
Service
•2-year worldwide guarantee: Yes, Plus 3-years
with registration
Production date (or serial number)
Optional (accessories)
•No specic issues
YYWW
YYWW
General information

4
HC3510/13 /15 /85
To remove the Cutter assy
1. Remove comb from the clipper
2. Push button for opening cutter
3. Clean the cutter/chamber with a brush
1
2
To place the Cutter assy:
1. Place nocks in front o clipper
2. Push on back to replace the cutter correctly
Disassembly- and Reassembly advice

5
Trim-n-Flow technology
Our new, innovative comb is designed to prevent
hair from getting stuck in the clipper. So you can
continue cutting your hair, from start to nish,
without interruption.
DualCut Technology
Power through any type of hair with our advanced
DualCut technology: an innovative two-sided
cutting element that cuts hair twice as fast as one-
sided blades.
Stainless steel blades
Self-sharpening stainless steel blades are
incredibly long-lasting. Even after 5 years, they cut
just like they did on day one.
13 lock-in length settings
Simply select and lock in the length you want.
The adjustable comb has 12 lock-in length
settings from 1 mm to 23 mm, with precisely 2 mm
between each length. Remove the comb entirely
for a close 0.5 mm trim.
Ecient corded use
The 1.8 m long power cord provides constant
power.
Comfortable grip
The HAIRCLIPPER Series 3000 is designed to be
comfortable to use, convenient to handle and easy
to operate. The special texture and grip allow you
to easily move the clipper and cut all around your
head.
Extra adjustable beard comb
Whether you have a beard or want the perfect
stubble, just attach the adjustable beard comb and
select one of 12 lock-in settings, from 1 to 23 mm.
There are precisely 2 mm between each length.
To get a shorter stubble, remove the comb entirely
for a close 0.5 mm trim.
Easy to clean
Simply click to release the detachable head to
quickly release and clean the blades.
Zero maintenance
No oil needed, for easy maintenance and to save
you time.
Functions/features explanation

6
1 2
3
5
4
HC3510/13 /15 /85
Pos Service code Description Remark
1 4222 036 32661 Cutter Unit FMG
2 4222 036 32611 Adjustable Hair Comb 1-23 mm
3 4222 036 32621 Adjustabl Beard Comb 1-23 mm
4 4222 036 02771 Cleaning Brush
5 4222 036 23831 Power Plug UK 3P HQ8505
4222 036 31071 Power Plug EU HQ8505
NT1150 See separate Service Manual on pww.pcc.philips.com
Service parts

7
19/01 Version 1.1 : HC3510 initial release.
Version history
