Philips LX3600D/25 Operating manual

~AC
MAINS
FRONT
RIGHT
CENTER FRONT
LEFT
REAR
RIGHT
REAR
LEFT
SUB-
W
SPEAKERS (4 )
AUX IN LINE OUT
AUDIO
L
R
L
R
S-VIDEO
MW
FM/MW ANTENNA
FM 75
SCART
LX3600D
Rear of TV
(example only)
VIDEO
AUDIO
OUT IN
S-VIDEO
IN
SCART IN
SCART IN
IN
First connect ...
... then play
(see next page)
Helpful Hints
You only need to make one video connection to your TV in
order to view the DVD playback.
If yourTV is not equipped with a SCART
connector, connect your TV through the
corresponding S-VIDEO connection (cable not
supplied).
S-VIDEO
Front Speaker
(right)
Front Speaker
(left)
Rear Speaker
(right)
Rear Speaker
(left)
Centre Speaker
MW loop
antenna FM antenna
Subwoofer
Scart cable
A
B
C
D
E
F
G
HI
12nc: 3139 115 22691

Detailed playback features and additional functions are described in the
accompanying owner’s manual.
Make sure your DVD system
and TV are connected and
turned on!
Playing a disc
1Press DISC on the remote control.
You can also adjust the SOURCE button on the front panel until “DISC” appears on the display
panel.
2Turn on theTV and select the correct Video In mode.
You should see the blue Philips DVD background screen on the TV (if no disc in the DVD system).
3Press OPEN/CLOSE 0on the front of the DVD system and load a disc,
then press OPEN•CLOSE 0again to close the disc tray.
Make sure the disc label is facing up. For double-sided discs, load the side you want to play face up.
4Playback will start automatically.
If a disc menu appears, use 3412buttons on the remote to make the necessary selection, then
press OK to confirm. Or, use the numeric keypad on the remote to select features. Follow the
instructions given in the disc menu.
5To stop playback, press STOPÇ.
Region Codes
DVDs must be labelled for ALL regions or for Region 2 in
order to play on this DVD system. ALL
2
No picture?
Check the AV (Audio/Video) mode on your TV.
* Usually this channel is between the lowest and highest channels and may be called FRONT, A/V IN, or
VIDEO.
* Or, you may go to channel 1 on your TV, then press the Channel down button repeatedly until you see
the Video In channel.
* Or, your TV remote control may have a button or switch that chooses different video modes.
* See your TV manual for more details.
