Philips Azur GC4250 User manual

ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Steam Iron Azur 4200
GC4250
03/06
PRODUCT INFORMATION
Features
- Electronic Iron (Digital Display)
- Color : Black
- Careeza soleplate
- Steam output (40 gram/min)
- Shot Of Steam, SOS (95 gram/min)
- Vertical SOS
- Spray feature
- Tank capacity (340 ml)
- Cord winder
- Cord length (2.4 m)
- Drip stop feature
- Anti-calc feature
- Self clean feature
- Auto-Shut-Off (ASO) feature
- Safety light
- Soleplate storage cover
Safety Information
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements and
legal regulations as officially laid down at this moment.
TECHNICAL INFORMATION
Voltage : 220 - 240 V
Frequency : 50 - 60 Hz
Power : 2000 - 2400 W
Dimension (F-box) : 328 (L) x 143 (W) x 181 (H) mm
Weight : 1.7 kg (include soleplate cover)
Water Advice
Suitable for tap water use. Advice to mix with equal portion
of distilled water or use only distilled water if the tap water is
very hard.
Self Clean
When the self clean button is pressed, a sudden release of
water into the soleplate loosen scale particles by thermal
shock. These particles are then flushed out through the steam
vents by the water.
Careeza Soleplate
Careeza is a multi-layer chemical substance that gives an
excellent gliding effect and better care for the garment.
Vertical Steam
When the iron is kept in a vertical position, the SOS button
can be used to iron hanging fabrics such as curtains.
Anti Drip
Water is only released into steam chamber via the tank
valve when the soleplate temperature is high enough. If the
temperature is too low, the tank valve is closed by means of a
bi-metal disc.
Auto-Shut-Off
The power to the heating element is cut off when the iron has
been motionless. The “Auto-Off” pilot light starts blinking.
When the iron is moved, it is automatically switched on.
Safety Light
A bright LED built into the water tank stays on as long as the
iron is plugged into a power socket. The LED light, obvious
from anywhere in the room, remind user that the iron is on.

GC4250
BACKPLATE 3
BACKPLATE COVER 26
CORDSET 4
BALL SWIVEL 5
Remove Screw A
Remove Screws B1, B2
FILLING DOOR 6
INLAY 7
OPERATION KNOBS 8
ELECTRONIC
CONTROLLER 9
Remove Screw A
Remove Backplate 3, 26
DISASSEMBLY ADVICE
REPAIR INSTRUCTIONS
- Due to the high voltage of the iron, ONLY the specified cordsets must be used.
- When replacing thermister assembly (Pos 2), ensure torque applied to the screw is
20 kgfcm. Also, handle the thermister assembly with care so as not to damage it.
- No information about the type number and voltage is stamped onto the typeplate.
When replacing the back plate (typeplate is at the bottom), engrave at least the type
number & voltage on the typeplate with a sharp object.
- Parts with numbers from 100 and higher cannot be ordered separately, except 101,
102, 117, 118.
OPTIONAL (accessories)
- No specific issues
SLIDE UNIT 10
NEEDLE SET 11
TANK SEAL 12
HANDLE 13
SELF CLEAN BUTTONS 14
SPRAY NOZZLE ASSY 15
PUMP ASSY 16
Remove Screw A
Remove Backplate 3, 26
Remove Inlay 7
Remove Operation knobs 101, 102
Remove Screws C1, C2
Remove Slide Unit 103, 104
Remove Needle set
105, 106, 107, 108, 109
Remove Screws D1, D2
WATER TANK 18
SAFETY LIGHT REAR CAP 1
SAFETY LIGHT 29
Remove Screw A
Remove Backplate 3, 26
Remove Screw J
Remove Safety light 29
Remove Inlay 7
Remove Operation knobs 101, 102
Remove Screws D1, D2
Remove Handle 13
Remove Screws E1, E2
Remove Water tank 18
Remove Screw F
SOLEPLATE COVER 19
ISOLATION PLUG 20
SOS SEAL 21
DOSING SEAL 22
THERMISTER 2
SOLEPLATE ASSY 23
Remove Screw A
Remove Backplate 3, 26
Remove Inlay 7
Remove Operation knobs 101, 102
Remove Screws D1, D2
Remove Handle 13
Remove Screws E1, E2
Remove Water tank 18
Remove Screw F
Remove Heat shield
Remove Screws G1, G2
Remove Soleplate cover 19
2-4

GC4250
PARTS LIST
HEATING
t
UNIT
THERMAL
FUSE
BROWN
Electronic
Module
(Control
Board)
Electronic
Module
(Power
Board)
INPUT
BLUE
RED
WHITE
BLACK
RED
L
N
E
3-4
Pos Service code Description Consist of
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
4239 026 15400
4239 021 18120
4239 026 05740
4239 000 06580
4239 000 06650
4239 022 54020
4239 021 17100
4239 021 17060
4239 026 14150
4239 026 14160
4239 021 18900
4239 022 54030
4239 022 54040
4239 015 54400
4239 021 17770
4239 022 54080
4239 021 03040
4239 020 90560
4239 026 14080
4239 026 14090
4239 021 17130
4239 026 14110
4239 025 98250
4239 015 54410
4239 015 54390
4239 021 18180
4239 021 17140
4239 015 55010
4239 026 14170
4239 026 05990
4239 026 05760
4239 021 18910
Safety light rear cap
Thermister assembly
Backplate
Cordset EU
Cordset Swiss
Ball swivel 112, 113
Filling door assembly
Inlay printed 116
SOS knob (Dark grey) 101
Spray knob (Dark grey) 102
Electronic controller
Slide unit 103, 104
Needle set 105, 106, 107, 108, 109
Tank seal
Handle printed
Self clean button (Dark grey) 110, 111
Spray nozzle unit
Pump assembly
Switch button (+) 117
Switch button (-) 118
Water tank assembly (Dark grey) 114
Cover
Isolation plug
SOS seal
Dosing seal
Soleplate assembly 115, 2
Soleplate storage cover
LCD cap
Backplate cover (Translucent grey)
Filling cup
Steam slider (Blue)
Safety light

GC4250
