Philips GC6400 SERIES User manual

GC6400 SERIES

2

3
A B DC
F
I
J
P
K L M
Q
G
H
E
N O
5

4


 6
 14
한국어 22
 30
ภาษาไทย 39
繁體中文 45
简体中文 52
65
72

6

Congratulations on your purchase and welcome to Philips! To fully benet from the support that
Philips offers, register your product at www.philips.com/welcome.

1 Ergonomic board height (Fig. 1)
Set the ironing board to the correct height. When you stand the distance between your elbow and
the ironing board has to be approximately 27cm. You can use the heat-resistant iron resting mat as a
guide.
2 Ergonomic iron design (Fig. 2)
The upward sloping handle ensures a comfortable position of the wrist.
3 Ergonomic iron resting mat (Fig. 3)
The iron resting mat allows you to place your iron horizontally on the ironing board.
Only use the resting mat on an ironing board - never use it on a surface that is not heat
resistant (Fig. 4).
Do not put the switched-on iron on the heat-resistant iron resting mat for a long period of time.
Only use the heat-resistant iron resting mat to put down the iron briey during ironing.

 Supply hose
 Temperature dial
 Temperature indicator
 Temperature light
 Steam trigger
 Steam tank cap
 Iron stand
 Steam tank
 Soleplate
 Mains cord
 On/off switch with power-on light
 ’Steam ready’ light (GC6450/GC6440 only)
 ’Steam tank empty’ light (GC6450/GC6440 only)
 Iron lock slide (GC6450/GC6440/GC6430 only)
 Steam control (GC6450/GC6440 only)
 Heat-resistant iron resting mat (GC6450/GC6440/GC6430 only)
 Heat-resistant iron resting mat (GC6433/GC6420/GC6410/GC6406/GC6405 only)

Read this user manual carefully before you use the appliance and save it for future reference.

- Never immerse the iron or the steam tank in water.

- Check if the voltage indicated on the type plate corresponds to the local mains voltage before
you connect the appliance.
- Do not use the appliance if the plug, the mains cord, the supply hose or the appliance itself
shows visible damage, or if the appliance has been dropped or leaks.
- If the mains cord or the supply hose is damaged, you must have it replaced by Philips, a service
centre authorised by Philips or similarly qualied persons in order to avoid a hazard.
- Never leave the appliance unattended when it is connected to the mains.


- This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their
safety.
- Children should be supervised to ensure that they do not play with the appliance.
- Do not let the mains cord and supply hose come into contact with the hot soleplate of the iron.
- If steam escapes from under the steam tank cap when the appliance heats up, switch off the
appliance and tighten the steam tank cap. If steam continues to escape when the appliance heats
up, switch off the appliance and contact a service centre authorised by Philips.
- Do not remove the steam tank cap from the steam tank when the steam tank is still under
pressure.
- Do not use any other cap on the steam tank than the cap that has been supplied with the
appliance, as the steam tank cap also functions as a safety valve.
- Do not put the switched-on iron on the heat-resistant iron resting mat for a long period of
time. Only use the heat-resistant iron resting mat to put down the iron briey during ironing.

- Only connect the appliance to an earthed wall socket.
- Check the mains cord and the supply hose regularly for possible damage.
- Always place and use the iron and the steam tank on a stable, level and horizontal surface.
- The iron stand and the soleplate of the iron can become extremely hot and may cause burns if
touched. If you want to move the steam tank, do not touch the stand.
- When you have nished ironing, when you clean the appliance, when you ll or empty the
steam tank and also when you leave the iron even for a short while: put the iron on the iron
stand, set the on/off switch to ‘O’ and remove the mains plug from the wall socket.
- Rinse the steam tank regularly according to the instructions in chapter ‘Cleaning and
maintenance’.
- This appliance is intended for household use only.

This Philips appliance complies with all standards regarding electromagnetic elds (EMF). If handled
properly and according to the instructions in this user manual, the appliance is safe to use based on
scientic evidence available today.

1 Remove any sticker or protective foil from the soleplate and clean the soleplate with a soft
cloth.
2 Fully unwind the mains cord and supply hose.
3 Place the steam tank on a stable, level surface.
4 Place the iron on the iron stand.


Never immerse the steam tank in water.
Do not open the steam tank cap when the iron and the steam tank are still hot.
1 Remove the mains plug from the wall socket.
2 Slowly unscrew the steam tank cap (Fig. 6).
 7

You may hear a sound when you remove the cap. This sound is caused by the vacuum or residual
pressure inside the steam tank and is perfectly normal.
3 Pour water into the steam tank (max. 800ml) (Fig. 7).
Use tap water to ll the tank.
If the tap water in your area is very hard, we advise you to use 50% distilled water and 50% tap
water.
Do not put perfume, vinegar, starch, descaling agents, ironing aids or other chemicals in the steam
tank.
4 Screw the steam tank cap tightly onto the lling opening of the steam tank.

If the steam tank becomes empty during ironing, follow the procedure below to quickly rell the
steam tank.
1 Keep the appliance plugged into the mains and make sure the on/off switch is set to ‘I’ (Fig. 8).
2 Press the steam trigger until you no longer hear any steam escaping from the
appliance (Fig. 9).
3 To depressurise the steam tank, keep the steam trigger pressed in and slowly unscrew the
steam tank cap anticlockwise.
Place a piece of cloth over the cap when you unscrew it. Make sure there is no steam left in the
steam tank.
4 Remove the mains plug from the wall socket and wait approximately 15 minutes for the
appliance to cool down.
5 Fill the steam tank as described in section ‘Filling the steam tank’ and let the appliance heat
up again.

Always place the steam tank on a stable, level and horizontal surface. Do not put the steam tank
on the soft part of the ironing board.
1 Put the iron on the iron stand.
Do not put the hot iron on the supply hose or the mains cord. Make sure the cord does not
come into contact with the hot soleplate.
2 To set the required ironing temperature, turn the temperature dial to the appropriate
position (Fig. 10).
Check the laundry care label for the required ironing temperature:

Symbol on laundry
care label
Type of fabric Temperature
setting
Steam setting
(specic
types only)
BSynthetic fabrics (e.g. acetate, acrylic,
viscose, polyamide, polyester) and
silk
1 -
CWool 2ECO
DCotton, linen 3 to Max ECO to ;
8

Symbol on laundry
care label
Type of fabric Temperature
setting
Steam setting
(specic
types only)
ZPlease note that Z on the label
means that the article cannot be
ironed.
- -
If you do not know what kind or kinds of fabric an article is made of, determine the right ironing
temperature by ironing a part that is not visible when you wear or use the article.
Silk, woollen and synthetic materials: iron the reverse side of the fabric to prevent shiny patches.
Start ironing the articles that require the lowest ironing temperature, such as those made of
synthetic bres.
3 Put the mains plug in an earthed wall socket and set the on/off switch to ‘I’.
,The steam tank and the soleplate heat up.
,When the temperature light goes out, the iron has reached the set temperature. As soon as
the water in the steam tank is ready for steam ironing:
- GC6450/GC6440: the ‘steam ready’ light goes on.
- GC6433/GC6430/GC6420/GC6410/GC6406/GC6405: the power-on light in the on/off switch
goes out.
Note: During steam ironing, the temperature light goes on from time to time. This indicates that the iron
is heating up to the set temperature.
Note: If you have been ironing at a high temperature and then set the temperature dial to a lower
setting, wait until the temperature light goes on and goes out again before you continue ironing. This
prevents damage to your fabrics.

- If the fabric consists of various kinds of bres, always select the temperature required by the
most delicate bre, i.e. the lowest temperature. For example: if an article consists of 60%
polyester and 40% cotton, it should be ironed at the temperature indicated for polyester ( 1)
and without steam.
- When you steam iron woollen fabrics, shiny patches may occur. To prevent this, use a dry
pressing cloth or turn the article inside out and iron the reverse side.
- Iron velvet and other fabrics that tend to acquire shiny patches in one direction only (along with
the nap) while you apply very little pressure.
- Do not use steam when you iron coloured silk. This could cause stains.


1 Make sure that there is enough water in the steam tank.
2 Set the required ironing temperature (see chapter ‘Preparing for use’).
Note: Steam ironing is only possible at higher ironing temperatures (temperature settings 2 to MAX).
3 Put the mains plug in an earthed wall socket and set the on/off switch to ‘I’.
- The power-on light in the on/off switch and the temperature light on the iron go on to indicate
that the steam tank and the iron start to heat up.
4 Specic types only: Select a steam setting suitable for the selected ironing
temperature: (Fig. 11)
- Select steam setting ECO for temperature setting 2.
 9

- Select a steam setting between ECO and ; for temperature settings 3 to MAX.
5 The steam tank and the soleplate heat up.
- Cold start: the soleplate takes approximately 2 minutes to heat up and the steam tank takes
approximately 6 minutes to heat up.
- Quick reheat: if you rell the steam tank during the ironing process, the water in the steam
tank takes approximately 6 minutes to heat up.
,When the iron has reached the set temperature, the temperature light goes out.
,As soon as the water in the steam tank is ready for steam ironing:
- GC6450/GC6440: the ‘steam ready’ light goes on (Fig. 12).
Note: During steam ironing, the ‘steam ready’ light goes out from time to time. This indicates that the
steam tank is heating up to the right temperature.
- GC6433/GC6430/GC6420/GC6410/GC6406/GC6405: the power-on light in the on/off switch
goes out.
6 Press the steam trigger and keep it pressed while you steam iron (Fig. 9).
Note: If you have not used the steam function for some time, the steam that was still present in the
supply hose has condensed into water. When you start steam ironing again, this may cause some
spluttering in the appliance and a few droplets of water may escape from the soleplate.
Note: To prevent droplets from falling onto your garments, hold the iron over an old cloth and press the
steam activator until the steam production has normalised before you start steam ironing again.

1 Set the required ironing temperature (see chapter ‘Preparing for use’).
2 Iron without pressing the steam trigger.
,Some steam escapes if you press the steam trigger by accident while you iron.
,If the steam tank is empty or has not heated up yet, you hear a clicking sound inside the
steam tank. This happens when the steam valve opens and is perfectly harmless.


You can also steam iron when you hold the iron in vertical position. This is useful for removing
creases from hanging clothes (e.g. jackets, suits and coats), curtains etc.
1 Hold the iron in vertical position and press the steam trigger (Fig. 13).
Never direct the steam at people.

The steam control is continuously adjustable and can be set to any position between ECO and ;
(see chapter ‘Preparing for use’).

When the water in the steam tank runs out during use, the ‘steam tank empty’ light goes on.
1 Rell the steam tank with water (see chapter ‘Preparing for use - Fast rell’).

When the steam tank is ready for steam ironing, the ‘steam ready’ light goes on.
10



1 Set the on/off switch to ‘O’ (Fig. 8).
2 Remove the mains plug from the wall socket.
3 Put the iron on the iron stand, set the steam control to l (specic types only) and let the
appliance cool down.

1 Clean the iron with a damp cloth.
2 Wipe scale and any other deposits off the soleplate with a damp cloth and a non-abrasive
(liquid) cleaner.
Never immerse the iron in water nor rinse it under the tap.

Rinse the steam tank once a month or after you have used the appliance approximately 10 times.
1 Carefully remove the steam tank cap (Fig. 6).
Let the appliance cool down sufciently before you remove the steam tank cap.
2 Rinse the steam tank with 500ml of fresh water.
3 Hold the steam tank upside down over the sink and pour out the water (Fig. 14).
4 Screw the steam tank cap back onto the steam tank.

1 Remove the mains plug from the wall socket and let the appliance cool down.
Make sure the appliance has cooled down sufciently before you put it away.
2 Empty the steam tank.
3 Regularly check if the mains cord and the supply hose are still undamaged and safe.
4 Specic types only: For safe storage, lock the iron onto the stand with the iron lock slide.
First put down the tip (1) and then put down the heel (2) (Fig. 15).
5 Wind up the hose and cord separately.
6 Insert the hose and cord neatly in the cord storage compartment (Fig. 16).

- Do not throw away the appliance with the normal household waste at the end of its life, but
hand it in at an ofcial collection point for recycling. By doing this, you help to preserve the
environment (Fig. 17).

If you need service or information or if you have a problem, please visit the Philips website at
or contact the Philips Consumer Care Centre in your country (you nd its
phone number in the worldwide guarantee leaet). If there is no Consumer Care Centre in your
country, go to your local Philips dealer.
 11


This chapter summarises the most common problems you could encounter with the appliance. If
you are unable to solve the problem with the information below, contact the Consumer Care
Centre in your country.
Problem Cause Solution
Some smoke
comes out of the
appliance after it
has been
switched on for
the rst time.
This is normal. Some parts of the
appliance have been greased lightly in
the factory.
This phenomenon ceases after a
short while.
Dirt particles
come out of the
soleplate of the
new iron.
This is normal with a new iron. These particles are harmless
and stop coming out of the
soleplate after you have used the
iron a few times.
Droplets of
water escape
from the
soleplate.
The temperature dial has been set to
a temperature that is too low for
steam ironing.
Set an ironing temperature that is
suitable for steam ironing
(temperature settings 2 to MAX).
The appliance is not switched on. Set the on/off switch to ‘I’.
The steam tank has been placed on an
unstable and/or uneven surface.
Put the steam tank on a stable and
even surface.
When you start steam ironing, the
hose is cold. Steam condenses in the
hose, causing droplets of water to
escape from the soleplate.
This is normal. Hold the iron over
an old cloth and press the steam
trigger. The cloth absorbs the drops.
After a few seconds, the steam
production becomes normal.
The appliance
does not
produce any
steam.
The appliance is not switched on. Set the on/off switch to ‘I’
The steam tank is not hot enough to
produce steam.
Wait 6 minutes for the steam tank
to heat up.
You are not pressing the steam trigger. Press the steam trigger and keep it
pressed while you steam iron.
There is not enough water in the
steam tank.
Fill the steam tank. See chapter
‘Preparing for use - Filling the Steam
tank’.
No steam comes
out of the
soleplate.
Superheated (i.e. high-quality) steam is
hardly visible, especially when the
temperature dial is set to maximum
position and even less so when the
ambient temperature is relatively high.
To check if the iron really produces
steam, hold a (cold) mirror in front
of the soleplate vents.
The soleplate is
dirty.
Impurities or chemicals present in the
water have deposited on the soleplate.
Clean the soleplate with a damp
cloth.
12

Problem Cause Solution
You have been ironing at too high
temperatures.
Clean the soleplate with a damp
cloth. Set the iron to the required
ironing temperature (see chapter
‘Preparing for use’, section ‘Setting
the temperature’).
Steam escapes
from the lling
hole area during
ironing.
You may not have tightened the steam
tank cap properly or you have spilled
some water around the lling hole
Switch off the appliance and let it
cool down. Remove the steam tank
cap, wipe away the water round the
lling hole and tighten the steam
tank cap again. Then switch on the
appliance again.
Wet spots
appear on the
garment during
ironing
The wet spots that appear on your
garment after you have steam ironed
for some time may be caused by
steam that has condensed onto the
ironing board. Iron the wet spots
without steam for some time to dry
them. If the underside of the ironing
board is wet, wipe it dry with a piece
of dry cloth.
To prevent steam from condensing
onto the ironing board, use an
ironing board with a wire mesh top.
I cannot put the
iron on its heel.
This iron has been designed in such a
way that it can only be placed
horizontally.
Place the iron on the heat-resistant
iron resting mat.
 13

59

60

61

62

63

64

65
