Philips Intellicare GC8080 User manual

Intellicare
GC8080

2

3

4

ENGLISH 6
ČESKY 18
MAGYAR 29
HRVATSKI 41
EESTI 52
LATVISKI 63
LIETUVIŠKAI 75
БЪЛГАРСКИ 86
GC8080

Introduction
Thank you for buying the Intellicare GC8080, the new intelligent steam-
ironing system from Philips.
The iron offers non-stop ironing and also has a detachable water tank
that can be refilled at any moment.
The iron has a constant high steam output, which is a unique feature
for steam-ironing systems with unlimited autonomy.This gives you a
constant and fast ironing result.
The Intellicare GC8080 is equipped with intelligent electronic
temperature control with fabric-specific settings. It has an easy-to-use
programmable interface with audio feedback and an Iron-off function
that automatically switches the soleplate off when the iron has not
been used for several minutes for extra safety and to save energy.
General description
ATemperature button (+)
BTemperature button (-)
CMenu button
DDisplay
ESteam activator
FIron stand
GPower on/off switch with pilot light
HCord storage facility for mains cord & supply hose
ISteam tank pilot light
JSteam tank
KSupply hose
LSoleplate
MDetachable water tank
NFilling opening
OWater tank release lever
PTransport handgrip
QMains cord
R'Water tank refill' indicator light
SCalc-Clean rinsing cap & plug
TFunnel
UCup
VKey (for removing Calc-Clean plug)
Important
Read these instructions for use carefully before using the appliance and
save them for future reference.
◗Check if the voltage indicated on the bottom of the steam tank
corresponds to the mains voltage in your home before you
connect the appliance.
ENGLISH6

◗Rinse the steam tank once a month or after every 10 times of use
to prevent damage to your iron.
◗Do not put perfume, vinegar, starch, descaling agents, ironing aids
or other chemicals in the water tank.
◗Never use the appliance if it is damaged in any way. Regularly
check if the mains cord and the supply hose are still undamaged
and safe.
◗If the mains cord is damaged, it must be replaced by Philips, a
service centre authorised by Philips or similarly qualified persons
in order to avoid a hazard.
◗Only connect the appliance to an earthed wall socket.
◗Never immerse the iron or the steam tank in water.
◗Never remove the Calc-Clean rinsing cap and unscrew the Calc-
Clean rinsing plug when the steam tank is hot.
◗Do not leave the iron unattended when it is connected to the
mains, even if it is equipped with an Iron-off function.
◗Always place the appliance on a stable, level and horizontal
surface.
◗Always place the iron on the iron stand or on its heel. Do not put
the hot iron on the supply hose or the mains cord. Make sure that
mains cord and the supply hose do not come into contact with
the hot soleplate.
◗The iron stand and the soleplate of the iron can become
extremely hot and may cause burns if touched. If you want to
move or carry the steam tank, avoid touching the iron stand.
◗This appliance is not intended for use by young children. Infirm
person should not be allowed to use the appliance without
supervision.
◗Keep an eye on children to make sure that they do not play with
the appliance.
◗If steam escapes from the steam tank when the appliance is
heating up, switch the appliance off and contact a service centre
authorised by Philips.
Before first use
BThe iron may give off some smoke when you use it for the first time.This
is normal and will stop after a short while.
BWhite particles may come out of the soleplate when you use the iron for
the first time.This is normal; the particles are harmless and will stop
coming out of the iron after a short while.
BWhen you switch the appliance on, the steam tank may produce a
pumping sound.This is normal; the sound tells you that water is being
pumped into the steam tank.
1Remove any sticker or protective foil from the soleplate and
clean the soleplate with a soft cloth.
ENGLISH 7

C2Place the steam tank on a stable and level surface, i.e. on the
ironing board or on a table.
Preparing for use
Filling the detachable water tank
If the tap water in your area is very hard, we advise you to mix the tap
water with an equal amount of demineralised water.
Do not put perfume, vinegar, starch, descaling agents, ironing aids, other
chemicals or 100 percent distilled water in the water tank.
C1Remove the detachable water tank from the steam tank.
2Fill the water tank with water up to the MAX indication.
3Slide the water tank back into the steam tank.
◗The water tank can be refilled at any time during use.
◗This appliance has a built-in water level sensor.When the
minimum level of the detachable water tank has been reached, the
'water tank refill' indicator light goes on.
Steam ironing will not be possible!
BNote:When you use the appliance for the first time or after Calc Clean,
a lot of water will be pumped from the detachable water tank into the
steam tank. Refill the water tank, if necessary.
◗The message "Water low, refill tank" is shown on the display and
you will hear two short beeps.
Setting the temperature
1Check the garment label for the required ironing temperature.
C2Switch the appliance on
Put the mains plug in an earthed wall socket and switch the appliance
on by pressing the on/off switch on the steam tank.
◗The display lights up and you will hear a short beep.The following
message moves across the display:
"Welcome to Philips - Checking Sensor - Warming Up".
ENGLISH8

C◗When you switch the appliance on, it will automatically heat up to
temperature setting 2.
3Press temperature button + or - (hotter or colder) to set the
required ironing temperature/fabric type.
◗The display shows the type of fabric for which the selected
temperature is most suitable.
C◗The display indicates that the iron is heating up or cooling down
to the selected temperature.
A double beep and a message on the display indicate that the soleplate
has reached the selected temperature.
C◗As soon as the steam tank has reached its maximum pressure
level and is ready for steam ironing, the steam tank pilot light goes
out.
Tips
- If the article consists of various kind of fibres, always select the
temperature required by the most delicate fibre, i.e. the lowest
temperature. If, for example, the fabric consists of 60% polyester and
40% cotton, it should be ironed at the temperature indicated for
polyester (2).
- If you do not know what kind of fabric(s) the article is made of,
determine the right ironing temperature by ironing a part that will
not be visible when you wear or use the article.
- Silk, woolen and synthetic materials : iron the reverse side of the
fabric to prevent shiny patches.
- Fabrics that tend to acquire shiny patches should be ironed in one
direction only (along with the nap) while applying very little pressure.
ENGLISH 9

- Start ironing the articles that require the lowest ironing temperature,
i.e. those made of synthetic materials.
◗To make the iron cool down faster, simply apply steam or iron a
piece of cloth.
Display menu
BFor an explanation of the English terms on the display, see the table at
the end of these instructions for use.
The GC8080 offers 3 functions that allow you to adjust the settings of
the appliance to your own preferences.
C◗These functions are listed in a menu.You can use the menu by
pressing the menu button and the + & - buttons.
◗The menu structure of these functions is:
- Language: (several language possibilities)
- Sound: (on)/off
- Iron off: 5/(10)/15/20 minutes
Note: default settings are shown between ( ).
To select your preferred settings:
1Press the menu button for 1 second.
2Use the + and - buttons to scroll through the available settings.
3When you have reached the setting of your choice, press the
menu button again.The message "Selection Confirmed"
appears on the display.
4To exit the menu, wait 3 seconds.
Using the appliance
Steam ironing
The supply hose may become hot during a long ironing session.
BThe system may occasionally produce a pumping sound during steam
ironing.This is normal and tells you that water is being pumped into the
steam tank.
1Make sure there is enough water in the water tank.
◗Steam ironing is only possible at higher ironing temperatures
(higher than 2).
ENGLISH10

C2Press the steam activator to start steam ironing.
◗During steam ironing, the 'steam tank heating up' pilot light goes
on from time to time to indicate that the steam tank is heating up
to maintain the right temperature and pressure.
◗The opening and closing of the steam valve in the steam tank will
cause a clicking sound.This is perfectly normal.
C◗The steam function is controlled automatically and it is linked to
the selected temperature.The steam symbol is shown on the
display when the temperature of the iron is high enough for steam
ironing.
-2: visible wet steam
- MAX: invisible dry steam
◗The steam function will be automatically disabled at ironing
temperatures that are not suitable for steam ironing.
Ironing without steam
1Start ironing without pressing the steam activator.
Features
Vertical steaming
Never direct the steam at people.
C◗You can steam iron hanging curtains and clothes (jackets, suits,
coats) by holding the iron in vertical position and pressing the
steam activator.
Iron-off function
The iron-off function automatically switches off the soleplate when the
steam activator has not been pressed for a particular number of
minutes, depending on the iron-off time you have selected.
You can select an iron-off time of 5, 10, 15 or 20 minutes (see section
'Display menu').
1The display will show the text "Iron off" and you will hear an
intermittent beep.
2If you want to start ironing again, press any button on the iron.
The soleplate will then start heating up again.
ENGLISH 11

BNB: the Iron-off function switches off the soleplate but does not switch
off the steam tank. If you intend to stop ironing, you should switch the
appliance off and unplug the steam tank.
After Ironing
C1Put the iron on the stand.
C2Switch the appliance off.
3Remove the mains plug from the wall socket and let the iron
cool down.
Cleaning and maintenance
After each use
Never immerse the iron in water nor rinse it under the tap.
1Clean the iron with a damp cloth.
2Wipe scale and any other deposits off the soleplate with a
damp cloth and a non-abrasive cleaning agent.
Calc Clean
Never remove the Calc-Clean rinsing cap and unscrew the Calc-Clean
rinsing plug when the steam tank is hot.
VERY IMPORTANT: Rinse the steam tank once a month or after every
10 times of use to prevent damage to your iron.
BThe scale that develops inside the steam tank will not deposit onto the
walls. Just calc-clean the steam tank once or twice a month to keep your
Intellicare in good condition.
1Make sure that the steam tank has been unplugged for more
than 2 hours and is not hot.
ENGLISH12

C2Remove the detachable water tank.
C3Hold the steam tank with both hands and shake well.
C4Turn the steam tank on its side and remove the Calc-Clean
rinsing cap & rinsing plug with the special key supplied or with
a coin.
C5Empty the steam tank by pouring out the water into the cup or
into the sink.
C6Fill the steam tank with fresh water by means of the cup and
funnel and shake again.
ENGLISH 13

C7Empty the steam tank by pouring out the water into the cup or
into the sink.
Repeat steps 6 & 7 twice to obtain the best result.
C8Put the Calc-Clean rinsing plug back into the steam tank and
tighten it with the special key supplied or with a coin.
C9Put the Calc-Clean rinsing cap back onto the steam tank.
Calc-Clean reminder
When the display shows the following message:
"SWITCH IRON OFF - CALC-CLEAN STEAM TANK"
You are advised to calc-clean the steam tank as described above in
steps 1 to 9.
Storage
Always let the iron cool down before storing it.
C1Empty the water tank and store the supply hose and the mains
cord.
2There are handgrips on the either side of the steam tank for
easy transport.
ENGLISH14

Guarantee & service
If you need information or if you have a problem, please visit the Philips
website at www.philips.com or contact the Philips Customer Care
Centre in your country (you will find its phone number in the
worldwide guarantee leaflet). If there is no Customer Care Centre in
your country, turn to your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and Personal Care BV.
ENGLISH 15

Solution
Check the mains cord, the plug and
the wall socket.
Set the on/off switch to 'on'.
Press any button on the iron to
deactivate the Iron-off function.The
soleplate will then start heating up
again.
This phenomenon is perfectly normal
and will cease after a short while.
Fill the water tank (see 'Preparing for
use', section 'Filling the detachable
water tank').
Wait until the pilot light goes out.
Set the temperature to 2or higher.
Attach the water tank to the steam
tank properly (you will hear a click).
Set the iron to a lower temperature,
e.g. 2, to check if the iron is actually
producing steam.
Clean the soleplate with a damp cloth.
Contact an authorised Philips service
centre.
This is normal.
Unplug the iron immediately and
contact an authorised Philips service
centre.
Rinse the steam tank. See chapter
'Cleaning and maintenance'.
Possible cause(s)
There is a connection problem.
The steam tank has not been switched
on.
The Iron-off function has switched the
soleplate off.
Some parts of the appliance have
been lightly greased in the factory and
may initially give off some smoke when
heated.
There is not enough water in the
water tank.
The steam tank pilot light is still on.
The selected ironing temperature is
too low for steam ironing.
The water tank has not been properly
attached to the steam tank.
When the iron has been set to a very
high temperature, the steam produced
is dry and hardly visible. It will be even
less visible when the ambient
temperature is relatively high and it will
be entirely invisible when the
temperature has been set to MAX.
Impurities or chemicals present in the
water have deposited in the steam
vents and/or on the soleplate.
A sensor failure has been detected.
Water is being pumped into the steam
tank.
The pumping sound does not stop.
Too much scale and minerals have
accumulated inside the steam tank.
Problem
The appliance does not become hot.
Smoke comes out of my new iron
when I switch it on.
The iron does not produce any steam.
Flakes and impurities come out of the
soleplate or the soleplate is dirty.
"Error" has appeared on the display
and the iron beeps continuously.
The appliance produces a pumping
sound.
Dirty water comes out of the
soleplate.
Troubleshooting
This chapter summarises the most common problems you could encounter with your iron. Please
read the different sections for more details. If you are unable to solve the problem, please contact the
Philips Customer Care Centre in your country.
ENGLISH16

Translation
WELCOME TO PHILIPS -
CHECKING SENSORS -
CHECKING WATER
LANGUAGE
ENGLISH - DUTCH -
FRENCH - GERMAN -
CONFIRMED
SOUND - << OFF >> -
>> ON << -
CONFIRMED
IRON OFF - 5 MIN - 10
MIN - 15 MIN - 20 MIN -
CONFIRMED
IRON OFF - STANDBY -
PRESS ANY KEY TO
RESUME
ACETATE - ACRYLIC -
VELVET - NYLON - SILK -
VISCOSE - POLYESTER -
WOOL - RAYON -
COTTON - JEANS - LINEN
WARMING UP
COOLING
TEMP OK
WATER LOW - REFILL
WATERTANK
SWITCH OFF IRON -
CALC-CLEAN STEAM
TANK
ERROR 01
Message in English
WELCOME TO PHILIPS -
CHECKING SENSORS -
CHECKING WATER
LANGUAGE
ENGLISH - DUTCH -
FRENCH - GERMAN -
CONFIRMED
SOUND - << OFF >> -
>> ON << -
CONFIRMED
IRON OFF - 5 MIN - 10
MIN - 15 MIN - 20 MIN -
CONFIRMED
IRON OFF - STANDBY -
PRESS ANY KEY TO
RESUME
ACETATE - ACRYLIC -
VELVET - NYLON - SILK -
VISCOSE - POLYESTER -
WOOL - RAYON -
COTTON - JEANS - LINEN
WARMING UP
COOLING
TEMP OK
WATER LOW - REFILL
WATERTANK
SWITCH OFF IRON -
CALC-CLEAN STEAM
TANK
ERROR 01
Option
Choosing a language
Switching the sound on or
off
Setting the auto shut-off
time
Choosing the type of fabric
Iron warming up because
different type of fabric has
been selected
Iron cooling down because
different type of fabric has
been selected
Correct temperature for
selected type of fabric has
been reached
Action
Switching the appliance on
Using the menu button
Iron switches off after the
auto shut-off time has
elapsed
Pressing the + and - buttons
Water tank is empty or has
not been placed (properly)
Iron has been used 10 times:
rince the steam tank
Iron should not be used
Explanation of display
ENGLISH 17

Úvod
Děkujeme vám, že jste si zakoupili žehličku Intellicare GC8080, která
pře stavuje nový žehlicí systém o firmy Philips.
Žehlička poskytuje žehlení non-stop a má též o nímatelný zásobník
vo y, íky tomu ji lze k ykoli naplnit vo ou.
Žehlička má konstantní vy atný výstup páry, což je je inečná výho a
systémů pro žehlení s parou. Poskytují totiž konstantní a rychlý výsle ek
žehlení.
Žehlička Intellicare GC8080 je vybavena inteligentním elektronickým
regulátorem teploty se specifickým nastavením po le ruhu textilie. Má
sna no programovatelné rozhraní s akustickou zpětnou vazbou a se
speciální funkcí, která automaticky topné těleso žehličky vypne, poku
byla žehlička několik minut v nečinnosti.To zmenšuje spotřebu žehličky
a zvětšuje její bezpečnost.
Všeobecný popis
ARegulátor teploty +
BRegulátor teploty -
CTlačítko menu
DDisplej
EAktivátor páry
FPo stavec žehličky
GSpínač a vypínač s kontrolkou
HProstor pro uložení síťového přívo u a příslušenství
IKontrolka zásobníku páry
JZásobník páry
KPřívo ní ha ice
LDno žehličky
MO nímatelný zásobník vo y
NPlnicí otvor
OPáčka k uvolnění zásobníku vo y
PTransportní rukojeť
QSíťový přívo
RKontrolka pro naplnění zásobníku vo ou
SVíčko a zátka pro funkci Calc-Clean
TNálevka
UNá obka
VKlíč k otevření zátky Calc-Clean
D ležité
Pře použitím přístroje přečtěte po robně tento návo a uschovejte
ho pro přípa né poz ější nahlé nutí.
◗Zkontrolujte, zda napětí, udané na typovém štítku přístroje,
souhlasí s napětím ve vaší světelné síti.
ČESKY18

◗Zásobník páry vypláchněte jednou za měsíc nebo v dy po
desetinásobném pou ití ehličky abyste předešli jejímu poškození.
◗Do zásobníku vody nikdy nenalévejte parfémy, ocet, škrob nebo
prostředky k odstranění vodního kamene ani jiné chemikálie.
◗Nikdy přístroj nepou ívejte, pokud zjistíte jeho jakékoli poškození.
Pravidelně té kontrolujte síťový přívod a napájecí hadici, zda
nejsou poškozeny.
◗Poškozený síťový přívod musí být vyměněn v servisu firmy Philips
nebo v servisu, který byl firmou Philips autorizován, či obdobně
kvalifikovaným pracovníkem, aby se zabránilo případné pozdější
hazardní situaci.
◗Pou ívejte v dy zásuvku s nulovým kolíkem.
◗Nikdy nesmíte ehličku nebo zásobník páry ponořit do vody.
◗Nikdy nesnímejte víčko funkce Calc-Clean a neodšroubovávejte
zátku Calc-Clean pokud je zásobník páry ještě horký.
◗Pokud je ehlička připojena k síti, nenechávejte ji nikdy bez
dozoru a to i kdy je vybavena funkcí automatického vypnutí.
◗Přístroj umístěte v dy na stabilní a vodorovnou podlo ku.
◗V dy odkládejte ehličku na její podstavec nebo na její zadní stěnu.
Nepokládejte ehličku na přívodní hadici nebo na síťový přívod.
Dbejte na to, aby síťový přívod ani přívodní hadice nepřišly do
styku s horkým dnem ehličky.
◗Podstavec ehličky a dno ehličky jsou velmi horké a při dotyku
poko ku popálí. Pokud potřebujete přemístit zásobník páry, nikdy
se nedotýkejte podstavce ehličky.
◗Tento přístroj není vhodný pro menší děti. Neznalé osoby by
neměly s ehličkou pracovat bez dozoru.
◗Sledujte děti, zda si s ehličkou nehrají.
◗Pokud ze zásobníku páry vystupuje pára kdy se obsah ohřívá,
přístroj vypněte a kontaktujte servis firmy Philips nebo
autorizovanou opravnu.
Před prvním použitím
BŽehlička může po prvním použití poněkud kouřit.To je běžný jev, který
zakrátko zmizí.
Be dna žehličky mohou též zpočátku vystupovat bílé částečky.To je též
běžný jev, který zakrátko zmizí.
BKdyž přístroj zapnete, zásobník páry vydává slabý přerušovaný zvuk.To je
rovněž zcela normální, protože to dokazuje, že je do zásobníku páry
čerpána voda.
1Ze dna ehličky sejměte všechny nálepky i ochrannou fólii a
dno vyčistěte měkkým hadříkem.
C2Zásobník páry umístěte na stabilní a rovnou podlo ku,
například na ehlicí desku nebo na stůl.
ČESKY 19

Příprava k použití
Plnění odnímatelného zásobníku vodou
Poku je vo a ve vaší oblasti na měrně tvr á, oporučujeme vám
míchat ji v poměru 1:1 s emineralizovanou vo ou.
Do zásobníku vo y nenalévejte parfémy, ocet, škrob, prostře ky pro
o stranění vo ního kamene nebo jiné chemikálie. Ne oporučujeme
používat ani 100 % estilovanou vo u.
C1Vyjměte zásobník vody ze zásobníku páry.
2Zásobník naplňte vodou a po označení MAX.
3Zasuňte zásobník vody zpět do zásobníku páry.
◗Zásobník vody mů ete plnit kdykoli během pou ívání ehličky.
◗Žehlička je vybavena vestavěným čidlem vodní hladiny. Jakmile by
hladina v oddělitelném zásobníku vody klesla pod minimální
úroveň, kontrolka "doplňte vodu" se rozsvítí.
Žehlení s parou není možné!
BPoznámka: Pokud jste použili přístroj poprvé nebo po realizované funkci
Calc-Clean, je načerpána voda z oddělitelného zásobníku vody do
zásobníku páry. Pokud je třeba, zásobník vody doplňte.
◗Na displeji se zobrazí informace "Water low, refill tank" (nízká
hladina vody, doplňte vodu) a ozvou se dva krátké akustické
signály.
Nastavení teploty
1Řiďte se údajem na nášivce tkaniny určené k ehlení.
C2Zapněte přístroj
Zasuňte zástrčku o nulované zásuvky a přístroj zapněte stisknutím
prvku on/off na zásobníku páry.
◗Displej se rozsvítí a uslyšíte krátký akustický signál. Na displeji se
posouvá následující informace:
"Welcome to Philips - Checking Sensor - Warming Up".
C◗Kdy přístroj zapnete, automaticky se ohřeje na teplotní nastavení
2.
3Stiskněte tlačítko teploty + nebo - (teplejší nebo chladnější)
abyste nastavili doporučenou teplotu podle ehlené textilie.
ČESKY20
