Philips Mistral GC2225 User manual

ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Steam Iron Mistral
GC2225
03/06
PRODUCT INFORMATION
Features
- Color : Transparent Blue
- Stainless steel soleplate
- Steam output (28 grams/min)
- Shot of Steam (60 grams/min)
- Vertical Shot of Steam
- 3 steam level
- Spray feature
- Tank capacity (250 ml)
- Cord length (1.8 m)
- 360 degrees swivel
- Integrated calc-clean feature
- Integrated cord winder feature
- Filling door
- Drip Stop feature
- Auto-Shut-Off (ASO)
Safety Information
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements and
legal regulations as officially laid down at this moment.
TECHNICAL INFORMATION
Voltage : 230 - 240 V
Frequency : 50 - 60 Hz
Power : 1500 - 1800 W
Dimension (F-box) : 306 (L) x 128 (W) x 157 (H) mm
Product weight : 1.2 kg
Water Advice
Suitable for tap water use. Advice to mix with equal portion
of distilled water or use only distilled water if the tap water is
very hard.
Stainless Steel Soleplate
The stainless steel soleplate glides smoothly & very easy to
clean. Stainless steel has a high scratch resistance and its
durability is very competitive in the market.
Shot of Steam
The shot of steam features a steam boost (60 grams/min) that
helps to remove stubborn wrinkles easily.
Vertical Shot of Steam
This features a steam boost in vertical position to remove
wrinkles in hanging garments.
Integrated Calc-clean
This ensures a longer life time of the iron and to allow the use
of normal tap water.
Drip Stop
Water is only released into steam chamber via the tank
valve when the soleplate temperature is high enough. If the
temperature is too low, the tank valve is closed by means
of a bi-metal disc. This prevents water from dripping onto
garment.
Auto-Shut-Off
The power to the heating element is cut off when the iron has
been motionless. The “Auto-Off” pilot light starts blinking.
When the iron is moved, it is automatically switched on.

GC2225
BACKPLATE 1
BALL SWIVEL 2
SWIVEL PLATFORM 20
CORDSET 3
Remove Screw A 1x
Remove Backplate 1
Remove Screw B 2x (cord clamp)
OPERATION KNOB 4
DOSING UNIT 5
INLAY 6
FILLING DOOR 19
PUMP 8
NOZZLE 9
Remove Screw A 1x
Remove Backplate 1
Remove Screw B 2x (cord clamp)
Remove Cord set 3
Remove Dosing unit 5
Remove Screw D 1x
Remove Inlay 6
Remove Operation knob 4
DISASSEMBLY ADVICE
REPAIR INSTRUCTIONS
- Due to the high voltage of the iron, ONLY the specified cordsets must be used.
- Thermostat that is fitted to the soleplate (Pos 16) was pre-adjusted by the suppliers and secured by glue.
To avoid mal-function of the iron, NEVER re-adjust the thermostat.
- No information about the type number and voltage is stamped onto the typeplate. When replacing the cover (typeplate is at the
bottom), engrave at least the type number & voltage on the typeplate with a sharp object.
- Part number 107, 108 cannot be ordered separately.
OPTIONAL (accessories)
- No specific issues
DIAL 10
RATTLE SPRING 11
TANK SET 12
TANK SEAL 106
ASO MODULE 13
Remove Screw A 1x
Remove Backplate 1
Remove Screw B 2x (cord clamp)
Remove Cord set 3
Remove Dosing unit 5
Remove Screw D 1x
Remove Inlay 6
Remove Operation knob 4
Remove Screw C 3x
COVER 14
THERMOSTAT BUSH 15
SOLEPLATE 16
SEAL 102, 103
Remove Screw A 1x
Remove Backplate 1
Remove Screw B 2x (cord clamp)
Remove Cord set 3
Remove Dosing unit 5
Remove Screw D 1x
Remove Inlay 6
Remove Operation knob 4
Remove Screw C 3x
Remove Tank set 12
Remove Screw E 3x
Remove Cover 14
2-4

GC2225
PARTS LIST
THERMOSTAT
HEATING
UNIT
FUSE
BLACK
BROWN
ELECTRONIC
MODULE
INPUT
BLUE
RED
L
N
E
3-4
Pos Service code Description Consist of
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
4239 026 12420
4239 026 12430
4239 000 09090
4239 026 12490
4239 026 12500
4239 021 15260
4239 021 17160
4239 015 54210
4239 015 55070
4239 015 51450
4239 015 54400
4239 020 90560
4239 025 99230
4239 021 15850
4239 026 12460
4239 021 15140
4239 021 17440
4239 026 12390
4239 026 13220
4239 021 15320
4239 026 05570
4239 021 15230
4239 025 92220
Backplate
Ball swivel
Cordset - EU
Operation knob - Spray (Blue) 104
Operation knob - SOS (Blue) 105
Dosing unit - non extra steam
Inlay
Sealing - Tank top seal 101
Sealing - Cover seal 102
Sealing - SOS seal 103
Sealing - Tank seal 106
Pump
Nozzle
Dial - French/Dutch text
Plastic rattle spring
Tank set - SOS (Blue) 107
ASO module - HV
Cover
Thermostat bush
Soleplate assembly - 230V 108
Lamp cover
Filling door assembly (Blue)
Swivel platform

GC2225
EXPLODED VIEW
D
B
C
C
C
E
E
E
B
A
5
18
6
102
107
108
103
1
11
2
17
19
13
16
15
14
12
101
104
105
8
9
106
3
10
4-4
