Philips Calculite C4X9LEDLW240 User manual

631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • A0708
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Calculite®ColorWash C4X9LEDLW240
Page 1 of 2 4 1/2" X 9 1/8" Aperture, LED Color-Changing Matrix® Wall Washer for Export
Lightolier is a Philips group brand
10 1/2"
(267mm)
5 3/4" (146mm)
4 1/2" (115mm) 8137
1911
12 2
6
3
10 1/2" (93mm)
9 1/8" (93mm)
5
9 5/16" (237mm)
4
10
Vertical Adjustment
5/8" (16mm)
2 7/8" (73mm)
20" (508mm) to 30" (762mm)
18 1/2" (470mm)
2" (51mm)
max. ceiling thk.
13 3/8" (340mm)
14
Features
1. Heat Sink Housing: Die-cast aluminum, design thermally optimized to
reduce LED junction temperature to maintain light output, color and life.
2. LED Array: Series of 48 high-power red, green, blue and amber (RGBA)
LEDs generate millions of colors and high quality white light at variable
color temperatures. Static colors and dynamic effects are programmable
by DMX controls. Average expected life, under normal operating conditions
is 50,000 hours with lumen maintenance of 70% of original light output.
Factory calibrated integral color sensor and self-adjusting feedback software
guarantee color consistency over life.
3. Aperture Cone: Pre-finished aluminum, 55° visual and reflected cutoff.
Overlap flange accommodates different ceiling types, white or polished
flange. Precision mitered flange corner. 4. MicroBlend optics: Internal
collective mixing technology ensures smooth washing and color uniformity
and eliminates undesirable color fringing.
5. Aperture Lens: Tempered glass, fine texture provides additional mixing at
the aperture and minimizes the appearance of the individual RGBA sources.
6. Torsiontite Springs: Secure solid state lighting module tight against ceiling
surface without sagging. Accommodates ceilings from ½” to 2” thick.
7. Power Supply Unit/Slave Control Drive Module: PSU: 240VAC 50/60
Hz., Class 2, high power factor, FCC Class B approved, short circuit protection.
SCD: low voltage DC, provides power and data to control LED array with a
maximum of 8 LED channels. Electronics are enclosed in a black extruded
aluminum housing providing optimal thermal dissipation for reliable operation
and long life. Module is replaceable from below the ceiling.
8. DMX Connectors: Two RJ45 jacks mounted at one end of PSU/SCD module
provide DMX512-In and DMX512-Out connections (see page 2). Uses standard
shielded, plenum rated, CAT5 round, 8 conductor, twisted pair, network
cables (not supplied).
9. Flexible Metal Conduit/Quick Connector: Quick connector for easy field
data connection.
10.Mounting Frame: 0.048" thk., galv. steel.
Features (continued)
11. Frame Vertical Adjustment Mechanism: Vertical adjustment mechanism
accommodates mounting to virtually any ceiling system using pre-installed
mounting bars, or 1/2" EMT tubing (by others). Single locking feature secures
all adjustments. Alignment holes and markings allow fixture to be pre-set
prior to installation.
12.Mounting Bars: 0.048" (18-ga.) Pre-installed, telescoping bars extend to
30"long and lock securely into position. Built-in locking tabs provide positive
attachment to common T-bar systems. Self-centering feature simplifies
installation in 24" O.C. grid systems. Attaches to steel or wood joists without
accessories.
13.Junction Box: UL and cUL Listed for through branch circuit wiring with max.
of (8) No. 12 AWG, 90ºC supply conductors.
14.Thermal Protector: Meets (NEC) UL and (CEC) CSA requirements. Insulation
must be kept 3" away from fixture sides and wiring compartments and must
not be placed above fixture in a manner which will entrap heat.
Electrical
240V, 50/60Hz: Input Watts: 75W Max.
Labels
cULus Listed for dry locations. I.B.E.W.
Ordering Information
Solid State Lighting Unit Light Source Frame-In Kit Line Voltage
White Flange Polished Flange Finish
C4X9LEDLWCLW C4X9LEDLWCLP Specular Clear
RGBA LED Array
C4X9CCLEDLW240 240, 50Hz
C4X9LEDLWCCLW C4X9LEDLWCCLP Comfort Clear
C4X9LEDLWCCDW C4X9LEDLWCCDP Comfort Clear Diffuse

Job Information Type:
Lightolier is a Philips group brand
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • A0708
Calculite®ColorWash C4X9LEDLW240
Page 2 of 2 4 1/2" X 9 1/8" Aperture, LED Color-Changing Matrix® Wall Washer for Export
Lighting Data (All data is based on 3000K color temperature)
Example: With multiple units located
3' from wall and spaced 4' on center, the
illumination on the wall 3' down from
ceiling will be 20 f.c. beneath units and
16 f.c. between units. Footcandle values
are averaged and rounded off and are
based on a minimum of five units.
Color Temperature: 3000K
Report No: 22905
Lightolier Lytemode
DMX Master Station
LIGHTOLIER
LYTEMODEÆ
DMX CONTROL
SYSTEM
Strand Lighting
Accent DMX
CAT5 (8) wires round cable with RJ45 plugs (by others)
DMX512 Out
DMX512 In DMX512 Out
To Next Luminarie
or
DMX512 Out
DMX512 In
120VAC 60 HZ.
Power Input
RJ45 DMX Terminator
(Required to terminate
the last luminaire in the
same data line)
DMX512 Out
Shielded CAT5 9 Pin Connector Wiring
ILS Network (optional)
Mini Master
(order seperately)
Stand-Alone
Accent DMX
Entertainment Technology
DMX Control
Connected Console or
Computer to create
scenes
OPTIONS DMX512 Systems*
RJ45 jacks
Color-Changing Lensed Wall Washer
Horizon 512 Channel DMX Interface or others
Other Standard
DMX512 Interface
Control
DMX Interface XLR-5 Port (Female)
Receptacle (By Others)
DMX512 Cable
DMX512 In
RJ45 jacks
Color-Changing Lensed Wall Washer
240VAC 50/60HZ. Power Input240VAC 50/60HZ. Power Input
CAT5 (8) wires round cable with RJ45 plugs (by others)
* All systems shown are stand-alone. For
additional information and other DMX
systems, please visit http://www.genlyte.com/"
for link to each manufacturer web site.
Input Power
120 - 240VAC 50/60HZ.
XLR-5(Femal port)
MARQUEEÆ PC DMX INTERFACE
USB Port to PC
DMX512 Cable
DMX Network
Accessories
Addressable Interface Kit: Cat. No. CLEDAIK
Load addresses and select operating mode for
DMX protocol, load serial numbers and specific
lighting preset, update firmware to each LED
lighting unit
DMX Terminator: Cat. No. CLEDDMXTERM
Stepdown Transformer: Cat. No. 7997.
Supplies 120V fixture from a 277V 60Hz. branch
circuit (20 amp. minimum). Can be used up to (4)
fixtures (not to exceed 300W maximum load).
2' From Wall - Single 2' From Wall - 2' On Center 2' From Wall - 3' On Center 2' From Wall - 4' On Center
1 1 427 41 1 38 34 38 131 18 31 128 928
2 1 834 81 2 54 52 54 241 30 41 237 17 37
3 1 924 91 3 46 45 46 332 29 32 327 18 27
42 7 14 7 2 433 33 33 423 22 23 418 15 18
525852524 24 24 516 16 16 512 11 12
61353 1 6 18 18 18 612 12 12 6999
712321 713 13 13 7999 7 7 7 7
812221 810 10 10 8777 8 5 5 5
911111 9 9 8 9 9 666 9 4 4 4
3' From Wall - Single 3' From Wall - 3' On Center 3' From Wall - 4' On Center 3' From Wall - 5' On Center 3' From Wall - 6' On Center
11383 1 1 12 10 12 110 710 19391939
2 1 6 15 6 1 2 22 20 22 218 13 18 216 616 216 616
3 2 7 15 7 2 3 25 24 25 320 18 20 318 12 18 317 817
42 7 13 7 2 423 23 23 418 16 18 416 12 16 414 914
52696 2 519 19 19 514 14 14 512 11 12 511 811
6 2 5652 6 16 16 16 612 11 12 610 910 6878
72343 2 7 13 13 13 7999 78787 7 6 7
823332 810 10 10 8777 8666 8 5 5 5
912221 9 9 8 9 9 666 9 5 5 5 9 4 4 4
