24MHT45RS
Lytespan, Mini HID T4.5 Spot Reflector
Page 1 of 2
Features
1. Spot reflector: Aluminum, faceted, specular,
anodized and sealed.
Finish
Specular anodized and sealed.
Labels
UL, cUL
Ordering Information
Catalog No. Finish Lamps For Use With Luminaires
24MHT45RNF
24MHT45RNFCCZ
24MHT45RNFWRM
Anodized
Champagne Bronze
Incandescent Warm
T4.5 8114, 8115
3 5/32 in
[80.0 mm]
5/8 in
[16.3 mm]
2 11/16 in
[68.6 mm]
1 17/32 in
[39.2 mm]

Philips Lightolier
e: [email protected]
t: [phone]
w: www.lightolier.com
24MHT45RS January 20, 2011
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2010. All rights reserved.
Job Information Type:
24MHT45RS
Lytespan, Mini HID T4.5 Spot Reflector
Page 2 of 2
L Beam length D Distance
W Beam Width A Aiming Angle
C Distance to FC Footcandles
center beam
L and W are the outer points where the candle
power drops to 50% of the maximum. FC are
the initial footcandles at the center of the beam.
Lamp data shown is typical. Consult lamp
manufacturers for availability and performance.
CBCP = Center Beam Candle Power.
Aiming angle: 0° 30° Horizontal 30° Vertical 45° Vertical
Lamp
Beam Spread CBCP Rated
(To 50% CBCP) Life (Hrs.)
D FC L W D C FC L W D C FC L W D C FC L W
Lamp
Beam Spread CBCP Rated
(To 50% CBCP) Life (Hrs.)
D FC L W D C FC L W D C FC L W D C FC L W
29706 10000
24MHT45RS
39W T4.5 9°
8114
56441 10000
24MHT45RS
70W T4.5 9°
8115
12 6.9 134 2.5 2.2
14 8.1 98 2.9 2.5
16 9.2 75 3.4 2.9
18 10.4 60 3.8 3.3
14 8.1 187 2.9 2.5
16 9.2 143 3.4 2.9
18 10.4 113 3.8 3.3
20 11.5 92 4.2 3.6
4 6.9 232 2.6 1.3
5 8.7 149 3.2 1.6
6 10.4 103 3.8 1.9
7 12.1 76 4.5 2.2
6 10.4 196 3.8 1.9
7 12.1 144 4.5 2.2
8 13.9 110 5.1 2.5
9 15.6 87 5.8 2.8
6 6.0 292 1.9 1.3
7 7.0 214 2.2 1.6
8 8.0 164 2.5 1.8
9 9.0 130 2.9 2.0
8 8.0 312 2.5 1.8
10 10.0 200 3.2 2.2
12 12.0 139 3.8 2.7
14 14.0 102 4.4 3.1
14 152 2.2 2.2
16 116 2.5 2.5
18 92 2.8 2.8
20 74 3.1 3.1
16 220 2.5 2.5
18 174 2.8 2.8
20 141 3.1 3.1
22 117 3.5 3.5
Note: For Champagne Bronze (CCZ), multiply FC values by 0.64.
For Incandescent Warm (WRM), multiply FC values by 0.85
