Philips EvoKit 2x4 P 36L 36W 835 2 0-107 G2 User manual

Installation guide
Philips EvoKit LED 2x4 and 2x2
Products 2x4
EvoKit 2x4 P 36L 36W 835 2 0-10 7 G2
EvoKit 2x4 P 36L 36W 840 2 0-107 G2
EvoKit 2x4 P 36L 34W 835 1 Mk10 7 G2
EvoKit 2x4 P 36L 34W 840 1 Mk10 7 G2
EvoKit 2x4 P 36L 33W 835 5 Mk10 7 G2
EvoKit 2x4 P 36L 33W 840 5 Mk10 7 G2
EvoKit 2x4 P 36L 34W 830 1 Mk10 7 G2
EvoKit 2x4 P 36L 33W 830 5 Mk10 7 G2
EvoKit 2x4 P 36L 36W 830 2 0-10 7 G2
EvoKit 2x4 P 42L 39W 835 2 0-10 7 G2
EvoKit 2x4 P 42L 39W 840 2 0-10 7 G2
EvoKit 2x4 P 42L 40W 835 1 Mk10 7 G2
EvoKit 2x4 P 42L 40W 840 1 Mk10 7 G2
EvoKit 2x4 P 42L 42W 835 5 Mk10 7 G2
EvoKit 2x4 P 42L 42W 840 5 Mk10 7 G2
EvoKit 2x4 P 42L 40W 830 1 Mk10 7 G2
EvoKit 2x4 P 42L 42W 830 5 Mk10 7 G2
EvoKit 2x4 P 42L 39W 830 2 0-10 7 G2
EvoKit 2x4 P 52L 51W 835 2 0-10 5 G2
EvoKit 2x4 P 52L 51W 840 2 0-10 5 G2
EvoKit 2x4 P 52L 52W 835 1 Mk10 5 G2
EvoKit 2x4 P 52L 52W 840 1 Mk10 5 G2
EvoKit 2x4 P 52L 53W 835 5 Mk10 5 G2
EvoKit 2x4 P 52L 53W 840 5 Mk10 5 G2
EvoKit 2x4 P 52L 52W 830 1 Mk10 5 G2
EvoKit 2x4 P 52L 53W 830 5 Mk10 5 G2
EvoKit 2x4 P 52L 51W 830 2 0-10 5 G2
This installation guide is only valid for the following Philips EvoKit models:
Products 2x2
EvoKit 2x2 P 23L 23W 835 2 0-10 7 G2
EvoKit 2x2 P 23L 23W 840 2 0-10 7 G2
EvoKit 2x2 P 23L 23W 835 1 Mk10 7 G2
EvoKit 2x2 P 23L 23W 840 1 Mk10 7 G2
EvoKit 2x2 P 23L 25W 835 5 Mk10 7 G2
EvoKit 2x2 P 23L 25W 840 5 Mk10 7 G2
EvoKit 2x2 P 23L 23W 830 1 Mk10 7 G2
EvoKit 2x2 P 23L 25W 830 5 Mk10 7 G2
EvoKit 2x2 P 23L 23W 830 2 0-10 7 G2
EvoKit 2x2 P 32L 31W 835 2 0-10 7 G2
EvoKit 2x2 P 32L 31W 840 2 0-10 7 G2
EvoKit 2x2 P 32L 32W 835 1 Mk10 7 G2
EvoKit 2x2 P 32L 32W 840 1 Mk10 7 G2
EvoKit 2x2 P 32L 34W 835 5 Mk10 7 G2
EvoKit 2x2 P 32L 34W 840 5 Mk10 7 G2
EvoKit 2x2 P 32L 32W 830 1 Mk10 7 G2
EvoKit 2x2 P 32L 34W 830 5 Mk10 7 G2
EvoKit 2x2 P 32L 31W 830 2 0-10 7 G2
20130919

220130919
WARNING
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS MAY RESULT IN SERIOUS INJURY OR
SIGNIFICANT PROPERTY DAMAGE.
For your protection, carefully read these warnings and instructions in their entirety before installing or maintaining this equipment. These
instructions do not attempt to cover all installation and maintenance situations. If you do not understand these instructions or if additional
information is required, contact your local Philips representative. Retain these instructions for maintenance reference.
WARNING
RISK OF FIRE OR ELECTRIC SHOCK
The EvoKit must be installed and maintained by a professional electrician in accordance with the applicable federal, state and local laws,
regulations and electrical codes, and the installation instructions provided in this document. This professional should be familiar with the
construction and operation of this product and any hazards involved. If not qualified, do not attempt installation. Contact a qualified electrician.
WARNING
RISK OF FIRE, ELECTRIC SHOCK OR
PERSONAL INJURY
Do not install in a damaged fixture.
Install the EvoKit only in NEMA type G or
Type NFG t-grids with a minimum troer
depth of 3”.
Before installation, turn power o.
WARNING
RISK OF PERSONAL INJURY
This equipment may have sharp edges.
Wear gloves to prevent cuts or abrasions
when removing from carton, handling and
maintaining this equipment.
WARNING
RISK OF FIRE OR ELECTRIC SHOCK
To prevent wiring damage or abrasion, do
not expose wiring to edges of sheet metal
or other sharp objects.
Caution
This kit is designed for permanent
installation in ordinary (Non-Hazardous)
locations in accordance with the National
Electrical Code and all applicable local
codes. Do not use in areas of limited
ventilation or in high ambient enclosures.
Caution
Do not make or alter any open holes
in an enclosure of wiring or electrical
components during kit installation except if
specifically mentioned in these installation
guide.
Notice
Handle components with care. Do
not drop, slide or scratch any of the
components to prevent visual damage
to the product, loss of functionality or
diculties during installation.
Notice
Do not use abrasive materials, glass cleaners or other solvents on cover plate or lens. To clean
the faceplate, use a mild soap solution.
Do not expose the product to substances and /or materials containing sulphur, chlorine or
other halogen compounds and to chemicals mentioned in below table.
Category Chemical Name
Solvents Toluene, xylene, benzene, chloromethane, chloroform, ethyl
acetate, butyl acetate, acetone, MEK, MIBK
Acid HCl, H2SO4, HNO3
Alkali KOH, NaOH, LiOH, Ca(OH)2
Oil Diesel oil, petroleum, hydro carbons
Host lighting fixture

The Philips EvoKit is designed for installation in a wide variety of 2x4 and 2x2 indoor fluorescent based fixtures in horizontal applications.

• The Philips EvoKit is non-air handling.
• Install the Philips EvoKit only in fluorescent based host lighting fixtures only with a minimum depth of 3”.
• Install the Philips EvoKit only in combination with 15/16” NEMA G or NEMA NFG t-grids.
• Due to the wide variety in troers and ceiling grids, it is recommended that the installer does a test install before commencing a renovation.
• Please verify voltage on the Philips EvoKit product label matches the mains voltage.
WARNING
RISK OF FIRE OR ELECTRIC SHOCK
Luminaire wiring and electrical parts may
be damaged when drilling for installation of
LED retrofit kit. Check for enclosed wiring
and components.

320130919
WARNING
RISK OF FIRE, ELECTRIC SHOCK
OR PERSONAL INJURY
Before installation, turn power o.
Installation Philips EvoKit 2x4 and 2x2
Remove host fixture contents
Installation of Side Panels (A)
Set contains Tools required
A
D
C
B
E
2x
A Side Panel
B LED Panel
C Troer Label
D Closing Panel
E Diuser
A
A
1. Turn power o and take out original cover.
5. Install Side panels (A) in-between troer and
T-grid.
4. Disconnect host fixture ballast from mains.
Notice
Make sure to remove packaging (except the
LED protection*), from EvoKit components
before installing.
Do not install with total power input greater
than power rating of original fixture.
When space in the troer is limited, remove
original ballast.
2. Take out TL tubes.
* Remove LED protection just before installing
the Diuser (E) (see step 14).
3. Remove belly pan. If remaining troer height
is limited, remove ballast.
6. Slide Side Panel (A) outwards as far as
possible.

420130919
Installation Philips Bodine BSL310 (Optional)
Installation LED Panel (B)
Installation Troer Label (C)
Ground connection (Situation 1 - 2)
1
2B
1
DO NOT
TOUCH LED
THIS LUMINAIRE HAS BEEN MODIFIED
FROM ITS ORIGINAL CONFIGURATION.
THIS LUMINAIRE WILL NO LONGER ACCEPT THE
ORIGINAL LAMPS STATED ON THE RELAMP LABEL.
CE LUMINAIRE A SUBI DES MODIFICATIONS PAR
RAPPORT À SA CONFIGURATION D’ORIGINE.
CE LUMINAIRE N’ACCEPTERA PLUS LES
AMPOULES PRÉVUES À L’ORIGINE ET REPRISE
SUR L’ÉTIQUETTE RELATIVE AU REMPLACEMENT.
C
THIS LUMINAIRE HAS BEEN MODIFIED
FROM ITS ORIGINAL CONFIGURATION.
THIS LUMINAIRE WILL NO LONGER ACCEPT THE
ORIGINAL LAMPS STATED ON THE RELAMP LABEL.
CE LUMINAIRE A SUBI DES MODIFICATIONS PAR
RAPPORT À SA CONFIGURATION D’ORIGINE.
CE LUMINAIRE N’ACCEPTERA PLUS LES
AMPOULES PRÉVUES À L’ORIGINE ET REPRISE
SUR L’ÉTIQUETTE RELATIVE AU REMPLACEMENT.
ATTENTION
ESD SENSITIVE
90o
ground
ground
B
ground
ground
B
For installation of the Philips Bodine BSL310 Emergency LED Driver, please see the emergency driver installation section from this EvoKit manual
7. Install LED panel (B) in between troer and
T-grid.
9. Place Troer Label (C) inside original troer.
Notice
Make new electrical connections to mains
by employing applicable connectors in
accordance with the applicable federal, state
and local laws, regulations and electrical
codes.
Notice
Do not touch the LEDs with hands or
tooling! Touching LEDs can lead to failure of
the product.
Notice
It is imperative to use the retrofit warning
sticker included with the product in order
to alert the end user that this luminaire will
no longer operate on the originally intended
lamps.
WARNING
RISK OF PERSONAL INJURY
Proper grounding of EvoKit metal parts is
required to ensure personal safety.
WARNING
RISK OF PERSONAL INJURY
While installing the LED panel (B) and
Closing Panel (D), make sure the electrical
wiring is not clamped between panels.
8. Fit tab on LED Panel (B) through slot hole on
Side Panel.
Fixate panels and establish ground by turning
each fastener 90 degrees.
10a. Situation 1 Grounding:
Screw grounding cable from Led Panel (B)
to original troer if host fixture ground
connection is made trough host fixture.
10b. Situation 2 Grounding:
Connect to the incoming ground lead
from conduit.

520130919
Mains connection
mains
B
11. Connect main cables and hide connected
wires behind LED Panel (B).
Installation Closing Panel (D)
Installation Diuser (E)Remove LED protection
1
2
1
D
E
LED PROTECTION
90o
12. Install Closing Panel (D) in-between troer
and T-grid.
15. Slide Diuser (E) under the tabs on one side
from either Panel and press diuser (E) over
the tabs on opposite panel.
14. Tear o LED protection.
13. Fixate panels and establish ground by
turning each fastener 90 degrees.
Connection 0-10V and MK10 dimmer (Optional)
DIM+ Class 1 Wiring
or Class 2 Circuit
0-10VDC
DIM-
EvoKit 0-10V wiring diagram
0-10V
}120V / 277V
Dimmer
LINE 2
NEUTRAL
EvoKit MK10 wiring diagram
MK 10
16a. Optional: For connection EvoKit 0-10V
input, use indicated connections on the
driver.
16b Optional: For connection a dimmer to the
EvoKit Mark 10, use indicated connections
on the driver.
Notice
Use 18 AWG Solid Copper Wire
Rated>=300V. Strip Wire 3/8”
In case the EvoKit MK10 277V is installed in
combination with a dimmer, use a minimum
of 2 EvoKits MK10 277V per dimmer.
WARNING
RISK OF FIRE OR ELECTRIC SHOCK
While installing the LED panel (B) and
Closing Panel (D), make sure the electrical
wiring is not clamped between panels.

620130919
Initial installation Philips Bodine BSL310 Emergency LED driver (Sold separately)
X
W
2x
violet
brown
Y
15 mm
max.
1. Secure BSL310 (X) to the back side of LED
Panel (B) using two screws (W).
Components: Screws (W), Emergency LED
driver (X), Test switch (Y) Wiring harnass (Z).
3. Install the test switch by feeding the violet
and brown wires through this 1/2” hole and
hand tighten the plastic nut included with the
test switch/LED combo. Add connect from
test switch to wiring harnass (Z) (violet -
violet, brown - brown).
2. Drill 1/2” hole in the LED Panel (B) for
installation of LED/test switch on indicated
area.
Notice
Ensure an un-switched hot circuit is available
to the fixture. This is required for proper
emergency fixture operation.
If the Philips Bodine BSL310 Emergency LED Driver is to be installed into the EvoKit retrofit fixture, please follow these instructions and the
instructions provided with the Emergency driver.
WARNING
RISK OF PERSONAL INJURY
Ensure all warning and cautionary markings
given in the Philips Bodine BSL310 installation
instructions are heeded.
blue
BSL310
red/white
yellow /
black red/white
blue/white
yellow
black
white
4. Disconnect the red/white single wire from
the EvoKit driver. Replace it with the blue
output wire from the BSL310 (Z). Place a
wire nut over the original red/white wire for
proper isolation.
5. Connect the yellow output wire from the
BSL310 to the EvoKit blue/white wire
connection block and the yellow/black
output wire from the BSL310 (Z) to the
EvoKit red/white wire connection block.
6. Disconnect black wire and insert white/black
wire (Z) in the EvoKit driver.
AC DRIVER
Emergency
LED
Driver
LOAD
SELECT
JUMPER
WIRE
RED
RED
WHT/RED
BLACK
HOT
COMMON WHITE
BLACK
WHITE
WHT/BLK
WALL SWITCH
CONVERTER
CONNECTOR
7. Connect WHT/RED, BLACK and WHITE
(2x) wires (Z) as per the BSL310 wiring
diagram.
Connect the BSL310 red to red as indicated
in schematic (Z).
© 2013 Philips Lighting Company.
A Division of Philips Electronics North
America Corporation.
All rights reserved.
Printed in USA 8/13
www.philips.com
Philips Lighting
281 Hilmont Road
Markham, Ontario
Canada, L6C 253
1-800-555-0050
A Division of Philips Electronics Ltd.
Philips Lighting Company
200 Franklin Square Drive
Somerset, NJ 08873
1-800-555-0050
Notice
For the EVOkit, do not connect the jumper
wire / load select (yellow/red) on BSL310.
2x
W
X
Y
Z
