Philips BDS4223V User manual

Multi-Purpose Public Display Solution
42" Wide VGA Plasma Monitor
State of the art, cost effective plasma monitor specially designed for indoor public
display applications. The high class scaler, advanced digital video processing and the
latest plasma technology guarantee optimal display of your message.
Operational flexibility
• Multiple PC input formats up to WXGA
• Wide choice of analog and digital connectivity
• Monitor is network controllable for remote management
• Able to operate in portrait mode
• Quiet and reliable fanless operation
• VGA loop through to daisy chain other monitors
Optimized for public viewing
• High brightness (1000cd/m2) and 3000:1 contrast ratio
• Motion Adaptive De-interlacing for razor sharp images
• PiP allows watching a second source simultaneously
Lower total cost of ownership
• Long expected panel lifetime of over 60.000 hours
Philips
plasma monitor
42"
WVGA
BDS4223V

BDS4223V/27
Specifications Product highlights
plasma monitor
42" WVGA
Date of issue 2007-06-01
Version: 2.0
12 NC: 8639 000 16277
© 2007 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
Picture/Display
•Panel Size: 42" / 106.7cm
•Aspect ratio: 16:9
•Panel resolution: wVGA (854 x 480 pixels)
•Pixel pitch: 1.095 x 1.110 mm / 0.0431 x 0.0437"
•Brightness: 1000 cd/m²
•Contrast ratio (typical): 3000:1
•Display colors: 16.7 Million colors
•Viewing angle: 160º (H) / 160º (V)
•Horizontal Scanning Frequency: 31 - 69 kHz
•Vertical Scanning Frequency: 50 - 85 Hz
•Picture enhancement: Picture in Picture
Supported Display Resolution
Connectivity
•PC: RS232 D-Sub9, DVI-D x1, VGA-in D-Sub
15HD, VGA-out D-Sub 15HD
•Audio input for PC: Audio Left/Right (RCA 2x)
•AV input: Component (YPbPr) 2x, Audio (L/R)
for YPbPr 2x, S-video x2, Composite (CVBS) x
2, Audio (L/R)x2 for CVBS & S-Vid
•Audio output: Stereo Out (2 cinch), Subwoofer
Out
Convenience
•Picture in Picture: Picture in Picture All Inputs,
Double window
•Network controllable: RS232
•Convenience Enhancements: On-screen Display
•Monitor Controls: Left/Right, Power On/Off,
Up/Down, Source Select, Menu (OK), Volume
control
•OSD Languages: English, French, Spanish
•Built-in Audio: Built-in amplifier and 5 Watts
RMSx2 stereo speakers
•Screen saving functions: Full white, pixel shift
•Regulatory Approvals: CE Mark, FCC-B, UL,
CSA
Power
•Consumption: 350 Watts (color bar pattern)
•Power supply: 100-240VAC, 50/60Hz
•Sleep Mode: 5 Watts Max.
Dimensions
•Set dimensions in inch (W x H x D):
42.56 x 26.65 x 3.740 inch
•Dimensions (without base) (W x H x D):
1081 x 677 x 95 mm
•Dimensions (with base) (W x H x D):
1081 x 722 x 220 mm
•Product weight (lb): 80.3
•Weight: 36.5 kg
•Lifetime to 50% brightness: 60000 hr
•Temperature range (operation): 0°C to 40°C
•Temperature range (storage): -5°C to +50°C
•Relative Humidity: 20% - 80%
Accessories
•Included Accessories: AC Power Cord, Remote
Control, Battery, VGA cable
•User Guide on CD-ROM
•Optional accessories: Ceiling mount, Flexible
wall mount, Fixed wall mount
•User Manual: English, Spanish
Miscellaneous
•Bezel: Metalic Antracite
•
•Computer formats
Resolution Refresh rate
1366 x 768 60Hz
1280 x 1024 60Hz
1024 x 768 60, 70, 75, 85Hz
800 x 600 56, 60, 72, 75,85Hz
720 x 400 70Hz
640 x 480 60, 72, 75, 85Hz
•Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
1080i 50, 60Hz
720p 60Hz
Multiple PC input formats
The product supports PC compatibility for VGA, SVGA,
XGA and WXGA. A universal public display solution
requires versatile PC input support.
Network controllability: RS232
Network controllability allows user to control and adjust
monitors remotely through RS232 protocol.
Portrait mounting possible
This display is also able to be safely and reliably
mounted in portrait position.
Fanless operation
A system without fans is quiet and doesn't collect dust
inside the monitor. No moving parts inside the monitor
will thus improve the reliability of the product.
VGA loop through
In case more than one screen need to share the same
input signal, VGA loop through offers a cost effective
solution in which the VGA input signal is amplified and
made available on a VGA output connector which can
be connected to the next monitor
High brightness & contrast
High brightness and contrast values are extremely
beneficial in public environments where lighting
conditions are variable and often beyond control.
Motion adaptive de-interlacing
This smart de-interlacing algorithm is able to detect the
type of video source (such as Still Picture, Motion Picture
or Film) and automatically optimize the de-interlacing
process with Spatial, Temporal or Film mode de-
interlacing. The result is that it delivers razor sharp and
stable images every time.
Picture In Picture (PIP)
Provides the ability to watch simultaneously two
different sources, either two video sources or a
combination with data/graphics
Long expected panel lifetime
In public display applications 24/7 operation is often
required. Even after 60000 hours of operation the
brightness level of the display will be at least 50% of the
initial value.
