Philips PD7001B User manual

www.philips.com/welcome
User manual
Always there to help you
Register your product and get support at
Question?
Contact
Philips
Question?
Contact
Philips
PD7001B

1EN
Contents
1 Important 3
Safety and notice 3
Safety 3
Compliance 4
Care of the environment 4
Copyright 5
Warranty 6
2 Your portable DVD player 7
Introduction 7
What's in the box 7
Overview of the main unit 8
3 Get started 10
Charge power 10
Switch on/off 12
Select OSD language 12
4 Play discs 13
Play options 13
Connect additional equipment 16
5 Settings 18

2EN
6 Product information 19
7 Troubleshooting 21

3EN
1 Important
Safety and notice
Read and understand all instructions before you use this product. If damage is
caused by failure to follow the instructions, the warranty does not apply.
Safety
Only use attachments/accessories specied by the manufacturer.
Use only power supplies listed in the user manual.
The product shall not be exposed to dripping or splashing.
Do not place any sources of danger on the product (e.g. liquid lled objects,
lighted candles).
Batteries (battery pack or batteries installed) shall not be exposed to excessive
heat such as sunshine, re or the like.
Danger of explosion if battery is incorrectly replaced. Replace only with the same
or equivalent type.
Where the plug of the Direct Plug-in Adapter is used as the disconnect device, the
disconnect device shall remain readily operable.
Warning
•Never remove the casing of this product.
•Never lubricate any part of this product.
•Never place this product on other electrical equipment.
•Keep this product away from direct sunlight, naked ames or heat.
•Never look into the laser beam inside this product.
•Ensure that you always have easy access to the power cord, plug or adaptor to disconnect the
product from the power.

4EN
Compliance
This apparatus includes this label:
Note
•The type plate is located on the bottom of the product.
Care of the environment
Environmental information
All unnecessary packaging has been omitted.We have tried to make the packaging
easy to separate into three materials: cardboard (box), polystyrene foam (buffer)
and polyethylene (bags, protective foam sheet.)
Your system consists of materials which can be recycled and reused if
disassembled by a specialized company. Please observe the local regulations
regarding the disposal of packaging materials, and old equipment.
Recycling the product and the built-in battery
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused.
Never dispose of your product with other household waste. Please inform
yourself about the local rules on the separate collection of electrical and electronic
products and batteries.
The correct disposal of these products helps prevent potentially negative
consequences on the environment and human health.
Please visit www.recycle.philips.com for additional information on a recycling
center in your area.

5EN
Caution
•Removal of the built-in battery invalidates the warranty and can destroy the product.
Always bring your product to a professional to remove the built-in battery.
Copyright
This item incorporates copy protection technology that is protected by U.S.
patents and other intellectual property rights of Rovi Corporation. Reverse
engineering and disassembly are prohibited.
Specications are subject to change without notice. Trademarks are the property
of Koninklijke Philips Electronics N.V or their respective owners. Philips reserves
the right to change products at any time without being obliged to adjust earlier
supplies accordingly.

6EN
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, Inc, a
subsidiary of Rovi Corporation. This is an ofcial DivX Certied® device that plays
DivX video. Visit divx.com for more information and software tools to convert
your les into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certied® device must be
registered in order to play purchased DivX Video-on-Demand (VOD) movies.
To obtain your registration code, locate the DivX VOD section in your device
setup menu. Go to vod.divx.com for more information on how to complete your
registration.
Warranty
• Never attempt to repair the product, this could lead to the risk of injury,
damage to the product and will void your warranty.
• Use the product and accessories only as intended by the manufacturer.The
caution sign printed on the back of the product indicates risk of electric
shock.
• Never remove the cover of the product. Always contact Philips Customer
Support for service or repairs.
• Any operation expressly prohibited in this manual, or any adjustments and
assembly procedures not recommended or authorized in this manual shall
void the warranty.

7EN
2 Your portable DVD player
Congratulations on your purchase, and welcome to Philips! To fully benet from
the support that Philips offers, register your product at www.philips.com/welcome.
Introduction
On this portable DVD player, you can play the following discs (including CD-R,
CD-RW, (S)VCD, DVD±R and DVD±RW):
• DVD-Video
• Video CD
• Audio CD
• MP3 CD
• Divx
• Discs with JPEG les
What's in the box
Check and identify the contents of your package:
• Portable DVD player
• AC power adaptor, ASUC12E-090080 (Philips)
• Car adaptor
• Short user manual

8EN
Overview of the main unit
a POWER
• Turns on/off DVD player.
AUDIO
• For DVD, selects an audio language.
• For VCD, selects an audio mode.
SUBTITLE
• Selects DVD subtitle language.
DISC MENU
• For DVD, accesses or exits disc menu.
• For VCD, turns on or off PBC (Playback Control) mode.
• For VCD version 2.0 or SVCD with PBC turned on, returns to the
menu.
h
d
e
f
c
b
g
i
j
a

9EN
• Stops disc play.
• Accesses options relating to the current activity or selection.
• Accesses or exits the setup menu.
,
• Skips to the previous or next title, chapter, or track.
b 9-12V DC IN
• Power supply socket.
c
• Headphone jack.
d AV OUT
• Audio/video output jack.
e VOLUME
• Increases or decreases volume.
f RESET
• When the player hangs up, press it with a ball-point pen or similar tool
to reset the player.
g , , ,
• Navigates menus.
,
• Searches backward/forward at different speeds.
/OK
• Conrms an entry or selection.
• Starts, pauses or resumes disc play.
h CHR/
• Charging indicator/Power indicator.
i OPEN
• Opens the disc compartment.
j Display panel

10 EN
3 Get started
Caution
•Use the controls only as stated in this user manual.
•Always follow the instructions in this chapter in sequence.
Charge power
Charge through the AC adaptor
Caution
•Risk of product damage. Ensure that the power supply voltage corresponds to the voltage printed
on the bottom of the player.
•Use only the supplied adaptors to charge the battery.
•You can only charge the player when it is powered off.
1 Press to switch off the player.
Power

11EN
2 Connect the supplied AC adaptor to the player and the AC outlet.
» The CHR indicator turns on (red).
» When the battery is fully charged, the CHR indicator turns off.
Tip
•To maximize battery life, recharge the battery immediately once the battery is fully discharged. If
you do not use the player for a long time, recharge the battery once every two months.
Charge through car adaptor
Connect the supplied car adaptor to the player and car cigarette lighter.

12 EN
Switch on/off
1 Press to switch on the player.
» The power indicator turns on (green).
2 To switch off the player, press .
» The power indicator turns off.
Select OSD language
You can choose a different language for the on-screen display text.
1 Press .
» The options menu is displayed.
2 Select [Setup] > [General] > [Language].
3 Press / to select an option.
4 Press /OK to conrm.
5 Press to exit.
Power

13EN
4 Play discs
1 Slide OPEN on the player.
2 Insert the disc with label side facing up.
3 Push down to close the disc compartment.
» Play starts automatically. If not, press /OK.
• If a menu is displayed, select an item, then press /OK to start play.
• To pause, press /OK. Press again to resume play.
• To stop, press twice.
• To select the previous/next item, press or .
• To start search within video/audio, press or once or more.
Play options
Select subtitle language
You can select a subtitle languages on DVDs.
1 Press .
» The option menu is displayed.
2 Select [Subtitles] and press /OK to conrm.
3 Press / to select a subtitle.
4 Press /OK to conrm.
Select an audio language
You can select an audio language on DVDs or DivX discs.
1 Press .
» The option menu is displayed.
2 Select [Audio language] and press /OK to conrm.
3 Press / to select an audio language.

14 EN
4 Press /OK to conrm.
Repeat
During play, you can select different repeat options.
1 Press .
» The option menu is displayed.
2 Press to select [Repeat] and press /OK.
» The repeat options is displayed.
For DVD
• [Repeat A]: the start of the section to repeat
• [Repeat B]: the end of the section to repeat
• [Repeat Chapter]: repeat the current chapter
• [Repeat Title]: repeat the current title or track
• [Repeat all]: repeat all titles on the disc
• [Repeat Off]: switch off the repeat mode
For VCD
• [Repeat A]: the start of the section to repeat
• [Repeat B]: the end of the section to repeat
• [Repeat 1]: repeat the current track
• [Repeat all]: repeat all tracks on the disc
• [Repeat Off]: switch off the repeat mode
For MP3/CD/DivX
• [Repeat 1]: repeat the current track
• [Repeat Folder]: repeat all the tracks in current folder
• [Off]: switch off the repeat mode
3 Select an option and press /OK to conrm.
4 Press to exit.
Tip
•You cannot repeat items when PBC is on during VCD/SVCD play.

15EN
Random play
You can play tracks in random order on audio CDs or MP3 CDs.
1 Press .
» The option menu is displayed.
2 Select [Shufe All] and press /OK.
3 Select [On] or [Off], then press /OK to conrm.
4 Press to exit.
Zoom
You can zoom in and out for video images or pictures on DVDs, VCDs or JPEG
CDs.
1 Press .
» The option menu is displayed.
2 Select [Zoom & Pan] and press /OK.
3 Press /OK repeatedly to zoom in and out.
4 When the video image or picture is enlarged, press
, , , to pan through it.
Display play information
You can view the play information during play.
1 Press .
» The option menu is displayed.
2 Press to select [Display] and press /OK to conrm.
» For DVDs, title number, chapter number and elapsed play time is
displayed. For VCDs, track number and elapsed play time is displayed.
Select an audio mode
When you play VCDs, you can select an audio mode.
1 Press .
» The option menu is displayed.

16 EN
2 Select [ Audio] and press /OK.
» The audio mode options are displayed.
3 Press / to select an audio channel.
4 Press /OK to conrm.
Select a view angle
You can select different view angle on DVDs that contain alternate scenes.
1 Press .
» The option menu is displayed.
2 Select [Angle] and press /OK to conrm.
3 Press / to select an angle.
4 Press /OK to conrm.
Connect additional equipment
You can connect the player to a TV or an amplier to enjoy DVDs.
Caution
•Turn off your player before you connect it to any additional equipment.
L
R
VIDEO IN
not supplied

17EN
1 Connect the AV cable (not supplied) to the AV OUT jack of the player.
2 Match the color of the AV cables (not supplied) with the jacks on your TV:
• the yellow cable is for the yellow video jack,
• the red or white cable is for the red or white audio jacks.

18 EN
5 Settings
To maximize your play experience, use the setup menu to ne tune your settings.
1 Press .
» The options menu is displayed.
2 Select [Setup].
» The setup menu is displayed.
3 Use navigation keys to select an option and press /OK to conrm.
[General]
[Language] Select on-screen display language
[PBC settings] Set playback control function on/off.
[Power save] Set power saving mode.
[DivX (VOD)] Get DivX registration code.
[DivX subtitles] Select DivX subtitle language.
[Parental(DVD)] Select parental options.
[Set password] Change existing password (3308 by default).
[Factory settings] Restore factory settings.
[Video]
[LCD Display] Set screen display aspect ratio.
[TV standard] Set video output format to TV system.
[Brightness] Adjust screen brightness.
[Contrast] Adjust screen contrast.
[ Audio]
[Dolby] Set Dolby output.
[Version] Check the version information.
4 Press to go back to the previous menu.
5 Press to exit.
