Philips bSure 1 User manual

multimedia projector
cClear
Philips
User guide
English
XP cClear10 English (good) 24-07-2003 15:52 Pagina 1

>
4-5
Packaging contents 4
Optional accessories 5
Service accessories 5
6-11
Controls 6-9
Remote control 10
Connections 11
12-14
Positioning the projector and screen 12
Switching the projector on and off 12
Adjusting the focus and size of the image 13
Adjusting the vertical angle of the projector 13
Keystone correction 13
Moving/transporting the projector 14
Preparation 14
Moving/transporting the projector 14
Inserting the batteries in the remote control 14
15-23
General information 15
Computer input 15
RS-232 connection 15
Universal Serial Bus (USB) 15
External monitor connection 16
Wireless image transfer (cClear Wireless version only) 16
Video input 16
Connecting to a computer 17-19
Analog connection 17
Connection to an external monitor 18
Digital connection 19
Connecting to video equipment 20-22
CVBS (Video) 20
S-VHS (S-Video) 20
Scart connection 20
Component/HDTV (Pr,Y, Pb/ Cr,Y, Cb) 21
Scart connection (RGBS) 22
Connecting to audio equipment 23
1. Introduction
2. Functional overview
3. Set up
4. Installation
Index
Philips Multimedia Projector 2English User guide cClear
XP cClear10 English (good) 24-07-2003 15:52 Pagina 2

<
24-40
Preparation 24
General 24
Messages 24-25
Direct key feedback 24
Feedback messages 25
Error messages 25
Warning messages 25
Some examples 18
On Screen Display Menu 26-40
Menu tree 26-28
General explanation 29
Computer adjustments 30-31
Picture adjustments 30
Display adjustments 31
Component/Video/S-Video adjustments 31-32
Picture adjustments 31
Display adjustments 32
General adjustments/settings 33
Settings 33
Audio adjustments 33
General settings 25-27
Examples 34-40
Digital Zoom/Magnification 34
Auto image 34
Horizontal size 34
Shift 34
Picture in picture (PIP) / Double window 35
PIP / Double window - Possible combinations 36-38
Picture Format 38
Loading your own personal start-up screen 39
Restarting the projector 40
41-43
Cleaning 41
Cleaning the cabinet 41
Cleaning the lens 41
Cleaning the dust filter 41
Lamp 42
Lamp replacement 43
Resetting the lamplife time 43
44-47
5. Operation
6. Maintenance
7.Troubleshooting
Index
Philips Multimedia Projector 3English User guide cClear
XP cClear10 English (good) 24-07-2003 15:52 Pagina 3

>
Congratulations on your purchase of one of the most sophisticated and reliable products on the
market today. We are sure that, used properly, it will bring you years of enjoyment.You will want
to keep this manual handy, as it is a convenient source of information about your projector.
For your own protection and prolonged operation of your projector, please read the enclosed
Safety Sheet.
Please confirm that the following items are packed in the projector box.They are provided to
help you use or set up your projector.
Projector - Lens cap Projector - Lens cap Laser pointer remote
cClear - XG1 Brilliance cClear - XG1 Wireless control + batteries 2 x
cClear - SV10 AAA Zinc Carbon, 1.5 V
Mains Lead Integrated VGA/USB Cable Audio/Video RCA Cable
S-Video Cable DVI-I Cable VGA-Y Cable
DVI-I/VGA adapter Scart/RCA Audio Video Softbag
adapter (not for USA version)
Cd-rom (with Projection Quick set up Card and
Assistant, Warranty card, Safety Sheet
SecurityMax, User Guide,
Data sheet and more.)
Packaging contents
1. Introduction
Philips Multimedia Projector 4English User guide cClear
LASER
VOolume
OKMenu
Standby
On
AVMute
SelectModeSource
Mouse RIGHTLEFT RIightLeft
6
Window
XP cClear10 English (good) 24-07-2003 15:52 Pagina 4

The following accessories are available via the dealer from whom you purchased your Philips projector:
• LCA 3123/00 - 200 W replacement lamp - 8670 931 23009
• LCA 2211/00 - Ceiling mount - 8670 922 11009
• LCA 5310/00 - Monitor Y-cable - 8670 953 10009
• LCA 5300/00 - VGA extension cable (15 m) - 8670 953 0009
• LCA 5312/00 - Scart/RCA Component Video adapter - 8670 953 12009
The following accessories are available via the Philips Projectors Service organisation only:
• Compact remote Control - 3139 228 60500
• Laser pointer remote Control - 3139 228 60550
• Dust filter - 3122 434 01570
• Mains lead USA - 4822 321 11294
• Mains lead Euro - 4822 321 11399
• Mains lead UK - 4822 321 11431
• Integrated VGA/ USB cable - 3122 438 75120
• MAC adapter (option) - 4822 263 21201
• Audio/Video RCA cable (cinch) - 4822 320 12281
• SCART/RCA Audio Video adapter - 2422 033 00345
• User Guide (Cd- rom) - 3122 438 71130
Optional accessories
Service accessories
1. Introduction
Philips Multimedia Projector 5English User guide cClear
<
XP cClear10 English (good) 24-07-2003 15:52 Pagina 5

>
Mutes sound and picture of the projector.
Selects the current projection source: Auto, RGB sync,YPbPr, RGB sog, S-Video,Video,
Mutimedia, Wireless (only available on cClear Wireless version), DVI-RGB, DVI-YPbPr.The button
toggles between the nine/ten signals.
Adjusts the volume.
Activates and deactivates the menu.
Confirms actions in the menu when the menu is on screen.
Switches the projector in or out of the Power/Standby mode.
The Standby indicator (text on button/ring around button):
– lights up orange when the projector is warming up;
– lights up red when the projector is in Power/Standby mode;
– lights up green as when the projector is operating;
– slowly blinks orange when the projector is cooling down.
– Lights up red in case of temperature error.
– Flashes in case of fan error.
– Lights up green when the lamp is on.
– Lights up orange when lamp life has almost expired.
– Lights up red when lamp life has expired.
– Fast blinks red when lamp start has failed.
Receives the signals from the remote control.
Corrects picture distortion of the horizontal and vertical keystone type by internal scaling.
Manipulate the mouse cursor on the connected computer as long as the menu is not active.
When the menu is active the Cursor Control controls the menu cursor to navigate through the
OSD menu.The cursor control works with up/down and left/right button operation.
The Cursor Control can only function as a mouse cursor when projector and computer are connected
via the USB or PS/2 connectors. Make sure your operating system supports USB or PS/2.
A(udio)/V(ideo) Mute 1
Source 2
Volume – / + 3
Menu 4
OK 5
Standby/
Standby indicator 6
Temperature indicator 7
Lamp indicator 8
IR sensor 9
Keystone 0
Cursor Control !
Note
2. Functional overview
Philips Multimedia Projector 6English User guide cClear
@#
0
45
Menu OK
AV
Mute Source
Stand
by
Lamp
Tem p
Menu OK
AV
Mute Source
Stand
by
Lamp
Temp
789
123
6!
Controls
XP cClear10 English (good) 24-07-2003 15:52 Pagina 6

Adjusts the focus of the projected image.
Adjusts the size of the projected image.
Focus ring @
Zoomring #
2. Functional overview
Philips Multimedia Projector 7English User guide cClear
Controls >
@#
0
45
Menu OK
AV
Mute Source
Stand
by
Lamp
Tem p
Menu OK
AV
Mute Source
Stand
by
Lamp
Temp
789
123
6!
XP cClear10 English (good) 24-07-2003 15:52 Pagina 7

cClear Wireless version only
Lights up green when wireless operation is activated.
Lights up green when the projector operates in a wireless network.
Lights up green when wireless connection has been made.
Resets all network settings to the default settings
The Reset button is recessed to prevent accidental resets of the network settings.To reset:
Insert e.g. a paperclip into the small hole marked Reset and gently press the Reset button.
Do not use excessive force to press the RESET button for this could damage the button.
Power indicator $
Ready indicator %
WLAN indicator ^
(Wireless Local Area
Network)
Reset &
Note
2. Functional overview
Philips Multimedia Projector 8English User guide cClear
Controls >
%^ $
&
XP cClear10 English (good) 24-07-2003 15:52 Pagina 8

<
To adjust the vertical angle of the projector.
To connect the projector to the mains.
To insert an optional locking device (Kensington lock).
Height/Level adjuster #
Dust filter $
Mains inlet socket %
Lock slit ^
Lamp compartment &
2. Functional overview
Philips Multimedia Projector 9English User guide cClear
#$
%^&
Controls
XP cClear10 English (good) 24-07-2003 15:52 Pagina 9

Philips Multimedia Projector 10 English User guide cClear
2. Functional overview
Activates the laser pointer to indicate items on the screen.
Note:The laser pointer sends out a laser beam. Do not look into this beam!
Function as the Left and Right mouse keys of your pc when USB or PS/2 connection has been
made.
Adjusts the volume.
Activates and de-activates the menu.
Mutes sound and picture of the projector.
Selects the current projection source: Auto, RGB sync,YPbPr, RGB sog, S-Video,Video,
Mutimedia, Wireless (only available on cClear wireless version), DVI-RGP, DVI-YPbPr.The button
toggles between the nine/ten signals.
Selects projection from one or two input sources.The button toggles between:
– Default - only images from current source projected
– Double Window - images from two sources projected next to each other .
– PIP - images from second source projected within currently shown image .
Selects the window for which you wish to change settings when in PIP or Double Window
mode.
Switches the projector in or out of the Power/Standby mode.
Manipulates the mouse cursor on the connected computer as long as the menu is not active.
When the menu is active the Cursor Control controls the menu cursor to navigate through the
OSD menu.The cursor control works with up/down and left/right button operation.
The Cursor Control can only function as a mouse cursor when projector and computer are connected
via the USB or PS/2 connectors. Make sure your operating system supports USB or PS/2.
Confirms actions in the menu when the menu is on screen.
Exit point of laser pointer.
Laser 1
Mouse Left/Right 2
–Volume + 3
Menu 4
A(udio)/V(ideo) Mute 5
Source 6
Window Mode 7
Window Select 8
Stand by On 9
Cursor Control 0
Note
OK !
Laser pointer @
<Remote control
VOLUME
OKMENU
Stand by
On
SelectModeSOURCE
MOUSE RightLeft
Laser
RightLeft
2
3
1
9
6
5
4
0
!
7
8
AV MUTE
@
Window
6
XP cClear10 English (good) 24-07-2003 15:52 Pagina 10
