Philips MRD200 User manual

CLASS 1
LASER PRODUCT
Service
Service
Service
Service
Service
MRD200/37/37S
©Copyright 2002 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
Published by KC-ET0232 Service Audio Printed in The Netherlands Subject to modification
GB
3139 785 30092
DVD Receiver
Version 1.2
TABLE OF CONTENTS
Page
Location of PC Boards................................................1-2
Versions Variation & Package ....................................1-2
Specifications ..............................................................1-3
Measurement Setup ...................................................1-4
Service Aids ................................................................1-5
ESD & Safety Instruction ............................................1-6
Setting Procedure & Repair Instructions ....................... 2
Disassembly Instructions & Service positions .............. 3
Block & Wiring Diagram ................................................ 4
Key/ Volume/ LED/ Earphone Board ............................. 5
Tuner Board ................................................................... 6
DVD Module KIT572SE ................................................. 7
DVD Module KIT772SI ............................................... 7A
Main Board /Speaker Jack Board .................................. 8
MPEG Board .................................................................. 9
RGB Board .................................................................. 10
Surround Board ........................................................... 11
Power Board ................................................................ 12
Mechanical Exploded View & Parts List ...................... 13
History .......................................................................... 14
For repair information on the Subwoofer please
refer to Service Manual of Active Subwoofer SW200
12NC: 3139 785 30093
Service Manual
COMPACT
DIGITAL AUDIO
LX2000D/21H/30S

1-2
LOCATION OF PC BOARDS
VERSION VARIATION:
/37 /37S /21H /30S /33S /35S
RDS function
Progressive scan
RGB board x x x x x x
Power PCB (120V) x x
Power PCB (220-240V) x x x x
Type /Versions: MRD200 LX2000D
Features &
Board in used
POWER PCB
LED PCB KEY PCB
MAIN PCB
SPEAKER JACK PCB
RGB PCB
VOLUME PCB
EAR PHONE PCB
TUNER PCB
SERVO PCB
MPEG PCB
/37 /37S /21H /30S /33S /35S
SW200 / 17 x
SW200 / 17S x
SW2000 / 00S x x
SW2000 / 02S x
SW2000 / 15S x
Type /Versions: MRD200 LX2000D

SPECIFICATIONS
AMPLIFIER SECTION
Power Output
- Stereo mode (DIN)................................................2 x 20 W
-Surroundmode(1kHz)............................20WRMS/channel
Total Harmonic Distortion...........10 % at rated power (1 kHz)
Frequency Response .........................180 Hz-14 kHz/±1 dB
Signal-to-NoiseRatio........................................>65dB(CCIR)
InputSensitivity...........................................................400 mV
TUNER SECTION
Tuning Range ( /37,/37S )
.................................... FM 87.5 -108 MHz (100 kHz steps)
..........................................AM530 - 1700 kHz (10 kHzsteps)
Tuning Range ( /21H, /30S, /33S, /35S )
...................................... FM 87.5 -108 MHz (50 kHz steps)
..........................................MW531 - 1602kHz (9 kHz steps)
26 dB Quieting Sensitivity......................................FM 20 dB
26 dB Quieting Sensitivity..............................AM 3162 uV/m
Image Rejection Ratio...........................................FM 25 dB
................................................................................AM28dB
IF Rejection Ratio..................................................FM 60 dB
................................................................................AM24dB
Signal-to-NoiseRatio..............................................FM60 dB
................................................................................AM40dB
AM Suppression Ratio...........................................FM 30 dB
Harmonic Distortion.........................................FM Mono 3%
..........................................................................FMStereo3%
.....................................................................................AM5%
Frequency Response.....................FM 180 Hz-10kHz/±6 dB
StereoSeparation.........................................FM26dB(1kHz)
Stereothreshold..................................................FM 23.5 dB
DVD SECTION
Audio Performance :
LaserType......................................................Semiconductor
DiscDiameter.........................................................12cm/8cm
Video S/N ratio...............................................65 dB/A- WTD
AudioDAC........................................................24Bits/96kHz
FrequencyResponse...........................4Hz-20kHz(44.1kHz)
.............................................................4Hz-22 kHz (48 kHz)
.............................................................4Hz-44 kHz (96 kHz)
DigitalOutput....................................SPDIFCoaxial&Optical
Distortion.........................................................0.5% (1kHz)
MP3 :
MP3-CDbitrate......................32,64,96,128,192,256(kbps)
MP3 - CD sampling frequencies..............32, 44.1, 48(KHz)
Recording format.......................................................JPEG
Video Performances :
Video Decoding......................................................MPEG-2
VideoDAC....................................................................10Bits
SignalSystem........................................................PAL/NTSC
Video Format..........................................................4:3/16:9
CompositeVideoOutput.....................................1.0Vp-p,75Ω
S-VideoOutput.............................................Y- 1.0Vp-p,75Ω
..................................................................C-0.286Vp-p,75Ω
MISCELLANEOUS / GENERAL SECTION
Power Supply Rating (/37,/37S)........................120V/60 Hz
PowerSupplyRating(/21H,/30S,/33S,/35S)..220-240V/50Hz
Power Consumption.................................................. 120 W
Dimensions (w x h x d)............... 435 mm x 78 mm x 360mm
Weight...........................................................................7.1kg
IR REMOTE CONTROL
EffectiveRange.........................................................>8Meter
Number of Keys................................................................45
Battery (1.5V)............................................................AA x 2
SPEAKERS
Front Speakers / Rear (Surround) speaker
System............................................................2-wayshielded
Impedance/ohm................................................................8Ω
Speakerdrivers.....................................................3"fullrange
Dimensions (w x h x d)................... 94 mm x 155 mm x 88 mm
Weight..............................................................0.45Kg/each
Center Speaker
System............................................................2-wayshielded
Impedance/ohm................................................................8Ω
Speakerdrivers.........................................2x3"woofer, piezo
Dimensions (w x h x d)...................250mm x 95 mm x 88 mm
Weight...............................................................0.92Kg/each
1-3

1-4
FM SECTION
DISC SECTION
AC MILLIVOL TME TER AUTO DISTORTION METER
OSCIL LOSCOPE
LOAD 4 OHM
AM-FM STEREO SIGNAL
GENERATOR
SIGNAL GENERATORAC
LOOP
AM LOOP ANT
DUT
INPUT OUTPUT
INPUT
OUTPUT
RL
AM SECTION
............
............
AC MILLIVOL TME TER AUTO DISTORTION METER
OSCIL LOSCOPE
LOAD 4 OHM
AM-FM STEREO SIGNAL
GENERATOR
SIGNAL GENERATORAC
DUT
INPUT OUTPUT
INPUT
OUTPUT
RL
............
............
AC MILLIVOL TME TER AUTO DISTORTION METER
OSCIL LOSCOPE
LOAD 4 OHM
DOLBY TEST METER
SIGNAL GENERATORAC
DUT
INPUT OUTPUT
INPUT
OUTPUT
............
............
AUX SECTION
.......
............
.......
............
.......
............
.......
............
AC MILLIVOL TME TER AUTO DISTORTION METER
OSCIL LOSCOPE
LOAD 4 OHM
DUT
INPUT
............
............
.......
............
.......
............
.......
............
.......
............
DVD TEST DISC
R L C SRSLSWR L C SRSLSW

1-5
Service Tools:
Universal Torx driver holder .................................4822 395 91019
Torx bit T10 150mm ...........................................4822 395 50456
Torx driver set T6-T20 .........................................4822 395 50145
Torx driver T10 extended .....................................4822 395 50423
Compact Disc:
SBC426/426A Test disc 5 + 5A ...........................4822 397 30096
SBC442 Audio Burn-in test disc 1kHz .................4822 397 30155
SBC429 Audio Signals disc .................................4822 397 30184
Dolby Pro-logic Test Disc ....................................4822 395 10216
ESD Equipment:
Anti-static table mat - large 1200x650x1.25mm ...4822 466 10953
anti-static table mat - small 600x650x1.25mm .....4822 466 10958
Anti-static wristband ............................................4822 395 10223
Connectorbox (1MΩ) ..........................................4822 395 11307
Extension cable
(to connect wristband to conn.box) ..........4822 320 11305
Connecting cable
(to connect table mat to conn.box) ...........4822 320 11306
Earth cable (to Connect product to mat or box) --4822 320 11308
Complete kit ESD3
(combining all above products) ...............4822 320 10671
Wristband tester ...................................................4822 344 13999
SERVICE AIDS
HANDLING CHIP COMPONENTS

1-6
GB
WARNING
All ICs and many other semi-conductors are
susceptible to electrostatic discharges (ESD).
Careless handling during repair can reduce life
drastically.
When repairing, make sure that you are
connected with the same potential as the mass
of the set via a wrist wrap with resistance.
Keep components and tools also at this
potential.
F
ATTENTION
Tous les IC et beaucoup d’autres
semi-conducteurs sont sensibles aux
décharges statiques (ESD).
Leur longévité pourrait être considérablement
écourtée par le fait qu’aucune précaution n’est
prise à leur manipulation.
Lors de réparations, s’assurer de bien être relié
au même potentiel que la masse de l’appareil et
enfiler le bracelet serti d’une résistance de
sécurité.
Veiller à ce que les composants ainsi que les
outils que l’on utilise soient également à ce
potentiel.
ESD
D
WARNUNG
Alle ICs und viele andere Halbleiter sind
empfindlich gegenüber elektrostatischen
Entladungen (ESD).
Unsorgfältige Behandlung im Reparaturfall kan
die Lebensdauer drastisch reduzieren.
Veranlassen Sie, dass Sie im Reparaturfall über
ein Pulsarmband mit Widerstand verbunden
sind mit dem gleichen Potential wie die Masse
des Gerätes.
Bauteile und Hilfsmittel auch auf dieses gleiche
Potential halten.
NL
WAARSCHUWING
Alle IC’s en vele andere halfgeleiders zijn
gevoelig voor electrostatische ontladingen
(ESD).
Onzorgvuldig behandelen tijdens reparatie kan
de levensduur drastisch doen verminderen.
Zorg ervoor dat u tijdens reparatie via een
polsband met weerstand verbonden bent met
hetzelfde potentiaal als de massa van het
apparaat.
Houd componenten en hulpmiddelen ook op
ditzelfde potentiaal.
I
AVVERTIMENTO
Tutti IC e parecchi semi-conduttori sono
sensibili alle scariche statiche (ESD).
La loro longevità potrebbe essere fortemente
ridatta in caso di non osservazione della più
grande cauzione alla loro manipolazione.
Durante le riparazioni occorre quindi essere
collegato allo stesso potenziale che quello della
massa dell’apparecchio tramite un braccialetto
a resistenza.
Assicurarsi che i componenti e anche gli utensili
con quali si lavora siano anche a questo
potenziale.
“Pour votre sécurité, ces documents
doivent être utilisés par des spécia-
listes agréés, seuls habilités à réparer
votre appareil en panne”.
GB
Safety regulations require that the set be restored to its original
condition and that parts which are identical with those specified,
be used.
NL
Veiligheidsbepalingen vereisen, dat het apparaat bij reparatie in
zijn oorspronkelijke toestand wordt teruggebracht en dat onderdelen,
identiek aan de gespecificeerde, worden toegepast.
F
Les normes de sécurité exigent que l’appareil soit remis à l’état
d’origine et que soient utiliséés les piéces de rechange identiques
à celles spécifiées.
D
Bei jeder Reparatur sind die geltenden Sicherheitsvorschriften zu
beachten. Der Original zustand des Geräts darf nicht verändert werden;
für Reparaturen sind Original-Ersatzteile zu verwenden.
I
Le norme di sicurezza esigono che l’apparecchio venga rimesso
nelle condizioni originali e che siano utilizzati i pezzi di ricambio
identici a quelli specificati.
"After servicing and before returning set to customer perform a
leakage current measurement test from all exposed metal parts to
earth ground to assure no shock hazard exist. The leakage current
must not exceed 0.5mA."
CLASS 1
LASER PRODUCT
3122 110 03420
GB
Warning !
Invisible laser radiation when open.
Avoid direct exposure to beam.
S
Varning !
Osynlig laserstrålning när apparaten är öppnad och spärren
är urkopplad. Betrakta ej strålen.
SF
Varoitus !
Avatussa laitteessa ja suojalukituksen ohitettaessa olet alttiina
näkymättömälle laserisäteilylle. Älä katso säteeseen!
DK Advarse !
Usynlig laserstråling ved åbning når sikkerhedsafbrydere er
ude af funktion. Undgå udsaettelse for stråling.

1) System Reset
a) Press "SYSTEM" button on R/C. TV show "SETUP"
b) Select the menu using the " " and " " button on R/C
c) Go feature setup page to do system reset
2) Region Code Change
2-1
System, Region code, Tuner, etc. setting procedure
After replacement / repair of the MPEG board, the customer
setting and the reegion code may lost. Changing the Region
Code will put the player back in the state which it has left the
factory.
Region Code
1 USA
2EU
3AP
4 Australia, NZ, Latam
5 RUSSIA, INDIA
6 CHINA
TV System
1 NTSC
2PAL
3AUTO
Menu/ Audio Subtitle (AS) Language
1 English
2 English
3 English
4 English
AFS
001 LX2000D/LX3000D/LX3500D/ MRD200
002 MX3550D/MX3600D/MX3700D/MX3800D
oem derivative
08
.region code = 1 digit
.tv system = 1 digit
."as/menu lang" = 1 digit
."AFS" = "architechture Feature Set" = 3 digits
This field is used to define the architecture / features sets for
each product.
."oem derivative" = 2 digit
This field is use to define the OEM set. This will affect the
background display.
Hence in total, reprograming will be done by way of the
remote control. It should run as below :-
a) Put the player in stop mode. No disc loaded.
b) Press the following key on remote control:
For MRD200/37/37S (USA) :
<PLAY> <159> <111> <001> <08> <PLAY>
For LX2000D/21H (AP) :
<PLAY> <159> <331> <001> <08> <PLAY>
For LX2000D/30S (NZ, Australia) :
<PLAY> <159> <431> <001> <08> <PLAY>
For LX2000D/33S (Korea) :
<PLAY> <159> <311> <001> <08> <PLAY>
For LX2000D/35S (China) :
<PLAY> <159> <631> <001> <08> <PLAY>
∗After the Region Code is changed it is necessary to reset
the system so that the new Region Code will be fully
effective. All customer setting will be lost.
∗On top of the maximum number of times allowed for
changing the region code is changed to 25.
∗When the counter reeach 25, you will not be able to further
change the code until you reset the timer by the Region
Code timer reset procedure.
3) Region code change timer reset
Press below key to reset the timer :
a) In DISC source, stop mode and no disc in tray.
b) Press R/C "Play -159-PLAY" to reset timer to 25
4) Tuner area change
a) Press the "OPEN/CLOSE" button to openthe set's door
b) Press "1" "5" "9" button by using R/C.
c) TV Show "TUNER AREA ADJUST"
d) Select the tuner area you want by using the " " and
"" button on R/C, then press "OK" to confirm. TV show
" TUNER AREA CHANGED"
If you didn't press it in five seconds, the system will remain
original status.
USA FM 87.5M 108M 100K
AM 530K 1700K 10K
APAC FM 87.5M 108M 50K
AM 531K 1602K 9K
EUROPE FM 87.5M 108M 50K
AM 531K 1602K 9K
LATAM FM 87.5M 108M 50K
AM 530K 1710K 10K
AUSTRALIA FM 87.5M 108M 50K
/ NZ AM 531K 1602K 9K
Note :-
Please refer to the above different tuner area.
AREA BAND FREQUENCY (Hz) STEP(Hz)
5. Video Out Change
a) Press "SYSTEM" on R/C button
b) Select the menu using the " " and " " button on R/C
c) Go picture setup page select Video out item.
6. Password Change
a) Press "SYSTEM" on R/C button.
b) Select the menu using the " " and " " button on R/C.
c) Go feature setup page select "PASSWORD". TV show
"ENTER CODE". Press 4 times of "STOP" button on R/C.
d) Select "PARENTAL" "8 ADULT" on TV.
e) Enter PASSWORD to "1234".
∗"1234" is a default password supplied.
7. Checking on the Software version
a) Open the CD door.
b) Press "123" and "OK" on the remote control.
c) TV will show the version on screen.
8. Upgrading new software
a) Open the CD-door, then insert the CD-R program disc.
b) Close the CD-door.
c) TV will show:-
."disc loading"
."bank30.rom"
."writing" about 6 seconds.
."Done"
∗ The latest upgraded is in version VER0527.
2-1
CAUTION !
This information is confidencial and may not
be distributed. Only a qualified service
person should reprogram the Region Code.

2-2
REPAIR INSTRUCTIONS
2-2
Audio Output
No Sound DVD Audio No Output
C
Aux/TV
No Output Tuner No Output
E
Ear Head Phone
No Sound Audio Line No Output
G
Center Line
No Output Subwoofer Line No Output
I
DFHJ
VFD Display
No Show
B
Digital Line
No Output
K
B
VFD Display
No Show
RE-Insert and fix
the cable
Yes
And Key Function
And Key Function
Check Control BD CN205
Cable loose or bad INT RE-Insert and fix
the cable
Yes
No
And Standby BD RB202
Check Control BD CN205 Pin6
Yes Or No (+5V)
And Standby BD RB202 Pin3 Check Back Power Bd
Power Supply Circuit
No
Yes
Check Main BD CN201
Cable loose or bad INT
And CN904
No
Check Test CN201
Pin7=+5V
Pin8=-26V
Pin9.11=AC1.2V
Pin10=AC0V
Power Supply Circuit Pin7 No +5V
Check +5V
No
Check T901 CN904
Power Supply Circuit
Check Test CN201 Data From
Pin4/CE
Pin5/CLOCK
Pin6/DATA
And Fuse Resistor
R925. R926. R927
Mpeg BD CPU To RB102 Cable No Data Check RB102
Cable loose or bad INT RE-Insert and fix
the cable
Yes
No
Check Mpeg BD IC6(CPU)
And IC2 Bad Cause Damage
Yes Yes
Check VFD Control BD Section Bad Cause Damage
Note: BD=Board
All Function
No Working
A
All function
No Working
A
RE-Insert and fix
the cable
Yes
All cable is loose
or bad INT
Check Back power BD
F981
Work
OK
RB900 Pin1,3 = 5V
Change IC903
No
IC903 Pin3 to
Check All System
Check Mpeg BD section
All VCC=(+5V)
Yes
All power supply
Check Repair
Check CN203
Change F981 Bad
Yes
Pin3=(+5V)
Check Main BD fuse F903
Bad Cause Damage
OK
Change F903
Bad
Working or Not
Panel stanby LED show
Not
No
Bad Cause Damage
Check T901
Change T901
Bad
Bad Cause Damage
Ok
No
Between T981 to IC982
Circuit
Repair
CN203 Pin1 =(+ 5V)
Check back power BD
Yes
No
Check main BD
All VCC33=(+3.3V)
Repair Mpeg BD section
All power supply circuit
Check Mpeg BD
Pin49(OSC frequency 27MHz)
IC6(CPU) Pin24(Reset) and
Repair Mpeg BD
IC1,IC7,IC9 circuit
Between IC6(CPU) to
Systm power control
No
Control BD IC981
circuit
Yes
Yes Main BD = LVM0189C011
MPEG BD = LFF0205C001
Surround BD = LVA0192C001
Tuner BD = LVT0187C001
MAIN UNIT REPAIR CHART

2-3
Audio output
No Sound
C
All channel no oosund
IC501/IC502/IC503
RE-Insert and fix
the cable
Yes
Repair chart
Check IC405,IC406
Check IC405,IC406
No
At DVD AC3 Dolbly Digital Mode
At DVD AC3 Dolbly Digital Mode
IC405 Pin13=D/L
IC405 Pin13=D/L
Pin1=D/R
Pin1=D/R
Audio Signal input
Audio Signal input
Pin3=D/C
Pin3=D/C
No
See (D)
Repair chart
No
Pin2=L/CH
Pin2=L/CH
Check surround BD CN601
Check surround BD CN601
Pin3=R/CH
Pin3=R/CH
No
Check Ic401
Audio signal output
Audio signal output
Yes
Yes
Pin13 to C412 = L/Ch
Pin13 to C412 = L/Ch
Pin3 to C416 = R/CH
Pin3 to C416 = R/CH
Audio Signal input
Audio Signal input
Check Ic405 Ic406
Between Ic405.406 Pin9.10.11
Between Ic405.406 Pin9.10.11
To Ic408 Pin2 Circuit or
Check IC405. IC406
Pin16(VCC)=+7V
Power Supply
PIN7(VEE)=-7v
Repair IC405,IC406
Power supply Circuit
Yes
Repair
IC408 Circuit
Change IC405 , IC406
Yes
Yes
No
No
Check Surround BD
Power Suply:
Pin13=(+12V) Pin14=(-12V)
Repair power Supply circuit
No CN601
DVD audio
No output
Aux/TV/Tuner
No output
See (D)
Repair chart
See (E) and (F)
Check all cable is loose
or bad INT
Change fuse
F901 orF902
Bad
Check fuse F901/F902
Bad Cause Damage
No
OK
Check Amplifier
Change D901
No
Power supply
Pin1=-Vss(-17.5V to -20V)
Pin3=+Vcc(+17.5V to +20V)
Pin3=+Vcc(+17.5V to +20V)
Yes
IC501 or IC502 or IC503
Change Amplifier IC Yes Audio signal input
IC501 Pin7 from C473(L-CH)
IC501 Pin7 from C473(L-CH)
Check IC501/IC502/IC503
IC501 Pin11 from C478(R-CH)
IC501 Pin11 from C478(R-CH)
IC502 Pin11 from C491(C-CH)
IC502 Pin11 from C491(C-CH)
IC503 Pin7 from C483(SL-CH)
IC503 Pin7 from C483(SL-CH)
IC503 Pin11 from C487(SR-CH)
IC503 Pin11 from C487(SR-CH)
Audio signal output
Audio signal output
Pin31 to C471(L-CH)
Pin31 to C471(L-CH)
Check IC408
Pin32 to C476(R-CH)
Pin32 to C476(R-CH)
Pin33 to C489(C-CH)
Pin33 to C489(C-CH)
Pin34 to C481(SL-CH)
Pin34 to C481(SL-CH)
Pin35 to C485(SR-CH)
Pin35 to C485(SR-CH)
No
Power supply
Check IC409 IC410 IC411 Yes
Pin4=(-12V)
Pin4=(-12V)
Pin8=(+12V)
Pin8=(+12V)
R4105 or R4106 No
Check IC409 IC410 IC411
Bad Cause Damage
Yes No
Check system power supply No
IC901 Pin3=(-12V)
IC902 Pin3=(+12V)
Yes
Check IC901,IC902 or R901,R902
Bad Cause Damage
Audio signal input
Pin15 from C437(L-CH)
Pin15 from C437(L-CH)
Check volume control IC408
Pin13 from C438(R-CH)
Pin13 from C438(R-CH)
Pin11 from C439(C-CH)
Pin11 from C439(C-CH)
Pin9 from C440(SL-CH)
Pin9 from C440(SL-CH)
Pin8 from C441(SR-CH)
Pin8 from C441(SR-CH)
Switch control voltage
Repair
Repair
Check IC405 IC406
No
From C495 to subwoofer output
From C495 to subwoofer output
Pin36 to C493(Subwoofer)
Pin36 to C493(Subwoofer)
Pin6 from C442(Subwoofer)
Pin6 from C442(Subwoofer)
Pin39 from RB102 Pin26(CE)
Check IC408 data
Yes
No
Change
Power supply
Check IC408
Pin30=(-7V)
Pin30=(-7V)
Pin5=(+7V)
Pin5=(+7V)
Change
R466 or R467
No
Pin40 from RB102 Pin14(data)
Pin41 from RB102 Pin24(clk)
Change IC408
Ok Ok
Check Mpeg BD section
to CN102 circuit
Between IC6(CPU) to IC2,IC3
(Surround mode)
(Surround mode)
Ic405 Ic406 Pin9.10.11 = (0V)
Ic405 Ic406 Pin9.10.11 = (0V)
1: At aux/TV, tuner mode
1: At aux/TV, tuner mode
(5.1 CH mode)
(5.1 CH mode)
Ic405 Ic406 Pin9.10.11 = (+5V)
1: At DVD dolby mode
1: At DVD dolby mode
IC406 Pin13=D/SR
IC406 Pin13=D/SR
Pin1=D/SL
Pin1=D/SL
Pin3=D/subwoofer
Pin3=D/subwoofer
(Surround mode)
At aux/TV, tuner mode
IC405 Pin12=P/L
IC405 Pin12=P/L
Pin2=P/R
Pin2=P/R
Pin5=P/C
Pin5=P/C
IC406 Pin2=P/SR
IC406 Pin2=P/SR
Pin12=P/SL
Pin12=P/SL
Pin5=P/subwoofer
Pin5=P/subwoofer
Yes
Yes
Yes
Yes
RB601 Audio Signal output
RB601 Audio Signal output
Pin4=R
Pin4=R
Pin5=L
Pin5=L
Pin6=C
Pin6=C
Pin7=SR
Pin7=SR
Pin10=SL
Pin10=SL
Check Surround BD6CH mode
Control voltage Pin9=(0v)
Control voltage Pin9=(0v)
No
Yes
Between CN601 to
IC405,IC406 circuit
Repair
Audio Signal input
Audio Signal input
Surround BD circuit
Repair
No
Check IC401 power supply
Change Ic401
Yes
Pin16(VDD)=+7V
Pin16(VDD)=+7V
Pin7(VEE)=-7V
Pin7(VEE)=-7V
At aux/TV, tuner mode
Between IC402 to CN601
Repair
Pin2 and Pin3 circuit
And power supply circuit
Power Supply circuit
No
Yes
Check IC401Pin9 and Pin10
Switch control voltage
Switch control voltage
Pin10=(A)
Pin10=(A)
No
Pin9=(B)
Pin9=(B)
(Pin10=+5V, Pin9=0V) for aux mode
(Pin10=+5V, Pin9=0V) for aux mode
(Pin10=0V, Pin9=0V) for TV mode
(Pin10=0V, Pin9=0V) for TV mode
(Pin10=+5V, Pin9=+5V) for tuner mode
Between IC401 Pin9,10 to
IC408 Pin3,4 Circuit or
Repair
IC408 Circuit
(Pin10=0V, Pin9=+5V) for DVD line out
(Pin10=0V, Pin9=+5V) for DVD line out
REPAIR INSTRUCTIONS
2-3

DVD Audio
No Output
No Output
D
Check RB104 To Mpeg BD
Cable loose or bad INT RE-Insert and fix
the cable
Yes
CN104
Check RB104 6 Channels
Pin2=L Pin3=R
Audio Signal
Pin5=SL
Pin6=SRPin8=C
Pin9=Woofer
No Check Mpeg Bd
D/A section
Yes
No
Between RB104 to IC405,IC406
Check
circuit
Ok
Of IC405,IC406 section circuit
See(C)
Bad
Between RB104 to IC405,IC406
Repair
circuit
Repair chart (at DVD mode)
Aux/TV
No Output
E
Check Main BD
Between JK401 to IC401 Bad
Ok
Circuit
Repair
Between JK401 to IC401
Circuit
Of IC401 section circuit
See(C)
Repair chart (at surround mode)
REPAIR INSTRUCTIONS
2-4 2-4

F
Tuner No Output
Check to tuner
Yes
Yes
Power supply
Power supply
Check tuner VT
From Main BD From C161
From C161
No
Yes
Change
Check
Check RB101
Pin12=5V
No
Pin11=12V
Check Q910/Q911/Q912
Check IC101 audio output
to IC101 Pin1 circuit
IC101 Pin16 to RB101 Pin13 (R-CH)
IC101 Pin16 to RB101 Pin13 (R-CH)
Yes
Yes
Yes
REpair FM IF section:
REpair FM IF section:
Q101/Q102
Between EF001 to Q101/Q102
No
IC152 Pin15=5V
Q910 or Q911 or Q912
Q910 or Q911 or Q912
No
Check
YES
IC101 Pin8=12V
L153 or L154/L104
Change
Low frequency=1.5-2.0V
Higt frequency=8.0-9.0V
Check IC152 Data
From RB101
From RB101
Pin3/CE
Pin4/DI
Pin5/CL
Pin6/DO
Check IC152 osc input
Pin14/FM input
Pin14/FM input
Pin13/AM input
VT No Change
Check Main BD RB102
Check Main BD RB102
Cable loose or bad INT
Cable loose or bad INT
RE-Insert and fix
the cable
Yes
No
Check Q103/Q104
Check Q103/Q104
(Between EF001 Pin8 to IC152 Pin14 circuit)
No
Between Main BD CN101
Between Main BD CN101
to RB102 Circuit
to RB102 Circuit
Check Mpeg BD CPU IC6
Check Mpeg BD CPU IC6
And IC2/IC3 Bad Cause Damage
And IC2/IC3 Bad Cause Damage
No FM function
Check tuner pack EF001
Power supply
Pin6=12V
Pin6=12V
No Yes
Yes
Cnange Q103/Q104
Check IC152 or
Check IC152 or
VT section Circuit
A: Repair Am osc section (T003) or
(Between IC101 Pin30 to IC152 Pin13 circuit)
B: Repair Fm osc section
No
Check AM IF T102/CF103
No AM function
Yes
Yes
Check FM IF output
Check FM IF output
Yes
No
Check T105
Check T105
Yes
OK
OK
OK
IC101 Pin17 to RB101 Pin15 (L-CH)
IC101 Pin17 to RB101 Pin15 (L-CH)
to IC101 Pin1 circuit
REpair FM IF section:
REpair FM IF section:
Between EF001 to Q101/Q102
Between EF001 to Q101/Q102
No
Repair tuner signal input circuit
CN101 Pin13 to IC401 Pin4 (R-CH)
CN101 Pin13 to IC401 Pin4 (R-CH)
CN101 Pin15 to IC401 Pin11 (L-CH)
CN101 Pin15 to IC401 Pin11 (L-CH)
(From Main BD)
(From Main BD)
EAR Head Phone
No Sound
G
Check
Cable loose or bad INT
Cable loose or bad INT
RE-Insert and fix
the cable
the cable
Yes
Ear head phone BD RB301
Ear head phone BD RB301
No
No
Yes
Repair Power Supply
Repair Power Supply
Circuit
Yes
To main BD CN301
To main BD CN301
No
Check
Pin6=(+12V)
Pin6=(+12V)
Ear head phone BD RB301
Ear head phone BD RB301
To main BD CN301
To main BD CN301
No
No
Repair Power Supply
Repair Power Supply
(Q308) Circuit
(Q308) Circuit
Check
Pin2=(+6V)
Ear head phone BD
Ear head phone BD
IC304
Yes
No
No
Check IC304
Pin7 from RB301 Pin5=(R/CH)
Pin7 from RB301 Pin5=(R/CH)
Audio signal input
Audio signal input
Pin6 from RB301 Pin4=(L/CH)
Repair main BD
Between R472, R478
Between R472, R478
(From main BD)
(From main BD)
to CN301 circuit
No
No
Check IC304
Pin3 to FB301=(L/CH)
Pin3 to FB301=(L/CH)
Audio signal output
Audio signal output
Pin1 to FB302=(R/CH)
Pin1 to FB302=(R/CH)
Change IC304
Change phone jack
Change phone jack
JK301
Yes
2-5 2-5
REPAIR INSTRUCTIONS

Check main BD
Check main BD
Pin4=(-12V)
Pin4=(-12V)
Repair IC407
Repair IC407
Power supply circuit
Power supply circuit
No
No
IC407 power supply
IC407 power supply
Check IC407
Check IC407
Pin7 to C449=(L/CH)
Pin7 to C449=(L/CH)
Audio Signal output
Audio Signal output
Pin1 to C454=(R/CH)
Pin1 to C454=(R/CH)
Yes
Yes
Repair
Repair
Between C449 ,C454 to JK401(audio out)
Yes
Yes
Check IC407
Check IC407
No
No
Of IC401 to IC402 section circuit
Of IC401 to IC402 section circuit
See(C)
See(C)
Yes
Yes
Chage IC407
Chage IC407
Repair chart
Repair chart
H
Audio Line
Audio Line
No Output
No Output
Check IC413
Check IC413
Pin3 from C4008
Pin3 from C4008
Audio Signal input
Audio Signal input
No
No
Yes
Yes
(Center line out)
(Center line out)
Repair
Repair
Between C4004 to JK402 Circuit
Between C4004 to JK402 Circuit
I
Center Line
Center Line
No Output
No Output
Check main BD
Check main BD
Subwoofer Signal output
Subwoofer Signal output
C495 to R409 to JK402
C495 to R409 to JK402
No
No
Yes
Yes
Between IC411 to IC405,IC406
Between IC411 to IC405,IC406
See (C) Repair chart
See (C) Repair chart
circuit
circuit
J
Subwoofer Line
Subwoofer Line
No Output
No Output
At DVD mode
At DVD mode
JK106 Pin2 power supply
JK106 Pin2 power supply
No
No
Check main BD
Check main BD
Yes
Yes
K
Digital Line
Digital Line
No Output
No Output
Pin8=(+12V)
Pin8=(+12V)
No
No
circuit
circuit
Pin5 from C447 to R422=(L/CH)
Audio Signal input
Audio Signal input
Pin3 from C452 to R428=(R/CH)
At DVD mode
At DVD mode
No DVD line out
No DVD line out
All function
All function
IC407 power supply
IC407 power supply
At (surround) mode
At (surround) mode
No Aux/TV/tuner line out
No Aux/TV/tuner line out
Repair
Repair
between (RB104 Pin1,Pin2)
between (RB104 Pin1,Pin2)
to (IC401 Pin2,Pin15) circuit
to (IC401 Pin2,Pin15) circuit
No
No
No
No
See (E) and (F)
See (E) and (F)
Repair chart
Repair chart
Check main BD
Check main BD
Pin4=(-12V)
Pin4=(-12V)
Repair IC413
Repair IC413
Power supply circuit
Power supply circuit
No
No
IC413 power supply
IC413 power supply
Pin8=(+12V)
Pin8=(+12V)
Between C4008 to R490 Circuit
Between C4008 to R490 Circuit
Repair
Repair
Check IC413
Check IC413
Pin1 to C4004
Pin1 to C4004
Audio Signal output
Audio Signal output
No
No
Yes
Yes
Change IC413
Change IC413
Yes
Yes
Yes
Yes
(Woofer out)
(Woofer out)
Repair
Repair
Circuit
Circuit
Between C495 to JK402
Between C495 to JK402
(At DVD mode) and (Surround)
(At DVD mode) and (Surround)
Check at surround mode
Check at surround mode
Subwoofer signal output
Subwoofer signal output
IC404 Pin7 to C435
IC404 Pin7 to C435
Check at DVD mode
Check at DVD mode
Subwoofer signal input
Subwoofer signal input
IC406 Pin3
IC406 Pin3
No
No
See (D)
See (D)
Repair chart
Repair chart
No
No
Check main BD
Check main BD
Pin4=(-12V)
Pin4=(-12V)
Repair
Repair
Power supply circuit
Power supply circuit
No
No
IC403 and IC404
IC403 and IC404
Pin8=(+12V)
Pin8=(+12V)
Power supply
Power supply
IC403 and IC404
IC403 and IC404
No
No
Check IC403
Check IC403
Subwoofer signal input
Subwoofer signal input
Pin2 from C420,C421
Pin2 from C420,C421
Repair
Repair
circuit
circuit
Between IC403 to IC404
Between IC403 to IC404
Yes
Yes
See(C)
See(C)
IC401 to IC406 circuit
IC401 to IC406 circuit
Repair chart
Repair chart
No
No
Repair JK106
Repair JK106
Power supply circuit
Power supply circuit
Check
Check
JK106 Pin1 digital signal
JK106 Pin1 digital signal
Change JK106
Change JK106
Yes
Yes
Check
Check
RB102 Pin15 digital signal
RB102 Pin15 digital signal
No
No
Check
Check
Between JK106 Pin1 to RB102 Pin15
Between JK106 Pin1 to RB102 Pin15
circuit
circuit
Yes
Yes
Check MPEG BD
Check MPEG BD
Betweeen CN102 Pin15 to IC6 Pin41
Betweeen CN102 Pin15 to IC6 Pin41
circuit
circuit
No
No
REPAIR INSTRUCTIONS
2-6 2-6

DVD SECTION REPAIR CHART
Video output
No signal No sound
Analog no output
ON
Cannot read
Disc or
M
Intermittent
Note: BD=Board
Tray cannot
open
L
Tray cannot open
L
No
Pin5=(+9V)
Yes
No
No
Pin1,3=(+5V)
Check main BD RB900
MPEG BD = LFF0205C001
Video jack board(LX3000D/MRD200D)=LVB0184C001
Check loader server BD
Cable loose or bad INT
RE-Insert and fix
the cable
Yes
CN600 to moter CN001
Check loader server BD
Cable loose or bad INT
RE-Insert and fix
the cable
Yes
CN900 to moter RB900
Repair main BD
Power supply circuit
Check Repair
IC602 circuit
Loader server BD
Cannot read the disc
M
No
Check loader server BD
Cable loose or bad INT
RE-Insert and fix
the cable
Yes
CN610 And CN100
or intermittent
Check Repair
Circuit
A: Loader LD head BD
Circuit
B: Loader server BD
Video output
N
No
No
Check Video jack BD
S-Video(UL)
no output
RE-Insert and fix
the cable
Yes
SCART Video(CE)
Check MPEG BD
CVBS-video signal output
Video jack BD
(LVB0184C001) for
Yes
IC6 Pin114 to CN107 Pin2
Check Repair
IC6 MPEG decoder
Check Repair
Circuit
Check loader server BD
Cable loose or bad INT
RE-Insert and fix
the cable
Yes
CN200 to MPEG BD CN1
No
No signal
CVBS-Video
no output
Section circuit
Check MPEG BD
Cable loose or bad INT
RE-Insert and fix
the cable
Yes CN107 to Video jack BD
Model(LX3000D/MRD200D)
Video jack BD
(LVA0204C001) for
Model(LX3500D)
Check MPEG BD
Cable loose or bad INT
CN108 to Video jack BD
Check MPEG BD CN108
Video signal output
2. (CE) R,G,B/Pin4,3,2
1. (UL) S-Video C/Y Pin5,6
No
Check Video jack BD
Yes
Check Repair
Circuit
Check MPEG BD IC6
Video signal output
2. Pin108=CDAC
1. Pin106=UDAC
No
3. Pin113=YDAC
No Check Repair
IC6 MPEG decoder
Section circuit
Between Pin 106,108,113 to
CN108 Pin4,3,2 circuit
Yes
Check Repair IC6
Video jack board(LX3500D)=LVA0204C001
REPAIR INSTRUCTIONS
2-7 2-7

Check MPEG BD CN104
Analog Signal output
Pin4=L/CH
All Channal
(a)
No signal output
O
No Sound
Analog No Output
Yes
Pin6=LS/CH
Pin5=R/CH
Yes
No
No
Yes
No
Pin9=C/CH Pin10=SUB/CH
Pin7=RS/CH
L, R, C /CH
(b)
No signal output
Check IC18 power supply
Pin7(VEE)=-7V
Pin16(VCC)=+7V
Repair IC18 power supply
Circuit
See (a)
Repair chart
Check power supply
The follwing
IC11, IC12, IC13,
Pin8=(+12V) Pin4=(-12V)
IC14, IC15, IC16, IC17
Repair power supply
Circuit
Check analog Signal
C78=L/CH
C80=LS/CH
C79=R/CH
Pin82=C/CH C83=SUB/CH
C81=RS/CH
Check repair
Between C78, C79, C80, C81,
C82, C83, to CN108 Circuit
Power supply
Check IC10
Pin1,8,14,22=(+5V)
Repair power supply
Circuit
No
Yes
Check IC10 data
1. CCLK/Pin11 from IC2 Pin9
2. CDIN/Pin12 from IC2 Pin6
4. MCLK/Pin7 from IC6 Pin39
3. CS/Pin13 from IC2 Pin5
5. SCLK/Pin5 from IC6 Pin40
Check repair
Between IC2 to IC6 circuit
And IC6 Circuit
No
Check IC10 data
1. LRCK/Pin6 from IC6 Pin32
2. SDIN1/Pin2 fronm IC6 Pin33
3. SDIN2/Pin3 from IC6 Pin36
(Digital signal input)
5. SDIN3/Pin4 from IC6 Pin37
Yes
Check repair
IC6 Circuit
No
Change IC10
Yes
2-8 2-8
REPAIR INSTRUCTIONS

3-1
DISASSEMBLY INSTRUCTIONS
1) Open the DVD Tray by using the Open/Close Button
whiletheSetisONanddisconnectthemainssupplyafter
removing the Tray Cover.
Note: Ifthisisnotpossible,theDVDTrayhastobeopen
manually.
Take a mini screw driver about 2mm diameter and make
a marking 24mm from the tip as shown in figure 2. Place
the set on its side, insert the mini screw driver till the
marking and slide it towards the right as shown in figure
1 until the Tray moves out of the Front Panel.
3) Loosen11screwsandremovetheTopCoverbyliftingthe
rearportionupwardsbeforeslidingitouttowardstherear.
-7screws on the back
-2screws each on the left & right side
4) Loosen 7 screws & lift up the top edge of Front Panel
assembly to free some catches (see figure 3) before
sliding it out towards the front.
-5screws on the bottom
-1screw each on the left & right side
Dismantling of the Key Board Assembly
2) Return the set to its upright position and remove the Tray
Cover as shown in Figure 3 and close the tray manually
by pushing it back in.
Figure 1
Figure 2
3-1
Dismantling of the MPEG Board
1) Loosen 4 screws A to remove the metal cover together
withMPEGboardandremovetheconnectorasshownin
figure 4.
Dismantling of the DVD Module
1) Loosen4screwsB toremovetheDVDmoduleasshown
in figure 5 .
Figure 4
B
Figure5
A
Note: Do not lost the limited
between the MPEG
board and the servo
board
Marking just outside the
slot on the rear cabinet
Marking just outside the
slot on the rear cabinet
24mm
2mm
Figure 3

3-2
SERVICE POSITIONS
Service position A
Service position C
Service position B
Note: In some service positions the components or copper patterns of one board may risk touching its neighbouring pc
boards or metallic parts. To prevent such short-circuit use a piece of hard paper or other insulating material between them.
3-2
Dismantling of the Main Board (include Tuner & Surround Board)
1) Loosen 6 screws F on the top of main board as shown in figure 7.
2) Loosen 10 screws C at the back panel as shown in figure 8.
3) Loosen 3 screws D on the bottom cover as shown in figure 9.
4) Remove all connectors on tuner, surround, RGB & main board.
Figure 9
D
Figure 8
Dismantling of the Speaker Jack Board & Fan
1) Loosen 6 screws E at the back panel as shown in figure 8.
2) Remove all connectors at speaker jack and Fan.
F
Figure 7
C
E

4-1
BLOCK DIAGRAM
4-1
MPEG PCB TUNER PCB
RGB PCB
VOLUME PCB
EARPHONE PCB
MAIN PCB
KEY PCB
POWER PCB
SURROUND PCB
DVD LOADER
Pr/Cr
Component Video Out
Pb/Cb Y
Component
Video Out

4-2
WIRING DIAGRAM
4-2

KEY / VOLUME / LED /
EARPHONE BOARD
TABLE OF CONTENTS
FTD Display Pin Assignment...........................................5-1
Pin Connection ................................................................5-1
Circuit Diagram ................................................................5-2
PCB Layout Top View ......................................................5-3
PCB Layout Bottom View ................................................5-3
Electrical Parts List ..........................................................5-4
5-1
FTD DISPLAY PIN ASSIGNMENT
PIN CONNECTION
## Note ##
1. Fn: Filament pin
2. nG : Grid pin
3. Pn : Anode pin
4. NP : No Pin
5. NC : No Connection pin
5-1
a
b
hjk
f
gm
erpnc
d
(4G-11G)
3G 2G 1G
4G 5G 6G 7G 8G 9G 10G 11G
P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
P11
P12
P13
P14
P15
P16
1G 2G 3G 4G 5G 6G 7G 8G 9G 10G 11G
Program
Sleep
DIGITAL
ProLogic
Stereo
L
C
R
SL
Sub
SR
a
b
h
j
k
f
g
m
e
r
p
n
c
d
a
b
h
j
k
f
g
m
e
r
p
n
c
d
a
b
h
j
k
f
g
m
e
r
p
n
c
d
a
b
h
j
k
f
g
m
e
r
p
n
c
d
a
b
h
j
k
f
g
m
e
r
p
n
c
d
a
b
h
j
k
f
g
m
e
r
p
n
c
d
a
b
h
j
k
f
g
m
e
r
p
n
c
d
a
b
h
j
k
f
g
m
e
r
p
n
c
d
Col Dp MHz
KHz
L
C
R
SL
Sub
SR
SR
PIN NO.
CONNECTION
1
F
1
2
F
2
3
N
P
4
1
G
5
2
G
6
3
G
7
4
G
8
5
G
9
6
G
1
0
7
G
1
1
8
G
1
2
9
G
1
3
10
G
1
4
11
G
1
5
N
C
1
6
N
C
1
7
P
1
1
8
P
2
1
9
P
3
2
0
P
4
2
1
P
5
2
2
P
6
2
3
P
7
2
4
P
8
2
5
P
9
2
6
P
10
2
7
P
11
2
8
P
12
2
9
P
13
3
0
P
14
3
1
P
15
3
2
P
16
3
3
N
P
3
4
F
2
3
5
F
2

5-2 5-2
CIRCUIT DIAGRAM - KEY BOARD
4.9v
4.9v
0v
4.9v
4.9v
4.9v
0v
0v
4.9v
3.5v
3.5v
0v
+5v
5.1v
5.1v
5.1v
3.5v
4.9v
4.9v
4.9v
4.9v
4.9v
4.9v
4.9v
5.1v
AC 1.3v
4.2v
0v
5.1v
0v
0v
AC 1.3v
0v
0v
LVU0219C021
VOLUME SCHEMATIC
LVU0219C031
LED SCHEMATIC
LVU0219C041
PHONE SCHEMATIC
C201 A1
C202 A1
C203 A1
C204 D3
C205 D3
C207 B1
C208 B1
C209 B1
C212 F2
C213 F2
C214 F4
C215 F4
C328 B6
C331 B6
C334 B6
C340 C6
C341 C6
C342 B5
C345 B5
C346 D6
C347 C6
C348 C6
C350 A6
C351 A6
C991 F3
C992 F2
C993 F2
C994 F2
D201 C3
D202 C3
D203 C3
D301 D6
D302 B6
D985 E3
DP201 A3
IC251 B2
IC304 B6
IC981 F3
JK301 A5
LD201 E4
Q201 D1
Q202 D2
Q203 D3
Q204 D4
Q306 C6
Q307 D5
Q308 B5
Q983 E2
R201 A1
R202 B1
R203 B1
R204 B1
R205 B1
R206 B1
R213 A1
R214 A2
R215 C5
R216 D3
R223 C4
R224 C4
R225 D3
R227 E3
R228 C1
R229 C1
R230 C1
R231 C1
R232 D2
R233 D2
R234 D2
R235 D2
R236 D3
R237 D3
R238 A1
R239 B1
R241 D4
R242 D4
R349 B6
R350 B6
R353 C6
R354 C6
R355 D6
R356 D6
R357 D6
R358 D6
R359 D6
R360 C6
R361 C6
R362 C5
R363 C6
R364 C6
R365 B6
R366 B6
R367 D6
R987 F2
R988 E2
R991 F3
R992 F3
R993 F3
R995 E3
R996 F2
1
A
B
C
D
E
F
A
B
C
D
E
F
2 3 4 5 6
1 2 3 4 5 6
R998 E2
R9002 D3
R9003 C4
R9004 E4
RB201 D5
RB202 F5
RB204 E4
RB205 F4
RB301 E6
SN201 C3
TA202 D1
TA204 C2
TA205 C2
TA206 C2
TA207 C2
TA208 D2
TA209 D2
TA210 F4
VR201 E5
XL981 F2
FB302 B6
FB303 B6
ZD201 C4
ZD202 D3
ZD203 D3
ZD301 B5
