SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
1
Contents
1. SpaceWise Technology Industry Luminaire .......................................................................................... 2
1.1 SpaceWise Technology Luminaire sensor coverage area ............................................................. 3
2. Layout.................................................................................................................................................... 4
3. SpaceWise Remote (IRT 9090).............................................................................................................. 5
4. Grouping ............................................................................................................................................... 7
5. Application Modes ................................................................................................................................ 9
6. Application Mode Selection................................................................................................................10
7. Maximum light output selection.........................................................................................................12
8. Creating zones in a group ................................................................................................................... 15
9. Activate / Deactivate occupancy sensor............................................................................................. 18
10. Activate / Deactivate daylight sensor ............................................................................................. 20
11. Daylight Calibration.........................................................................................................................22
12. Test occupancy coverage area (walk test)......................................................................................24
13. Path of egress mode for emergency applications ..........................................................................25
14. Troubleshooting..............................................................................................................................28
15. FAQs ................................................................................................................................................29
16. FCC Compliance Statement............................................................................................................. 30
17. Warranty .........................................................................................................................................30
18. Technical support............................................................................................................................30
This document should only be used for commissioning a SpaceWise Industrial System
with high bay luminaires. For office applications, please refer to the commissioning
manual of SpaceWise for Office Applications.

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
2
1. SpaceWise Technology Industry Luminaire
Philips luminaires with wireless SpaceWise Technology are stand-alone LED lighting systems with
integrated high bay occupancy sensing and daylight harvesting, designed specifically to meet the
lighting control needs of an industrial space. With this technology, installers can group multiple
luminaires and activate automated dimming behaviors using a SpaceWise remote control.
A SpaceWise Technology Luminaire contains an integrated MultiSensor which comprises of the
following elements –
A maximum of 50 luminaires can be grouped together using the SpaceWise remote. Users can
pick an application mode that best suits their lighting controls preference.

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
3
1.1 SpaceWise Technology Luminaire sensor coverage area
To limit unwanted motion detection, the coverage of the luminaire can be restricted by applying
a cover. The cover is a plastic circular ring sticker that can be peeled and applied on the lens of
the sensor. In any instance the view of the sensor should not be blocked with any obstructions.

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
4
2. Layout
Do not install the luminaire close to steel or concrete constructions. A distance of at least 2 feet should
be maintained in all directions. Installing the luminaire near heater fans and air-conditioning outlets will
hamper the performance of the sensor and therefore it is important to have a minimum of 6.5 feet
distance between air outlets and the luminaire.
Also check that the first luminaire is in the right position and oriented correctly with respect to
the edge of the isle. Refer to section 12 (walk test) for details on testing the coverage area of the
sensor. Note the luminaire needs to be grouped before performing the walk test.

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
5
When configuring industrial spaces with SpaceWise Remote, large groups of 30-50 luminaires are
recommended to maintain the lighting aesthetics of the space and improve reliability of the
system. Smaller groups may turn off more frequently than desired.
Install luminaires per manufacturer installation instructions and ensure sensors from adjacent
luminaires are not positioned next to one another.
3. SpaceWise Remote (IRT 9090)
The SpaceWise remote is the only tool required by the installer to group the SpaceWise
Technology Luminaires together and to change any default configuration settings. A set of 2 AAA
batteries of 1.5V each are supplied with the remote. Before proceeding to the commissioning
instructions, make sure that the batteries are correctly installed in the remote and the luminaires
are powered. Also, while commissioning always aim the remote directly at the sensor.

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
6

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
7
4. Grouping
Grouping is required to initiate system functionality and dimming behaviors.
The Luminaires have to be in a factory new state to group them together. If changes
were previously made on the luminaires then perform a factory reset as per the
instructions in section 12 “Troubleshooting”before proceeding.
a.
Point remote to any luminaire and press
“Open,” once.
Wait for the luminaire to dim
down to 5%.
Make sure the button is pressed only once. Pushing multiple times can
create multiple networks which can cause undesired operation.
b.
Walk to the next luminaire to be added
to the group, point to the luminaire and
press “add.”
Repeat step for adding all the luminaires
in the group.
Added luminaire will dim down
to 5%.
c.
Point to any of the luminaires added in
the group and press “close.”
All the luminaires in the group
will go to 50% light level.

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
8
d.
Verify the group by pointing to any of
the luminaires in the group and pressing
“on” and “off.”
All the luminaires in the group
will turn ON and OFF together.
If any luminaires in the group do not turn ON/OFF, they are not part of the
group. Go back to step “a”to add the luminaires back in to the group.
e.
Point to any of the luminaires in the
group and press “lock.”
Wait for LED to stop blinking (apx. 10
seconds) then press “send.”
Red LED on remote will start
blinking.
The luminaire will FLASH twice.
Group is ready for normal
operation.
Once the group is locked it will not accept any configuration changes. To
make any changes the group has to be unlocked first. In order to save time,
you can choose to lock the group after finishing all configuration changes
such as max light level changes, scene customization, etc have been
executed.
Refer to the FAQ section for additional information on how to correct non
responsive luminaires.

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
9
5. Application Modes
Various industrial application modes are supported within SpaceWise Technology. The default
factory setting is set as the warehouse mode (mode# 6) and since the behavior varies for each
mode, it is recommended to select the mode that closely reflects the installed application space.
See the SpaceWise Design Guide (www.philips.com/spacewise) for details.
Application
setting
Mode 6
(default):
Warehouse
Mode 7:
Gymnasium
Mode 8:
Warehouse
comfort
Mode 9:
Manufacturing
Mode 17:
Retail
Out of the box
behavior
Behavior of the luminaires before grouping or being altered via the commissioning
remote.
Power-up state
On
On
On
On
On
Hold Time1
15 min
15 min
15 min
15 min
15 min
Background Level
30%
30%
30%
30%
70%
Prolong Time2
Infinite
Infinite
Infinite
Infinite
Infinite
Start-up and Dim
behavior
Behavior of the luminaires after grouping.
Switch ON Level3
60%
60%
60%
60%
70%
Background Level
10%
20%
10%
20%
70%
Hold Time
2 min
5 min
2 min
5 min
20 min
Fading to Switch
ON Level
0s
0s
0s
0s
0s
Fading to
Background Level
10s
10s
10s
10s
10s
Prolong Time
2 min
5 min
Infinite
Infinite
Infinite
Switch OFF to 0%
Yes
Yes
No. Stays at
background level
No. Stays at
background level
No. Stays at
background level
1
Hold time is the occupancy time out after which the luminaire dims from the task level to the
background level.
2
Prolong time is the time for which the luminaire stays at the background level before switching off.
3
Level at which lights turn ON before ramping up to full output or the level determined by the
daylight sensor.
Application
ON/OFF behavior
Mode
Warehouse (Default)
Auto ON/Auto OFF
6
Sporting Area
Auto ON/Auto OFF
7
Warehouse Comfort
Auto ON/Auto DIM to Background Level
8
Manufacturing
Auto ON/Auto DIM to Background Level
9

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
10
6. Application Mode Selection
a.
Point remote to any luminaire and press
“unlock,” once.
Wait for LED to stop blinking (apx. 10
seconds).
Point remote to any of the luminaires
and press “send.”
Red LED on remote will start
blinking.
Red LED on remote will stop
blinking.
The luminaire will FLASH twice
and group light level will go to
50%.
b.
Point to any of the luminaires in the
group and press “mode.”
While the LED is still blinking red, enter
the number for the preferred mode (see
list at step 5).
Eg. Select “8” for warehouse comfort
application mode.
Red LED on remote will start
blinking.
Red LED on remote will stop
blinking.

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
11
Point to any of the luminaires in the
group, press “send.”
The luminaire will FLASH twice
and group light level will go to
50%.
If unsure about mode selection or remote blinking status then wait for the
remote blinking to stop and redo step “b.”
c.
Point to any of the luminaires in the
group and press “lock.”
Wait for LED to stop blinking (apx. 10
seconds) then press “send.”
Red LED on remote will start
blinking.
The luminaire will FLASH twice.
Group is ready for normal
operation.

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
12
7. Maximum light output selection
Choice of max light output per group will be influenced by existing conditions such as partition
height, reflectances, light level preference and energy goals.
Light output setting
Percentage
High
100%
Medium (default)
88%
Low
77%
Minimum
66%
a.
Point remote to any luminaire and press
“unlock,” once.
Wait for LED to stop blinking (apx. 10
seconds).
Point remote to any of the luminaires
and press “send.”
Red LED on remote will start
blinking.
Red LED on remote will stop
blinking.
The luminaire will FLASH twice
and group light level will go to
50%.

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
13
To select light output settings, use the up and down arrows to
change between high, medium, low and minimum. Light level
can be altered one step at a time. The daylight button must
be pressed to initiate a new change after every end of step.
b.
FOR EACH STEP UP OR DOWN:
Point to any of the luminaires in the
group and press “daylight.”
While the LED is still blinking red, select:
OR
Then press “send.”
END OF STEP
Red LED on remote will start
blinking.
Red LED on remote will stop
blinking.
This will move the light output
setting by one step. The
luminaire may or may not flash at
the end of the step depending
upon firmware version.
Note that the default setting is Medium. To get to high, go one step up. To get to
Minimum, go two steps down.
Medium to High: Will move light output setting from default of 88% to 100%.
Medium to low: Will move light output setting from default of 88% to 77%.
Low to minimum: Will move light output setting from 77% to 66%.
During programming, the fixture is temporarily at 50% (unlocked state). So, while
changing the light level from default 88% to 77%, you will notice the fixture getting
brighter because it is actually going from the temporary 50% light level to
permanent 77% light level. If you repeat the step down sequence again then upon
careful observation you will see the subtle change in light level from 77% to 66%.

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
14
c.
Point to any of the luminaires in the
group and press “lock.”
Wait for LED to stop blinking (apx. 10
seconds) then press “send.”
Red LED on remote will start
blinking.
The luminaire will FLASH twice
and group is ready for normal
operation.

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
15
8. Creating zones in a group
Up to 16 zones can be created within a SpaceWise group and each luminaire can be part
of just one zone.
When a group is created with zones, occupancy detected by one SpaceWise luminaire is
distributed across the zone and also across the whole group. All luminaires within the
zone will react in the same way to any sensor in the zone. All other luminaires that are in
the same group but in a different or no zone will react on the occupancy signal by going
to background level.
Zones can only be created within a group so a group should be created first as per the
instructions in section 4.
a.
Point remote to any luminaire and press
“unlock,” once.
Wait for LED to stop blinking (apx. 10
seconds).
Red LED on remote will start
blinking.
Red LED on remote will stop
blinking.
Group
Zone

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
16
Point remote to any of the luminaires
and press “send.”
The luminaire will FLASH twice
and group light level will go to
50%.
b.
Point remote to any luminaire that is
going to be part of the zone and press
“Zone,” once.
The luminaire will go to 50%
while the rest of the luminaires
go to 5%.
Make sure the zone button is pressed only once. Up to 16 zones can be
defined and every time the zone button is pressed a new zone creation
process is initiated.
c.
Walk to the next luminaire to be added
to the zone, point to the luminaire and
press “add.”
Repeat step for adding all the luminaires
in the zone.
Added luminaire will go to 50%.
To create new zones execute steps “b” and “c” again. Note that a luminaire
can only be part of one zone.
d.
To stop the zone creation process, point
to any of the luminaires added in the
zone and press “close.”
All the luminaires in the group
will go to 50%.
Rest of the group

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
17
e.
To test the zone, point to any luminaire
and press the “right arrow” key.
Press the right arrow key again to move
to verify the next zone.
All the luminiare in the selected
zone will go to 50% while the
luminaires in the other zone will go
to 5%.
f.
Point to any of the luminaires in the
group and press “lock.”
Wait for LED to stop blinking (apx. 10
seconds) then press “send.”
Red LED on remote will start
blinking.
The luminaire will FLASH twice.
Group is ready for normal
operation.
g.
Alternately zones can also be re-tested
after locking the group.
Point remote to any of the luminaires in
the created zone and press “zone”.
Point to the same luminaire and press
“on” or “off.”
To stop the test process, point to the
same luminaire and press “close.”
The entire zone turns on or off
accordingly.
Rest of the group

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
18
9. Activate / Deactivate occupancy sensor
Occupancy sensor is active by default. Changes have to be performed on each
luminaire in the group.
a.
Point remote to any luminaire and press
“unlock,” once.
Wait for LED to stop blinking (apx. 10
seconds).
Point remote to any of the luminaires
and press “send.”
Red LED on remote will start
blinking.
Red LED on remote will stop
blinking.
The luminaire will FLASH twice
and group light level will go to
50%.
b.
Press “pir” button.
While the LED is still blinking red, enter
the numbers:
“10”: Enable occupancy sensing
“12”: Disable occupancy sensing (lights
will stay at 100%)
Red LED on remote will start
blinking.
Red LED on remote will stop
blinking.

SpaceWise for Industrial Applications
v. 1.6
Philips Lighting North America
19
Point to the luminaire that needs to be
altered, press “send.”
The luminaire will FLASH twice
and group light level will go to
50%.
Repeat step “b”for all the luminaires that need to be reconfigured.
c.
Point to any of the luminaires in the
group and press “lock.”
Wait for LED to stop blinking (apx. 10
seconds) then press “send.”
Red LED on remote will start
blinking.
The luminaire will FLASH twice.
Group is ready for normal
operation.
