Philips SOPHO 2000 IPS User manual

A Publication of
NEC PHILIPS Unified Solutions Nederland B.V.
HILVERSUM, THE NETHERLANDS
Order No: 3522 009 11349
Date : September 2007
Great care has been taken to ensure that the information
contained in this handbook is accurate and complete.
Should any errors or omissions be discovered or should any users
wish to make suggestions for improving this handbook, they are
invited to send the relevant details to:
NEC PHILIPS Unified Solutions Nederland B.V.
P.O. BOX 32
1200 JD HILVERSUM
THE NETHERLANDS
© NEC PHILIPS Unified Solutions Nederland B.V. 2007.
All rights are reserved. Reproduction in whole or in part is
prohibited without the written consent of the copyright owner. All
brand names and product names in this document are trademarks
or registered trademarks of their respective companies.

i
PREFACE
This manual is valid for the SOPHO 2000 IPS telephone system.
In this manual the term NEAX 2000 IPS or NEAX PBX telephone system represents the
SOPHO 2000 IPS system.
This book might refer to products not included in the SOPHO portfolio.
Certain items in this manual do not apply to the European market.
In case of doubt, please contact your supplier.

ii
LIST OF TERMS
Abbr. NEC
Description NEC
Abbr. PBC
Description / Remarks PBC
(Trunk) Route Restriction Class TRFC Traffic Class
AIMWorX SMDR & CTI based management platform
Authorization Code PID code
Background music (feature) When phone is idle, user can have
background music on speaker
Boss/Secretary dialing Executive/Secretary
Broker's call Shuttle : alternate between 2 parties
occupying one line
Busy in/busy out - ACD Group - Absent/Present switching
Class of Service Facility Class Mark (sometimes traffic class)
Coin lines
Consecutive Speed Dialing Common number can be speed dial,
individual choice dialed manually
Consultation hold Enquiry
Development table Analysis tree : table within numbering plan
Dial conversion Conversion from pulse to DTMF
Dynamic Dial Pad Pressing numeric keys grabs a line as well.
Executive calling VIP status assigned to a station.
Ground Start Earth calling : analog trunk protocol
Hearing Aid Compatibility Voice volume control on terminals
Home side trunk User side
trunk For ISDN trunks
Legacy TDM based equipment (non IP)
Location number Division based on capabilities or priorities in
the IP system
Loop Start Subscriber signalling e.g. an ATU-SS
Mate side trunk Network
side trunk For ISDN trunks
MATWorX Operational Maintenance interface tool
Multi line terminal SOPHO Set / ErgoLine : digital terminal with
soft key assignment possible
Multiple Call Forwarding Multi hop (maximum 5 hops allowed)
My Line Users own station number.
Nailed down connection (data) Fixed connection between two data
adapters.
Night Connection - fixed PLE Permanent Line Extension
Night connection - fixed Permanent Line Extension
Night Connection - flexible CF on night extension
Office Code CLID Cluster Identity used for Open Numbering
Plans
One touch key Dterm keys, work (and programmed) like
speed dial function
OpenWorX CTI Application platform
Operator PSTN operator / provider
Party lines
Peer to peer Peer to peer : one to one relation on
functional level
Pilot number Group number
Preset dialing En-block dialing : prepare number and send
it in one go (versus overlap dialing)
Prime Line Seized line (trunk line or extension) when
going off-hook (or speaker)
Restriction Class TRFC Traffic Class
Route Advance Alternative routing when trunk(s) busy
Route Pattern Tree : part of the number analysis table
Save and Repeat LNR Last Number Redial
Secondary appearance park position / sub line

iii
Abbr. NEC
Description NEC
Abbr. PBC
Description / Remarks PBC
Single line terminal Analog Phone
Software Line Appearance Virtual Extension
Split Call Forwarding Separate CF for internal and external calls.
Stack Dial LNNR Last Number/Number Repetition
Outgoing calling list (5 entries)
Stack Dial Redial List : maximum 5 numbers
Station Extension /
DNR
Station Class FCM Facility Class Mark
Sub Line Lines on the stations, other then the prime
line
Tenant Analysis group : multi company on one PBX
Trunk Route Route
Voice Call
Whisper page Announcement without 3rd party hearing it.
AC Account Code (Client Billing Code) PID Password integrated dialing
ACF Authorization Code Facility OAI related.
ADF OAI related.
ALM DSPP (External) Alarm Display Panel
ANI Automatic Number Identification Caller subscriber number coming in with MF
signaling on T1 trunks
ANS Answer
AOC Advice of charge
AP Application Card
AP Analog Port
ATND Attendant
AttCon Attendant console Operator console
BATTM Battery Module
BGM Back Ground Music service
BHCA Busy Hour Call Attempts
BK Black
BSY Busy
BT Busy Tone
CAMA Centralized Message Accounting A standard related to 911 service
CAS Centralized Attendant Service
CAT Customer Administration terminal Dterm used as programming device for PBX
CCIS Common Channel Interoffice
Signalling Comparable to IMP
CCSA Common Control Switching
arrangement Customer specific leased lines/network, US only
CCT CCIS Trunk
CF-D Call Forwarding - Destination Call Forwarding – Destination : no
preparation on originator necessary.
CFT Conference trunk
CIC Circuit Identification Code Trunk channel ID for virtual IP trunk
channels (Line number)
CID Call ID Display
CIR Caller ID Receiver
CIS Call Information System
CM Command See Commands Manual
CNP Closed Numbering Plan
CO Central Office
COT Central Office Trunk
CPN Calling Party Number ISDN calling party number
CPN Calling Party Number
CPU Central Processing Unit
CRD Call Redirect
CS Cell Station
CSU
DAT Digital Announcement Trunk

iv
Abbr. NEC
Description NEC
Abbr. PBC
Description / Remarks PBC
DBM Commands Manual - AP00 card
DCH D-Channel Handler
DD key Do not Disturb Key
DDD Direct Distance Dialing
DDI Direct Digital interface T1/E1 interface to public network
DDOVR Do not Disturb Override
DeskCon Desk Console SV SuperVisor / Operator Console
DID calls Direct Inward Dialing calls DDI Direct dialing in : not for FX and WATS
trunk (USA only)
DISA Direct Inward System Access Remote access to system
DIT DID trunk / Direct Inward Termination PLE Permanent Line Extension(s) : for limited
direct inward dialing: 1/more trunk(s) related
to 1 station
DLC Digital Line Circuit For Dterm, Attendant and Desk Console.
DM Distributed Module
DMS Distributed Module Small
DNIS Dialed number Identification Service
DOD Direct Outward Dialing DDO Direct Dialing Out : setting up external calls
without attendant assistance
DP (Rotary) Dial Pulse Pulse dialing
DPC Data Port Controller
DPC Destination Point Code Kind of Cluster ID; for terminating office
DRS Device Registration Server Compare with Gatekeeper function:
registering endpoints
DS Differential Services (DiffServ)
DSS/BLF Direct Station Select / Busy Lamp
Field
DSW Device Server WorX For Dterm assistant software
DT Dial Tone
DTE Data Terminal Equipment
Dterm Digital (or IP) terminal Dterm Desktop Telephone (analog or digital)
DTG Digital Tone Generator
DTI Digital Trunk Interface
FAC Forced Account Code
FCC Federal Communications
Commission American regulation office
FD Floppy Disk
FDA Forwarded - All calls
FDB Forwarded - Busy
FDN Forwarded - No answer
FG Frame Ground
FGD Feature Group D format Signalling format for ANI.
FLF Free Location Facility OIA related, Desksharing look-a-like.
NOT available for IPS 2000
FP Firmware Processor Compare with PMC
FX Foreign Exchange Specific part of PSTN; US only
HDT Hold Tone
HWT howler tone Alarm tone
ICH ISDN channel handler
ICI Incoming Call Identification
ICM Intercom
IEC International Electro-technical
Commission
ILC ISDN line card
IP Internet Protocol IP Internet Protocol
IPM Indications per minute For flashing lamps / LEDs
IPS Internet Protocol Server
IPT IP trunk
IPX Internet Protocol eXchange
IVS Integrated Voice Server

v
Abbr. NEC
Description NEC
Abbr. PBC
Description / Remarks PBC
KF Key Feauture (registration) Key systems are operating directly on
outside lines.
KTF Key Transfer Facility OAI related.
LAN Local Area Network LAN Local Area Network
LCR Least Cost Routing LCCR Least cost call routing : number analysis
development manner
LDN Listed Directory Number
LDT Loop Dial trunk
LEN Line Equipment Number EHWA Equipment hardware Address : PIM nbr (0 ~
7)+ Port nbr (00 ~ 63) LEN = (000 ~ 763)
LT Line/Trunk
MAT Maintenance Administration Terminal OMM Operation Maintenance module : PC
needed in terminals mode
MB Make Busy SETOUT Set to Out Of Service : Out of Service / Not
installed situation for reset or maintenance
MCI Message Center Interface Interface for Voice Mail system
MEM Main Memory
MFG
MFR MF receiver / MFC receiver/sender
MIB management Information Base
MIC Microphone Microphone or its key
MIS management Information System
MJ Major (alarm)
MLDT Melody Trunk
MN Minor (alarm)
MOC OM terminal window, part of MATWorX
MP Main Processor Compare with CPU
MRF Mode Reset Facility OAI related.
MSF Mode Set Feature OAI related.
MSG Message
NEAX NEC PBX SOPHO
NS Network Station
NTF Number Transfer Facility OAI related.
NTS Night Transfer Station Night Extension
OAI Open Application Interface CTI interface
ODT OD Trunk 2/4 wire E&M
ODT Outband Dialing Trunk
ONP Open Numbering Plan
OPC Origional Point Code Kind of Cluster ID; for originating office
OPR Operator Attendant
PAD (IP) Packet Assembler /
Disassembler Used for TDM / IP translation
PBR Push Button Receiver DTMF receiver
PBSND Push Button Sender DTMF sender
PC Point Code
PCK Pickup
PFT Power Failure Transfer
PIM Port Interface Module Shelf : comparable with CSM and PM
shelves
PLO Phase Locked Oscillator
PMS Property Management System PMS Property Management System (in hotel
environments)
PN Part Number For example PN-8DLCC board
PNA Phone line Network Alliance
PPS Pulses per second Used in pulse dialing
PROTIMS Proprietary protocol, used for building CCIS
PRT ISDN primary rate interface trunk
PS Personal Station
PS Portable Station NEC wireless system
QoS Quality of Service

vi
Abbr. NEC
Description NEC
Abbr. PBC
Description / Remarks PBC
RAS Registration Admission Status Registration Admission Status
RBT Ringback Tone
RC Room Cutoff
REN Ring Equivalence Number
RLS Release
ROT Reorder Tone
RPIM Remote PIM
RSC Route restriction Class
RST Restricted
RTP Real Time Protocol
SCF Switch Control Facility OAI related.
SDT Special Dial Tone
SLT Single Line Telephone Analog telephone
SMDR Station Message Detail Recording FDCR Full Detailed Call Recording
SMFN Status Monitor Facility (Notification) OAI related.
SMFR Status Monitor Facility (Request)
SOC System on chip
SP Soft Phone
SPID Service Profile ID (ISDN) BSP-ID Basic Service Profile ID (ISDN)
SPN Special Part Number
SSFM Service Set facility Monitor OAI related.
SSFR Service Set Facility Request OAI related.
SST Service Set Tone
STA Station
STN Station
TAH Trunk Appearance Hold
TAS Trunk Answer Any Station Pickup incoming calls in night mode
TCF Terminal Control Facility OAI related.
TCM (Deluxe) Travelling Class Mark
TDM Time division multiplexing
TDS Time division switching
TDSW Time Division Switch
TIC (Individual) Trunk identification Code Line numbers of trunk lines
TMF Terminal Multi-information transfer
Facility OAI related.
TMSF (Terminal) Mode Set Facility OAI related.
TNT Tone/Music source interface
TRF Transfer
TSW Time Switched
UAP User Application Processor
UCD Uniform Call Distribution Basic ACD. Distribution of calls based on
longest idle.
UNP Uniform Numbering Plan (Network) numbering plan
USOC User Service Order Code Other word for REN
VC Voice Compression
VCT Voice CODEC circuit card
VDSL Very high data rate Digital Subscriber
Line
VM Voice Mail
VOIP Voice over IP VOIP Voice over IP
WAN Wide Area Network WAN Wide Area Network
WATS Wide Area Telephone Service Specific part of PSTN, US only
WCS Wireless Communication System "Analog DECT"
WH White
WU Wake up
ZT Zone Transceiver For Wireless system

vii
Dterm icon Meaning
Hold
Transfer
Speaker
Answer
Redial
Conf(erence)
Recall
Feature
MIC
Message
Directory
- / +
Help
Exit

viii

NEAX 2000 IPS
ISDN System Manual
TABLE OF CONTENTS
– i – NWA-008852-001 Rev.5.0
98toc001.fm
INTRODUCTION .................................................................................................................. 1
PURPOSE .................................................................................................................... 1
OUTLINE OF THIS MANUAL ...................................................................................... 1
TERMS IN THIS MANUAL ........................................................................................... 2
PBX System Designation ................................................................................................... 2
Terminal Name .................................................................................................................... 2
REFERENCE MANUAL ............................................................................................... 3
CHAPTER 1 GENERAL INFORMATION ........................................................................... 5
SYSTEM OUTLINE ...................................................................................................... 6
System Outline of ISDN-PRI .............................................................................................. 6
System Outline of ISDN-BRI .............................................................................................. 7
System Outline of ISDN-VPN ............................................................................................. 9
System Outline of ISDN Terminal ...................................................................................... 11
DTI ........................................................................................................................................ 15
DCH ...................................................................................................................................... 15
PRT ....................................................................................................................................... 16
BRT ...................................................................................................................................... 17
PLO ...................................................................................................................................... 19
ICH ........................................................................................................................................ 20
ILC ........................................................................................................................................ 20
OUTLINE OF EVENT BASED CCIS ............................................................................ 21
Common Channel and Voice Channel Link Control ........................................................ 22
Event Based CCIS Feature List ......................................................................................... 24
Event Based CCIS Service Conditions ............................................................................. 27
CARD NAME AND FUNCTION ................................................................................... 28
SYSTEM CAPACITY ................................................................................................... 30
System Capacity for ISDN-PRI .......................................................................................... 30
System Capacity for ISDN-BRI .......................................................................................... 31
SYSTEM CONDITIONS ............................................................................................... 33
Time Slot Assignment Condition ...................................................................................... 33
Time Slot Allocation for DTI/PRT/DCH Card .................................................................... 34
Line Distance between PBX and NT1/ISDN Terminal ...................................................... 35
DTI SPECIFICATIONS ................................................................................................. 36
Transmission Characteristics ........................................................................................... 36
Frame Configuration of 24DTI ........................................................................................... 38
Frame Configuration of 30DTI ........................................................................................... 42

– ii – NWA-008852-001 Rev.5.0
98toc001.fm
TABLE OF CONTENTS
CHAPTER 2 INSTALLATION ............................................................................................. 45
PRECAUTIONS ........................................................................................................... 46
Static Electricity Guard ...................................................................................................... 46
REQUIRED EQUIPMENT ............................................................................................ 49
ISDN-PRI Required Equipment .......................................................................................... 49
ISDN-BRI Required Equipment .......................................................................................... 50
ISDN Terminal Required Equipment ................................................................................. 50
Event Based CCIS Required Equipment .......................................................................... 51
INSTALLATION PROCEDURE FOR ISDN-PRI .......................................................... 52
Mounting DTI and DCH Card ............................................................................................. 53
Mounting PRT Card ............................................................................................................ 53
Mounting CONN Card ......................................................................................................... 54
Selection of PLO in MP Card ............................................................................................. 57
DTI/PRT Cable Connection via MDF ................................................................................. 58
Cable Connection via CONN Card .................................................................................... 61
INSTALLATION PROCEDURE FOR ISDN-BRI .......................................................... 63
Mounting BRT Card ............................................................................................................ 64
BRT Cable Connection via MDF ........................................................................................ 65
INSTALLATION PROCEDURE FOR ISDN TERMINAL .............................................. 72
Mounting ICH Card ............................................................................................................. 73
Mounting ILC Card .............................................................................................................. 74
ILC Cable Connection via MDF .......................................................................................... 75
INSTALLATION PROCEDURE FOR EVENT BASED CCIS ....................................... 78
Mounting CCH Card ............................................................................................................ 79
CHAPTER 3 SYSTEM DATA PROGRAMMING ................................................................ 81
HOW TO READ THIS CHAPTER ................................................................................ 82
PRECAUTIONS ........................................................................................................... 83
System Data Backup .......................................................................................................... 83
Office Data Conversion ...................................................................................................... 84
LEN Assignment by CM14 ................................................................................................. 85
Trunk Number Assignment ................................................................................................ 88
AP Number Assignment ..................................................................................................... 88
ISDN-PRI PROGRAMMING ......................................................................................... 89
Digital Trunk Data Assignment ......................................................................................... 89
D Channel Handler Assignment ........................................................................................ 101
ISDN-BRI PROGRAMMING ........................................................................................ 104
BRT Assignment ................................................................................................................. 104
ISDN FEATURE PROGRAMMING .............................................................................. 114
CLI Transparency ............................................................................................................... 115
DID Addressing ................................................................................................................... 117
NOVEMBER/15/2006

– iii – NWA-008852-001 Rev.5.0
98toc001.fm
TABLE OF CONTENTS
MEGACOM®Access ........................................................................................................... 121
SID to Network-Present ...................................................................................................... 122
CPN to Network-Present .................................................................................................... 122
SID to Terminating User-Display ....................................................................................... 128
CPN to Terminating User-Display ..................................................................................... 131
Subaddress-Present ........................................................................................................... 133
Trunk Provisioning Service Selection .............................................................................. 134
ISDN PRI Call By Call Service Selection ........................................................................... 135
Advice of Charge-Display .................................................................................................. 141
Alternate Routing for ISDN ................................................................................................ 143
Centrex SHF over ISDN ...................................................................................................... 144
ETSI ISDN Overlap Sending ............................................................................................... 145
ETSI ISDN Overlap Receiving ............................................................................................ 148
ETSI ISDN Addressing ....................................................................................................... 153
ETSI ISDN Channel Negotiation ........................................................................................ 156
Connected Line Identification Presentation (COLP) /
Connected Line Identification Restriction (COLR) .......................................................... 157
Malicious Call Trace ........................................................................................................... 159
Call Completion to Busy Subscriber (CCBS) ................................................................... 160
ISDN-VPN PROGRAMMING ....................................................................................... 162
ISDN TERMINAL DATA PROGRAMMING ................................................................. 164
ILC Assignment ..................................................................................................................164
ICH Assignment ..................................................................................................................167
Point-to-Point Connection ................................................................................................. 170
Point-to-Multipoint Connection ......................................................................................... 172
Individual Terminal Call ..................................................................................................... 174
Group Call ........................................................................................................................... 178
EVENT BASED CCIS PROGRAMMING ..................................................................... 183
Programming Summary ..................................................................................................... 183
Numbering Plan Programming .......................................................................................... 185
BRI Trunk Programming .................................................................................................... 186
Home-Side Trunk Programming ........................................................................................ 194
Mate-Side Trunk Programming ......................................................................................... 196
Incoming Termination for Event Based CCIS Calls ......................................................... 203
Access Code/Terminating Number Assignment for Outgoing Event Based Calls ....... 204
Release Timer for Virtual Tie Lines (Home-Side and Mate-Side Trunks) ...................... 205
CCH Data Assignment ........................................................................................................ 206
Tandem Connection Programming ................................................................................... 207
Closed Numbering Programming ..................................................................................... 208
Event Based CCIS Trunk Data Table ................................................................................ 209
JULY/01/2006

– iv – NWA-008852-001 Rev.5.0
98toc001.fm
TABLE OF CONTENTS
CHAPTER 4 CIRCUIT CARD INFORMATION ................................................................... 211
HOW TO READ THIS CHAPTER ................................................................................ 212
MOUNTING LOCATION OF CIRCUIT CARDS ........................................................... 213
Regular PIM ......................................................................................................................... 213
PIM for Backup CPU System ............................................................................................. 215
LIST OF REQUIRED CIRCUIT CARDS ....................................................................... 217
PN-BRTA (BRT) ...................................................................................................................218
PN-2BRTC (BRT) ................................................................................................................. 223
PN-2BRTK (BRT) ................................................................................................................. 228
PN-4BRTA-A (BRT) ............................................................................................................. 233
PN-24DTA-C (DTI) ............................................................................................................... 241
PN-30DTC-C (DTI) ............................................................................................................... 248
PN-24PRTA (PRT) ............................................................................................................... 254
PN-30PRTA (PRT) ............................................................................................................... 262
PN-DTA (PRT) ...................................................................................................................... 269
PN-DTB (PRT) ...................................................................................................................... 276
PN-SC00 (CCH) ...................................................................................................................283
PN-DTA (CCH) ..................................................................................................................... 286
PN-DTB (CCH) ..................................................................................................................... 292
PN-SC01 (DCH) ...................................................................................................................298
PN-SC03-B (ICH) .................................................................................................................301
PZ-M542 (CONN) ................................................................................................................. 303
PZ-M557 (CONN) ................................................................................................................. 305
PN-2ILCA (ILC) .................................................................................................................... 307
PN-2ILCC (ILC) .................................................................................................................... 310
CHAPTER 5 OPERATION TEST ....................................................................................... 315
INTEROFFICE TRANSMISSION LINE TEST .............................................................. 316
PLO OPERATION TEST .............................................................................................. 324
Clock Signal Generation Test ............................................................................................ 324
Clock Signal Synchronization Test ................................................................................... 325
Interoffice Synchronization Test ....................................................................................... 328
JULY/13/2007

INTRODUCTION
– 1 – NWA-008852-001 Rev.5.0
98ch0001.fm
INTRODUCTION
PURPOSE
This manual describes the hardware installation and the programming procedure for the Integrated Service
Digital Network (ISDN) on the NEAX 2000 IPS System.
OUTLINE OF THIS MANUAL
This manual consists of five chapters. The following paragraphs summarize Chapters 1 through 5.
CHAPTER 1 GENERAL INFORMATION
This chapter explains the ISDN system outline, the equipment name and function,
system specifications, capacity and conditions.
CHAPTER 2 INSTALLATION
This chapter explains the hardware installation procedure to provide ISDN interface
to the PBX.
CHAPTER 3 SYSTEM DATA PROGRAMMING
This chapter explains the programming procedure to provide the ISDN feature to
the PBX.
CHAPTER 4 CIRCUIT CARD INFORMATION
This chapter explains the mounting location, the meaning of lamp indications, and
the switch settings of each ISDN circuit card.
CHAPTER 5 OPERATION TEST
This chapter explains the operation test to be performed after you completed the
installation of ISDN. For fault diagnosis by MAT or CAT, refer to the Maintenance
Manual.
JANUARY/31/2006
PURPOSE/OUTLINE OF THIS MANUAL

INTRODUCTION
– 2 – NWA-008852-001 Rev.5.0
98ch0001.fm
TERMS IN THIS MANUAL
PBX System Designation
PBX system is designated as “PBX” or “system” usually.
When we must draw a clear line between the PBX systems, they are designated as follows.
2000 IPS : NEAX 2000 IPS INTERNET PROTOCOL SERVER
IPSDMR : NEAX IPSDMR INTERNET PROTOCOL SERVERDMR
IPSDM : NEAX IPSDM INTERNET PROTOCOL SERVERDM
Terminal Name
The following IP terminals are designated as “DtermIP” usually, unless we need to mention the type of ter-
minal in particular.
DtermIP (IP Adapter Type) [For North America Only]
DtermIP (IP Bundled Type)
DtermIP INASET
DtermSP20
DtermSP30
NOTE 1: Dterm75 (Series E)/Dterm85 (Series i) terminal can be used as the IP terminal by attaching the
IP Adapter (IP Enabled Dterm). This terminal provides users with all features currently avail-
able in DtermIP.
NOTE 2: In regard to the China market, we have not released NEAX 2000 IPS INTERNET PROTOCOL
SERVER but NEAX 2000 is released.
JANUARY/31/2006
TERMS IN THIS MANUAL

INTRODUCTION
– 3 – NWA-008852-001 Rev.5.0
98ch0001.fm
REFERENCE MANUAL
During installation, refer also to the manuals below:
System Manual:
Contains the system description, hardware installation procedure and the programming procedure for
the NEAX 2000 IPS System.
Command Manual:
Contains the Customer Administration Terminal (CAT) operation, command functions, setting data
required for programming the system and the Resident System Program.
Office Data Programming Manual:
Contains the Customer Specifications Sheets and the Office Data Programming Sheets.
Maintenance Manual:
Contains the maintenance service features and the recommended troubleshooting procedure.
Installation Procedure Manual:
Contains the installation procedure for the PBX system.
CCIS System Manual:
Contains the installation and the programming procedure for the CCIS system.
JANUARY/31/2006
REFERENCE MANUAL

– 4 – NWA-008852-001 Rev.5.0
98ch0001.fm
THIS PAGE LEFT BLANK INTENTIONALLY.

– 5 – NWA-008852-001 Rev.5.0
98ch1001.fm
CHAPTER 1
GENERAL INFORMATION
This chapter explains the ISDN system outline, the equipment name and
function, system specifications, capacity and conditions.
SYSTEM OUTLINE .................................................................... 6
OUTLINE OF EVENT BASED CCIS ......................................... 21
CARD NAME AND FUNCTION ................................................. 28
SYSTEM CAPACITY ................................................................. 30
SYSTEM CONDITIONS ............................................................. 33
DTI SPECIFICATIONS .............................................................. 36
CHAPTER 1 GENERAL INFORMATION

CHAPTER 1 GENERAL INFORMATION
– 6 – NWA-008852-001 Rev.5.0
98ch1001.fm
SYSTEM OUTLINE
This system can be interfaced with an ISDN with the Primary Rate Interface or the Basic Rate Interface at
the reference point S/T and ISDN Terminal.
System Outline of ISDN-PRI
The system is configured with a 24/30-channel Digital Trunk Interface (DTI) for digital network interface,
D Channel Handler (DCH) for receiving/transmitting D channel signaling data from/to the ISDN ex-
change. Since the Main Processor (MP) contains Phase Locked Oscillator (PLO), the system can be syn-
chronized to the ISDN as a clock receiver office.
The figure below shows the system outline of ISDN-PRI.
System Outline of ISDN-PRI
NOTE 1: NT1 equipment must be installed in the premise.
NOTE 2: The PRT provides a built-in DCH.
PBX
23B/30B
D
SLT
LC
Dterm
DLC
MP
DTI
DCH
1.5 M/2 M PCM
DIGITAL LINE (23B/30B + D)
DCH : D Channel Handler
DTI : Digital Trunk Interface
NT1 : Network Termination One
PLO : Phase Locked Oscillator
PRT : Primary Rate Interface Trunk
TDSW
CLOCK
SIGNAL
/PRT NT1 ISDN
(PLO)
SYSTEM OUTLINE
