Philips QP6520 User manual

Introduction Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that Philips
offers, register your product at www.philips.com/welcome. General
description (Fig.1)
1Blade
2Blade release slide
3Travel lock (QP6520 only)
4Battery status percentage (QP6520 only)
5Charge symbol (QP6520 only)
6Display (QP6520 only)
7On/off button
8Battery status indicator (QP6510 only)
9Charging stand (QP6520 only)
10 Small plug of the charging stand (QP6520 only)
11 Pouch (QP6520 only)
12 Small plug
13 Supply unit (adapter, type HQ8505)
14 Precision trimming comb 15 Hair length setting
wheel
Important safety information
Read this important information carefully before you use
the appliance and its accessories and save it for future
reference. The accessories supplied may vary for different
products.
Danger
- Keep the supply unit dry.

Warning
-To charge the battery, only use the
detachable supply unit (HQ8505) provided
with the appliance.
-The supply unit contains a transformer. Do
not cut off the supply unit to replace it with
another plug, as this causes a hazardous
situation.
-This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
-Always unplug the appliance before you
clean it under the tap.
-Always check the appliance before you use
it. Do not use the appliance if it is damaged,
as this may cause injury. Always replace a
damaged part with one of the original type.

-Do not open the appliance to replace the
rechargeable battery.
Caution -Never immerse the charging stand in
water and do not rinse it under the tap.
-Do not use the supply unit in or near
wall sockets that contain an electric air
freshener to prevent irreparable damage to
the supply unit.
-Only use this appliance for its intended
purpose as shown in the user manual.
-For hygienic reasons, the appliance should
only be used by one person.
-Never use water hotter than 60°C to rinse
the appliance.
-Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive
liquids such as petrol or acetone to clean the
appliance.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
General -This appliance is waterproof. It is suitable for use in the bath or
shower and for cleaning under the tap. For safety reasons, the
appliance can therefore only be used without cord.

-The supply unit is suitable for mains voltages ranging from 100 to
240 volts.
-The supply unit transforms 100-240 volts to a safe low voltage of
less than 24 volts.
-Maximum noise level: Lc = 75 dB(A).
Charging Note: This appliance can only be used without cord.
QP6520, QP6510: Charging takes approx. 1 hour. A fully
charged appliance has an operating time of up to 90
minutes (QP6520) or 60 minutes (QP6510).
Charge the appliance before you use it for the first time and
when the charge symbol indicates that the battery is almost
empty.
Battery status indicator QP6520
-When the charge symbol flashes orange, the battery is
almost empty. The remaining battery capacity is
indicated by the battery status percentage shown on the
display.
-To indicate that the appliance is charging, the charge
symbol flashes white.
-Quick charge: after approx. 5 minutes charging, the
appliance contains enough energy for 5 minutes using.
During quick charge the charge symbol flashes white
quickly until quick charge is finished.
-The battery is fully charged when the battery status
percentage shown on the display is 100% and the charge
symbol lights up continuously.
-Approx. 30 minutes after the battery is fully charged or
when you disconnect the appliance from the mains, the
display switches off automatically.
Battery status indicator QP6510

-When the battery status indicator flashes orange, the
battery is almost empty.
-To indicate that the appliance is charging, first the
bottom light flashes white and then lights up white
continuously. Then the second light flashes and then
lights up continuously, and so on until the appliance is
fully charged.
-Quick charge: after approx. 5 minutes charging, the
appliance contains enough energy for 5 minutes using.
During quick charge the lights of the battery status
indicator will light up continuously one after another
and then all switch off. This will repeat itself until quick
charge is finished.
-The battery is fully charged when all lights of the
battery status indicator light up continuously.
-Approx. 30 minutes after the battery is fully charged or
when you disconnect the appliance from the mains, the
lights of the battery status indicator switch off
automatically.
Charging with the adapter
1Insert the small plug into the appliance and put the
supply unit in the wall socket.
2After charging, remove the supply unit from the wall
socket and pull the small plug out of the appliance.
Charging in the charging stand (QP6520 only)
1Insert the small plug into the charging stand and put the
adapter in the wall socket.
2Put the appliance in the charging stand.
3After charging, remove the adapter from the wall socket
and pull the small plug out of the charging stand.

Using the appliance
You can use the appliance to trim, edge or shave facial hair
(beard, moustache and sideburns). Shave for a smooth
result, trim to obtain a certain length and edge to create
perfect edges and sharp lines. This appliance is not intended
for shaving, edging or trimming hairs on lower body parts
or scalp hair. Take your time when you first start to use the
appliance. You have to acquire practice with the appliance.
Switching the appliance on and off
1To switch on the appliance, press the on/off button
once.
2To switch off the appliance, press the on/off button
once.
Before you use the appliance, always check the
blade for damage or wear. If the blade is
damaged or worn, do not use the appliance, as
injury may occur. Replace a damaged blade
before you use the appliance (see chapter
‘Replacement’).
Shaving tips and tricks
-Make sure that the blade is in full contact with the skin
by placing it flat on the skin.
-For the best result, move the appliance against the grain.
-Make long strokes while pressing lightly.
-You can use the appliance dry or wet with gel or foam.
You can even use the appliance in the shower.
-Shaving a clean beard and face gives the best results.
1Switch on the appliance.
2Place the blade on the skin and move the appliance up
or against the grain in long strokes while you press it
lightly.
Note: This appliance can only be used without cord.
Note: Make sure you hold the surface of the blade flat
against your skin.

3Switch off and clean the appliance after every use (see
‘Cleaning and maintenance’).
Edging
You can also use both edges of the blade to create sharp
lines and perfect edges. Hold the appliance in such a way
that the blade is perpendicular to the skin and one of its
edges touches the skin. This allows more precise detailing
of sideburns and the area around the mouth and nose.
1 To create sharp edges and lines, you can use
either edge of the blade. 2 Switch on the
appliance.
3 Place the edge of the blade perpendicular onto the skin.
- Make straight strokes while applying gentle pressure.
4 Switch off and clean the appliance after every use (see
‘Cleaning and maintenance’).
Trimming with comb
Tips
-Always trim in the direction of the
teeth of the precision trimming comb
making sure the flat part of the comb is in
full contact with the skin for an even
trimming result.
-Since hair grows in different directions, you need to
hold the appliance in different positions as well.
However, always make sure that you move the
appliance upwards against the grain.
-Trimming is easier when the skin and hair are dry.

The precision trimming comb allows you to trim hair to
different lengths. Start at the highest setting to acquire
practice with this appliance. The settings on the wheel
correspond to the hair lengths in millimeters.
1Place the front part of the comb onto the blade and push
the projection at the back of the comb into the appliance
(‘click’).
2Turn the hair length setting wheel to select the desired
hair length setting.
The settings on the wheel correspond to the hair lengths in
millimeters.
-QP6520 -QP6510
3Switch on the appliance.
4Place the comb onto the skin and
move the appliance upwards slowly,
against the grain.
5Switch off and clean the appliance
after every use (see ‘Cleaning and
maintenance’).
6To remove the comb, pull its back
part off the appliance and then slide it off
the blade.

Cleaning and maintenance
Clean the appliance after every use.
Caution: Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive liquids such as
petrol or acetone to clean the appliance.
Caution: Do not tap the appliance against a surface to
remove water from it, as this may cause damage.
Replace the blade if it is damaged.
Cleaning the appliance
Caution: Do not dry the blade with a towel or a
tissue as this may cause damage.

1Remove the comb from the blade. Always turn the
appliance off before putting on or taking off the comb.
2If a lot of hairs have accumulated on the comb, first
blow them off.
3If a lot of hairs have accumulated on the appliance, first
blow them off.
4Then switch on the appliance and rinse the blade with
lukewarm water.
5Then rinse the comb with lukewarm water.
6Let the appliance and comb dry.
Storage
Note: We advise you to let the appliance and its
attachments dry before you store them for the next use.
1 Always attach the precision
trimming comb on the blade to protect the
blade from damage during travelling or
storage.
Travel lock (QP6520 only)
Note: The blade is fragile. Handle it carefully. Replace
the blade if it is damaged.
1
2

You can lock the appliance when you are going to travel.
The travel lock prevents the appliance from being switched
on by accident.
Activating the travel lock
1 Press the on/off button for 3 seconds.
-While you activate the travel lock, the travel lock
symbol lights up and the digital display counts down.
-When the travel lock is activated, the travel lock symbol
flashes.
Deactivating the travel lock
1 Press the on/off button for 3 seconds.
-While you deactivate the travel lock, the display counts
down. Then the travel lock symbol lights up and
switches off.
-The appliance is now ready for use again.
Replacement
Usage indicator
For optimal cutting and gliding performance, we advise you
to replace the blade every 4 months, when it no longer
provides the shaving or trimming results you expect or
when the usage indicator appears.
The blade is equipped with a usage indicator which
gradually turns green. When the green bar is highly visible,
it is recommended to replace your blade. Always replace
the blade with an original Philips blade.
Depending on your usage behavior, the exact lifetime
of the bladecould be longer or shorter. Similar to a manual
blade, the blade becomes blunt over time, which results in increased hair
pulling and reduced cutting performance. Replacing the blade

1Push the blade release slide upwards carefully, and hold
the blade on both sides to remove the blade. This will
prevent the blade from flying off the handle.
2Hold the new blade on its sides and press it onto the
handle (‘click’).
Ordering accessories
To buy accessories or spare parts, visit
www.shop.philips.com/service or go to your Philips
dealer. You can also contact the Philips Consumer Care
Center in your country (see the international warranty
leaflet for contact details).
The following parts are available:
-QP210 Blade 1-pack
-QP220 Blade 2-pack Recycling
-This symbol means that this product shall not be
disposed of with normal household waste (2012/19/EU).
-This symbol means that this product contains a built-in
rechargeable battery which shall not be disposed of with
normal household waste (2006/66/EC). Please take your
product to an official collection point or a Philips
service center to have a professional remove the
rechargeable battery.
-Follow your country’s rules for the separate collection
of electrical and electronic products and rechargeable
batteries. Correct disposal helps prevent negative
consequences for the environment and human health.
Note: When you hear a click, the new blade is placed
correctly and ready for use.

Removing the rechargeable battery
Caution: Only remove the rechargeable battery when
you discard the appliance. Make sure the battery is
completely empty when you remove it.
Note: We strongly advise you to have a professional
remove the rechargeable battery.
1Disconnect the appliance from the mains and let the
appliance run until the motor stops.
2Remove the blade from the appliance.

3Insert a screwdriver under the back panel and remove
the panel.
4Break the snap connections on both sides with the
screwdriver.
5Push out the inner body by pushing the screwdriver into
the bottom of the handle. - Now you see the printed
circuit board.
6QP6510: remove the cover of the printed circuit board
with the screwdriver.
7Remove the printed circuit board from the inner body
with the screwdriver.
8Lift the battery out of the inner body with the
screwdriver. The battery is connected with double-sided
tape.
Warranty and support
If you need information or support, please visit
www.philips.com/support or read the international
warranty leaflet.
Warning: Be careful, the battery strips are very
sharp.

Guarantee restrictions
The blade is not covered by the terms of the international
guarantee because it is subject to wear.
Troubleshooting
This chapter summarizes the most common problems you
could encounter with the appliance. If you are unable to
solve the problem with the information below, visit
www.philips.com/support for a list of frequently asked
questions or contact the Consumer Care Center in your
country.
Problem Possible cause Solution
I cannot switch You cannot use the Disconnect the appliance on the
appliance appliance when it from the mains before use.
when it is is charging. You can connected to the
only use the
mains. appliance without
cord.
Problem Possible cause Solution
The appliance does
not work anymore.
The rechargeable
battery is empty.
Charge the appliance (see
chapter ‘Charging’). During
charging, the battery charge
indicator flashes white. If the
battery charge indicator does
not flash, check whether there
is a power failure or if the wall
socket is live. If there is no
power failure and the wall
socket is live but the battery
charge indicator still does not
flash, take the appliance to your
dealer or a Philips service
center.

The blade is blocked
by dirt.
Switch on the appliance and
rinse the blade under the tap
with warm water.
Hold the blade in a cup with
warm water (60°C and not
hotter) for approx. 30 seconds.
Travel lock is activated.
Press the on/off button for 3
seconds to deactivate travel
lock.While you deactivate the
travel lock, the display counts
down. Then the travel lock
symbol lights up and switches
off.The appliance is now ready
for use again.
The appliance does
not cut hairs
anymore.
The blade is placed on
the handle incorrectly.
Push the blade onto the
appliance until you hear a click.
The blade is damaged
or worn.
Replace the blade with a new
one. See chapter
‘Replacement’.
Problem Possible cause Solution
The appliance makes
a strange noise.
The blade is damaged
or worn.
Replace the blade with a new
one. See chapter
‘Replacement’.
The blade is placed on
the handle incorrectly.
Remove and reattach the blade.
Push it onto the appliance until
you hear a click.
The blade is blocked
by dirt.
Remove the blade and clean the
blade thoroughly.
The appliance does
not function
optimally anymore.
The blade is blocked
by dirt.
Remove the blade and clean the
blade thoroughly.

The blade is subject to
wear and therefore its
performance
decreases over time.
Replace the blade with a new
one. See chapter
‘Replacement’.
The blade is a delicate
part of the appliance
and can easily be
damaged. If the blade
is damaged, it may not
function optimally
anymore.
Replace the blade with a new
one. See chapter
‘Replacement’.
