Philips SpeedPro FC6724/01 User manual

Service
Manual
SpeedPro
FC6724/01

2
Contents
FC6724/01
Important repair instructions
•Only skilled personnel should carry out the repair.
•After repair the appliance should function properly.
•After repair the appliance has to meet the regulatory- and safety requirements that were applicable at the
time of release of the model.
•After repair the appliance always has to be tested for electrical safety according VDE 0701-0702 and for
medical products IEC 62353.
General information 3
Performance
Usability
Design
Filtration
Nozzles and accessories
Sustainability
Weight and dimensions
Optional (accessories)
Technical information 4
Production date (or serial number)
Electrical diagram
Disassembly- and Reassembly advice 5
Functions/features explanation 12
Fast. Powerful reach, even in the toughest spots
Troubleshooting 13
Service parts 15
Version history 23

3
Performance
•Airow (max): Up to 800 l/min
•Battery type: Li-Ion
•Battery voltage: 21.6 V
•Charging time: 5 hour(s)
•Runtime: 40 minute(s)
•Runtime (turbo): 20 minute(s)
•Sound power level: 80 dB
Usability
•Carrying handle: Top
•Wheel type: Rubber
Design
•Design features: 2-in-1
•Color: Dark Royal Blue
Filtration
•Dust capacity: 0.4 L
•Motor lter: Washable lter
Nozzles and accessories
•Accessories included: AC power adaptor,
Crevice tool, Integrated brush, Wall-mount
docking
•Standard nozzle: 180° suction nozzle
Sustainability
•Packaging: > 90% recycled materials
Weight and dimensions
•Weight of product: 2.48 kg
Optional (accessories)
•Mini Turbo Brush
General information

4
FC6724/01
Electrical diagram
M
M
M
Main PCB
UI Panel
Battery pack
12
On/Off
Speed 1 + 2
Suction
Motor
Input
100-240V AC Nozzle
Brush
Motor
Adaptor
Mini
Turbo
Brush
Brush
Motor
Production date (or serial number)
Technical information

5
•Release the Bucket (1), the lter (170) on the
bottom can be taken o.
•Unclick UI-panel (8):
Remove with screwdriver then lift the UI-Panel.
•Remove screw C.
•Take out the Back Cover (11).
Disassembly- and Reassembly advice

6
FC6724/01
•Remove screw D.
•Remove side panels (9+10) by pushing them
to the outside, unclick and remove screw on the
side.
•Remove the screws Eon both sides.
Disassembly- and Reassembly advice

7
•Push the Rear cover (13) backwards. •Remove tiewrap (see picture).
•Turn the Handheld and unclick the connector
from the PCB (Battery).
Disassembly- and Reassembly advice

8
FC6724/01
•Remove the 2 screws J. •Remove the other connector.
•Remove the battery assy (28):
Now the battery can be replaced.
Disassembly- and Reassembly advice

9
•When replacing the new battery and motor:
First remove the 4 screws Gon the front.
•Remove screw Fin the idle.
•Pull the inlet part (17) forwards.
Disassembly- and Reassembly advice

10
FC6724/01
•Remove the Rim (16):
Unclick (with small screw driver) the 3 knocks
on the side. (both sides) Push the knocks in,
otherwise it cannot be unclicked.
•Remove the 4 screws H.
•Remove the Motor Cover (20):
Pull the Motor Cover upwards with a screwdriver.
•Check the wires, disconnect them.
The motor assy can be taken out and can be
replaced.
Disassembly- and Reassembly advice

11
•Remove / repair motor (23):
Disconnect the wiring from the PCB. Uplift the
motor assy with plastic parts and 2 springs.
•Remove PCB:
After removing battery, disconnect all
connectors, remove screw Kto separate the PCB
(30) from the frame (29) it is screwed on.
Remark: Motor + PCBA must always be replaced
as one part !!
Remark: To replace the motor:
Push and check whether the rubber (21)
is positioned correctly.
•Pull the wires.
•When replacing the Charging plate assy:
Check if screw Fhas been removed (visible via
type plate-side).
•Below you can see that the screw is still present,
remove it then place the Charging Plate assy.
When replacing the Rim:
First place the Side panels.
To re-install the side panels:
First click the clicks on the backside - check the
wiring when re-installing the Front inlet.
Disassembly- and Reassembly advice

12
FC6724/01
Fast. Powerful reach, even in the toughest spots
The new SpeedPro cordless vacuum cleaner provides a fast clean, with powerful reach. It’s equipped with
the 180° suction nozzle for precise dirt pick-up, even in the toughest spots - close to walls, furniture and
in the corners.
Fast clean, with powerful reach
•180° suction nozzle for powerful and precise dirt pick-up
•Two speed settings to suit dierent oors and dirt types
Uninterrupted, eective cleaning
•Up to 40 min of cleaning power, with 21.6 V Li-Ion batteries
•Integrated handheld unit, crevice tool and brush
•Fast reach everywhere, even under low furniture
•Unique dust bucket design empties without dust clouds
High air speed for long-lasting performace
•PowerBlade motor is engineered for high air speed
•PowerCyclone 7 maintains strong performance for longer
•Washable lter ensures high air speed for longer
Functions/features explanation

13
Problem Possible cause Solution
1. The appliance does not
work when I push the
button.
a. When the battery is empty,
the bottom segment of the
display ashes red.
b. You have to push the slider
forward to switch on the
appliance.
• To charge the battery, connect the
appliance to the charging base or attach
the handheld vacuum cleaner directly to
the magnet on the charging base.
• Push the slider forward to setting 1 to
switch on. Increase the suction power
further by pushing the slider to setting 2 to
clean dirty surfaces.
2. The appliance has a lower
suction power than usual.
a. The lter and the cyclone
are dirty.
b. You have not attached the
dust container lid properly
to the dust container. You
have not attached the dust
container to the appliance
properly. In both cases, there
will be a loss of suction
power.
c. An object may be stuck
inside the tube.
• Clean the lter and the cyclone. Make sure
that you wash the sponge lter at least
once a month if you use the appliance
regularly.
• Make sure that you attach the dust
container lid to the dust container and the
dust container to the appliance properly.
• Remove the tube and check for blockages.
3. Dust escapes from the
appliance.
a. The lter is dirty.
b. The lter is not present in the
appliance.
c. Something blocks the
cyclone.
d. If dust falls out of the dust
container, the dust container
lid is probably not attached
properly to the dust
container.
• Clean the lter.
• Make sure that the lter is in the appliance
and assembled correctly.
• Check the cyclone for objects stuck in it and
remove any object that blocks the cyclone.
• Empty the dust container and attach the
dust container lid correctly.
4. The appliance does not
move smoothly across
the oor when cleaning a
carpet.
a. You selected a too high
suction power.
• Reduce the suction power by choosing
setting 1.
5. The brush does not turn
anymore.
a. The brush encounters too
much resistance.
b. The brush may stop turning
when it encounters too
much resistance from high-
pile carpet.
c. You have not installed the
roller brush in the nozzle
properly after cleaning.
• Clean the brush with a pair of scissors or by
hand.
• Switch o the appliance and then switch it
back on again.
• Follow the instructions in the cleaning
chapter of the user manual to slide the
roller brush into the nozzle properly and
secure it inside the nozzle by snapping
home the locking lever.
Troubleshooting

14
FC6724/01
Problem Possible cause Solution
6. FC6729, FC6728,
FC6727, FC6726,
FC6725, FC6723:
The LEDs in the nozzle do
not come on.
a. You have not attached the
nozzle to the appliance or
handheld properly.
• Attach the nozzle to the appliance or
handheld properly.
7. The appliance is not
charging.
a. The magnetic connector
is not connected correctly
to the charging disk or the
adapter is not inserted into
the wall socket properly.
• Make sure that the magnetic connector is
connected properly to the charging disk
and that the adapter is inserted into the wall
socket properly.
• If you have checked the above and the
appliance still does not charge, take it
to a Philips service center or contact the
Consumer Care Center via
www.philips.com/support.
8. FC6729, FC6727,
FC6726:
The mini turbo brush does
not function properly.
a. The roller brush is blocked.
b. The roller brush is blocked
by fabric or surfaces during
cleaning.
c. The mini turbo brush is not
fully closed.
• Remove hairs from the brush with a pair of
scissors (see user manual).
• Keep the mini turbo brush aligned with the
surface and do not push the turbo brush
into soft surfaces.
• Make sure that the top and bottom parts
of the mini turbo brush are properly
connected and there is no gap between
the two parts. Check if the locking ring is in
closed position (see user manual).
9. When I use my vacuum
cleaner I sometimes feel
static electricity shocks.
a. Your vacuum cleaner builds
up static electricity. The
lower the air humidity, the
more static electricity the
appliance builds up.
b. You vacuumed up ne sand,
lime or a similar substance.
This also causes static
electricity.
• Discharge the appliance by frequently
holding the tube against other metal
objects in the room (for example the legs of
a table or chair, etc.). You can also raise the
air humidity level in the room.
• Empty the dust container and clean the
lter according to the instructions in the
user manual.
10. The bottom segment of
the display ashes red.
a. The battery is empty. • To charge the battery, connect the
appliance to the charging base or attach
the handheld vacuum cleaner directly to
the magnet on the charging base.
11. All segments of the display
ash red quickly.
a. An error has occurred. • First try to recharge the appliance, empty
the dust container and clean the lter.
If this does not help, take the appliance
to a Philips service center or contact the
Consumer Care Center via
www.philips.com/support.
Troubleshooting

15
2
1
32
33
Pos Service code Description Remark CRP
1 3000 034 92091 Bucket assy WEU FC6724/01
2 3000 034 72831 Adapter + Disc ETEK ZD12D290050EU 21.6 V Euro plug (rated 29 V)
32 3000 035 34601 Wall Mount Dark slate 011612
33 3000 034 75581 Handheld Dark Royal Blue/Magmatic Orange
Service parts

16
150
140
130
120
110
180
170
160
FC6724/01
Pos Service code Description Remark CRP
110 Bucket Lid Smoke Black Transparent 80235
120 Bucket Lid Sealing
130 Dust Outlet Smoke Black Transparent 80235
140 Vortex Finder Magmatic Orange 20986
150 Bucket Smoke Black Transparent 80235
160 3000 027 63521 Skywalker inlet lter assy
170 Bucket return valve assy Dark Slate 011612
180 Vortex Cap Magmatic Orange 20986
Service parts

17
A
B
B
510
5
520
310
3
410
4
Pos Service code Description Remark CRP
3 3000 035 35031 Tube assy Dark Royal Blue/Magmatic Orange
310 3000 034 92071 Integrated Brush Malibu 061385
4 3000 035 87101 Mini Turbo Brush Skywalker
410 3000 005 04521 MTB Brush
5 3000 034 75531 Active Nozzle FC6724/01 Malibu 061385
510 3000 029 00931 Brush assy Active Nozzle
520 Rear Wheel assy
Service parts

18
C
9
11
10
810
8
FC6724/01
Pos Service code Description Remark
8 UI Cover Malibu 061385
810 3000 034 75402 Slider Malibu 061385
9 Side Panel Right Dark Royal Blue
10 Side Panel Left Dark Royal Blue
11 Handle Cover Dark Royal Blue 613776
Service parts

19
V
E
E
D
F
12
15
13
14
Pos Service code Description Remark
12
13 Rear Cover Malibu 061385
14 Anti Slip Rubber Dark Slate 011612
15 Charging Plate assy Malibu 061385
Service parts

20
Y
G
4x
18
1910
1920
17
16
FC6724/01
Pos Service code Description Remark
16 Rim Malibu 061385
17 Inlet Piece Malibu 061385
18 Inlet Sealing Dark Slate 011612
1910 Female Connector Top Dark Slate 011612
1920 Female Connector Dark Slate 011612
Service parts
