Philips Voice Tracer
Meeting recorder
LFH0895
Get your meeting going
The simplest way to make your meeting a success!
The Voice Tracer captures every word in an excellent audio quality. Just put the plate-
shaped microphones on the meeting table, connect them to the recorder and get going!
Superior audio quality
• Record in the popular MP3 or PCM format
• Adjustable microphone sensitivity for optimal quality
• Innovative microphones with 360-degree sound pickup
Easy and intuitive experience
• Rapidly transfer recordings and data via USB 2.0
• Organize your files in a fast and easy way with four folders
• Portable and easy-to-use solution
Designed around you
• Recharge the batteries via USB
• All-in-one carry case for comfortable transportation

Specifications
LFH0895/00
Meeting recorder
Highlights
Portable and easy solution
Light, powerful and easy-to-use solution for recording
your meetings.
All-in-one carry case
The all-in-one carrying case not only stores your
recorder neatly, but also keeps meeting microphones
well organized and well protected.
360-degree sound pickup
The revolutionary boundary layer microphone is, as
opposed to other prevalent devices, non-directional.
The design allows sound pick-up from a 360 degree
radius, so that no important details are lost.
Record in MP3 or PCM
Recordings can be taken in the popular MP3 or the
high quality PCM format. The PCM format offers
outstanding audio CD like recording quality and
therefore makes listening to your audio files a
pleasure.
Adjustable microphone
The signal-to-noise (S/N) ratio of the high-sensitivity
microphone is far better than those of standard
microphones. Recording sensitivity is increased (picks
up more voice signal) without compromising sound
quality.
Easy file organisation
The Digital Voice Tracer supports up to 99 recordings
in each of four available folders to organize your files
in a fast and easy way.
Rapidly transfer recordings
Thanks to the fast data transfer of a hi-speed 2.0 USB
connection, transfering recordings to your PC is up to
40 times faster compared with the original USB
standard.
Recharge the batteries via USB
Help protect the environment by simply recharging
the batteries of your device using USB instead of
buying new batteries.
What is included?
• Digital recorder LFH0882
• Meeting microphones: 2
Connectivity
• Headphones: 3.5 mm
• Microphone: 3.5 mm
• Line-in
• USB: High-speed USB 2.0
Display
•Type:LCD
• Diagonal screen size: 39 mm/1.5 in.
• Backlight: white
Storage media
• Built-in memory capacity: 4 GB
• Buit-in memory type: NAND Flash
• Mass storage class compliant
Audio recording
• Recording formats: MPEG1 layer 3 (MP3), PCM
(WAV)
• Built-in microphone: high-sensitivity, low-noise
microphone, stereo
• Recording modes: PCM (WAV/stereo), SHQ (MP3/
stereo), HQ (MP3/stereo), SP (MP3/mono), LP
(MP3/mono), SLP (MP3/mono)
• Bit rate: 16, 32, 48, 64, 192, 1411 kbps
• Recording time: 572 hours (SLP), 286 (LP), 190
hours (SP), 143 hours (HQ), 47 hours (SHQ), 6.4
hours (PCM)
• Sample rate: 44.1 kHz (PCM/SHQ), 22 kHz (HQ), 16
kHz (SP/LP/SLP)
Sound
• Speaker type: built-in round dynamic speaker
• Speaker diameter: 30 mm
• Speaker output power: 110 mW
• Frequency response: 50–20,000 Hz
• Signal to noise ratio: > 60 dB
Music playback
• Compression format: MP3, WMA
• MP3 bit rates: 8–320 kbps
• WMA bit rates: 48–320 kbps (44 kHz), 64–192 (48
kHz), stereo
• Digital rights management: not supported
• Equalizer settings: Classical, Jazz, Pop, Rock
Tuner
• Tuner bands: FM stereo
• Frequency range: 87,5-108 MHz
• Station presets: 20
• Auto digital tuning
Convenience
• Voice volume indicator
• Instant one-touch recording
• Voice-activated recording
•Keypadlock
• Firmware upgradeable
Power
• Battery type: AAA/LR03 Alkaline, Philips AAA Ni-
MH LFH9154
• Number of batteries: 2
• Rechargeable: yes, via USB
• Battery lifetime: up to 50 hours in SLP recording
mode
• Batteries included: rechargeable
Meeting microphone
• Design: boundary layer microphone
• Type: electret condenser microphone
• Impedance: approx. 2,2 kOhm @ 1 kHz
•Sensitivity:-38dBV
• Frequency response: 30–18,000 Hz
• Phantom supply voltage: 1,5 to 5 V/0,5 mA
• Connector: 3.5 mm
• Cable length: 2 m / 6.5 ft.
• Product dimensions (W x D x H): 13 × 13 × 1.8 cm/
5.1 × 5.1 × 0.7 in.
• Net weight: 0.108 kg/0.238 lb
System requirements
• Operating system: Linux, Mac OS X, Windows 7/
Vista/XP/2000
• Free USB port
Green specifications
• Lead-free soldered product
Accessories
•USBcable
• Stereo headphones
• 2 meeting microphones
•Carrycase
• Splitter cable
• 2 × AAA batteries
• Quick start guide
• User manual
Design and finishing
• Color(s): aluminum silver/black
Product dimensions
• Product dimensions (W x H x D):
3.9 x 10.7 x 1.8 cm
• Product dimensions (W x H x D):
1.5 x 4.2 x 0.7 inch
• Weight: 0.058 kg
• Weight: 0.128 lb
•
Issue date 2010-11-29
Version: 4.4.9
12 NC: 8735 089 50011
UPC: 6 09585 17599 0
