Phistek P104VG Installation and operating instructions

1
User Manual / Installation Guide
Model No. P104VG / P104VR / P104VP
Warning! It will cause malfunction if the monitor is operating with unspecified power supply adaptor
or incorrect power voltage. Do not expose this unit in the rain or moisture environment to reduce the
risk of fire or electric shock.
PRECAUTIONS
Do not use the monitor near water.
Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a
person and cause serious damage to the appliance. Use only a cart or stand recommended by the
manufacturer or sold with the monitor. If you mount the monitor on a wall or shelf, use a mounting
kit approved by the manufacturer and follows the kit instructions.
The monitor should be operated with type of power adaptor indicated on the label.
Normally it is packed with monitor, or using an adaptor approved by the manufacturer.
Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will
protect the monitor from being damaged due to power surges.
Never spill liquids on the monitor.
Do not attempt to service the monitor yourself; opening or removing covers can damage to the
monitor or panel. Please refer all servicing to qualified service personnel.
For Wall mount adaptor, wall socket shall be installed near the equipment and shall be easily
accessible.

2
Index:
I. Introduction --------------------------------------------------------------------------------------------------- 3
Features--------------------------------------------------------------------------------------------------------- 3
Unpack the monitor------------------------------------------------------------------------------------------ 3
Check Accessories-------------------------------------------------------------------------------------------- 3
II. Installation----------------------------------------------------------------------------------------------------- 4
Power Supply & Signal connection ---------------------------------------------------------------------- 4
Function Touch Key Control ------------------------------------------------------------------------------ 4
OSD Lock/ Unlock -------------------------------------------------------------------------------------------- 5
Structure of OSD settings----------------------------------------------------------------------------------- 5
III. For your safety------------------------------------------------------------------------------------------------ 6
IV. Support timing chart ---------------------------------------------------------------------------------------- 6
V. 5 Wires Resistive Touch Panel ---------------------------------------------------------------------------- 7
VI. Projected Capacitive Touch Panel ----------------------------------------------------------------------- 14
VII. Mechanical dimension------------------------------------------------------------------------------------- 15
VIII. EMC Warning Statement----------------------------------------------------------------------------------- 16
FCC Class A Warning ---------------------------------------------------------------------------------------- 16
CISPR 22 class A Warning --------------------------------------------------------------------------------- 16
IX. Product General Specification---------------------------------------------------------------------------- 17

3
I. Introduction
- This monitor produces clear images with the vivid color at resolutions from VGA up to XGA and used
with graphics adapter of scanning frequency from 30KHz to 82KHz in horizontal sweep while vertical
refresh rate is 55Hz to 76 Hz continuously.
- On Screen Display provide flexibility with simple & user-friendly controls.
- USB interface Projected Capacitive Touch Panel and Resistive Touch (for touch model only)
Features
- 10.4inch diagonal screen with native display resolution 800 x 600.
- Full flat front panel with high quality Projected capacitive touch panel, Resistive touch panel or
cover lens.
- Fully Glossy surface throughout monitor’s appearance.
- Rimless front bezel design, spill & dust proof.
- Cable management down routing through the mounting stand.
- Light weight.
- Mitsubishi PMMA cover lens for P104VG.
- 5 Wires Resistive Touch Panel Control Function for P104VR.
- Projected Capacitive Touch panel for P104VP.
Unpack the monitor
- Put the monitor on a clean surface, make sure the box in upright position.
- Remove packing materials from inside of box.
Check accessory
Please make sure the entire accessory is included:
Power Adaptor, the plug
type could be modified
by order.
1.8meter VGA 15 pin
D-sub video cable
USB cable for Touch
control
(For touch model only).

4
II. Installation:
Power Supply & Signal connection:
Power supply: Use attached Wall-mount Power adaptor to get 12Vdc power.
VGA signal: Use attached 1.8meter 15pin D-sub VGA cable to connect System PC.
Touch Control: Use attached USB cable to connect system PC.
Function Key Control:
Power
( )
Use the power switch to turn the power ON or OFF. We recommend turning
your system power on first, then the LCD monitor.
Press Power key to turn on and press again for 2~3sec. to power off monitor.
Auto Adjust
(AUTO)
a. Pressing to execute AUTO-Adjusting function. This function will optimize the
display image.
b. Sometimes this function can't achieve the optimal effects. Please follow the
manual adjusting procedure.
c. After OSD menu is activated, press this key can turn off the OSD menu.
Touch Control
for Touch Model only
VGA input
15pin D-sub
DC12V input

5
Menu
(MENU)
a. Press Menu key to activate OSD Menu.
b.
This key also means “OK”.
- Press “Up” or “Down” key to move the indicator to the desired item, then
press Menu key to select and read to adjust.
- After adjustment, press this key to return to previous Menu.
Up
( ▲)
a. When OSD mode is activated (When “MENU” key is pressed). These two
keys are used to select the adjustment items.
b. When adjustment item is selected, these
two keys are defined to decrease or
increase the value of each selected item.
Down
( ▼)
OSD Lock/ Unlock:
Press “Menu” Key for more than 7 seconds shall lock all control keys’ function.
After keys locked, press “Menu” key again for more than 7 second shall unlock the key function.
Structure of OSD settings:
Item Level 1 Level 2 Level 3 Operating Procedure
Main
Menu
Auto Adjust −−Press “UP” or “DOWN” to adjust H-phase & H-position & V-
position clock automatically.
Luminance
Brightness −Press “UP” key to increase brightness, “DOWN” key to
decrease brightness.
Contrast −Press “UP” key to increase contrast, “DOWN” key to decrease
contrast.
Black levels −Press “UP” key to increase background brightness, “DOWN”
key to decrease background brightness.
Sharpness −Press “UP” key to increase image sharpness, “DOWN” key to
decrease image sharpness.
Exit −Exit to previous Menu.
Management
H. Position Press “UP” key to shift screen left, “DOWN” key to shift screen
right.
V. Position −Press “UP” key to shift picture upward, “DOWN” key to shift
picture downward.
Pixel Clock −
To reduce any vertical bars or strips visible on the screen
background. Adjusting the Clock will also
change the horizontal
screen image width.
Phase −
To remove any horizontal noise and clear or sharpen the image
of characters.
Exit −Exit to previous Menu.
Color
9300K −
Press “UP” or “DOWN” to choose three types of color
temperature 9300°k, 6500°k, sRGB and user define.
6500K −
sRGB −
User Preset
Red
Select User Preset to enter Color Adjust Menu, and select
desired color to adjust.
Green
Blue
Exit
Exit −Exit to Main Menu.

6
Main
Menu
OSD
H. Position −Adjust OSD Menu horizontal position, press “UP” key to shift
Menu right, “DOWN” key to shift Menu left.
V. Position −Adjust OSD Menu vertical position, press “UP” key to shift
Menu upward, “DOWN” key to shift Menu downward.
OSD Time −Sets the time duration in seconds that the OSD is visible after
the last button is pressed.
Exit −Exit to previous Menu.
Language
English −
Press Up/Down key to move OSD bar to desired language,
then press to confirm. The OSD Menu will change to desired
language and return to Main Menu.
Francais −
Deutsch −
Italino −
Espanol −
日本語 −
繁體中文 −
简体中文 −
Recall
Recall Color Yes No Press ”Yes” to reset Color to factory setting.
Recall All Yes No Press “Yes” to rest all settings back to factory setting, except
language.
Exit −Press “Exit” to return to Main Menu.
Information
Display
Information −Press Display information to display resolution and refresh
rate.
Exit −Press “Exit” to return to Main Men.
Exit −−Press “Exit” key will close OSD Menu and save the settings.
III. For your safety
1. When move the monitor, always switch off power and disconnect all cables to avoid any danger.
2. Please use the power and signal cables correctly when install it.
3. In case of notice any abnormal smell or noise, please stop operation and call the nearest dealer or
service center.
IV. Support timing chart
Timing
Mode
Reference
Standard
Resolution Pixel MHz FH KHz FV Hz Interlace H Polarity V Polarity
Mode 1
VESA
800 × 600
36.000
35.156
56.250
NO
+
+
Mode 2
VESA
800 × 600
40.000
37.879
60.317
NO
+
+
Mode 3
VESA
800 × 600
50.000
48.077
72.188
NO
+
+
Mode 4
VGA
640 x 480
25.17
31.47
59.94
NO
−
−
Mode 5
VGA
720 x 400
28.32
31.47
70.08
NO
−
+
Mode 6
VESA
1024 x 768
65.000
48.363
60.004
NO
−
−

7
V. 5 Wires Resistive Touch Panel (For Resistive Touch Model only):
Resistive Touch panel:
Type : 5 Wires Resistive Touch
Touch Control Type : USB
Transmission : 80%
Touch Driver installation:
Please go to the EETI website to get Touch Driver
https://www.eeti.com/drivers.html
1.0 Download driver and run the installation. Screen display as below, please click Next>.

8
2.0 Select the setup type, don’t tick the box if PS2 interface is not required, Click “Next>
.
3.0 RS232 interface driver installed is default, please click Next>

9
4.0 You can select to do Touch screen calibration after system boot up or not.
Default setting is” None”
5.0 Select to use Multi-Monitor system, then press Next>

10
6.0 Choose destination location, default folder location shown as below. Press Next>
7.0 Figure shown below, please press Next> to complete installation.

11
Calibration
1.0 Execute “eGalaxTouch”
2.0 Click “Tools” tab and click “4 Points Calibration”

12
3.0 Four Calibration points will appear on screen sequentially, please to press the center of circle
on screen in 15 seconds one by one.
4.0 After finish 4 points calibration the diagram will appear as follow.

13
5.0 Click “Tools” tab and click “Linearization”.
6.0 Nine Calibration points will appear on screen sequentially, please to press the center of circle
on screen one by one.

14
7.0 After finish all linearization calibration the diagram will appear as follow.
VI. Projected Capacitive Touch Panel (For Projected Capacitive Touch Model only):
Projected Capacitive Touch panel:
Type : Projected Capacitive
Touch Control Type : USB
Transmission : 85%
Touch Control Driver : eGalax Touch driver (Mouse emulation driver)
or supported by driver embedded in OS after windows 7
Touch Driver installation:
Please go to the EETI website to get Touch Driver
https://www.eeti.com/drivers.html
Note:
The driver is a mouse emulation driver, if your Windows version is Windows 7 or later, we
suggest you DO NOT install this driver.

15
VII. Mechanical dimension

16
VIII. EMC Warning:
FCC Class A Warning
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.

17
IX. Product General Specification:
Model P104VG P104VR P104VP
LCD Panel
Size 10.4"
Resolution 800 x 600
Aspect Ratio 4:3
Contrast Ratio (Typ.) 500:1
Brightness (Typ., cd/m² ) 300
MTBF (Min., hrs) 10,000
Front Cover
Type PMMA
5-wires resistive
touch
10-points
projected
Surface Hardness 5H 3H 6H
Transparency 93% 80% 85%
Touch Control Interface - mini USB mini USB
Touch Control IC - EETI EETI
Signal Interface
VGA 1 1 1
Power
Input Voltage 12Vdc
Power Consumption (Typ., W) 9 W
Standby power consumption (W) < 1 W
AC Power Supply (Vac) 100 ~ 240
Feature
Key Control 5 keys (Power / Auto / Up / Down / Menu)
OSD Language 8 countries (English, French, German, Italian, Spanish,
Japanese, Simple Chinese, Traditional Chinese)
Others
VESA Wall Mount (mm) 75 x 75
Physical Dimension (with stand, mm) 249 x 237 x 140
Physical Dimension (w/o stand, mm) 249 x 205 x 29
Net Weight (with stand, Kg) 1.28 Kg
Net Weight (w/o stand, Kg) 0.96 Kg
Operation Temperature ( °C) 0 ~ 40
Operation Humidity ( % ) 20 ~ 80 (non-condensing)
Storage Temperature ( °C) -10 ~ 50
Storage Humidity ( % ) 10 ~ 90
Certification CE, FCC
*Product specification is subject to change without prior notice.
*Made in Taiwan.
