Piazzetta P158 T User manual

EN - The instruction manual is an integral part of the product.
EN
The instruction manual is an integral part of the product
Pellet stoves
P158 T
Please read this entire manual before installation and use of
this pellet fuel-burning room heater.
Failure to follow these instructions could result in property
damage, bodily injury or even death.
Contact local building autorithy (such as municipal
building department, re department, re prevention,
bureau. etc.) before installation to determine if a permit
and/or inspection is required.
Contact local building or re ocials about restrictions and
installation inspection requirements in your area.
Save these Instructions.
PRODUCT INFORMATION,
INSTALLATION AND MAINTENANCE

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02
2
This booklet code DT2005161_H072534EN0_02 - (06/2022) comprises 44 pages.
Dear Customer,
We thank you for having chosen one of our products, the fruit of extensive and continuous research for a superior product in terms of safety,
reliability and performance.
In the documentation supplied, you will find all the information and advice you need to use your product as safely and efficiently as possible.
i Please read the instructions and all information supplied with the product and any accessories, as well as any documenta-
tion referred to in this manual carefully, before proceeding with installation, use or any repairs.
■ If any problems or doubts should arise, please contact your local dealer or the authorized T.A.C. (authorized technical assis-
tance centre).
i This manual contains INFORMATION REGARDING THE PRODUCT, INSTALLATION AND MAINTENANCE.
■ For information regarding operation, please refer to the manual "
OPERATING INSTRUCTIONS ".
For the restrictions, limitations and exclusions please refer to the warranty included with the product. In line with its policy of constant
product improvement and renewal, the manufacturer may make changes without notice.
The images shown in this manual are for explanatory purposes and at times may not accurately depict the product.
This document is the property of Gruppo Piazzetta S.p.A. and no part of it may be reproduced or disclosed to third parties, whol-
ly or in part, without written permission All rights reserved by Gruppo Piazzetta S.p.A..
This booklet code
- Rev.
comprises
pages.
Code

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02 3
CONTENTS
1 GENERAL INFORMATION 4
2 PRODUCT INFORMATION 7
2.1 Product description 7
2.2 Part identification 8
2.3 Safety devices 9
2.4 Check devices 9
2.5 Product identification data 10
2.6 Characteristics 10
2.7 Accessories upon request 10
2.8 Technical data 11
2.9 Sizes 12
3 FUEL 13
3.1 Pellet specifications 13
3.2 Information regarding pellet loading 14
4 GENERAL INFORMATION REGARDING THE SYSTEM 15
4.1 Installation room 15
4.2 Fresh air intake 16
4.3 Chimney 16
4.4 Flue pipe 16
4.5 Interior vent installation 18
4.6 Connecting to a conventional chimney 19
4.7 Installing into an existing fireplace chimney 20
4.8 Short rise installation - wall outlet 21
4.9 Minimum flue vent configuration 21
4.10 Venting: termination requirements 22
4.11 Mobile home installation 23
5 PREPARATIONS FOR INSTALLATION 24
5.1 Handling 24
5.2 Unpacking 24
6 INSTALLATION 24
6.1 Access to the internal parts of the product 24
6.2 Minimum safety distances 25
6.3 Installation kit and accessories 26
6.4 Multifuoco system 26
6.5 Safe ducting clearance 28
6.6 Combustion air connection 28
6.7 Connection to the smoke outlet 29
6.8 Electrical connections 30
7 STARTUP AND OPERATING TEST 31
8 CLADDING AND TRIM 31
9 USE 32
9.1 Humidifier (accessories) 32
10 CLEANING AND MAINTENANCE 32
10.1 Scheduled maintenance 33
10.2 Cleaning the ceramic cladding 33
10.3 Cleaning the painted metal parts 34
10.4 Opening the door 34
Positioning the firedoor opening tool 34
10.5 Cleaning the glass 34
10.6 Disposal of ashes 34
10.7 Cleaning the ash tray 34
10.8 Cleaning the grate and grate support 34
10.9 Cleaning the combustion chamber 35
10.10 Cleaning the smoke chamber 36
10.11 Cleaning the extractor fan 36
10.12 Cleaning the room fan 36
10.13 Cleaning the smoke outlet 37
10.14 Replacing the fuses 37
10.15 Remove the door 38
10.16 Replacing the gaskets 38
10.17 Replacing the glass 39
11 WHEN NOT IN USE 39
12 DISPOSAL OF PRODUCT AT END OF PRODUCT LIFE 39
13 WIRING DIAGRAM 40
14 REFERENCE STANDARDS 41
15 WARRANTY 42

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02
4
1 GENERAL INFORMATION
Definition: The term system indicates the unit consisting of the
appliance and all the necessary installations which affect its op-
eration, including air intakes, the entire system for the evacuation
of the flue gases (connecting flue pipe, flue, chimney terminal)
the area, other sources of heat, installations for the propagation
of heat (hot air ducting or plumbing system).
Definition: The term standards or regulations indicates all appli-
cable national legislation, local regulations, particular or conven-
tional requirements arising from joint ownership building regula-
tions, and easement or laws or administrative acts, in force in the
place where the appliance is to be installed.
- This instruction booklet has been prepared by the manufactur-
er and is an integral part of the product. In the event of sale
or relocation of the product make sure this booklet accompa-
nies it, since the information contained in it is addressed to the
purchaser and to anyone involved in the installation, use and
maintenance of the product.
- Please read the instructions and all information supplied with
the product and any accessories, as well as any documentation
referred to in this manual carefully, before proceeding with in-
stallation, use or any repairs. If any problems or doubts should
arise, please contact your local dealer or the authorized T.A.C.
(authorized technical assistance centre).
- Gruppo Piazzetta S.p.A. cannot be held liable for situations of
risk, defects, damage, product malfunctioning or for damage
to objects, people or animals resulting from tampering of the
appliance and installation, use and maintenance which does
not respect the indications provided by regulations and the
manufacturer.
- Any changes to the original parameters which determine prod-
uct operation may only be carried out by authorised persons
from the company and with the values set by the manufactur-
er. Non-authorised interventions on the product will be consid-
ered tampering.
a All local regulations, including those refer-
ring to national standards need to be com-
plied with when installing the appliance
and when operating the appliance.
■ Product installation, use and maintenance
must be carried out in compliance with
the applicable instructions provided by
the manufacturer and in compliance with
all relevant regulations. Failure to respect
the indications provided and any incorrect
interventions may create dangerous situ-
ations, cause damage to people, property
or animals, or lead to health problems or
operating faults.
a Product installation and maintenance
must be carried out exclusively by quali-
ed personnel with sucient knowledge
of the product itself.
■ Only use original spare parts as recom-
mended by the manufacturer.
■ Spare/Replacementpartsaretobeordered
through our dealers or distributors. For
more information visit www.piazzetta.com
under "Support".
a In the event of a malfunction or fault, be-
fore carrying out any intervention and
before discontinuing product use, please
refer to the manual provided by the manu-
facturer in the sections " FAULTS " or " MES
SAGES  SAFETY WARNINGS  ANOMA
LIES ".
a In the event of re in the ue, stop using
the appliance, do not open the door of the
appliance, observe all safety recommen-
dations and contact the appropriate au-
thorities.
■ For appliances which are powered electri-
cally, do not disconnect the power supply
if unburned smoke/gas forms inside the
rebox. Move away and adopt all neces-
sary safety precautions.
a Smoke coming from a blocked ue is dan-
gerous. Keep the ue and connecting ue
pipe clean. Follow the manufacturer's
cleaning instructions.
■ Keep the exchangers and smoke passages
on the boiler clean. Follow the manufac-
turer's cleaning instructions.
■ Only use the recommended fuel.
■ Please read and comply with the instruc-
tions for installation, use and mainte-
nance.

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02 5
a Product use may cause some surfaces to
become extremely hot (the glass, the ex-
ternal surfaces, the handles, the smoke
outlet passage). Any contact between
clothing or body parts and these surfac-
es, including where accidental, may cause
burns or res.
■ Before performing work on parts of the
appliance that may be hot (e.g. top surface
panel, grilles, covers, door, settings devic-
es and control devices), take the necessary
precautions and use suitable protective
devices (glove, redoor opening tool or
other specic devices).
■ Since the glass becomes hot, make sure
that no person other than those experi-
enced in operating the appliance remain
in the area from where the heat emanates.
a Everyone (both children and adults)
should be informed of the risk of coming
into contact with hot surfaces.
■ Babies, young children, animals or anyone
else may experience burns as a result of
accidental contact. If there are any at-risk
subjects in the home, a protective barrier
should be installed. To limit access to the
appliance, install a safety gate to keep ba-
bies, young children and other at-risk sub-
jects out of the room and away from the
hot surfaces.
a This appliance is not for use by persons
(including children) with reduced physi-
cal, sensory, mental capacity or with a lack
of experience and knowledge, unless they
are helped or have been instructed on how
to use the appliance by the person who is
responsible for their safety.
■ Children shall not play with the appliance.
Cleaning and user maintenance shall not
be made by children.
■ Young children should be carefully super-
vised when they are in the same room as
the stove.
a If you expect that small children or vulner-
able adults may come into contact with
this appliance, the following precautions
are recommended:
■ Install a physical barrier such as a decora-
tive rescreen or an adjustable safety gate.
■ Install a switchlock or a wall/remote con-
trol withchild protection lockout feature.
■ Keep remote controls out of reach of chil-
dren.
■ Never leave children alone near a hot
stove, whether operating or cooling down.
■ Teach children to NEVER touch the stove.
■ Consider not using the stove when chil-
dren will be present.
a During the operation and/or cooling
phase, slight creaking noises may be
heard. This is not considered a defect, but
is a consequence of the thermal expansion
of the materials used.
d Do not install the product too close to
neighbors or in valleys that would cause
unhealthy air quality or nuisance condi-
tions.
d It is forbidden any unauthorized modica-
tion of the appliance.
d Do not stand or place objects which are
not heat-resistant within the prescribed
minimum safety distance.
■ This also applies when the appliance is
o. The appliance may be turned on by
somebody else or, where the appliance
is pre-congured, may be automatically
switched on (programmed or via remote
control), at any time.
■ Do not place food, drinks or other contain-
ers with liquids on parts of the appliance
or the surround, except for compartments
specically designated by the manufac-
turer for cooking or warming up food.

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02
6
d Do not install the product near walls or
objects in heat-sensitive or combustible
combustible material (wood or similar).
It is important to observe and respect
the distances and safety indications pre-
scribed by regulations and indicated in
the manual provided by the manufacturer
in the section "
INSTALLATION ".
■ IT IS FORBIDDEN TO USE THE APPLIANCE
WITHOUT SUITABLE CLADDING.
d THIS WOOD HEATER NEEDS PERIODIC IN-
SPECTION AND REPAIR FOR PROPER OP-
ERATION. IT IS AGAINST FEDERAL REGULA-
TIONS TO OPERATE THIS WOOD HEATER IN
A MANNER INCONSISTENT WITH OPERAT-
ING INSTRUCTIONS IN THIS MANUAL.
d THIS WOOD HEATER HAS A MANUFACTUR-
ER-SET MINIMUM LOW BURN RATE THAT
MUST NOT BE ALTERED. IT IS AGAINST
FEDERAL REGULATIONS TO ALTER THIS
SETTING OR OTHERWISE OPERATE THIS
WOOD HEATER IN A MANNER INCONSIST-
ENT WITH OPERATING INSTRUCTIONS IN
THIS MANUAL.
d Never use gasoline, gasoline-type lantern
fuel, kerosene, charcoal lighter uid, ethyl
alcohol or similar liquids to start or "reig-
nite" a re in this heater. Keep all such liq-
uids well away from the heater while it is
in use.
■ Only power the appliance with fuel which
has the characteristics as indicated in the
section "
FUEL " in the manual provided by
the manufacturer.
d Do not overre - If any external part starts
to glow, you are overring. Reduce feed
rate. Overring will void your warranty.
a Warning against overring:
■ pellets must not be fed manually into the
grate
■ never add additional fuel by hand
■ do not ll the hopper with any fuels other
than wood pellet
■ the residual pellets in the grate after a
failed ignition must be removed before
starting a new ignition process
d Do not use the appliance as an incinerator
or in any way other than that for which it
was designed.
■ Do not use the appliance if the glass or
seals on the door are damaged.
■ Do not open the door during operation.
a For monitoring and inspection techniques
ensuring heater is operating properly, in-
cluding ensuring visible emissions are
minimized, consult the section "
CLEAN
ING AND MAINTENANCE " and " OPER
ATING INSTRUCTIONS " (consult the sec-
tion " MESSAGES  SAFETY WARNINGS
 ANOMALIES
").

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02 7
Before carrying out any assembly, installation or ignition proce-
dures, the enabled installer must check that the system has been
manufactured in compliance with the applicable instructions
provided by the manufacturer and in compliance with all relevant
regulations. In particular, check:
- suitability of the room where the appliance is to be installed as
well as any restrictions
- the existence of any other appliances
- fresh air intake
- ventilation within the area where the appliance is to be installed
- sufficient clean air flow for combustion: air cannot be taken
from potentially polluted areas
- smoke evacuation system comprising a connecting flue pipe,
flue and chimney.
Installation may also include a series of operations to be carried
out correctly by enabled personnel and for which system com-
patibility must be guaranteed:
- connection to the air intake
- connection to the smoke evacuation system
- ventilation
- assembly and installation
- any necessary electrical or plumbing connections
- insulation
- start-up and operating tests, and where necessary calibration
and adjustment
- cladding and trims
- presentation of additional documentation as prescribed by the
regulations
- end user training by the installer on how to use and maintain
the appliance
- checking and maintenance.
Other requirements for compliance may be necessary in relation
to specifications required by the appropriate Authorities.
a DO NOT USE MAKESHIFT COMPROMISES
WHEN INSTALLING THIS APPLIANCE. DAM-
AGE AND/OR INJURY MAY RESULT.
2 PRODUCT INFORMATION
2.1 PRODUCT DESCRIPTION
This appliance is:
- a heat generator designed to be run with pellets
- to be used solely for the purpose for which it was designed; all
other uses are to be considered improper and therefore dan-
gerous
- equipped with a flue evacuation fan which maintains the com-
bustion chamber in negative pressure.
The use of a fuel which can be easily transported and stored such
as pellets, facilitates the ease of use of this appliance.
Heat diffusion is also ensured by the Multifuoco System forced
ventilation system offering different personalised functions and
the option of ducting.
The control unit allows the user to manage a range of functions
and programmes, while the basic controls can also be managed
using the control panel on the appliance itself.
The pellets are loaded into the hopper manually and the ignition
is electronic.
An electronic control unit controls the pellet dosing into the grate
as well as the flue gas expulsion.
The unit controls the appliance to make sure it operates correctly.
Thanks to a series of safety devices, it signals any faults and, if nec-
essary, initiates the appropriate procedures.

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02
8
2.2 PART IDENTIFICATION
1
3
4
5
8
9
7
6
15
14
13
2
16
11
12
23
22
26
21
20
19
18
17
24
25
10
1 Pellet hopper cover
2 Pellet hopper grille
3 Door
4 Ceramic glass
5 Door handle
6 Ash drawer
7 Smoke chamber
8 Smoke intake/Extractor fan
9 Adjustable feet
10 Electronic control unit
11 Environment fan/s
12 Pressure switch
13 Grate
14 Grate deflector
15 Pellet delivery hole
16 Combustion chamber
17 Firedoor opening tool
18 Combustion air duct
19 Safety thermostat
20 Electrical power cable
21 Smoke outlet
22 Auger motor
23 Pellet indicator
24 Pellet hopper
25 Metal structure
26 Appliance control panel
Fig. 1

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02 9
2.3 SAFETY DEVICES
The appliance is equipped with the following safety and check
devices which stop the stove from operating if any faults occur
against over-firing and ensuring heaters is operating properly, in-
cluding ensuring visible emissions are minimized.
If any safety warnings or alarms are activated, please consult the
“ OPERATING INSTRUCTIONS ”.
Pressure switch:
controls the vacuum inside the appliance. The pressure switch is
activated if the correct operating conditions are altered (inappro-
priate use or installation, obstacles or blockages in the flue, lack
of maintenance, adverse weather conditions such as persistent
wind etc.). The pressure switch activates and isolates the supply
voltage to the auger, thus stopping pellet feed to the grate and
then initiates the appliance shut down process.
Fuel hopper thermal cut-out:
this is a thermal device with automatic rearming that serves to
safeguard the pellet hopper against excessive temperatures.
If the temperature of the hopper exceeds the safety threshold, the
device isolates the supply voltage to the auger, pellet feed to the
grate is stopped and the appliance shut-down procedure begins.
Smoke temperature probe:
this is connected to the electronic control unit and constant-
ly monitors the operating temperature. If during this phase the
smoke temperature:
a) exceeds the safety threshold, the electronic control unit isolates
the supply voltage to the auger, thus stopping pellet feed to the
grate and starting the appliance shut down process
b) falls below the minimum operating temperature, the appliance
stops and an acoustic alarm signal is activated.
Furthermore, if during the start-up phase a system malfunction is
detected, an acoustic alarm signal is activated.
Auger safety:
the operation of the auger is constantly monitored by the elec-
tronic control unit. In the event of a malfunction, an acoustic
safety signal is activated. The electronic control unit isolates the
supply voltage to the auger, thus stopping pellet feed to the grate
and starting the appliance shut down process.
Extractor fan safety:
the rotation of the extractor fan is constantly monitored by the
electronic control unit. In the event of a fan malfunction, an
acoustic alarm signal is activated. The electronic control unit iso-
lates the supply voltage to the auger, thus stopping pellet feed to
the grate and starting the appliance shut down process.
Electrical safety:
the appliance is protected by fuses in the event of a power surge.
Electronic control unit:
the electronic control unit signals and controls a series of events
including power and ignition failure.
d The safety devices are there to eliminate the risk of
damage or injury to persons, animals or objects. IT IS
FORBIDDEN to tamper with the safety devices or allow
any intervention to be carried out by non-qualied per-
sonnel.
2.4 CHECK DEVICES
The appliance is equipped with some check devices which are to
be used exclusively by personnel authorised to carry out fine tun-
ing operations during installation and maintenance procedures.
Pressure plug (A) : for measuring the pressure drop inside the
appliance.
DB9 serial port (B) : to carry out checks on the correct operation
of the product and any necessary maintenance operations. A re-
mote appliance-management system (GPRS or Wi-Fi) can be con-
nected to the DB9 serial port.
A
B
Fig. 2

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02
10
2.5 PRODUCT IDENTIFICATION DATA
Each product is identified in the following way:
- IDENTIFICATION DATA PLATE (1) with the model (A) and ap-
pliance performance specifications
- SERIAL NUMBER PLATE (2) with the serial number of the ap-
pliance (B)
- LABEL WITH IMPORTANT ADDITIONAL INFORMATION (3)
with important information.
The identification plates are positioned as shown below.
i When asking for technical support and/or spare parts,
always provide these data to the dealer or T.A.C. (au-
thorised technical assistance centre).
A
B MATR. ...
1
2
Fig. 3
1
Fig. 4
2
3
Fig. 5
2.6 CHARACTERISTICS
Structure:
- in steel
Cladding:
- in painted steel
Top surface:
- majolica
- in cast iron
Firebox:
- in cast iron
Grate:
- in cast iron
Ash collection:
- extractable ash drawer
Door:
- in cast iron
- 0.197" (5 mm) ceramic glass resistant to 750°C (1382 °F)
Door handle:
- in painted steel
- nickel plated finish
Power adjustment:
- 4 positions
Heating:
- forced ventilation with Multifuoco System
- 1 fan
- 3 speed settings
- maximum permitted length approximately 26.24' (8 m)
- outlet diameter 3'' (Ø 75 mm)
Function control:
- appliance control panel
Provided as standard:
- power cable (length 6' / 1.8 m)
- room temperature probe
- grate deflector
- hex wrench
- firedoor opening tool (separable handle)
2.7 ACCESSORIES UPON REQUEST
To consult the full list of accessories supplied upon request and
to check the compatibility of internal components, cladding and
accessories, consult your dealer.
- Remote control kit
- Smoke outlet kit
- Accessories for hot air ducting
- Humidifier (in stainless steel)
- Accessories for cleaning and maintenance

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02 11
2.8 TECHNICAL DATA
Model P158 T
Description Unit of meas-
urement High burn rate Medium burn
rate Low burn rate Overall burn
rate
Power Setting P4 P2 P1
Fuel natural pure wood pellets
Heat Input
Btu/hr 38600 18954 15015 20259
KJ/hr 40691 19980 15828 21356
kW 11.3 5.5 4.4 5.9
Heat Output
Btu/hr 31491 15527 12482 16785
KJ/hr 33197 16368 13158 17694
kW 9.2 4.5 3.7 4.9
Burn Rate (wet) lb/hr 4.89 2.40 1.90 2.54
kg/hr 2.22 1.09 0.86 1.15
Burn Rate (dry) lb/hr 4.73 2.32 1.84 2.48
kg/hr 2.15 1.05 0.83 1.13
Heating Efficiency (HHV basis) % 81.6 81.9 83.1 82.9
Heating Efficiency (LHV basis) % 88.0 88.4 89.7 89.4
CONTENT OF SMOKE EMISSIONS
Overall Particulate Emission Rate g/hr 0.793
CO emissions g/min 0.231 0.098 0.032 0.077
ELECTRICAL DATA
Current during ignition phase (peak) A 3.5
Electrical power input during ignition phase (peak) W 380
Current in operation (peak) A 1.9 1.8 1.7 -
Current in operation (average value) A 1.8 1.5 1.4 -
Electrical power input (peak) W 115 101 89 -
Electrical power input (average value) W 104 82 70 -
Rated Voltage V 115/120
Rated Frequency Hz 60
DIMENSIONAL DATA
Approximate hopper capacity lb (kg) 39.7 (18)
gal (l) 6.60 (25)
Diameter of the flue gas outlet in (mm) 2.95 (75)
Weight of appliance with cladding lb (kg) 220 (100)
FRESH AIR DATA
Fresh air intake size (internal diameter) in 1.97
mm 50
CERTIFICATION DATA
Evaluation center (Laboratory) N° Intertek Testing Services NA Inc.
Test report N° 104207696MID-002R1
UT0014 COD_ETICH IND_ETICH IND_ETICH IND_ETICH
DATA_REV REV_ETICH REV_ETICH REV_ETICH
U.S. ENVIRONMENTAL PROTECTION AGENCY Certified to comply with 2020 particulate emission standards using pellet fuel.
Laboratory data, in accordance with the product technical regulations.
The above data vary in relation to the size and type of fuel used (refer to the section " FUEL ”), chimney vacuum and system characteristics.
Data regarding the electric absorption vary depending on the network voltage and any KITS or ACCESSORIES which have been installed.
Refer to the instructions attached to the Kits or accessories.

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02
12
2.9 SIZES
values in inch (mm)
P158 T Fig. 6
20.67"
525 mm
42.83"
1088 mm
21.18"
538 mm
A
7.59"
193 mm
C
A*
7.68"
195 mm
17.91"
455 mm
3.76"
95 mm 3.94"
100 mm
1.69"
43 mm
B
3.74"
95 mm 1.84"
47 mm
ABC
2.95"
(75mm)
2.95"
(75mm)
1.97"
(50mm)
A Smoke outlet
B Ducting outlet
C Combustion air duct
* standard position

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02 13
3 FUEL
d Never use gasoline, gasoline-type lantern fuel, kero-
sene, charcoal lighter uid, ethyl alcohol or similar liq-
uids to start or "reignite" a re in this heater. Keep all
such liquids well away from the heater while it is in use.
Prohibited Fuel Types:
- Residential or commercial garbage
- Lawn clippings or yard waste
- Materials containing rubber, including tires
- Materials containing plastic
- Waste petroleum products, paints or paint thinners, or asphalt
products
- Materials containing asbestos
- Construction or demolition debris
- Paper products, cardboard, plywood, or particleboard
- Railroad ties, pressure-treated wood or pallets
- Manure or animal remains
- Salt water driftwood or other previously salt water saturated
materials
- Unseasoned wood (defined as wood with an average moisture
content of 20% or more)
- Any materials that are not included in the warranty and owner’s
manual for the subject wood heater
- Any materials that were not included in the certification tests
for the subject wood heater
Burning these materials may result in release of toxic fumes or
render the heater ineffective and cause smoke.
3.1 PELLET SPECIFICATIONS
d Under no circumstances use fuel other than pellets.
d DO NOT use pellets with dimensions other than those
recommended by the manufacturer.
Owner and operators of wood heaters certified to burn pel-
let fuels must only burn pellets that have been specified in the
owner’s manual and graded under a licensing agreement with a
third-party organization approved by the EPA . The Pellet Fuels In-
stitute, ENplus and CANplus are initially deemed to be approved
third-party organizations for this purpose. Additional organiza-
tions may apply to the Administrator for approval.
There are various types of pellet on the market with qualities and
characteristics that vary depending on the processes they have
undergone and the type of wood used in their production. Pel-
let fuel quality can fluctuate from manufacturer to manufacturer,
and even from bag to bag.
Since the characteristics and quality of the pellet considerably
affect product performance, efficiency and proper operation, we
recommend that you use "premium grade" pellets.
In order to guarantee efficient product operation, Gruppo Pi-
azzetta S.p.A. has tested and programmed its own products with
pellets with the characteristics as shown in the table.
Minimum fuel specifications
Original raw material Natural pure wood pellet
Length 1/4" - 1 1/4" (6 - 32 mm)
Diameter 0.23" - 0.285" (6 - 7 mm)
Net calorific value ≥ 7500 Btu/lb (4.8 kWh/kg)
Density ≥ 38 lb/ft3(609 kg/m3)
Moisture < 8 %
Inorganic fines ≤ 1 %
Chlorides ≤ 300 ppm by weight
Ash content ≤ 1 %
Contains no demolition or construction waste
Trace metals ≤ 100 mg/kg
Using good quality pellets but with dimensions and heat-produc-
ing properties different from those above may require the appli-
ance operating parameters to be changed.
a This "customisation" of appliance operating settings
must only be carried out by a T.A.C. (technical assis-
tance centre) or by specially qualied personnel au-
thorised by Gruppo Piazzetta S.p.A..
■ Using pellets that are out of date or not in conformity
with the manufacturer's recommendations not only
damages the stove and jeopardises its performance,
but can render the guarantee null and void and relieves
the manufacturer of all liability.
d DO NOT use pellets containing sawdust, bark, maize,
resins or chemical substances, additives or adhesives.
■ DO NOT use damp pellets.
The technical characteristics can be determined only using the
relevant tools, but a visual check at the time of purchase can serve
to identify:
- good quality: shiny, smooth, regular length, minimal dust
- poor quality: horizontal and diagonal splits, irregular length,
abundant dust
Choosing other unsuitable pellets may:
- obstruct the grate and flue gas pipe
- increase fuel consumption yet reduce performance
- mean that proper stove operation cannot be guaranteed
- cause dirt to build up on the glass
- leave particles which have failed to burn and heavy cinders.
The presence of moisture in the pellets increases their vol-
ume and causes them to split which in turn causes:
- malfunction of the fuel-loading system
- inefficient combustion.
Performance
Higher ash content requires more frequent maintenance.“Premi-
um” grade pellets will produce the highest heat output.

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02
14
Pellets must be stowed in a dry, sheltered place that complies
with the relevant safety clearances from the appliance and
from heat sources which could cause combustion.
Wood pellets should be left in their original sealed bag until ready
to use, to prevent moisture. Do not store fuel within the specified
clearance areas, or in a location that will interfere with routine
cleaning and maintenance procedures.
Ash
The ash content of the fuel and operation of your stove will direct-
ly determine the frequency of cleaning.
The use of high ash fuels may result in the stove needing to be
cleaned daily. Pellets made from hardwoods generally produce
more ash than those made from softwoods.
Clinkers
Minerals and other non-combustible materials, like sand, will turn
into a hard glass-like substance when heated.
Trees from different areas will vary in mineral content. For this rea-
son, some fuels will produce more clinkers than others.
3.2 INFORMATION REGARDING PELLET
LOADING
In order to load pellets into the hopper, we recommend removing
the bag flap opening and emptying it into the hopper. This way,
the loading operation is easier and you avoid spilling the pellets
over the appliance.
d Do not allow the build-up of residue at the bottom of
the hopper.
■ Do not empty any residue from the pellet bag into the
hopper.
■ During loading operations, make sure that no pellets
fall out of the hopper as they could come into contact
with hot surfaces and ignite.
■ Do not leave leftover pellets on top of the stove: they
could catch re.
■ Do not ll the pellet hopper in excess of normal capaci-
ty and do not compress the fuel.
■ Don't remove the protective grill inside the pellet hop-
per.
a Some appliances are equipped with a protection grille
inside the hopper. Removing this grille is forbidden.
■ Only keep the cover of the pellet hopper open for as
long as it takes to complete the rell operation. To en-
sure optimal operation, some models activate an error
signal in the event the hopper cover is left open for a
time exceeding the set time.
3.2.1 Pellet indicator
When the red reload indicator can be seen inside the hopper, it is
possible that the auger is not perfectly loaded which would cause
irregular pellet unloading in the grate and start-up failure.
Fig. 7
a DO NOT LOAD PELLETS WHEN APPLIANCE IS ON if the
red rell indicator is visible inside the pellet tank.
Follow the instructions below if the red refill indicator is visible:
- switch off the appliance
- with the appliance off, reload the hopper
If the auger is even partially emptied, it is probable that the first
start-up attempt may fail.
In this case, refer to the manual " OPERATING INSTRUCTIONS " in
the sections " FILL AUGER " and " MESSAGES  SAFETY WARNINGS
 ANOMALIES ".
If an alarm is triggered, deactivate the appliance by pressing the
ON/OFF key for a few moments, remove the fuel to be found in
the grate and set a new ignition cycle.
Any unburned pellets to be found in the grate must be disposed
of.

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02 15
4 GENERAL INFORMATION REGARDING
THE SYSTEM
Below is some general information regarding the system, appli-
ance installation and products manufactured by Gruppo Piazzet-
ta S.p.A.
i Please refer to the installation standards or other in-
formative documentation provided by the manufac-
turer for further information.
4.1 INSTALLATION ROOM
The appliance is to be installed in a room which allows installa-
tion, user and maintenance operations to be performed safely
and easily.
Contact local building authority before installation to determine
if a permit and/or inspection is required.
When locating your appliance, consider the building structure to
ensure the vent will not interfere with any ceiling joists, roof raft-
ers, wall studs, water pipes or electrical wiring. It may be easier to
relocate the appliance than to rework the building structure.
The layout of your house and the location of the pellet stove will
determine how effective it is at heating the intended area (e.g., in
main living area versus basement versus outdoors in sub-freezing
temperatures).
Pellet stoves use mainly air circulation to disperse their heat,
therefore a central location works best.
Consider the following things when selecting a location:
- use of an existing chimney
- location of vent termination
- aesthetic considerations
- interference with house framing, plumbing and wiring
- floor protection
- room traffic patterns
- proximity to combustibles
- location of air for combustion
- electrical outlet
- pellet fuel storage.
d The room where the appliance is to be installed must
comply with the following requirements:
■ It must not be used as a garage, store for combustible
material or for activities with a risk of re.
■ Locating the stove in a room with an explosive atmos-
phere is prohibited.
■ must not be smaller than stated in the regulations and
calculated by a specialist heating technician
■ must not be a bedroom, studio at, bathroom, shower
room or similar
■ it must not have a low pressure compared to the exte-
rior due to a counter draught caused by the presence
of another appliance or extractor device in the room
where the appliance is installed (eg. forced ventilation
systems or other heating systems using ventilation to
change the air).
a Appropriate ventilation in the installation room must
be ensured (refer to the section " FRESH AIR INTAKE ").
■ The installation room and the area which is to be heat-
ed must be suitable sized and have appropriate charac-
teristics in relation to the heating capacity of the appli-
ance. Compare the information provided in the section
" TECHNICAL DATA " with the power required by the
area which is to be heated.
■ If the room or the product installation area (technical
room, perimeter walls, recess, supporting walls, etc.)
are not suitably insulated, the heating capacity of the
appliance will be reduced.
■ Consult a heating technician or engineer for a correct
check and calculation of the requirement of the envi-
ronments to be heated and the corresponding regula-
tions.
■ The appliance cannot be installed or operated out-
doors, only indoors or in suitable technical rooms. In-
stalling the appliance outdoors could create dangerous
situations, cause health problems or lead to operating
faults.
a The existence of more than one appliance is only per-
mitted if allowed by the regulations and manufacturer
of each individual appliance.
■ If the existence of more than one appliance is permit-
ted, all regulations and provisions supplied by the
manufacturer of each individual appliance are to be
respected.
a Make sure that the oor of the installation room is able
to withstand the weight of the product including any
cladding, accessories and trim. If the oor does not
have a suitable load-bearing capacity, take adequate
counter-measures.
■ If the ooring is made of wood, provide a oor protec-
tion surface in compliance with current national stand-
ards.
a Have a smoke monitor/CO detector, especially in areas
that are expected to generate CO (e.g., heater fueling
areas, pellet fuel bulk storage areas).
■ Follow the smoke detector manufacturer’s placement
and installation instructions and maintain regularly.

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02
16
4.2 FRESH AIR INTAKE
In order to operate normally, each appliance must be provided
with the air needed for combustion.
If a number of appliances are to co-exist, sufficient airflow must
be guaranteed for each individual product in full compliance with
regulations and according to the manufacturer's indications.
For a question of health, in addition to providing the air flow
needed for combustion, it is also recommended that the air inside
the installation room is suitably changed.
The airflow needed for the firebox can be obtained in different
ways, for example:
- from the installation room or adjacent rooms
- by means of a fresh air intake directly into the room and with
ducting
- with a direct connection to the combustion chamber.
In brief, the fresh air intake:
- must guarantee sufficient clean air flow for combustion: air can-
not be taken from potentially polluted areas
- must have a total free cross section of at least the value indicat-
ed in the section " TECHNICAL DATA " and in any case, equal to
or greater than the section of the air intake on the appliance
- be protected by a grille or suitable protection which does not
reduce the recommended minimum section
- be positioned in such a way that it is not obstructed and main-
tenance and inspection operations are possible
- must NOT be fitted with manual closing devices that reduce the
minimum free cross-section.
Indications for airtight installations and installations with
combustion air intake directly from the outside (according to
reference standards)
Airtight installations must be carried out by connecting the com-
bustion air inlet of the appliance directly to the fresh air intake
using a connecting pipe.
The connecting pipe for the combustion air inlet of the appliance
must comply with the following requirements:
- have a diameter equal to or greater than the diameter of the
inlet on the appliance
- be of a suitable type and made from a non-combustible ma-
terial
- the pipes, the connectors used and the installation methods
must guarantee an airtight seal
- if they are connected directly to the outside, the inlet must
prevent atmospheric conditions from negatively affecting the
combustion, for example, by means of the installation of a 90°
bend at the inlet facing downwards or a shatter-proof guard.
For the product to operate correctly, the ducting must have the
characteristics specified in the section " COMBUSTION AIR CON
NECTION ".
4.3 CHIMNEY
Every appliance shall be connected to a chimney in order to dis-
charge the combustion gases outside via natural draught.
Location of the appliance and chimney will affect performance.
- Install through the warm airspace enclosed by the building
envelope. This helps to produce more draft, especially during
lighting and die-down of the fire.
- Penetrate the highest part of the roof. This minimizes the ef-
fects of wind loading.
- Locate termination cap away from trees, adjacent structures,
uneven roof lines and other obstructions.
- Minimize the use of chimney offsets.
It is recommended that the chimney has a chamber for collect-
ing solid matter and any condensate below the connection and
which may be easily opened and inspected by means of an air
tight door
DT2030321-3
1
2
3
4
5
6
7
8
9
10
11
Fig. 8
1 Chimney terminal
2 Flue
3 Connection to the flue
4 Flue pipe
5 Soot inspection
6 Fresh air intake
7 Electrical supply
8 Check the load bearing capacity of the floor
9 Minimum safety distances
10 Installation environment
11 Appliance (Heat generator)
4.4 FLUE PIPE
a The stove requires a UL or ULC listed pellet vent: a vent-
ing system composed of listed, factory-built compo-
nents assembled in accordance with the manufactur-
er's instructions and determined suitable for use with
solid fuel pellet-burning appliances.
d Do not use to vent pellet appliance these venting mate-
rials and products:
−Dryer vent
−Gas appliance vent
−PVC (plastic) pipe.

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02 17
a The pellet stove is not the same as other stoves. It has
a forced draught of ue gas by a fan, which keeps the
rebox in a vacuum and the entire ueway slightly
pressurized. For this reason the ue must be complete-
ly airtight and correctly installed to ensure both trou-
ble-free operation and user safety.
a The ueway must be made by specialised personnel or
rms.
■ All pellet vent pipe must be secured together either by
means provided by pipe manufacturer or by 3 screws
at each joint.
■ If vented horizontally, joints shall be made gastight in
a manner that shall be specied by the manufacturer.
■ Use silicone to create an eective vapor barrier at the
location where the chimney or outside air ducting
passes through to the exterior of the structure.
■ Using the relative pipe clips, x the ue to the wall so
that it does not weigh on the smoke fan.
d DO NOT INSTALL A FLUE DAMPER IN THE EXHAUST
VENTING SYSTEM OF THIS UNIT.
■ DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE
SERVING ANOTHER APPLIANCE.
■ Do not connect to a ueway into which extractor hoods
discharge vapours.
a The very hot exhaust gases may cause skin burns: keep
a considerable distance away from the appliance.
■ The exhaust gases from the combustion of pellets fuel
may dirty the outside of the walls. To avoid such possi-
bility terminate the vent above the roof line.
a INSTALL EXHAUST VENT AT CLEARANCES SPECIFIED BY
THE MANUFACTURER.
■ Follow these instructions along with all local codes re-
garding installation of this appliance.
■ Do NOT use makeshift compromises when installing
this appliance, serious consequences may result.
a THE CHIMNEY AND CONNECTOR MUST BE MAINTAINED
IN GOOD CONDITION AND KEPT CLEAN.
Pipes and maximum lengths which may be used
The exhaust pipe on all stoves is 2.95” O.D. so the stove was de-
signed to accommodate a 3” stove pipe adaptor but the diame-
ters of the pipes depends on the type of installation. Your installa-
tion may require the use of 4” vent as shown in the table.
TYPE OF INSTALLATION
WITH 3”
DIAMETER
PIPE
WITH 4"
DIAMETER
PIPE
For installations at altitudes
over 4000' (1200 m) -Required
Maximum number of elbows
or "TEE" connectors 3 4
Maximum length of horizon-
tal sections 10’ (3 m) 12' (3.6 m)
Maximum length of vertical
sections ≤ 15' (4.6 m) > 15' (4.6 m)
Where 4” (10 cm) diameter pipe must be used, connect it to the
stove flue outlet with a "TEE" connector.
Pellet stoves depend on a combustion fan to pull air through the
unit for combustion.The venting system restricts the ability of the
combustion fan to move the required amount of air through the
unit. A system with too much resistance will result in incomplete
combustion, more frequent required cleaning and poor unit per-
formance. It is always best to choose a location for the appliance
that will result in a venting system with the shortest vent length.
i Combustion optimization. If necessary, this appliance
allows a T.A.C. (technical assistance centre) or a quali-
ed personnel authorised by Gruppo Piazzetta S.p.A.
to optimize the combustion for dierent altitudes, ue
congurations and pipe dimensions by setting the fac-
tory recommended water column / Pascal dierential
rebox pressure with the use of a pressure gauge.
DT2033009-1
TEE W/TEE CAP
PELLET
STOVE
Fig. 9
“TEE” connector
The use of this type of fitting must allow for the collection of con-
densate mixed with soot, which builds up inside the pipe.
It must also permit periodic cleaning of the flue without the need
to disassemble the pipes.
Single or double clean-out tees may be used.
An example is given below of a flueway connection, which allows
complete cleaning without having to disassemble the pipes.

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02
18
DT2033008-2
INSULATING
MATERIAL
DIRECTION
OF CLEANING
DIRECTION
OF CLEANING
DIRECTION
OF CLEANING
TEE
PELLET
STOVE
SEE VENT MANUFACTURER'S
INSTRUCTIONS
TEE
TEE
0 ÷ 12 '
Fig. 10
Horizontal installations that terminate without any vertical sec-
tions of pipe are approved; however, it is recommended that the
vent system be installed with a minimum of 5’ (1.5 m) of vertical
rise above the exhaust port on the back of the stove.
Having a vertical section in the venting will help prevent smoke
from exiting the appliance during power failures.
FAILURETO PROVIDETHE NATURAL DRAFTTHAT RESULTS FROM A
VERTICAL RISE MAY RESULT IN SMOKE BEING RELEASED INTO THE
HOUSE WHEN ELECTRICITY TO THE UNIT IS INTERRUPTED WHILE
BURNING OR SMOLDERING FUEL REMAINS IN THE BURN GRATE.
It is not recommended to run vertical venting outside the heat-
ed environment where the stove is installed. Running a venting
system in a cold environment may cause the flue temperatures to
cool down too much for adequate drafting.
a Gruppo Piazzetta S.p.A. assumes no responsibility for,
nor does the warranty cover, smoke damage caused by
reverse drafting of pellet stoves under power failure
conditions or as a result of extreme negative pressure
in the home.
4.5 INTERIOR VENT INSTALLATION
This kind of installation provides the natural draft that results
from a vertical rise avoiding smoke being released into the house
when electricity to the unit is interrupted while burning or smold-
ering pellets remains in the burn grate.
General vent layout is shown in figure and the procedure is as fol-
lows:
- use a plumb line to determine location of PL Vent penetration
of ceiling
- cut hole in ceiling and frame to appropriate opening size. Fram-
ing material shall be the same as that of adjacent joist material
- install a black ceiling support from under the level of the beam
and fix using 4 twisted nails or screws, 1.5”(38 mm). Alternative-
ly, use a support attachment instead of a black ceiling support.
The attachment is suitable for openings in the ceiling from be-
low and is fixed to the beams with 4 twisted nails or screws, 1.5”
(38 mm)
- insert first vent section through support and tighten the clamp
screw. Additionally fasten the vent with four screw (max 1/2”
(13 mm) long) through the support collar and into the vent skin
- install the vent section(s) atop the first. Twist lock sections to-
gether with a clock-wise turn. Before twisting, push vent sec-
tions firmly together for proper lock barb engagement. Enough
twisting force must be applied to ensure that the collars will
compress gasket material
- firestops are required where the vent penetrates a floor or ceil-
ing. Cut a hole of the appropriate size in the ceiling/floor and
install the firestop from above or below the joist. Fasten the
firestop with nails through the corners
- continue the vent up through the roof line
- extend the vent up to the roof pitch
- slide the Flashing over the Vent until it sits on the roof line. Slip
the upper side of the Flashing base under the roof shingles. Nail
the flashing to the roof with a minimum of 8 roofing nails. Seals
the Flashing base with appropriate roofing mastic
- slide the Storm Collar down the Vent until it sits on the flashing.
Apply a bead of silicone around the top of the Storm Collar
DT2033034-1
FIRESTOP
ENCLOSURE
BLACK CEILING
SUPPORT
VENT
TEE
FRESH
AIR
INTAKE
RAIN CAP
STORM COLLAR
FLASHING
SEE VENT
MANUFACTURER'S
INSTRUCTIONS
SEE VENT
MANUFACTURER'S
INSTRUCTIONS
Fig. 11

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02 19
- extend the PL Vent at least 12”(305 mm) above the roof line and
terminate with a PL listed Rain Cap. If the Vent extends more
than 6’ (1.8 m) above the roof penetration, Roof Brace Poles
and a Roof Brace Band must be used to provide lateral support.
In geographical regions experiencing sustained low ambient
temperature is recommended to enclose exterior vents below
the roof line. This help reduce condensation, soot accumula-
tion, and poor drafting
- set the Rain Cap onto the top Vent section and twist lock it to
the top Vent section
- where the vent system penetrates the air/vapor barrier, the bar-
rier must be sealed to the ceiling support or firestop.
DT2033035-1
SUPPORT
RAIN CAP
STORM COLLAR
FLASHING
VENT SECTION
VENT
TEE
FRESH
AIR
INTAKE
12" MIN
TO ROOF
SEE VENT
MANUFACTURER'S
INSTRUCTIONS
Fig. 12
a Be sure to use approved pellet vent pipe and ceiling
pass-through ttings to go through combustible ceil-
ings.
■ Strictly observe the PLVent manufacturer’s safety spec-
ications when using ceiling pass through.
a INSTALL VENT AT CLEARANCES SPECIFIED BY THE VENT
MANUFACTURER.
■ Ensure that all installation work is carried out to profes-
sional standards.
4.6 CONNECTING TO A CONVENTIONAL
CHIMNEY
The stove may be connected to an existing Class A chimney or
a masonry chimney which meets the minimum requirements of
NFPA 211.
This kind of installation provides natural draft in the event of
a power failure, reducing the probability of burn-back and
back-drafting.
a Check that the connection to the ueway is gas/smoke-
tight.
If you wish to use an existing chimney it is strongly recommend-
ed that you have it checked by a professional chimneysweep to
ensure that it is completely airtight. The reason for this is that the
smoke, because it is slightly pressurised, can infiltrate any cracks
in the flue and escape into living spaces.
DT2033037-1
MASONRY MUD THIMBLE
PL ADAPTER
TEE (T)
VENT
SOOT
INSPECTION
APERTURE
Fig. 13
If upon inspection you find that the chimney is not completely
sound, a relining of the chimney with either PL vent or single wall
stainless steel pipe may be necessary to bring the chimney into
compliance.
Put attention: some areas require that a liner must be always in-
stalled to the top of the flue, as shown in figure even if the exist-
ing chimney is in compliance.
DT2033036-1
PL ADAPTER
TEE (T)
VENT
MASONRY MUD THIMBLE
SOOT
INSPECTION
APERTURE
Fig. 14

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005161_H072534EN0_02
20
When chimneys are relined, a chimney chase cap that reduces the
outlet of the chimney to the size of the liner is required. Extend
the exhaust vent above the chimney chase cap and finish it off
with a rain cap.
A single wall liner may need to be insulated to maintain ade-
quate exhaust temperatures in the vent system.
a Outside chimneys frequently are dicult to keep warm:
it is recommended that you insulate the liner.
Venting into the side of an existing masonry chimney must be
done through a masonry thimble. When wall penetration is nec-
essary to access a masonry chimney, use a listed PL vent wall
thimble.
When venting into a Class A steel chimney, use an appropriate PL
Vent adapter.
DT2033038-1
TEE
FRESH AIR
INTAKE
VENT
PL VENT ADAPTER
SEE VENT
MANUFACTURER'S
INSTRUCTIONS
Fig. 15
a Strictly observe the PLVent manufacturer’s safety spec-
ications.
■ INSTALL EXHAUST VENT AT CLEARANCES SPECIFIED BY
THE MANUFACTURER.
■ Ensure that all installation work is carried out to profes-
sional standards.
4.7 INSTALLING INTO AN EXISTING FIREPLACE
CHIMNEY
This kind of installation also provides natural draft in the event of
a power failure.
When installing as a hearth mount stove into a firebox the unit
must either be relined, terminating above the chimney chase top,
or positively connected to the existing chimney system using a
block off plate.
An approved flex liner of PL vent must be used.
DT2033039-0
TEE
POSITIVE
BLOCK OFF PLATE
Fig. 16
In some areas it is required that the vent pipe extend all the way
to the top of the chimney. The pipe or liner inside the chimney
should be 4” (10 cm) diameter.
DT2033040-0
TEE
POSITIVE
BLOCK OFF PLATE
RAIN CAP
CHIMNEY FLASHING
PL VENT SYSTEM
Fig. 17
a A chimney system with known drafting problems may
require a liner, which may also need to be insulated to
keep vent system warm in cold chimney environment.
■ A cap shall be installed on the chimney to keep out rain.
■ Strictly observe the PLVent manufacturer’s safety spec-
ications.
a INSTALL EXHAUST VENT AT CLEARANCES SPECIFIED BY
THE MANUFACTURER.
■ Strictly use listed pellet vent pipe ttings.
■ Ensure that all installation work is carried out to profes-
sional standards.
