Piazzetta P163 T User manual

EN - The instruction manual is an integral part of the product.
EN
The instruction manual is an integral part of the product
Pellet stoves
P163 T
Please read this entire manual before installation and use of
this pellet fuel-burning room heater.
Failure to follow these instructions could result in property
damage, bodily injury or even death.
Contact local building autorithy (such as municipal
building department, re department, re prevention,
bureau. etc.) before installation to determine if a permit
and/or inspection is required.
Contact local building or re ocials about restrictions and
installation inspection requirements in your area.
Save these Instructions.
PRODUCT INFORMATION,
INSTALLATION AND MAINTENANCE

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005169_H072536EN0_02
2
This booklet code DT2005169_H072536EN0_02 - (06/2022) comprises 44 pages.
Dear Customer,
We thank you for having chosen one of our products, the fruit of extensive and continuous research for a superior product in terms of safety,
reliability and performance.
In the documentation supplied, you will find all the information and advice you need to use your product as safely and efficiently as possible.
i Please read the instructions and all information supplied with the product and any accessories, as well as any documenta-
tion referred to in this manual carefully, before proceeding with installation, use or any repairs.
■ If any problems or doubts should arise, please contact your local dealer or the authorized T.A.C. (authorized technical assis-
tance centre).
i This manual contains INFORMATION REGARDING THE PRODUCT, INSTALLATION AND MAINTENANCE.
■ For information regarding operation, please refer to the manual "
OPERATING INSTRUCTIONS ".
For the restrictions, limitations and exclusions please refer to the warranty included with the product. In line with its policy of constant
product improvement and renewal, the manufacturer may make changes without notice.
The images shown in this manual are for explanatory purposes and at times may not accurately depict the product.
This document is the property of Gruppo Piazzetta S.p.A. and no part of it may be reproduced or disclosed to third parties, whol-
ly or in part, without written permission All rights reserved by Gruppo Piazzetta S.p.A..
This booklet code
- Rev.
comprises
pages.
Code

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005169_H072536EN0_02 3
CONTENTS
1 GENERAL INFORMATION 4
2 PRODUCT INFORMATION 7
2.1 Product description 7
2.2 Part identification 8
2.3 Safety devices 9
2.4 Check devices 9
2.5 Product identification data 10
2.6 Characteristics 10
2.7 Accessories upon request 10
2.8 Technical data 11
2.9 Sizes 12
3 FUEL 13
3.1 Pellet specifications 13
3.2 Information regarding pellet loading 14
4 GENERAL INFORMATION REGARDING THE SYSTEM 15
4.1 Installation room 15
4.2 Fresh air intake 16
4.3 Chimney 16
4.4 Flue pipe 16
4.5 Interior vent installation 18
4.6 Connecting to a conventional chimney 19
4.7 Installing into an existing fireplace chimney 20
4.8 Short rise installation - wall outlet 21
4.9 Minimum flue vent configuration 21
4.10 Venting: termination requirements 22
4.11 Mobile home installation 23
5 PREPARATIONS FOR INSTALLATION 24
5.1 Handling 24
5.2 Unpacking 24
6 INSTALLATION 24
6.1 Access to the internal parts of the product 24
6.2 Minimum safety distances 25
6.3 Installation kit and accessories 26
6.4 Multifuoco system 26
6.5 Safe ducting clearance 28
6.6 Combustion air connection 28
6.7 Connection to the smoke outlet 29
6.8 Electrical connections 30
7 STARTUP AND OPERATING TEST 31
8 CLADDING AND TRIM 31
9 USE 32
9.1 Humidifier (accessories) 32
10 CLEANING AND MAINTENANCE 33
10.1 Scheduled maintenance 33
10.2 Cleaning the ceramic cladding 34
10.3 Cleaning the painted metal parts 34
10.4 Opening the door 34
Positioning the firedoor opening tool 34
10.5 Cleaning the glass 35
10.6 Disposal of ashes 35
10.7 Cleaning the ash tray 35
10.8 Cleaning the grate and grate support 35
10.9 Cleaning the combustion chamber 35
10.10 Cleaning the smoke chamber 36
10.11 Cleaning the extractor fan 37
10.12 Cleaning the room fan 37
10.13 Cleaning the smoke outlet 38
10.14 Replacing the fuses 38
10.15 Remove the door 38
10.16 Replacing the gaskets 39
10.17 Replacing the glass 39
11 WHEN NOT IN USE 40
12 DISPOSAL OF PRODUCT AT END OF PRODUCT LIFE 40
13 WIRING DIAGRAM 41
14 REFERENCE STANDARDS 42
15 WARRANTY 43

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005169_H072536EN0_02
4
1 GENERAL INFORMATION
Definition: The term system indicates the unit consisting of the
appliance and all the necessary installations which affect its op-
eration, including air intakes, the entire system for the evacuation
of the flue gases (connecting flue pipe, flue, chimney terminal)
the area, other sources of heat, installations for the propagation
of heat (hot air ducting or plumbing system).
Definition: The term standards or regulations indicates all appli-
cable national legislation, local regulations, particular or conven-
tional requirements arising from joint ownership building regula-
tions, and easement or laws or administrative acts, in force in the
place where the appliance is to be installed.
- This instruction booklet has been prepared by the manufactur-
er and is an integral part of the product. In the event of sale
or relocation of the product make sure this booklet accompa-
nies it, since the information contained in it is addressed to the
purchaser and to anyone involved in the installation, use and
maintenance of the product.
- Please read the instructions and all information supplied with
the product and any accessories, as well as any documentation
referred to in this manual carefully, before proceeding with in-
stallation, use or any repairs. If any problems or doubts should
arise, please contact your local dealer or the authorized T.A.C.
(authorized technical assistance centre).
- Gruppo Piazzetta S.p.A. cannot be held liable for situations of
risk, defects, damage, product malfunctioning or for damage
to objects, people or animals resulting from tampering of the
appliance and installation, use and maintenance which does
not respect the indications provided by regulations and the
manufacturer.
- Any changes to the original parameters which determine prod-
uct operation may only be carried out by authorised persons
from the company and with the values set by the manufactur-
er. Non-authorised interventions on the product will be consid-
ered tampering.
a All local regulations, including those refer-
ring to national standards need to be com-
plied with when installing the appliance
and when operating the appliance.
■ Product installation, use and maintenance
must be carried out in compliance with
the applicable instructions provided by
the manufacturer and in compliance with
all relevant regulations. Failure to respect
the indications provided and any incorrect
interventions may create dangerous situ-
ations, cause damage to people, property
or animals, or lead to health problems or
operating faults.
a Product installation and maintenance
must be carried out exclusively by quali-
ed personnel with sucient knowledge
of the product itself.
■ Only use original spare parts as recom-
mended by the manufacturer.
■ Spare/Replacementpartsaretobeordered
through our dealers or distributors. For
more information visit www.piazzetta.com
under "Support".
a In the event of a malfunction or fault, be-
fore carrying out any intervention and
before discontinuing product use, please
refer to the manual provided by the manu-
facturer in the sections " FAULTS " or " MES
SAGES  SAFETY WARNINGS  ANOMA
LIES ".
a In the event of re in the ue, stop using
the appliance, do not open the door of the
appliance, observe all safety recommen-
dations and contact the appropriate au-
thorities.
■ For appliances which are powered electri-
cally, do not disconnect the power supply
if unburned smoke/gas forms inside the
rebox. Move away and adopt all neces-
sary safety precautions.
a Smoke coming from a blocked ue is dan-
gerous. Keep the ue and connecting ue
pipe clean. Follow the manufacturer's
cleaning instructions.
■ Keep the exchangers and smoke passages
on the boiler clean. Follow the manufac-
turer's cleaning instructions.
■ Only use the recommended fuel.
■ Please read and comply with the instruc-
tions for installation, use and mainte-
nance.

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005169_H072536EN0_02 5
a Product use may cause some surfaces to
become extremely hot (the glass, the ex-
ternal surfaces, the handles, the smoke
outlet passage). Any contact between
clothing or body parts and these surfac-
es, including where accidental, may cause
burns or res.
■ Before performing work on parts of the
appliance that may be hot (e.g. top surface
panel, grilles, covers, door, settings devic-
es and control devices), take the necessary
precautions and use suitable protective
devices (glove, redoor opening tool or
other specic devices).
■ Since the glass becomes hot, make sure
that no person other than those experi-
enced in operating the appliance remain
in the area from where the heat emanates.
a Everyone (both children and adults)
should be informed of the risk of coming
into contact with hot surfaces.
■ Babies, young children, animals or anyone
else may experience burns as a result of
accidental contact. If there are any at-risk
subjects in the home, a protective barrier
should be installed. To limit access to the
appliance, install a safety gate to keep ba-
bies, young children and other at-risk sub-
jects out of the room and away from the
hot surfaces.
a This appliance is not for use by persons
(including children) with reduced physi-
cal, sensory, mental capacity or with a lack
of experience and knowledge, unless they
are helped or have been instructed on how
to use the appliance by the person who is
responsible for their safety.
■ Children shall not play with the appliance.
Cleaning and user maintenance shall not
be made by children.
■ Young children should be carefully super-
vised when they are in the same room as
the stove.
a If you expect that small children or vulner-
able adults may come into contact with
this appliance, the following precautions
are recommended:
■ Install a physical barrier such as a decora-
tive rescreen or an adjustable safety gate.
■ Install a switchlock or a wall/remote con-
trol withchild protection lockout feature.
■ Keep remote controls out of reach of chil-
dren.
■ Never leave children alone near a hot
stove, whether operating or cooling down.
■ Teach children to NEVER touch the stove.
■ Consider not using the stove when chil-
dren will be present.
a During the operation and/or cooling
phase, slight creaking noises may be
heard. This is not considered a defect, but
is a consequence of the thermal expansion
of the materials used.
d Do not install the product too close to
neighbors or in valleys that would cause
unhealthy air quality or nuisance condi-
tions.
d It is forbidden any unauthorized modica-
tion of the appliance.
d Do not stand or place objects which are
not heat-resistant within the prescribed
minimum safety distance.
■ This also applies when the appliance is
o. The appliance may be turned on by
somebody else or, where the appliance
is pre-congured, may be automatically
switched on (programmed or via remote
control), at any time.
■ Do not place food, drinks or other contain-
ers with liquids on parts of the appliance
or the surround, except for compartments
specically designated by the manufac-
turer for cooking or warming up food.

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005169_H072536EN0_02
6
d Do not install the product near walls or
objects in heat-sensitive or combustible
combustible material (wood or similar).
It is important to observe and respect
the distances and safety indications pre-
scribed by regulations and indicated in
the manual provided by the manufacturer
in the section "
INSTALLATION ".
■ IT IS FORBIDDEN TO USE THE APPLIANCE
WITHOUT SUITABLE CLADDING.
d THIS WOOD HEATER NEEDS PERIODIC IN-
SPECTION AND REPAIR FOR PROPER OP-
ERATION. IT IS AGAINST FEDERAL REGULA-
TIONS TO OPERATE THIS WOOD HEATER IN
A MANNER INCONSISTENT WITH OPERAT-
ING INSTRUCTIONS IN THIS MANUAL.
d THIS WOOD HEATER HAS A MANUFACTUR-
ER-SET MINIMUM LOW BURN RATE THAT
MUST NOT BE ALTERED. IT IS AGAINST
FEDERAL REGULATIONS TO ALTER THIS
SETTING OR OTHERWISE OPERATE THIS
WOOD HEATER IN A MANNER INCONSIST-
ENT WITH OPERATING INSTRUCTIONS IN
THIS MANUAL.
d Never use gasoline, gasoline-type lantern
fuel, kerosene, charcoal lighter uid, ethyl
alcohol or similar liquids to start or "reig-
nite" a re in this heater. Keep all such liq-
uids well away from the heater while it is
in use.
■ Only power the appliance with fuel which
has the characteristics as indicated in the
section "
FUEL " in the manual provided by
the manufacturer.
d Do not overre - If any external part starts
to glow, you are overring. Reduce feed
rate. Overring will void your warranty.
a Warning against overring:
■ pellets must not be fed manually into the
grate
■ never add additional fuel by hand
■ do not ll the hopper with any fuels other
than wood pellet
■ the residual pellets in the grate after a
failed ignition must be removed before
starting a new ignition process
d Do not use the appliance as an incinerator
or in any way other than that for which it
was designed.
■ Do not use the appliance if the glass or
seals on the door are damaged.
■ Do not open the door during operation.
a For monitoring and inspection techniques
ensuring heater is operating properly, in-
cluding ensuring visible emissions are
minimized, consult the section "
CLEAN
ING AND MAINTENANCE " and " OPER
ATING INSTRUCTIONS " (consult the sec-
tion " MESSAGES  SAFETY WARNINGS
 ANOMALIES
").

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005169_H072536EN0_02 7
Before carrying out any assembly, installation or ignition proce-
dures, the enabled installer must check that the system has been
manufactured in compliance with the applicable instructions
provided by the manufacturer and in compliance with all relevant
regulations. In particular, check:
- suitability of the room where the appliance is to be installed as
well as any restrictions
- the existence of any other appliances
- fresh air intake
- ventilation within the area where the appliance is to be installed
- sufficient clean air flow for combustion: air cannot be taken
from potentially polluted areas
- smoke evacuation system comprising a connecting flue pipe,
flue and chimney.
Installation may also include a series of operations to be carried
out correctly by enabled personnel and for which system com-
patibility must be guaranteed:
- connection to the air intake
- connection to the smoke evacuation system
- ventilation
- assembly and installation
- any necessary electrical or plumbing connections
- insulation
- start-up and operating tests, and where necessary calibration
and adjustment
- cladding and trims
- presentation of additional documentation as prescribed by the
regulations
- end user training by the installer on how to use and maintain
the appliance
- checking and maintenance.
Other requirements for compliance may be necessary in relation
to specifications required by the appropriate Authorities.
a DO NOT USE MAKESHIFT COMPROMISES
WHEN INSTALLING THIS APPLIANCE. DAM-
AGE AND/OR INJURY MAY RESULT.
2 PRODUCT INFORMATION
2.1 PRODUCT DESCRIPTION
This appliance is:
- a heat generator designed to be run with pellets
- to be used solely for the purpose for which it was designed; all
other uses are to be considered improper and therefore dan-
gerous
- equipped with a flue evacuation fan which maintains the com-
bustion chamber in negative pressure.
The use of a fuel which can be easily transported and stored such
as pellets, facilitates the ease of use of this appliance.
Heat diffusion is also ensured by the Multifuoco System forced
ventilation system offering different personalised functions and
the option of ducting.
The control unit allows the user to manage a range of functions
and programmes, while the basic controls can also be managed
using the control panel on the appliance itself.
The pellets are loaded into the hopper manually and the ignition
is electronic.
An electronic control unit controls the pellet dosing into the grate
as well as the flue gas expulsion.
The unit controls the appliance to make sure it operates correctly.
Thanks to a series of safety devices, it signals any faults and, if nec-
essary, initiates the appropriate procedures.

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005169_H072536EN0_02
8
2.2 PART IDENTIFICATION
1
25
23
26
12
13
14
15
10
9
8
5
6
7
4
3
2
11
22
24
16
21
16
20
19
18
17
1 Pellet hopper cover
2 Pellet hopper grille
3 Door
4 Ceramic glass
5 Door handle
6 Ash drawer
7 Smoke chamber
8 Smoke intake/Extractor fan
9 Adjustable feet
10 Electronic control unit
11 Pressure switch
12 Grate
13 Grate deflector
14 Pellet delivery hole
15 Combustion chamber
16 Environment fan/s
17 Electrical power cable
18 Safety thermostat
19 Smoke outlet
20 Combustion air duct
21 Auger motor
22 Pellet indicator
23 Pellet hopper
24 Firedoor opening tool
25 Metal structure
26 Appliance control panel
Fig. 1

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005169_H072536EN0_02 9
2.3 SAFETY DEVICES
The appliance is equipped with the following safety and check
devices which stop the stove from operating if any faults occur
against over-firing and ensuring heaters is operating properly, in-
cluding ensuring visible emissions are minimized.
If any safety warnings or alarms are activated, please consult the
“ OPERATING INSTRUCTIONS ”.
Pressure switch:
controls the vacuum inside the appliance. The pressure switch is
activated if the correct operating conditions are altered (inappro-
priate use or installation, obstacles or blockages in the flue, lack
of maintenance, adverse weather conditions such as persistent
wind etc.). The pressure switch activates and isolates the supply
voltage to the auger, thus stopping pellet feed to the grate and
then initiates the appliance shut down process.
Fuel hopper thermal cut-out:
this is a thermal device with automatic rearming that serves to
safeguard the pellet hopper against excessive temperatures.
If the temperature of the hopper exceeds the safety threshold, the
device isolates the supply voltage to the auger, pellet feed to the
grate is stopped and the appliance shut-down procedure begins.
Smoke temperature probe:
this is connected to the electronic control unit and constant-
ly monitors the operating temperature. If during this phase the
smoke temperature:
a) exceeds the safety threshold, the electronic control unit isolates
the supply voltage to the auger, thus stopping pellet feed to the
grate and starting the appliance shut down process
b) falls below the minimum operating temperature, the appliance
stops and an acoustic alarm signal is activated.
Furthermore, if during the start-up phase a system malfunction is
detected, an acoustic alarm signal is activated.
Auger safety:
the operation of the auger is constantly monitored by the elec-
tronic control unit. In the event of a malfunction, an acoustic
safety signal is activated. The electronic control unit isolates the
supply voltage to the auger, thus stopping pellet feed to the grate
and starting the appliance shut down process.
Extractor fan safety:
the rotation of the extractor fan is constantly monitored by the
electronic control unit. In the event of a fan malfunction, an
acoustic alarm signal is activated. The electronic control unit iso-
lates the supply voltage to the auger, thus stopping pellet feed to
the grate and starting the appliance shut down process.
Electrical safety:
the appliance is protected by fuses in the event of a power surge.
Electronic control unit:
the electronic control unit signals and controls a series of events
including power and ignition failure.
d The safety devices are there to eliminate the risk of
damage or injury to persons, animals or objects. IT IS
FORBIDDEN to tamper with the safety devices or allow
any intervention to be carried out by non-qualied per-
sonnel.
2.4 CHECK DEVICES
The appliance is equipped with some check devices which are to
be used exclusively by personnel authorised to carry out fine tun-
ing operations during installation and maintenance procedures.
Pressure plug (A) : for measuring the pressure drop inside the
appliance.
DB9 serial port (B) : to carry out checks on the correct operation
of the product and any necessary maintenance operations. A re-
mote appliance-management system (GPRS or Wi-Fi) can be con-
nected to the DB9 serial port.
A
B
Fig. 2

PRODUCT INFORMATION, INSTALLATION AND MAINTENANCE
DT2005169_H072536EN0_02
10
2.5 PRODUCT IDENTIFICATION DATA
Each product is identified in the following way:
- IDENTIFICATION DATA PLATE (1) with the model (A) and ap-
pliance performance specifications
- SERIAL NUMBER PLATE (2) with the serial number of the ap-
pliance (B)
- LABEL WITH IMPORTANT ADDITIONAL INFORMATION (3)
with important information.
The identification plates are positioned as shown below.
i When asking for technical support and/or spare parts,
always provide these data to the dealer or T.A.C. (au-
thorised technical assistance centre).
A
B MATR. ...
1
2
Fig. 3
1
Fig. 4
3
2
Fig. 5
2.6 CHARACTERISTICS
Structure:
- in steel
Cladding:
- in painted steel
Top surface:
- majolica
- in cast iron
Firebox:
- in cast iron
Grate:
- in cast iron
Ash collection:
- extractable ash drawer
Door:
- in cast iron
- 0.197" (5 mm) ceramic glass resistant to 750°C (1382 °F)
Door handle:
- in painted steel
- nickel plated finish
Power adjustment:
- 5 positions
Heating:
- forced ventilation with Multifuoco System
- 2 fans
- 3 speed settings
- maximum permitted length approximately 26.24' (8 m)
- outlet diameter 3'' (Ø 75 mm)
Function control:
- appliance control panel
Provided as standard:
- power cable (length 6' / 1.8 m)
- room temperature probe
- grate deflector
- hex wrench
- firedoor opening tool (separable handle)
2.7 ACCESSORIES UPON REQUEST
To consult the full list of accessories supplied upon request and
to check the compatibility of internal components, cladding and
accessories, consult your dealer.
- Remote control kit
- Smoke outlet kit
- Accessories for hot air ducting
- Humidifier (in stainless steel)
- Accessories for cleaning and maintenance
