Pichler WPD-A3 User manual

manual “customer menu“
Dosing System
WPD-A3
PICHLER Kunststofftechnik GmbH
Lauterbachstraße 19
84307 Eggenfelden
phone:
telefax:
email:
Internet:
0 87 21-96 90 10
0 87 21-96 90 20
[e-mail]
www.pichler-dosiertechnik.de
2017/09
manual customer menue

Contents
dosing system customer menue WPD-A3
display panel...................................................................................................
2
LCD screen, Symbole on the screen...............................................................
2
print, setting, save, load, factory setting, contrast............................................
3
further adjustments, time, dosing alert, start delay.............................................
4
hand dosing (manuel dosing)..........................................................................
5
electrodes calibration, restore (Reset)............................................................
5,6
report on screen..............................................................................................
6
troubleshooting...............................................................................................
7
options, updates, service usw.........................................................................
7
PICHLER Kunststofftechnik GmbH
page 1 of 7 2017/09

control panel
PICHLER Kunststofftechnik GmbH
Following picture shown the control panel from the dosing system. You get a overview for apart buttons.
Some of them you need it from beginning to start the dosing system. Declarations for the using
and programming as following sections.
LCD - screen
Programming buttons
The LCD - Screen
On the LCD screen, you see the actually operating status from the dosing unit.
Aditional will shown alert- and fault reports.
Also can show the adjusting data in programming mode.
The screen can show 8 lines finaly.
If are further lines outside the LCD screen, will be shown as a arrow symbole on the
side.
Status LED for ORP
(Redox)
status LED for pH
Status SMD-LED (RGB) screen
The SMD LED lamps provide you quick view status-report (operating report).
If a measure value over or under, will flashing the this status LED (as example color „red“).
Also when already a electrode was calibrated, and the quality of electrode is not good as well,
the LED status light is flashing in the color „yellow“.
After 30 passed, and the electrode is not replaced the flash lighting changed to the color „red“.
If the LED lights shows the color „green“ for pH and Redox, the unit is working well.
page 2 to 7
flow activity gauge
(aktiv/inaktiv circulation pump)
start delay time counter
(waiting time until the unit is
activ again)
status-gauge
(date, weekday,
time)
2017/09

settings
menu customer
menu service
back
step: 1
21.09.2013 SA 13:07
=
=
7.2
755
PH
Redox
main pict.
print out the value
If a printer installed, can print out the measure values.
the values:
-quick print
-every hours aoutmatic print
-can adjust 8 different times for automatic printing.
This is a option, and can work only with a seperate printerNote!
via bluetooth connection.
settings
menu service
back
step: 3
menu customer
page 3 to 7
PICHLER Kunststofftechnik GmbH
Settings
Please choose the menu „menu customer“, Settings ( ).pic 1
Push the button „save settings“ withAdjustment. saving: ON/OFF
the „OK“ button, than with the arrow up it shows
the sign „ON“, for saving the changings push again the „OK“ button.
()Bild 1
Note: Please save every time if you change some settings.
Push the button „load settings“ withAdjustment load: ON/OFF
the „OK“ button, than push the arrow up it shows
the sign „ON“ for load the changings push again the „OK“ - button.
(this can restore to customer menu)factory settings: ON/OFF
It will reset to the factory setting. (but only the customer menu).
(The range of contrast can be adjustdisplay contrast: 1-150
1-150 Please choose the optimal step for you.
pic 1
„“▲
„“▲
settings
factory settings
save settings
An
load settings
display contrast 55
Aus
Aus
customer menu
settings
more settings
manuell dosing
back
calibrate
print off
2017/09
V4.03 V4.03
menu customer
back
Notification: Newest is a WLAN module for web view and printing. Please ask for the model our service.

PICHLER Kunststofftechnik GmbH
date and time adjustment
go to more settings than go with curser to „date or time“.(pic 2)
Use for adjusting these buttons .„OK“
Now you can select with the 3 buttons the time or date.
Confirm if finish with the „OK“ button.
„“▲„“▼pic.2
more settings
time 11:37
dosing alert
back
CL -/+ ------0------
date 01.09.17
i
Now you can select and adjust the border of alert.
decent or climb the selected value, will get a alert and the
LED lamp on the screen will flashing red light.
Suggested adjust values are .(pic 3,4)
You can also set alert „OFF“ if you don‘t want it.
pic.2
dosing alert
alert pH
alert redox
back
pic.3
alert pH
smaller
delay (min.)
back
bigger
8.0
6.3
15
alert on
pic.4
alert redox
smaller
delay (min.)
back
bigger
850
450
15
alert on
pic.5
start delay
(picture 5)
factory setting for the dosing activate is 30 min.
If you have a malifunction in your house current, or you connect it
on/off, will start at first the start delay, and you must wait for dosing
is active this setting time.
Same is when the circulation pump stopped.
The electrodes ph and redox need this time to make the correct voltage
on the end top.
This is important for well funktion of dosing.
page 4 to 7 2017/09
delay (min)
30
dosing alert
Press to select and adjust the minimum and maximum alert values
„alert pH“ or „alert redox“.
than you show min./max. border.(pic. 2)
fine tuning if to much or less clorine in the water
You can test it with test strips before. If to much chlorine in the water
you can set as example CL -2, so the chlorine level will decend about
0,5 mg. And also it is working in the direction. You can move with the+
„x“ to the right side position to get more chlorine into the water. pic.6
more settings
time 11:37
dosing alert
back
CL -2 ---x-0-----
date 01.09.17
delay (min)
30
more settings
time 11:37
dosing alert
back
CL -/+ ------0------
date 01.09.17
delay (min)
30

PICHLER Kunststofftechnik GmbH
manuel dosing (hand dosing function)
select the menu customer, than manuell dosing.
Confirm with the button .„OK“(pic.8)
Push the button pH or chlorine and confirm with again.„on“ „OK“
.(pic.9)
The dosing pump will turn in right direction for 10 seconds after than
will automaticly stop. (First time need depend the length of the
chemical tube 30 seconds before the chemical goes into the water).
Application:
If you fill the spa with new water, you can help with manuell dosing to
get the optimal value more fast.
The decent of pH value and this is the ,optimale carbon hardness
(4 german hardness).40ppm
How long that the unit need for time until get this optimal value depends
the houshold water hardness.
Usually after 3 days the pH level should be on 7.2 or 7.3 ph and hardness
40ppm.
is not necessary to dosing manuell.Chlorine
„“▲„“▼
manuell dosing
ph off
chlorine
pic.9
pic.8
electrode calibration
Close both water tap, so can avoid water come out of the measure cell
Screw out the electrodes pH and Redox/ORP.
And put the electrodes for 5-10 minute into the calibration container.
(red and yellow marker)
Die BNC-connector must connected during the 5-10 minutes.
After this while of 5-10 minutes should be calibrate pH and redox
Choose the menu customer „calibrate“(Bild 10)
Go with the curser up to the ph and push 2 times the ok button.
So act ph must show in the display 7.0 and calib also 7.0 pH.
If you also calibrate redox, please do the same way.
After the calibration screw the pH and redox electrode into the
measure cell tight.
Don‘t forget to open both water taps !
Now the start delay will turn on and start the countdown from 30min.
The unit will start the job after the 30 minutes is gone.
pic.10
menu customer
more settings
settings
manuell dosing
back
calibrate
print off
pic.11
calibrate
redox
ph
back
reset selection
act calib diag
7.0 7.0 0.0
420 420 0.0
page 5 to 7 2017/09
settings
more settings
manuell dosing
back
calibrate
print off
menu customer
back
off

PICHLER Kunststofftechnik GmbH
Reset (restore electrodes to factory setting)
Select on menu „reset“. ).(picture 16
Choose the „reset“ and push the button „OK“.
Now select between pH and redox electrode for reset, and press
the „ok“ button again. pic.16
page 6 to 7 2017/09
calibrate
redox
ph
back
act calib diag
7.0 7.0 0.0
420 420 0.0
reset ph

PICHLER Kunststofftechnik GmbH
Reports on the Display
Please get a note for the reports on the Display. If the reports not leave within 24 hours,
the fault must be clean.
Please read further faults possibilities.
Fehlerbehebung
Fault / malifunction
to absorb the fault
PH, or redox value is over-
or underline.
- check if the container with liquid full or empty
(Please refill or replace the liquid at time. !)
The flow gauge is marked
with „X“
- No flow, please check if the cone is down.
- The filter sieve in the measure cell is dirty, please clean it.
Best for use take a old toothbrush and clean under cold
water tap.
- The flow sensor is broken, please renew it.
It shows on the screen the
countdown.
- Sombody had a bath before.
- The circulation pump stopped more than 10 seconds.
- Short time before you made a calibration and the water tap
was closed short time before.
One of the status color
LED is lighting
yellow or red.
- Short time before you calibrate a eletrode, so the electrode
life time ended. Please replace a new electrode.
- In the mainscreen the gauge is changing, as example
only 30 days. This is a 30 days countdown, and within this
time must be replace the electrode.
- You had calibrate wrong, please repeat it.
Please take sure during the calibration the electrode was into
the reference cotainer with liquid.
The status LED are
lighting green.
- Everything is ok.
Options, Updates, Service
Optionen sind: free clorine cell ( for commercial using ), µS-electrode
Softwareupdates: Only the factory or dealer can update the software.
Service: If you have any questions please write an email to: [e-mail]
page 7 to 7 2017/09
