Overview 4
Chapter 1 - Overview
Welcome
Thank you for purchasing the PerfectPulse® Differential Time Domain Reflectometry
instrument. The J2154A TDR is an ultra-portable signal generator that produces a precise
fast edge. The device, packaged in a portable low power, easy to power format supports a
wide variety of applications.
It is the perfect tool for signal integrity testing, PCB trace characterization, cable testing,
DSP calibration, and Time Domain Reflectometry (TDR) tasks.
J2154A PerfectPulse® Features and Benefits
•Precise Differential or Single-Ended TDR – Time Domain Reflectometry in one
convenient package
•All applications requiring a fast, precise edge
•USB or battery powered
•Includes 12GHz internal power splitter for TDR operation
•Compatible with the Picotest P2104A 1-port and P2105A TDR probes, as well as
other manufacturers’ 50 Ohms probes
•Compatible with most oscilloscopes
J2154A Applications and Usage
•Low-cost PCB coupon tester - Characteristic Impedance PCB traces
•Measure cable and PCB trace length, characteristic impedance, return loss, VSWR,
and dielectric constant
•Locate and detect impedance mismatches
•Measure parasitic inductance and capacitance such as bond wires, vias, and ESL

Overview 5
•Verify the integrity of cable crimps and connector launches
•Measure PCB trace path rise/fall time and overshoot/undershoot
•Supports cable and trace loss modeling
•Troubleshoot clock jitter and crosstalk
•Measure microwave filters
•Test the frequency bandwidth, rise/fall time, and flatness of lab instruments and
probes
J2154A – How It Works
An internal, differential ultra-low jitter oscillator drives an ultra-high-speed CMOS
differential pre-driver. The pre-driver drives a differential ECL logic driver.
Figure 1: J2154A pulse response.
Internal 6dB resistor power dividers allow scope sampling either before or after 50 Ohm
source resistors. With the “VNA” ports connected to the sampler (scope) the FRA/TDR
output is sampled at the port. This provides TDR and FRA functionality.
Flipping the TDR to connect FRA/TDR to the scope, the sampler is before the 50 Ohm
source resistor. This provides RF VNA functionality.

Overview 6
Figure 2: The J2154A can be connected to support TDR and Frequency Response functions,
as well as Vector Network Analysis (VNA) functions (as detailed below).

Overview 7
What’s Included
Your Picotest PerfectPulse J2154A Signal Generator includes the following:
•J2154A PerfectPulse Signal Generator and Carrying Case
•TDR Demo board
•BNC-SMA PDN cables
•USB-C Power Cable
Figure 3: The J2154A comes with a test/demo board which has single and differential test
traces with impedance changes at different distances.
Documentation and Support
This documentation details the use the J2154A for various types of measurements.
Specifications are also included.
The support section of Picotest’s web site, https://www.picotest.com/support.html,
contains set files that support the J2154A TDR usage on various oscilloscopes.

Overview 8
Warranty
Every Picotest product you buy from Picotest.com is backed by a 1-year manufacturer’s
warranty. For warranty service or repair this product must be returned to a service facility
designated by PICOTEST. Please contact your local service representative for further
assistance.
Calibration and Test Board
The PerfectPulse Signal Generator does not require calibration.
Figure 4: The J2154A demo board.
•Trace 1 (TP1/TP2) – Single ended 50 Ohm trace
•Trace 2 (TP3/TP4) – Single ended OhmBeatty standard
•Trace 3 (TP5/TP6) – Single ended trace with two impedance steps 3000 mils apart
•Trace 4 (TP7/TP9) – Differential 50 Ohm test traces
•Trace 5 (TP11/TP12 and TP15/16) – Differential test traces; one with two impedance steps 200
mils apart and one with two larger discontinuities 750 mils apart
•Trace 6 (TP13/TP14 and TP17/18) – Differential test traces; one with two impedance steps 500
mils apart and one with two larger impedance steps 1000 mils apart

PerfectPulse® Fast Edge Signal Generator 9
Chapter 2 – Introduction to the PerfectPulse®
Signal Generator
Introduction and TDR Usage
The PerfectPulse TDR is a simple to use signal generator designed to support almost any
test requirement that can utilize a fast (rising or falling) edge including all TDR applications.
The device is completely self-contained, requiring only a 5V supply from any USB port,
including USB battery packs. This allows portable operation.
Power Up the J2154A
Plugging the key into a USB slot starts the operation. There is no need for any other
operation.
The J2154A includes a USB-C Cable that you can connect to any standard USB port
and to the connector on the J2154A.
Figure 5: The J2154A is powered using a supplied USB cable.

PerfectPulse® Fast Edge Signal Generator 10
Setting Up TDR Usage
For single-ended and differential mode TDR measurements, Connectors 1 and 3 connect to
the oscilloscope channels, while connectors 2 and 4 connect to the probes. This is the native
mode and most common mode of operation. These can be either single-ended or differential
measurements. Connectors 1 and 2 are used for single-ended measurements.
Figure 6: MSO software settings.
RHO rescales J2154A output voltage. Impedance converts from RHO to impedance. The
Capacitance equation integrates (the trace step) RHO to obtain the capacitance associated
with a step. Inductance integrates (the trace step) RHO to obtain the inductance associated
with a step.

PerfectPulse® Fast Edge Signal Generator 11
Figure 7: TDR response. The ringing on the left is the Gibbs phenomena, present because in
this case the scope bandwidth (10GHz) is LESS than the TDR bandwidth (12GHz). As the
scope becomes faster this ringing will disappear. The blip between M1 cursors is the P2105A
probe launch. The effective inductance can be seen on the right. The flat portion is the
response of a 50ohm transmission line (PCB trace).
Figure 8: Small value (500fF) capacitor measurement

PerfectPulse® Fast Edge Signal Generator 12
Figure 9: Capacitor ESL inductance measurement
Figure 10: Connections for TDR operation.
FRA Operation
For the measurement of an oscilloscope probe, the voltage is measured at the tip of the
probe, so that the 50 Ohm port resistance doesn’t damp the probe response. This is
equivalent to measuring with a very low source impedance, such as that presented by a
power supply. Connectors 1 and 3 connect to the oscilloscope channels, while connectors 2
and 4 connect to the probes. This is the same connection as the TDR, but the math
functions use Fast Fourier Transforms (FFTs) of the high-speed signal edge at the tip of the
probe and a high or low impedance scope input to measure the back end of the probe to

PerfectPulse® Fast Edge Signal Generator 13
display the probe transfer function. These can be either single-ended or differential
measurements.
A math function provides the FFT of the derivative of the pulse. The result is an impulse
that is flat response to the rise/fall time of the pulse (about 13GHz).
Dividing the FFT at the “output” connection by the FFT at the “input” connection results
in the transfer function. We can measure the scope, probes, or other devices without the 50
Ohm damping of an S-parameter measurement.
Figure 11: Connections for FRA operation.
FRA/TDR
FRA/TDR
VNA
VNA
ECL Driver
R1
R3
R2
R4
R
R
R
R

PerfectPulse® Fast Edge Signal Generator 14
VNA Operation
For VNA (frequency domain) measurements the signal is measured prior to the 50 Ohm
port resistance so that the output is 50 Ohm as required by S-parameters. This is
accomplished by connecting the oscilloscope to connectors 2 and 4 and the probes to
connectors 1 and 3. As with the FRA, the math functions use Fast Fourier Transforms
(FFTs) of the high-speed signal edge at the probe side as one 50 Ohm port and a second 50
Ohm scope channel as the second port. The math function displays S21. (It is possible also
to display S11, but not S22 or S21). These can be either single-ended or differential
measurements.
To change the mode:
Figure 12: Connections for VNA operation.
FRA/TDR
FRA/TDR
VNA
VNA
ECL Driver
R1
R3
R2
R4
R
R
R
R

PerfectPulse® Fast Edge Signal Generator 15
Chapter 3 - Specification
Specifications that are not defined to be guaranteed are typical and are published as general
information to the user. The instrument should have warmed-up for at least 20 minutes and
the environmental conditions should not exceed the unit's specified limits.
J2154A PerfectPulse® Specifications
J2154A
Characteristic
Rating
Typical rise/fall time
30ps
Power
USB Input
Output Connector
SMA Male
Output Impedance
50 Ohm
Output Voltage
-250mV +/-3mV @ 25C
Flatness
3dB at 10.5GHz 0.1dB (typ.) at 2GHz
Skew output to output
2 psec
Return Loss
typical 55dB max 40dB
Resolution
~164 mils (FR4) *
Operating Temperature
0 to 45° C (32° F to 104° F) at 80% relative
humidity
* Dependent on the oscilloscope and probe used
Safety Information
To avoid personal injury and to prevent fire or damage to this product or products
connected to it, review and comply with the following safety precautions. Be aware that if
you use this key assembly in a manner not specified, the protection this product provides
may be impaired. Only qualified personnel should use this key assembly. Do not connect the
key to any voltage that exceeds the maximum permissible input voltage specified in the data
sheet. Non-compliance with this instruction carries the risk of an electric shock. Make sure
not to cause any short circuits when performing measurements on sources with high output
currents. Short circuits may cause injuries or burns.
Use only grounded instruments.
Do not connect the key ground (USB connector) to a potential other than ground or earth
ground or to any power source that isn’t grounded. Always make sure the key and the
measurement instrument/power source are grounded properly.
Observe Key ratings.
Do not apply any electrical potential to the key input which exceeds the maximum ratings of
the Comb.

PerfectPulse® Fast Edge Signal Generator 16
Do not operate with suspected failures.
Refer to qualified service personnel.
Indoor use only.
Do not operate in wet/damp environment. Keep product surfaces dry and clean. Do not
operate the product in an explosive atmosphere.
Handling Information
Handle with care to avoid any injury. Note that the key cable is a sensitive part of the
key and connector. Do not damage through excessive bending or pulling. Avoid
mechanical shock to this product in general to guarantee accurate performance and
protection.
Caution: To avoid equipment damage and/or severe injuries or death ensure that the
absolute maximum ratings defined in this manual are observed at all times and never
exceeded.
Cleaning
To clean the exterior of the key, use a soft cloth moistened with either distillated water or
isopropyl alcohol. Before use allow the key to dry completely.
Table of contents
Other Picotest Test Equipment manuals
