Pillar JT-SA-KA User manual

MANUAL No.213
Sleeve Insertion Tool
JT-SA-KA
INSTRUCTION MANUAL
This instruction manual contains safety information.
Please read this manual carefully to ensure safe
and correct use of the product.
This manual should be kept readily accessible for
reference.
PPLP

Table of Contents
Preface and Safety Notices ...................................................................................2
1. Inserting sleeve into ϕ19 - 25/W6 - W8 standard tubes.....................................3
2. Inserting sleeve into ϕ6 - 12/W2 - W4 standard tubes.......................................5
3. Inserting sleeve into 0.25" x 0.12" color tube and ϕ3/ϕ4/W1 standard tubes ....7
4. Tightening (Nominal tube size: 6 - 25, W2 - W8, Color tube) ............................9
5. Tightening (Nominal tube size: 3, 4, W1).........................................................11
6. Dimensional tolerance of applicable tubes ......................................................14
7. Disposal Precautions .......................................................................................15
8. Office Locations ...............................................................................................15
Manual No. 213
1

Preface
Thank you very much for purchasing the P series Super 300 Type Pillar Fitting.
This instruction manual describes the structure, specifications, and installation, inspection and maintenance
procedures of the product.
Please read this manual carefully to ensure safe and efficient use of the product.
Safety Notices
The following lists safety notices which must be observed to ensure safe and proper use of the product and
prevent personal injury and/or property damage.
Because these safety notices contain important information, be sure to read and observe them.
In this manual, safety notices are divided into “Danger”, “Warning” and “Caution” according to the hazard level.
DANGER A danger notice with this symbol indicates an imminently hazardous situation which, if
not avoided, will result in death or serious personal injury.
WARNING A warning notice with this symbol indicates a potentially hazardous situation which, if not
avoided, could result in death or serious personal injury.
CAUTION A caution notice with this symbol indicates a potentially hazardous situation which, if not
avoided, may result in personal injury and/or property damage.
This symbol indicates prohibition.
This symbol conveys mandatory action or provides an instruction.
Be sure to follow instructions in this manual when installing,
retightening, reinstalling the fitting.
Poor installation or retightening may cause the liquid to leak or the fitting
to uncouple from tubing.
Do not retighten the fitting while tubing is in high-temperature or
pressurized conditions.
Doing so may deform or damage the fitting, resulting in a spout of the
liquid.
Before retightening the fitting, be sure to lower the temperature to 30 °C
(86°F) or less and reduce the pressure to 0 MPaG (0 psiG).
The fitting is made of resin. Exercise great care to avoid bending
or tensile stress to the fitting when or after tightening it.
Doing so may deform or damage the fitting, resulting in liquid leakage.
WARNING
Liquid
leakage
Do not use the fitting beyond the working range specified in this
manual.
Doing so may cause the liquid to leak or the fitting to uncouple from
tubing.
Never use the P series Super 300 Type Pillar fitting in combination
with other fittings.
Doing so may cause the liquid to leak or the fitting to uncouple from
tubing.
When the liquid temperature is 70 °C (158 °F) or higher, protect the
fitting and tubing with a cover or other suitable means.
Otherwise, a burn may result.
Exercise great care to avoid a burn during the tube flaring process.
The tube flaring process involves preheating of tubing.
Installation
work
Maintain good ventilation during the tube flaring process.
Preheating of tubing could generates toxic gases.
Do not dispose of the fitting with a liquid residue remaining in it.
Be sure to wash a liquid residue inside the fitting and then dispose of
the fitting as incombustible waste. Disposal of the fitting without
washing a liquid residue may be hazardous.
CAUTION
Disposal
Do not incinerate fitting parts.
Incineration of fluoro-resin parts will generate toxic smoke.
・After installing the fitting, keep this manual readily accessible for future reference
Manual No. 213
2

1. Inserting sleeve into ϕ19 - 25/W6 - W8 standard tubes
Fig. 3 - Tube locking length
Tube locking length
Fig. 1 - Parts designation of insertion tool
Tube holder Sleeve holder
Dia.
expansion
ring
Before
expansion
After
expansion
1. Setting the sleeve Fig. 2 - Setting the sleeve
· Install the sleeve holder to the insertion tool JT-SA- KA and then set
the sleeve as shown in Fig. 2 for the state before the diameter has
been expanded.
· After the sleeve has been set, push the diameter expansion ring
toward the sleeve until it clicks (see Fig. 2 for the state after the
diameter has been expanded and Table 1 for the applicable parts).
2. Clamping the tube
· Fit the tube holder onto the tube having the union nut in place. Lock
the tube with the clamp at the shortest locking length shown in Table
2 or more (see Fig. 3).
Table 2 - Tube locking length
Nominal tube size
Millimeter size 19 25
Inch size W6 W8
Tube locking length 35 41
3. Inserting the sleeve
· Turn the grip clockwise to insert the sleeve into the tube (see Fig. 4 (1)).
· Stop turning the grip when the tube end reaches the tube stop of the sleeve (see Fig.4 (1)).
· Turning the grip counterclockwise will move the sleeve holder backward and unlock the diameter expansion ring. Now
the inserted tube sleeve can be removed from the sleeve holder (see Fig. 4 (2)).
(1) Inserting the sleeve (2) Completely inserted sleeve
Fig. 4 - Sleeve insertion
3

Caution:
• Stop turning the grip clockwise when the tube end reaches the tube stop of the sleeve.
Otherwise, damage to the tube, sleeve and/or sleeve holder may result.
Notes:
• The P-SHP-SAK** sleeve holder is provided with a diameter expansion ring at its end. If the
diameter expansion ring becomes less secured, place an order for the diameter expansion ring
only.
• The sleeve holder for Super 300 Type Pillar
Fitting P Series has dual grooves on its flange
(see Fig. 5).
Grooves for
identificatio
n
Fig. 5 - Sleeve holder
Table 1 - JT-SA-KA parts list
Nominal tube size
Millimeter size 19 25
Inch size W6 W8
Sleeve holder P-SHP-SAK19(W6) P-SHP-SAK25(W8)
Dia. expansion ring P-KR-A19(W6) P-KR-A25
Tube holder J-TH-A19 －
Manual No. 213
4

2. Inserting sleeve into ϕ6 - 12/W2 - W4 standard tubes
Fig. 7 - Setting the sleeve
Dia.
expansion
rin
g
Before
expansion
After
expansion
Fig. 6 - Parts designation for insertion tool
Tube holde
r
Sleeve holde
r
Small dia. attachment
1. Setting the sleeve
· Install the sleeve holder and the attachment to the insertion
tool JT-SA-KA and then set the sleeve as shown in Fig. 7 for
the state before the diameter has been expanded.
Fig. 8 - Tube locking length
Tube lockin
g
len
g
th
· After the sleeve has been set, push the diameter expansion ring
toward the sleeve until it clicks (see Fig. 7 for the state after the
diameter has been expanded and Table 3 for the applicable
parts).
2. Clamping the tube
· Fit the tube holder onto the tube having the union nut in place.
Lock the tube with the clamp at the shortest locking length
shown in Table 4 or more (see Fig. 8).
3. Inserting the sleeve
· Turn the grip clockwise to insert the sleeve into the tube (see Fig. 9 (1)).
· Stop turning the grip when the tube end reaches the tube stop of the sleeve (see Fig.9 (1)).
· Turning the grip counterclockwise will move the sleeve holder backward and unlock the diameter expansion ring. Now
the inserted tube sleeve can be removed from the sleeve holder (see Fig. 9 (2)).
・
Table 4 - Tube locking length
Nominal tube size
Millimeter size 6 8 10 12
Inch size W2
W2Y - W3
W3Y W4
Tube locking length 20 23 25 30
(1) Inserting the sleeve (2) Completely inserted sleeve
Fig. 9 - Sleeve insertion
Manual No. 213
5

Caution:
• Stop turning the grip clockwise when the tube end reaches the tube stop of the sleeve.
Otherwise, damage to the tube, sleeve and/or sleeve holder may result.
Notes:
• The P-SHP-SBK** sleeve holder is provided with a diameter expansion ring at its end. If the
diameter expansion ring becomes less secured, place an order for the diameter expansion ring
only.
Grooves for
identification
Fig. 10 - Sleeve holder
• The sleeve holder for Super 300 Type Pillar Fitting P Series
has dual grooves on its flange (see Fig. 10).
Table 3 - JT-SA-KA parts list (6 - 12, W2 - W4)
Nominal tube size
Millimeter size 6 8 10 12
Sleeve holder P-SHP-SBK6(W2) P-SHP-SBK8 P-SHP-SBK10 P-SHP-SBK12
Dia. expansion ring P-KR-C6(W2) P-KR-C8 P-KR-A10 P-KR-A12
Tube holder J-TH-SB6 J-TH-SB8 J-TH-SB10 J-TH-SB12
Attachment SA-SB-AT
Nominal tube size
Inch size W2 W2Y W3 W3Y W4
Sleeve holder P-SHP-SBK6(W2) P-SHP-SBKW2Y P-SHP-SBKW3 P-SHP-SBKW3Y P-SHP-SBKW4
Dia. expansion ring P-KR-C6(W2) P-KR-CW2Y P-KR-ＡW3 P-KR-ＡW3Y P-KR-ＡW4
Tube holder J-TH-SBW2 J-TH-SBW3 J-TH-SBW4
Attachment SA-SB-AT
Manual No. 213
6

3. Inserting sleeve into 0.25" x 0.12" color tube and ϕ3/ϕ4/W1 standard tubes
Fig. 12 - Setting the sleeve
Sleeve
Tube holder
Sleeve holder
Attachment
Fig. 11 - Parts designation for insertion tool
Tube holde
r
Small dia. attachment
Sleeve holder
Fig 13 – Tube locking length
Tube lockin
g
len
g
th
1. Setting the sleeve
· Install the sleeve holder and the attachment to the insertion
tool JT-SA-KA, and then set the sleeve (see Fig. 12 for the
state before fitting the flaring tool; and Table 5 for the
applicable parts).
2. Clamping the tube and setting the flaring tool
· Install to insertion tool JT-SA-KA the tube holder.
Flaring tool
· Open the clamp and lock the tube having the union nut in
place to the tube holder at the shortest locking length
shown in Table 6 or more (see Fig. 13).
Tube
· Install the flaring tool to the tip of the sleeve holder (see
Fig. 13).
Fi
g
. 6 - Tube lockin
g
len
g
th
3. Expanding the tube diameter and inserting the sleeve
· Turn the grip clockwise to advance the screw and expand
the tube end with the flaring tool. Repeat this step several
times (see Fig. 14 (1)).
Nominal tube size
Millimeter size 3 4 -
Inch size W1 - Color tube
(0.25”×0.12”)
Tube locking
length 11 12 20
· After the diameter has been expanded, remove the flaring
tool (see Fig. 14 (2)).
· Turn the grip clockwise to insert the sleeve into the tube
(see Fig. 14 (3)).
· Stop turning the grip when the tube end reaches the tube
stop of the sleeve (see Fig. 14 (3)).
· Turning the grip counterclockwise will move the sleeve holder backward, allowing you to remove the inserted tube
sleeve easily.
(1) During dia. expansion (2) Completion of dia. expansion (3) Sleeve insertion
Fig. 14 - Tube dia. expansion and sleeve insertion
Manual No. 213
7

Caution:
• Stop turning the grip clockwise when the tube end reaches the tube stop of the sleeve. Otherwise,
damage to the tube, sleeve and/or sleeve holder may result.
Notes:
• If the flaring tool is moved forward after the diameter has been expanded, the tube may be
buckled. Upon the completion of diameter expansion, stop moving forward the flaring tool.
• If the flaring tool is difficult to remove, turn it. This will allow you to remove the flaring tool
easily.
• The P-SH-SBK** sleeve holder is provided with a flaring tool at its end.
• The sleeve holder for Super 300 Type Pillar Fitting P Series (excluding for color tubes) has
dual grooves on its flange (see Fig. 68).
Grooves for
identification
Fig. 15 - Sleeve holder
Table 5 - JT-SB parts list (3, 4, W1, Color tube）
Nominal tube size
3 4 W1
Color tube
(0.25”×0.12”)
Sleeve holder P-SH-SBK3 P-SH-SBK4 P-SH-SBKW1 J-SH-SKA6(W2)
Tube holder J-TH-SB3 J-TH-SB4 J-TH-SBW1
J-TH-SBW2
Attachment SA-SB-AT
Manual No. 213
8

4. Tightening (Nominal tube size: 6 - 25, W2 - W8, Color tube)
4-1. Structure and function of gauge ring (Nominal tube size: 6 - 25, W2 - W8, Color tube)
• The P Series Super 300 Type Pillar Fitting is provided with a gauge ring to facilitate controlling the tightening range
and limit, thereby ensuring safe and proper tightening (see Fig. 16).
6 - 10
W2 - W3
Blade
Base
Blade
Base
12 - 25
W4 - W8
Fig. 16 - Shapes of gauge rings
● At initial tightening, the boss at the end of the union nut
makes contact with the blade of the gauge ring, allowing you
to find from the feel and click sound that the initial tightening
has been completed.
● When the tightening limit of the fitting is reached, the base
will stop rotating and restrict the rotation of the union nut.
Note:
• The gauge ring is only applicable for the tubes of nominal sizes 6 to 25 and W2 to W8. For
the tubes of nominal sizes 3, 4, and W1, see Section 4.
4-2. Initial tightening (Nominal tube size: 6 - 25, W2 - W8)
• Insert the tube into which the sleeve has been inserted, into the main unit and then tighten it until the boss on the
union nut makes contact with the gauge ring and pulls the blade. Crunching sound should be heard (see Fig. 22).
• The use of the dedicated spanner allows you to more efficiently tighten the union nut (see Fig. 23 and Table 9).
Crunching sound
should be heard
Tighten the
union nut
Before tightening Initial tightening position
Crunching
sound
Tightening limit position
The bosses on the union nut
make contact with the gauge ring
Further tighten
the union nut
Fig. 17 - Initial tightening
Size Marking
Fig. 18 – Spanner for tightening the union nut
Table 7 - Spanner type
Nominal tube size
Millimeter size 6 8 10 12 19 25
Inch size W2, W2Y - W3, W3Y W4 W6 W8
Spanner type J-SN-6 J-SN-8 J-SN-10 J-SN-12 J-SN-19 J-SN-25
Size marking 6·W2 8 10·W3 12·W4 19·W6 25·W8
* Use type J-SN-6 spanner for color tube.
Manual No. 213
9

4-3. Removing and reinstallation (Nominal tube size: 6 - 25, W2 - W8, Color tube)
• To remove the installed fitting, loosen the union nut and then separate it from the main body. Manually hold the tube
and the main body, circularly move the tube, and then separate the sleeve from the main body.
• When reusing the removed fitting, do not disconnect the sleeve from the tube when removing the fitting.
• To install the removed fitting, insert the sleeve into the main body and then tighten until the gauge ring clicks again.
Even if the gauge ring clicks (in the position where the boss at the end of the union nut makes contact with the blade),
further hand-tighten the union nut so far as hand tightening is possible.
State in which
removal is complete
State in which the union
nut is loosened and then
separated from the main
bod
y
State in which
tightening is
com
p
lete
State in which the sleeve is
being separated from the
main body by circularly
movin
g
the tube
Trace of circular motions of tube: Start
with small circular motions and then
gradually make circular motions larger.
Fig. 19 - How to remove P series Super 300 Type Pillar Fitting (6 - 25, W2 - W8, Color tube)
Notes:
• In removing the fitting, circularly move the tube like first drawing small circles and then gradually
drawing larger circles (see Fig. 10).
If you greatly twist the tube to left or right or if you circularly moves the tube like suddenly
drawing large circles, then the sleeve may remain on the main body, hindering you from
retightening the tube.
• In reinstalling, do not damage the removed parts.
• Removal and reusing are acceptable up to 10 times. If this number of reusing times is exceeded,
replace the fitting. If the tightening limit is reached regardless of the number of reusing times,
replace the fitting immediately.
4-4. Measures against liquid leakage (Nominal tube size: 6 - 25, W2 - W8, Color tube)
• If the union nut needs to be retightened due to liquid leakage from the fitting, lower the temperature of the liquid to
30 °C (86 °F) or less and reduce the pressure to 0 MPaG (0 psiG); then retighten the union nut by turning it one
quarter-turn with a wrench. After retightening the union nut, check to be sure that the liquid no longer leaks from
the fitting.
• Note that, once liquid leakage occurs, the liquid may remain in the nut, resulting in the liquid exuding from the
fitting for a while even after retightening the union nut.
Safety Notices
The fitting is made of resin. Exercise great care to avoid bending or tensile
stress to the fitting when or after tightening it.
Doing so may deform or damage the fitting, causing the liquid to leak or the fitting to
uncouple from tubing.
CAUTION
Do not retighten the fitting while tubing is in high-temperature or pressurized
conditions.
Doing so may deform or damage the fitting, resulting in a spout of the liquid.
Before retightening the fitting, be sure to lower the temperature to 30 °C (86 °F) or
less and reduce the pressure to 0 MPaG (0 psiG).
Be sure to follow instructions in this manual when installing, retightening,
reinstalling the fitting.
Poor installation or retightening may cause the liquid to leak or the fitting to uncouple
from tubing.
Manual No. 213
10

5. Tightening (Nominal tube size: 3, 4, W1)
** Due to extremely small geometry, 3, 4mm and W1 (1/8”) fittings do not employ the integral gauge-
ring design used on all larger Super 300 fittings.
5-1. Cautions in tightening the union nut (Nominal tube size: 3, 4, W1, Color tube)
• The gap between the union nut and the fitting body serves as a criterion for proper tightening of the union nut. (Gap
specified for tightening control)
• The gap specified for tightening control has the upper and lower limits. Even if fittings have the same nominal size,
they are classified into the A-type and the B-type according to their shapes.
1) Upper limit ..... Represents the max. gap needed for the fitting to work well.
2) Lower limit ..... Represents the min. gap. When the gap is smaller than the lower limit, the fitting (with its union nut
and sleeve) needs to be replaced.
3) A Type ........... Applies to straight type (other than the fittings shown in table 8) injection-molded fittings and
machined PTFE fittings (see Fig. 20).
4) B Type ........... Applies to injection-molded fittings of elbow and Tee type (see Fig. 20).
Atype
A
Btype
B
Fig. 20 - Gaps as criterion for tightness check (3, 4, W1)
Table 8 - Fittings controlled with the B-type side of the gap gauge
Fitting shape
Elbow Tee
Fitting only (Note 1)
P-UE-3B
P-UE-4B
P-RUE 4-3B
P-UT-3B
P-UT-4B
P-RUT 4-3-4B
P-RUT 3-4-3B
Combination of fitting and
taper thread (Notes 1, 2)
P-ME 3-1B
P-ME 3-2B
P-ME 4-1B
P-ME 4-2B
P-MBT 3-1B
P-MBT 3-2B
P-MBT 4-1B
P-MBT 4-2B
Note 1: This is applicable even if “3” is changed to “W1” in the above table.
Note 2: This is applicable even if “1” or “2” representing the taper thread size is changed to
“
N
1” or “
N
2”
,
res
p
ectivel
y
.
Note:
• To check the gap, use gap gauges (feeler gauges) as shown in Section 5-2.
Manual No. 213
11

5-2. Checking the tightness of the union nut (Nominal tube size: 3, 4, W1)
• To check the tightness of the union nut, use gap gauges shown in Table 9. Using the gray part of gap gauges permits
you to check the gap for upper limit. The red part of gap gauges is for checking the gap for lower limit. Determine
whether or not a gap gauge can be inserted in the gap, as shown in Fig. 21.
(1) Checking the gap for upper limit:
As shown in Fig. 8, try to insert the gray part of the gap gauge in the gap between the fitting body and the union
nut to make sure the gray part cannot be inserted. If the gray part can be inserted, tighten the union nut until
the gauge cannot be inserted in the gap.
(2) Checking the gap for lower limit:
Try to insert the red part of the gap gauge in the same manner to mak sure the red part can be insertede . If the
red part cannot be inserted in the gap, the fitting has already exceeded its service life. Replace the fitting
immediately.
Atype Btype
A
A
B B
Gray part for checking
the gap for upper limit
Red part for checking
the gap for lower limit
Gauge type
Marking
Fig. 21 - How to use gap gauge (3, 4, W1)
）
Table 9 - Gap gauge type (3, 4, W1)
Nominal tube size
Gap gauge type Millimeter size Inch size
SSG-3(W1) 3 W1
SSG-4 4 -
Notes:
• Gap gauges are not supplied. They are available from Nippon Pillar Packing.
• The gap gages (for nominal tube size: 3, 4, and W1) are the same as those for the Super Type
Pillar Fittings.
5-3. Initial tightening (Nominal tube size: 3, 4, W1)
• Insert the tube with the inserted sleeve into the body of the fitting and then always tighten the union nut until the
gap between the union nut and the body becomes smaller than the upper limit.
Notes:
• It is recommended that you retighten the union nut 24 hours or more after initial tightening. This
is because a decrease in tightening torque due to a creep mostly occurs within 24 hours. If the
fitting is exposed to thermal cycles, it is also recommended that you retighten the union nut in a
cold state after one thermal cycle is completed.
• On the longer thread of the panel mount union, the gap cannot be used as a criterion for tightness.
In this case, tighten the union nut firmly by hand. For a special size tube where the gap cannot be
used as a criterion for tightness, tighten the union nut in the same manner.
Manual No. 213
12

5-4. Removing and reinstallation (Nominal tube size: 3, 4, W1)
• Loosen the union nut to remove the fitting.
• When removing the fitting and reinstalling it, do not uncouple the sleeve from the tube. Handle the tube and the
sleeve as an unit.
• When reinstall the fitting, tighten the union nut until the gap between the union nut and the fitting body
reaches the upper limit, and furthermore, turn the union nut a half-turn.
• The fitting resists ten times of reinstallation. If the gap between the union nut and the fitting body becomes
smaller than the lower limit, however, the fitting needs to be replaced even though it has not yet been reinstalled
ten times.
Caution:
• Do not damage the tube/sleeve and sealing surfaces of the fitting body when reinstalling the
fitting. Doing so may result in liquid leakage from the fitting.
5-5. Measures against liquid leakage (Nominal tube size: 3, 4, W1)
• If the union nut needs to be retightened due to liquid leakage from the fitting, lower the temperature of the liquid to
30 °C (86 °F) or less and reduce the pressure to 0 MPaG (0 psiG); then retighten the union nut by turning it one
quarter-turn with a wrench.After retightening the union nut, check to be sure that the liquid no longer leaks from the
fitting.
• Note that, once liquid leakage occurs, the liquid may remain in the nut, resulting in the liquid exuding from the
fitting for a while even after retightening the union nut.
Safety Notices
The fitting is made of resin. Exercise great care to avoid bending or tensile stress to the
fitting when or after tightening it.
Doing so may deform or damage the fitting, causing the liquid to leak or the fitting to uncouple
from tubing.
Do not retighten the fitting while tubing is in high-temperature or pressurized conditions.
Doing so may deform or damage the fitting, resulting in a spout of the liquid.
Before retightening the fitting, be sure to lower the temperature to 30 °C (86 °F) or less and
reduce the pressure to 0 MPaG (0 psiG).
CAUTION
Be sure to follow instructions in this manual when installing, retightening, reinstalling the fitting.
Poor installation or retightening may cause the liquid to leak or the fitting to uncouple from
tubing.
Manual No. 213
13

6. Dimensional tolerance of applicable tubes
• Table 10 shows the inside and outside diameters of nominal size tubes and their dimensional tolerances.
• Table 11 shows the inside and outside diameters of the color tube.
Table 10 - Dimensional tolerances of nominal size tubes
Units of inside/outside diameter and tolerance in mm
Nominal 3 4 6 8 10 12 19 25
O.D.×I.D. 3×2 4×3 6×4 8×6 10×8 12×10 19×15.8 25×22
O.D. tolerance ±0.1 ±0.1 ±0.1 ±0.12 ±0.12 ±0.12 ±0.12 ±0.2
Millimeter
size
Thickness
tolerance ±0.05 ±0.05 ±0.06 ±0.06 ±0.06 ±0.06 ±0.1 ±0.1
Nominal W1 W2 W3 W4 W6 W8
O.D.×I.D. 3.18×2.18 6.35×3.95 9.53×6.33 12.7×9.5 19×15.8 25.4×22.2
O.D. tolerance ±0.1 ±0.1 ±0.12 ±0.12 ±0.12 ±0.2
Inch size
Thickness
tolerance ±0.05 ±0.1 ±0.1 ±0.1 ±0.1 ±0.1
Nominal W2Y W3Y
O.D.×I.D. 6.35×4.35 9.53×7.53
O.D. tolerance ±0.1 ±0.12
Inch size
(Thin
wall)
Thickness
tolerance ±0.1 ±0.1
Remarks:
•
•
•
Body: in common use
with Super Type Pillar
Fitting
Nut: in common use with
Super Type Pillar Fitting
Sleeve: dedicated for P
Series Super 300 Type
Pillar Fitting
•
•
Body: in common use with J Series Super 300 Type Pillar Fitting
Nut: dedicated for P Series Super 300 Type Pillar Fitting
• Sleeve: dedicated for P Series Super 300 Type Pillar Fitting
Table 11 - Inside and outside diameter of color tube
Color tube
O.D.×I.D. 6.35×3.15
Manual No. 213
14

7. Disposal Precautions
• When disposing of fittings or tubes:
Be sure to wash the remaining liquid inside fittings or tubes and then dispose of them as incombustible waste.
Safety Notices
Do not dispose of the fitting with a liquid residue remaining in it.
Be sure to wash a liquid residue inside the fitting and then dispose of the
fitting as incombustible waste. Disposal of the fitting without washing a liquid
residue may be hazardous.
CAUTION Do not incinerate fitting parts.
Incineration of fluoro-resin parts will generate toxic smoke.
8. Office Locations
Head Office : 11-48, Nonakaminami 2 chome, Yodogawa-kul, Osaka, 532-0022 Japan
Tel : [phone] Fax : [phone]
Tokyo Office : 2-2, Uchisaiwaicho 2 chome, Chiyoda-ku, Tokyo, 100-0011 Japan
Tel : [phone] Fax : [phone]
U.S. Office : 1562 Parkway Loop, Suite 2-C, Tustin, California, 92780 USA
Tel : [phone] Fax : [phone]
Manual No. 213
15
