Pima RMC743 User manual

1
Wireless 2-Way Keyfob
Configuration and User Guide
Model: RMC743 / RMC786
Figure 1
Figure 1
Figure 2
1. Introduction
PIMA’s new Wireless 2-Way Keyfob / Remote Control combine the most
advanced technologies within a contemporary, compact and streamlined design,
the ideal choice for homeowners seeking the highest security standards. The
keyfob / remote control has been designed for use in family homes, apartments or
small offices. This accessory is easy to configure and is compatible with PIMA’s
FORCE and VISION intrusion systems.
How it works
The principal function of the Keyfob / Remote Control is to provide users with a
convenient way to control the security system. This accessory is easy to use with
large keys and is typically used for arming and disarming as well sending a
panic alarm to the system. Being bi-directional enables each command that is
sent to the panel to receive a reply status from the panel and indicate the status
to the user via the color LEDs. The Keyfob / Remote Control can be mounted on
a chain or worn as a pendant.
Main features
•Bi-directional wireless communication
•Simple battery replacement
2. Operation
Button
Pressed (0.5sec –2sec)
Hold (over 2sec)
Disarm
Disarm
Arm
Arm
Home
Home with entry delay canceled
Get status
Output toggle
+
-
Panic alarm
+
-
Enroll (see Configuration section)
3. Status LED Indications
The LED lights up after each press, indicating a successful signal transmission.
Operation
1st LED (Send
command)
2nd LED (Receive status)
Full Arm (Away)
Green
Red
Part Set (Home
Arm)
Green
Orange
Disarm
Green
Green
Alarm
Green
Blinks red
Low battery
Orange
-
UO (activation
Green
Blinks according to panel
status
4. Configuration
Enrollment the Keyfob / Remote Control to the receiver
The 2-Way Keyfob / Remote Control must be enrolled to the system receiver.
Enrollment can be done by entering the keyfob’s serial number into the system
or by using RF mode.
Auto Enrolling (using RF Communication):
1. Enter Installer menu, and select: System Configuration > Peripherals >
Wireless Peripherals > Enroll and delete > Keyfobs >Enroll >Auto Enrollment
2. Send an enrollment message by pressing the + keys for at least 2
seconds.
3. Select Enroll and press .
Manual Enrolling:
1. Enter Installer menu, and select:
System Configuration > Peripherals > Wireless Peripherals > Enroll and delete
> Keyfobs >Enroll >Manual Enrollment
2. Enter the serial number and press .
3. Select Enroll and press .
In both instances the system receiver will automatically recognize the Keyfob /
Remote Control and an enrollment message will sound. The LED on the Keyfob
/ Remote Control will blink.
Enrolling through the Force Manager Software:
You can enroll the keyfob using Force Manager software; For information refer
to the Force Manager Manual.
5. Cleaning and Maintenance
Cleaning the Keyfob / Remote Control
Clean the Keyfob / Remote Control with a dry or damp cloth to remove dirt or
dust. Do not expose the keys directly to liquid.
Replacing the Keyfob / Remote Control battery
1. Using a small screwdriver, twist to open the Keyfob / Remote Control (see
Figure 1).
2. Remove the old battery.
3. Press any one of the keys.
4. Insert the new battery (see Figure 2).
5. Close the Keyfob / Remote Control cover (see Figure 3).
Replace the batteries once a year or whenever the low battery LED indicates.
6. Technical Information
SPECIFICATIONS
Frequency:
433.92, 868.65 MHz
Battery Type:
CR2430, 3V lithium, 280 mA
Power Output
868.65MHz: 10 mW
Typical Battery Life:
4 years
Low Battery Threshold
2.5V
Quiescent Current Consumption
4 µA
Maximum Current Consumption
30 mA
Dimensions (H x W x D):
41 x 41 x 17 mm
(1.60 x 1.60 x 0.70“)
Operating temperature:
-10oC to 55 oC
(14 oF to 131 oF)
Average Relative Humidity
75%
Weight
20 gram (0.7 oz.)
Standards
EN50131-3 Grade 2,
Environmental Class II,
EN50131-6: Type C PD6662:2017
EN

2
7. Ordering Information
Model
Frequency
P/N
RMC743
433MHz
8843208
RMC786
868MHz
8843209
UKCA and CE RED Compliance Statement:
Hereby, PIMA declares that this equipment is in compliance with the essential requirements
of the UKCA Radio Equipment Regulations 2017 and CE Directive 2014/53/EU.
For the UKCA and CE Declaration of Conformity please refer to our website: www.pima-
alarms.com
Limited Warranty
PIMA Electronic Systems Ltd. does not represent that its product may not be compromised
and/or circumvented, or that the Product will prevent any death, personal and/or bodily
injury and/or damage to property resulting from burglary, robbery, fire or otherwise, or that
the Product will in all cases provide adequate warning or protection. The User understands
that a properly installed and maintained equipment may only reduce the risk of events such
as burglary, robbery, and fire without warning, but it is not insurance or a guarantee that
such will not occur or that there will be no death, personal damage and/or damage to
property as a result.
Read this guide in its entirety before attempting to program or operate your system. Should
you misunderstand any part of this guide, please contact the supplier or installer of this
system. Copyright © 2020 PIMA Electronic Systems Ltd. All rights reserved. E&OE
