Owner’s Manual and
Operating Instructions
Ceiling Mounted
Air Circulator
IMPORTANT: Read and understand all of the
directions in this manual before assembling,
starting or servicing the fan. Improper use of
this fan can cause serious injury. Keep this
manual for future reference.
This product meets and exceeds the require-
ments of OSHA 1910.212(a)(5), the standard
which regulates electric fan blade safety, and is
certified under UL# E234000, established and
made effective April 10, 2003, and updated
March 23, 2005, by Underwriters Laboratories,
Inc.
Table of Contents
Safety Information............................................2
Installation.........................................3
Maintenance and Storage...............................3
Exploded View..................................................4
Parts List..........................................................4
Troubleshooting................................................5
Warranty ..........................................................6

Page 2 Pinnacle Products International, Inc. Ceiling Mounted Air Circulator Owners’ Manual
Safety Information
WARNING:
1. This unit is designed for indoor use only. Do not expose to elements or allow to become
wet.
2. To guard against electric shock while operating, do not allow fan to come in contact with
other grounded objects such as pipes, radiators, etc.
3. To reduce the risk of electrical shock, do not use with any electronic components or solid
state speed control device.
4. Do not use to exhaust hazardous chemicals or use near any flammable liquids or gases as
sparks from motor may ignite fumes.
5. Operate only on 115 volt 60 Hz (cycle) current with a minimum of a 15 amp circuit.
6. Before operating always check fan for loose or damaged parts. Inspect power cord for any
damage. Never use fan if any parts are damaged or missing. Never use fan without safety
guards attached.
7. When used with an extension cord, use only cord of proper size (Amp rating), UL listed, and
with receptacle to accept three prong grounded plug furnished on the fan’s power cord.
Always keep power cord and extension cords away from heat, oil, and sharp edges. Inspect
cords periodically and replace if damaged.
8. Disconnect fan from power source when not in use, before servicing and when cleaning or
repairing.
9. Repair of this appliance should be done by a qualified electrician.
10. In case of power failure, turn fan off at switch to prevent unexpected restarting and
component damage.
11. Keep children away from fan at all times.
IMPORTANT: READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY,
SERVICE OR USE OF THIS FAN. FAILURE TO COMPLY WITH THESE
INSTRUCTIONS COULD RESULT IN SERIOUS PERSONAL INJURY AND / OR
PROPERTY DAMAGE.
Ceiling Mounted
Air Circulator
NEVER LEAVE A FAN
OPERATING UNATTENDED

Safety Cable Installation
1. Wrap one end of safety cables around beam and
pull through loop (figure 1).
2. Pull other end of safety cables down to sides of
fan (figure 2).
3. Open ends of safety cables and secure below
bolts where frame is atached to Supporter Frame
Assembly (figure 3).
Operation
This fan is equipped with a 2 speed control
switch.
To start fan:
1. Be sure the Power Switch is in the middle (OFF)
position.
2. Connect to an approved power source.
3. Make sure area is clear from all obstructions.
4. Push Power Switch to the LOW position and allow
to operate for 10 seconds.
5. Once 10 seconds have passed, you may now
push the Power Switch to the HIGH position.
To turn off the fan, simply return Power Switch to the
middle (OFF) position.
Note: For longer parts life, after 10 hours of con-
tinuous operation, turn fan off for 15 minutes to
allow motor and fan belt to cool.
Maintenance and Storage
1. Inspect your fan before each use. Check all wires
and extension cords, following the procedure out-
lined on Page 2 (Safety Information).
2. After use, always be sure fan’s Power Switch is
in the OFF position before unplugging.
Pinnacle Products International, Inc. Ceiling Mounted Air Circulator Owners’ Manual Page 3
figure 1
figure 2
figure 3
Ceiling Mounted
Air Circulator
NEVER LEAVE A FAN
OPERATING UNATTENDED

Replacement Parts
Page 4 Pinnacle Products International, Inc. Ceiling Mounted Air Circulator Owners’ Manual
figure 4:Exploded view of fan
Bill of Materials
Item # Description DDF-36CMA
1Front Guard 90-032-0100
2Rear Guard 90-032-0150
3Fan Blade Assy 90-003-4000
4 Motor 90-030-0600
5Ceiling Bracket 90-055-0100
6Ceiling Hanger Pipe Assy 90-055-0200
7 Frame 90-001-0900
8Power Switch 90-025-0100
9Power Cord 90-026-0050
10 Capacitor Assy 90-004-1600
11 Supporter Frame Assy 90-009-0300
12 Safety Cables 90-056-0200
13 Control Case 90-055-0500
14 Rubber Cap 90-056-0100
15 Level Bolt Holder Bracket 90-055-0400
Ceiling Mounted
Air Circulator
NEVER LEAVE A FAN
OPERATING UNATTENDED

Troubleshooting Guide
Problem Possible Cause Corrective Action
Fan does not operate 1. No power Inspect Power Cord for damage. Be sure
unit is plugged in and turned on.
2. Bad switch
Replace Power Switch (Note: To prolong
life of Power Switch, it is recommended
that the fan is first operated in LOW for 5-
10 seconds before switching to HIGH).
3. Bad motor Replace Motor.
Reduced Air Flow 1. Loose fan blade Tighten Fan Holder Hex Screw.
2. Obstructed airflow
Inspect back of fan to remove obstruction.
be sure back of fan has sufficient inflow of
air.
3. Motor is humming Capacitor is damaged. Replace Capacitor.
Excess Noise (vibration,
slapping, squealing) 1. Ceiling bracket is not tight. Turn off fan, and tighten Ceiling Bracket
bolts.
2. Loose fan blade Tighten Hex screw to tighten Fan Holder.
3. Defective motor bearings Replace Motor.
4. Defective fan bearings Replace Fan Bearings and Seals.
Pinnacle Products International, Inc. reserves the right to make any changes in materials,
specifications, prices or design without notice. Pinnacle Products International, Inc. may also
discontinue items at any time.
Pinnacle Products International, Inc. Ceiling Mounted Air Circulator Owners’ Manual Page 5
Specifications subject to change without notice
NEVER LEAVE A FAN
OPERATING UNATTENDED
Ceiling Mounted
Air Circulator
figure 5:Power Switch & Power Cord

1 YEAR LIMITED WARRANTY
Pinnacle Products International, Inc. warrants this
fan to the original retail purchaser only, to be free
from defects in material and workmanship for a peri-
od of one (1) year from the date of initial purchase.
This product must be properly installed, maintained
and operated in accordance with the instructions pro-
vided.
Pinnacle Products International, Inc. requires rea-
sonable proof of your date of purchase from an
authorized retailer or distributor. Therefore, you
should keep your sales slip, invoice, or cancelled
check from the original purchase. This Limited
Warranty shall be limited to the repair or replacement
of parts, which prove defective under normal use and
service within the warranty period, and which
Pinnacle Products International, Inc. shall deter-
mine at its reasonable discretion.
This warranty does not apply to products purchased
for rental use.
This Limited Warranty does not cover any failures or
operating difficulties due to normal wear and tear,
accident, abuse, misuse, alteration, misapplication,
improper installation or improper maintenance and
service by you or any third party. Failure to perform
normal and routine maintenance on the fan, shipping
damage, damage related to insects, birds, or animals
of any kind, and damage due to weather conditions
are also not covered. In addition, the Limited
Warranty does not cover damage to the finish, such
as scratches, dents, discoloration, rust or other
weather damage, after purchase.
All transportation costs for the return of the damaged
product or parts will be the responsibility of the pur-
chaser. Upon receipt of damaged item, Pinnacle
Products International, Inc. will examine the item
and determine if defective. Pinnacle Products
International, Inc. will repair or replace and return the
item, freight pre-paid. If Pinnacle Products
International, Inc. finds the item to be in normal
operating condition, or not defective, the item will be
returned freight collect.
This Limited Warranty is in lieu of all other express
warranties. Pinnacle Products International, Inc.
disclaims all warranties for products that are pur-
chased from sellers other than authorized retailers or
distributors.
AFTER THE PERIOD OF THE ONE (1) YEAR LIMIT-
ED WARRANTY EXPIRES, Pinnacle Products
International, Inc. DISCLAIMS ANY AND ALL
IMPLIED WARRANTIES, INCLUDING WITHOUT
LIMITATION THE IMPLIED WARRANTIES OF MER-
CHANTABILITY AND FITNESS FOR A PARTICULAR
APPLICATION. FURTHER, Pinnacle Products
International, Inc. SHALL HAVE NO LIABILITY
WHATSOEVER TO PURCHASER OR ANY THIRD
PARTY FOR ANY SPECIAL, INDIRECT, PUNITIVE,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
Pinnacle Products International, Inc. assumes no
responsibility for any defects caused by third parties.
This Limited Warranty gives the purchaser specific
legal rights; a purchaser may have other rights
depending upon where he or she lives. Some states
do not allow the exclusion or limitation of special,
incidental or consequential damages, or limitations
on how long a warranty lasts, so the above exclusion
and limitations may not apply to you.
Pinnacle Products International, Inc. does not
authorize any person or company to assume for it
any other obligation or liability in connection with the
sale, installation, use, removal, return, or replace-
ment of its equipment, and no such representations
are binding on Pinnacle Products International,
Inc.
Always be sure to specify model number and serial
number when making any claim with Pinnacle
Products International, Inc. For your convenience
use the space provided below to list this information:
Model #: ____________________
Serial #: ______________________
Date of Purchase: _________________
NEVER LEAVE A FAN
OPERATING UNATTENDED
Ceiling Mounted
Air Circulator
