Pioneer IKT-UVL32UL-AG User manual

UVC Bacterial Disinfection
for Ductless Mini-Split Systems
Owner’s Manual
Model Number: IKT-UVL32UL-AG
FREE
DISINFECTION SILENCE SANITIZATION RECYCLE SAFETYCLEAN AIR
ozoneozoneozone
UVUVUV
Specifications
•Input: AC 85-265V 50/60Hz
•Output: DC 12V 8W
•PF > 0.5, Tc < 176 ºF
•LED Input: 6.72W
•Current: 0.56A
•Voltage: 12V
Applicable for These Air System Types
Wall-Mount Floor-Ceiling
Cassette
1491.54 mm

The Contents of UVC Mini
Improves indoor air quality and fights biological contamination inside mini splits.
Prolonged exposure to direct LED UV light
may be harmful to eyes & skin.
This unit is equipped with an LED UV light disinfection system.
Disconnect power before servicing.
Indirect exposure (blue glow) is not harmful
CAUTION
UV LED LIGHT
K
K
UV LED Driver
RF Receiver (Optional)
RF Emitter (Optional)
LED UVC Strip
L
L
Screw
Ring Connector (Optional)
Adhesive Wire Base
Alcohol Wipe
Mounting Pads
Warning Sticker
Wired Switch (Optional)
UV Shield Strip
M
Manual
M
Only qualified persons should install this product
Install only in accordance with the relevant building code
Read instructions carefully, including the safety warnings
Operation Principles & Technology
X-RAYS ULTRAVIOLET VISIBLE LIGHT INFRARED
VAU UM-UV UV-C UV-B UV-A
100 200 280 315 400 700
UVC Radiation used for disinfection is most effective at a wavelength of 254nm.
The entire UV spectrum can wipe out or neutralize many microorganism
species, preventing them from replicating. UVC energy at 253.7 nanometers
provides the ideal germicidal effect. A combination of UVC + UVA is very
effective at disinfection as well as odor removal.
Scientific studies say:
When exposing microorganisms to
UVC light, the light penetrates through
their cell wall and disrupts the structure
of their DNA molecules, prohibiting
reproduction.
DNA Structure
UVC
Min i Kit s
Keep in Mind
Indirect exposure (blue glow)
is not harmful
Prolonged exposure to direct LED UV Light
may be harmful to eyes & skin
UVC
1491.54 mm

1491.54 mm
IMPORTANT!
Install LED strip so that the light shines into the air system, not into the room.
IMPORTANT!
Disconnect the power supply before you do anything on the installation!
Introduction to UVC Mini Kits
CAUTION UV LED LIGHT
Prolonged exposure to direct LED UV light may be harmful to eyes & skin.
Disconnect power before servicing. Indirect exposure (blue glow) is not harmful.
Cutaway View of Typical Installation of UVC MINI KITS in Mini Split
UVC MINI KITS are an innovative application of UV disinfection in Mini Splits
and other space-limited systems.
It is normally used to disinfect an air conditioning system, by halting any
bio-growth on fan, coils and other surfaces, and related bad odors. It helps
substantially to maintain a clean, fresh air conditioner system, improve the
indoor air quality, extends life span, and reduces maintenance cost.
Because space is tight and sufficient exposure of surfaces are required, the
UVC MINI KITS is best installed inside the supply vent with the light shining
onto the blower wheel (which is prone to contain concentrated mold growth).
Air System Preparation Before Installation
1. Remove the cabinet cover
Disconnect Power Supply
Detach filters
Dismantle the LED display assembly
Open the control box cover
2a. Detach drain pan to access
the area behind it.
2b. For systems with non-removable
drain pan, remove the louvers and
grills to access.
3. Unless not required, drill a 2/3 hole
to pass connector cable to the back.
(By the side of the control box)
UVC

1491.54 mm
Mounting the UVC LED Strip
1. Determine best location
Clean with cloth for any dust/dirt
Clean out with alcohol wipe
2. If needed, cut the strip into the length
that best ts into the space. (Cut-to-length
instruction is provided in this manual)
3.Pass the connector cable through
the drilled hole
3.Peel off paper from the adhesive
backing on the LED strip. Do this a
few at a time and press it down
firmly onto the clean surfaces.
Place the LED strip so the light will shine onto the blower wheel
Cut the strip only following the instructions by manufacturer
DON'T AIM THE UV LIGHT INTO THE ROOM
Install the Light Shield Strip
UVC light shield strip is designed by the manufacturer and recommended
to be installed with the UV LED strip. It is adhesive with a special material,
to shield these lights which may be exposed INTO THE ROOM.
To install, simply peel off the paper
from the adhesive side and stick
firmly to the UV LED strip, with an
angle of 90°, upright.
Electric Installation Preparation
Note:
Remote and wired control cannot be used
together
Mini Split
UV LED DRIVER
Input: 85-265 V~
Output: 12 Vac, 2A
Blue
Red
RF Receiver
RF Emitter
Remote Control
(Optional)
Wired Control
(Optional)
UVC LED Strip

1491.54 mm
Electrical Installation
1. Remove the control box cover and
connect the UV LED Driver power cable
with the following:
UV LED DRIVER
Blue Wire: “L”
Red Wire: “N”
Notice: UVC MINI KIT comes with a wide voltage 85-265VAC power supply.
2a. Connect the UV LED DRIVER cable connector to the strip directly, only
if the model is not equipped with either wired or remote controller.
Driver Cable LED Strip Cable
2b. If equipped with a wired control, connect the UV LED DRIVER cable to
one end of the wired control, and the other end to the UV LED Strip.
Driver Cable LED Strip Cable
Wired Control Cable
UV LED DRIVER
2c. If equipped with a wireless controller, connect the UV LED DRIVER cable
to one end of the RF receiver, and the other end to the UV LED Strip.
Driver Cable LED Strip Cable
RF Receiver
Electrical Installation
3. Tuck the power cable into the line chase
on the back of the unit or place it under the
control box or other secure location.
4. T urn on the power supply and confirm
that the UVC MINI KIT is working.
Or
a. Press once to
turn on/off
b. Long Press to
change strength
Press once
to turn on/off
5. Apply the UV Warning Sticker to a proper location.
Prolonged exposure to direct LED UV light
may be harmful to eyes & skin.
This unit is equipped with an LED UV light disinfection system.
Disconnect power before servicing.
Indirect exposure (blue glow) is not harmful
CAUTION
UV LED LIGHT

Benefits
Kits Include:
Features
■ Prevent mold and bacteria growth
■ Ensure a clean mini-split system
■ Extend life of a mini split system
■ Improve indoor air quality
■ Reduce maintenance cost
■ LED Strip (UVA/UVC)
■ LED Driver
■ Strip Cabinet
■ Bushing Block
■ Super compact / High intensity
■ Easy fit with simple installation
■ 85-265 VAC wide range power supply
■ Cut-to-length LED strip design
■ Water resistance / Heat dissipation
■ 50,000 hours+ expected LED life
■ Three years system warranty
■ Designed to fit major brands
■ For Wall-Mount, Floor-Ceiling & Cassette
EASY
INSTALLATION
UVC Bacterial Disinfection
for Ductless Mini-Split Systems
Prevents bio-growth & related odors
on fan, coil and other interior surfaces!
■ Adhesive Sticker
■ Hardware
■ User Manual
■ Cleaning Cloth
Parker Davis HVAC International, Inc.
3250 NW 107th Avenue
Doral, FL 33172
https://www.pdhvac.com
Phone: [phone]
Toll Free: [phone]
1491.54 mm
Cut-to-length Instruction
Concepts to know
UV Module Design
Actual Length = air outlet vent length
which determines the required actual "L".
One UV modular cycle is 10cm,
which includes UVC(1)+UVA(4)
End with bushing
First Cut Point(Most Recommended)
Cycle Point
Locate the best cutting point
Closed Elec. Cycle
1. Determine how long you need to cut.
10 cm is a LED Modular Cycle.
2. Cut from the end without the cable!
Take off the bushing and prepare to cut.
3. Cut from the rst cut point
(two copper n) if >=10cm.If < 10cm,
cut at the second point.
4. Seal the end with the bushing,
tightly, make sure not to wrinkle
the inner LED strip circuit.
Factory Pre-Cut Services are not available at this time.
