THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model No. Order No. Remarks
A-209R/MYXJ RRV2283
¶This service manual should be used together with the following manual(s):
STEREO AMPLIFIER
A-109
Type Model Power Requirement The voltage can be converted by
A-109 the following method.
MYXJ AC220-230V –––––
MVXJ AC220-230V –––––
MLXJ AC220-230V –––––
SBDXJ AC110V/120-127V/220V/240V With the voltage selector
CONTENTS
1. CONTRAST OF MISCELLANEOUS PARTS........2
2. SCHEMATIC DIAGRAM .......................................4
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

A-109
2
A-109/MYXJ, MVXJ, MLXJ, SBDXJ and A-209R/MYXJ are constructed the same except for the following :
1. CONTRAST OF MISCELLANEOUS PARTS
CONTRASTTABLE
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 101
47 x103
R50
1R0
561
473
5.62k RN1/4PC F562 x 1015621
Part No.
Ref. No. Mark Symbol and Description A-209R A-109 A-109 A-109 A-109 Remarks
/MYXJ /MYXJ /MVXJ /MLXJ /SBDXJ
PCB ASSEMBLIES
NSP CONTROL ASSY AWG7013 AWG7011 AWG7011 AWG7011 AWG7011
P5- 1 FRONT L ASSY AWX7123 AWX7120 AWX7120 AWX7120 AWX7120 ∗1
P5- 2 FRONT R ASSY AWX7124 AWX7121 AWX7121 AWX7121 AWX7121 ∗2
P5- 3 OPT ASSY AWX7125 Not used Not used Not used Not used
NSP AF COMPLEX ASSY AWM7357 AWM7353 AWM7353 AWM7353 AWM7509
P5- 4 AC PRIMARY ASSY AWX7113 AWX7113 AWX7113 AWX7113 AWX7670 ∗2
P5- 5 NSP HEADPHONE ASSY AWX7114 AWX7114 AWX7114 AWX7114 AWX7114
P5- 6 VOLUME ASSY AWX7118 AWX7112 AWX7112 AWX7112 AWX7112 ∗2
P5- 7 AF ASSY AWX7117 AWX7111 AWX7111 AWX7111 AWX7111 ∗1
PACKING SECTION
P3- 1 Operating Instructions (English) ARB7236 ARB7237 ARB7237 Not used Not used
P3- 2 Operating Instructions (German) ARC7322 ARC7324 Not used Not used Not used
P3- 3 Operating Instructions (French/Italian/ ARC7323 ARC7325 Not used Not used Not used
Dutch/Swedish/Spanish/Portuguese)
P3- 4 NSP Warranty Card ARY7022 ARY7022 ARY7022 Not used Not used
P3- 5 Remote Control Unit (CU-A019) AXD7193 Not used Not used Not used Not used
P3- 6 Battery Cover AZN2249 Not used Not used Not used Not used
P3- 7 NSP Dry Cell Battery (R6P,AA) VEM-013 Not used Not used Not used Not used
P3-11 Packing Case AHD7869 AHD7872 AHD7872 AHD7873 AHD7892
P3-14 Operating Instructions Not used Not used Not used ARE7269 ARE7269
(English/Spanish/Chinese)
P3-15 Caution Label 220V Not used Not used Not used Not used ARR1003
P3-16 AC Plug Adapter Not used Not used Not used Not used VKX1007
P3-17 NSP Air Cap Not used Not used AHG1087 Not used Not used
P3-18 Power Cord ADG1154 ADG1154 Not used ADG1154 ADG1154
P3-19 Power Cord with Fuse Not used Not used ADG1156 Not used Not used
P3-20 Fuse (T5A) Not used Not used AEK1046 Not used Not used
EXTERIOR SECTION
P5- 8 Fuse (FU1 : 1.25A) REK1023 Not used Not used Not used Not used
P5- 8 Fuse (FU1 : 800mA) Not used REK1021 REK1021 REK1021 Not used
P5- 8 Fuse (FU1 : 6.3A) Not used Not used Not used Not used REK1030
P5-11 Power Transformer (AC220-230V) ATS7190 ATS7192 ATS7192 ATS7192 Not used
P5-11 Power Transformer Not used Not used Not used Not used ATS7193
(AC110V/120-127V/220V/240V)
P5-13 Rear Panel ANC7925 ANC7931 ANC7931 ANC7933 ANC7934
P5-14 Insulator PNW2766 PNW2766 PNW2766 AMR7198 AMR7198
P5-25 NSP Shield Plate ANK7043 Not used Not used Not used Not used
P5-28 IR Filter AAK7532 Not used Not used Not used Not used
P5-38 Front Panel AMB7710 AMB7712 AMB7712 AMB7712 AMB7712
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

A-109
3
CONTRAST OF PCB ASSEMBLIES
AWX7111 and AWX7117 are constructed the same except for the following :
AF ASSY
F
D
Mark Symbol and Description Part No. Remarks
AWX7117 AWX7111
Q335, Q336 DTC143ES Not used
Q337, Q338 2SA1162 Not used
Q339, Q340 2SC2712 Not used
Q341 2SC5174P Not used
D341 UDZS5.1B Not used
D402 1SS355 Not used
D451 D5SBA20 D3SBA20
RY402 ASR7014 Not used
C301, C302, C305, C306 CEBA100M50 CEAT100M50
C307, 308 CEBA221M25 CEAT221M25
C334 CEANP221M16 Not used
C335, C336 CEAT100M50 Not used
C451 ACH7080 ∗1 ACH7082 ∗2∗1: 6800µF/42V
C452 ACH7081 ∗1 ACH7083 ∗2∗2: 4700µF/42V
C472 CKSQYF473Z50 Not used
R301, R302 RDR1/4VM240J Not used
R303, R304 RDR1/4VM561J Not used
R313, R314 Not used RS1/10S240J
R315, R316 Not used RS1/10S561J
R385–R388 RS1/10S473J Not used
R389, R390 RS1/10S471J Not used
R391, R392 RS1/10S102J Not used
R393 RS1/10S153J Not used
R460 RS1/10S2R2J Not used
401 SPEAKER TERMINAL AKE1011 ∗3 AKE1054 ∗4∗3: 8P, ∗4: 4P
HEAT SINK B ANH1021 Not used
JA401 REMOTE CONTROL JACK RKN1004 Not used
AWX7120 and AWX7123 are constructed the same except for the following :
FRONT L ASSY
F
E
Mark Symbol and Description Part No. Remarks
AWX7123 AWX7120
Q703, Q704 DTC124EK Not used
Q705 2SC2712 Not used
D702 Not used SLP9118C51H
D703, D705 SLP9118C51H Not used
D704 1SS355 Not used
S701 Not used VSG1009
S703, S704 VSG1009 Not used
R705 RS1/10S271J Not used
R708 RS1/10S472J Not used
R709 RS1/10S223J Not used
1603 3P CABLE HOLDER 51063-0305 Not used
J603 JUMPER WIRE DA15A03-100-2651 Not used
∗1 : Refer to “ 7CONTRAST OF PCB ASSEMBLIES ” and “ 2. SCHEMATIC DIAGRAM ”.
∗2 : Refer to A-209/SBDXJ on the service manual RRV2283.
Part No.
Ref. No. Mark Symbol and Description A-209R A-109 A-109 A-109 A-109 Remarks
/MYXJ /MYXJ /MVXJ /MLXJ /SBDXJ
P5-42 Voltage Selector (S2) Not used Not used Not used Not used AKX-507
P5-43 Fuse (FU2, FU3 : 800mA) Not used Not used Not used Not used REK1021
P5-44 PVC Cover Not used AAK7541 AAK7541 AAK7541 AAK7541
P5-45 Foot Not used REC1263 REC1263 REC1263 REC1263
