Operation Manual
NAVIGATION AV SYSTEM
AVIC-F910BT
AVIC-F710BT
AVIC-F9110BT
Be sure to read “Important Information for the user”first!
“Important Information for the user”includes the
important information that you must understand before
using this navigation system.
English

Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, keep this man-
ual in a safe place for future reference.
Important
The screens shown in the examples may differ
from actual screens.
Actual screens may be changed without notice
for performance and function improvements.
Introduction
Manual overview 8
–How to use this manual 8
–Terminology 8
–Definitions of terminology 8
Notice regarding video viewing 8
Notice regarding DVD-Video viewing 9
Notice regarding MP3 file usage 9
iPod compatibility 9
Map coverage 9
Protecting the LCD panel and screen 9
Notes on internal memory 10
–Before removing the vehicle
battery 10
–Data subject to erasure 10
–Resetting the microprocessor 10
Basic operation
Checking part names and functions 11
Inserting and ejecting a disc 12
–Inserting a disc 12
–Ejecting a disc 12
Inserting and ejecting an SD memory
card 12
–Inserting an SD memory card 13
–Ejecting an SD memory card 13
Plugging and unplugging a USB storage
device 13
–Plugging in a USB storage device 13
–Unplugging a USB storage device 13
Connecting and disconnecting an iPod 14
–Connecting your iPod 14
–Disconnecting your iPod 14
Flow from startup to termination 14
–On first-time startup 14
Regular startup 15
How to use the navigation menu
screens 16
–Screen switching overview 16
–What you can do on each menu 17
–Displaying the rear view camera
image 17
How to use the map 18
–How to read the map screen 18
–Switching the map mode 20
–Changing the scale of the map 20
–Scrolling the map to the position you
want to see 21
–Changing the tilt and rotation angle of
the map 21
The basic flow of creating your route 22
Operating list screens (e.g. city list) 22
Operating the on-screen keyboard 23
Searching for and selecting a location
Searching for a location by address 24
Searching for the vicinity Points of Interest
(POI) 26
–Searching for POIs around the
cursor 26
–Searching for a nearby POI 27
–Searching for POIs along the current
route 27
–Searching for POIs around the
destination 27
–Searching for POIs around the
address 27
–Using “Saved Criteria”27
Searching for POIs by using the data on
external storage devices (USB, SD) 30
Searching for a location by coordinates 30
Contents
Engb
2

Selecting a location you searched for
recently 32
–Deleting an entry in “History”32
Selecting a location stored in
“Favourites”32
–Deleting an entry in “Favourites”33
Setting up a route to your home 33
Setting a route by recalling a saved route 33
Searching for a location by scrolling the
map 34
After the location is decided (Map
Confirmation Screen)
What you can do with the “Map Confirmation
Screen”35
Route... 35
Save as... 36
Setting the location as a new destination 36
Setting the location as a waypoint 36
Replacing the location as the new final
destination 36
Setting the location as the start point 37
Viewing information about a specified
location 37
Placing a map pin on the location 37
–Removing a map pin 38
Registering the location as a customised
POI 38
Storing the location in “Favourites”39
Deleting an entry in “Favourites”39
Storing the position as a safety camera
location 39
Editing safety camera information 40
Checking the current route
Checking the current route conditions 41
–Playing simulated travel at high
speed 42
–Checking the entire route overview on
the map 42
Checking the current itinerary 42
Editing waypoints and the destination
Editing waypoints 44
–Adding a waypoint 44
–Sorting waypoints 44
–Deleting a waypoint 44
Storing the current route 44
–Deleting the entry in “Saved
Routes”45
Deleting the current route 45
Using traffic information
Viewing the traffic list 46
How to read traffic information on the
map 46
Setting the traffic information 46
Using hands-free phoning
Hands-free phoning overview 48
Preparing communication devices 48
Displaying the Phone Menu 48
Registering your mobile phone 48
–Searching for nearby phones 49
–Searching for a specified phone 49
–Pairing from your mobile phone 50
Connecting a registered mobile phone 51
–Disconnecting a mobile phone 51
–Deleting a registered phone 51
Receiving a phone call 52
–Answering an incoming call 52
–Rejecting an incoming call 52
Making a phone call 52
–Direct dialling 53
–Dialling from the history 53
–Calling a number in the “Contacts”
screen 54
–Dialling a phone number of the
POI 54
–Making a call home easily 54
Engb 3
Contents

Announcing incoming short mails 55
Transferring the phone book 55
Clearing memory 56
Setting the phone 56
–Setting the phone volume 56
–Stopping Bluetooth wave
transmission 57
–Answering a call automatically 57
–Setting the automatic rejection
function 57
–Echo cancelling and noise
reduction 57
–Setting automatic connection 58
–Editing the device name 58
Notes for hands-free phoning 58
Updating the Bluetooth wireless technology
software 59
Playing audio CDs
Reading the screen 61
Using the touch panel keys 61
Selecting a track from the list 62
Using the “Function”menu 62
Playing music files on ROM
Reading the screen 63
Using the touch panel keys 63
–Selecting a track from the list 64
–Browsing embedded text
information 64
Using the “Function”menu 65
Playing a DVD-Video
Reading the screen 66
Using the touch panel keys 66
–Resuming playback (Bookmark) 68
–Searching for a specific scene and
starting playback from a specified
time 68
–Direct number search 68
–Operating the DVD menu 68
–Frame-by-frame playback 69
–Slow motion playback 69
Using the “Function”menu 69
Playing a DVD-VR disc
Reading the screen 71
Using the touch panel keys 71
–Searching for a specific scene and
starting playback from a specified
time 72
–Switch the playback mode 73
–Using the short-time skip function 73
–Playing by selecting from the title
list 73
–Frame-by-frame playback 73
–Slow motion playback 73
Using the “Function”menu 74
Playing a DivX video
Reading the screen 75
Using the touch panel keys 75
–Frame-by-frame playback 76
–Slow motion playback 76
–Searching for a specific scene and
starting playback from a specified
time 76
Using the “Function”menu 77
DVD-Video, DVD-VR, DivX setup
Displaying DVD Setup menu 78
Setting the top-priority languages 78
Setting the angle icon display 78
Setting the aspect ratio 79
Setting the parental lock 79
–Setting the code number and level 79
Displaying your DivX VOD registration
code 80
Setting “Auto Play”80
Setting the subtitle file for DivX 80
Contents
Engb
4

Language code chart for DVDs 81
Playing music files (from USB or SD)
Starting procedure 82
Reading the screen 82
Using the touch panel keys (Music) 83
–Selecting a track from the list 84
–Browsing embedded text
information 84
Using the “Function”menu 84
Playing video files (from USB or SD)
Starting procedure 86
Reading the screen 86
Using the touch panel keys (Video) 87
–Searching for a specific scene and
starting playback from a specified
time 87
Using the “Function”menu 88
Using an iPod (iPod)
Starting procedure 89
Reading the screen 89
Using the touch panel keys (Music) 90
–Browsing for a song 90
Starting the video playback 91
Using the touch panel keys (Video) 92
–Browsing for a video 92
Using the “Function”menu 93
Using the radio (FM)
Reading the screen 95
Using the touch panel keys 95
–Switching between the detailed
information display and the preset list
display 96
–Storing and recalling broadcast
frequencies 96
–Using radio text 96
Using the “Function”menu 97
–Storing the strongest broadcast
frequencies 97
–Limiting stations to regional
programming 98
–Tuning in strong signals 98
–Searching for an RDS station by PTY
information 98
–Receiving traffic announcements 99
–Tuning into alternative frequencies 99
–Using news programme
interruption 100
–Interruption icon status (e.g. TRFC
icon) 100
–PTY list 101
Using the radio (AM)
Reading the screen 102
Using the touch panel keys 102
–Switching between the detailed
information display and the preset list
display 102
–Storing and recalling broadcast
frequencies 103
Using the “Function”menu 103
–Storing the strongest broadcast
frequencies 103
–Tuning in strong signals 103
Using AV input
Using AV1 105
Using AV2 105
Using the touch panel keys 105
Customising preferences
The options in the “Navi Settings”
menu 106
–Basic operations in the “Navi Settings”
menu 106
–GPS & Time Settings 106
–Time Settings 107
Engb 5
Contents

–POI Settings 108
–3D Settings 108
–Map Settings 108
–Displayed Info 109
–Smart Zoom 109
–Overview Mode 110
–Manage Track Logs 110
–Route 110
–Warnings 111
–Regional Settings 112
–Set Home 112
–Demo Mode 112
–Sound settings 113
–About 113
–POI display settings 114
–Creating new categories 114
–Editing your customised POI 115
–Recording your travel history 116
–Setting your home position 117
Options on the “System Settings”menu 118
–Displaying the “System Settings”
menu 118
–Selecting the language 118
–Changing the splash screen 119
–Setting the rear view camera 119
–Adjusting the response positions of the
touch panel (touch panel
calibration) 120
–Adjusting the screen brightness 120
–Setting the illumination colour 121
–Checking the version information 122
–Restore Factory Settings 122
–Turning off the screen 122
The “AV Sound Settings”menu options 122
–Displaying the “AV Sound Settings”
menu 122
–Using balance adjustment 123
–Using the equaliser 123
–Adjusting loudness 125
–Using subwoofer output 125
–Using the high pass filter 125
–Adjusting source levels 126
–Enhancing bass (Bass Booster) 126
Options on the “AV System Settings”
menu 126
–Displaying the “AV System Settings”
menu 126
–Setting video input 1 (AV1) 126
–Setting video input 2 (AV2) 127
–Switching the auto aerial setting 127
–Changing the wide screen mode 127
–Switching the sound muting/
attenuation 128
–Setting the rear output 128
–Switching Auto PI seek 128
–Setting the FM tuning step 129
Other functions
Setting the anti-theft function 130
–Setting the password 130
–Entering the password 130
–Deleting the password 130
–Forgotten passwords 130
Returning the navigation system to the
default or factory settings 131
–Setting items to be deleted 132
Appendix
Troubleshooting 134
Messages and how to react to them 139
Messages for audio functions 140
Positioning technology 142
–Positioning by GPS 142
–Positioning by “Dead Reckoning”142
–How do GPS and “Dead Reckoning”
work together? 142
Handling large errors 143
–When positioning by GPS is
impossible 143
Contents
Engb
6

–Conditions likely to cause noticeable
positioning errors 144
Route setting information 145
–Route search specifications 145
Handling and care of discs 147
–Built-in drive and care 147
–Ambient conditions for playing a
disc 147
Playable discs 148
–DVD-Video and CD 148
–AVCHD recorded discs 148
–Playing DualDisc 148
–Dolby Digital 148
–DTS sound 148
Detailed information for playable media 149
–Compatibility 149
–Media compatibility chart 152
Bluetooth 156
SD and SDHC logo 156
WMA 156
DivX 157
AAC 157
Detailed information regarding connectable
iPods 157
–iPod 157
–iPhone 158
–iTunes 158
Using the LCD screen correctly 158
–Handling the LCD screen 158
–Liquid crystal display (LCD)
screen 158
–Maintaining the LCD screen 158
–LED (light-emitting diode)
backlight 158
Display information 160
–Destination Menu 160
–Phone Menu 160
–Settings Menu 161
–Shortcut menu 163
–DVD Setup 164
Glossary 165
Specifications 168
Engb 7
Contents

Manual overview
Before using this product, be sure to read “Im-
portant Information for the user”(a separate
manual) which contains warnings, cautions,
and other important information that you
should note.
How to use this manual
Finding the operation procedure for
what you want to do
When you have decided what you want to do,
you can find the page you need from the
“Contents”.
Finding the operation procedure from
a menu name
If you want to check the meaning of an item
displayed on the screen, you will find the ne-
cessary page from the “Display information”at
the end of the manual.
Glossary
Use the glossary to find the meanings of
terms.
Terminology
Before moving on, take a few minutes to read
the following information about the conven-
tions used in this manual. Familiarity with
these conventions will help you greatly as you
learn how to use your new equipment.
!Buttons on your navigation system are de-
scribed in ALL CAPITAL,BOLD lettering:
e.g.)
MENU button, MAP button.
!Items in different menus, screen titles, and
functional components are described in
bold with double quotation marks “”:
e.g.)
“Destination Menu”screen or “AV
Source”screen
!Touch panel keys that are available on the
screen are described in bold in brackets [ ]:
e.g.)
[Destination], [Settings].
!Extra information, alternatives and other
notes are presented in the following for-
mat:
e.g.)
pIf the home location has not been stored
yet, set the location first.
!References are indicated like this:
e.g.)
=For details, refer to Setting your home
position on page 117.
Definitions of terminology
“Front Display”and “Rear Display”
In this manual, the screen that is attached to
the body of this navigation unit will be referred
to as the “Front Display”. Any additional op-
tional screen that is purchased for use in con-
junction with this navigation unit will be
referred to as the “Rear Display”.
“Video image”
“Video image”in this manual indicates mov-
ing images of DVD-Video, DivXâ, iPod, and any
equipment that is connected to this system
with an RCA cable, such as general-purpose
AV equipment.
“External storage device (USB, SD)”
The SD memory card, SDHC memory card
and USB memory device are collectively re-
ferred to as the “external storage device (USB,
SD)”. If it indicates the USB memory only, it is
referred to as the “USB storage device”.
Notice regarding video
viewing
Remember that use of this system for com-
mercial or public viewing purposes may con-
stitute an infringement on the author’s rights
as protected by the Copyright Law.
Introduction
Engb
8
Chapter
01

Notice regarding DVD-
Video viewing
This product incorporates copyright protection
technology that is protected by method claims
of certain U.S. patents and other intellectual
property rights owned by Macrovision
Corporation and other rights owners. Use of
this copyright protection technology must be
authorised by Macrovision Corporation, and is
intended for home and other limited viewing
uses only unless otherwise authorised by
Macrovision Corporation. Reverse engineering
or disassembly is prohibited.
Notice regarding MP3 file
usage
Supply of this navigation system conveys only
a licence for private, non-commercial use and
does not convey a licence nor imply any right
to use this product in any commercial (i.e. rev-
enue-generating), real time broadcasting (ter-
restrial, satellite, cable and/or any other
media), broadcasting/streaming via internet,
intranets and/or other networks or in other
electronic content distribution systems, such
as pay-audio or audio-on-demand applica-
tions. An independent licence for such use is
required. For details, please visit
http://www.mp3licensing.com.
iPod compatibility
This product supports only the following iPod
models and iPod software versions. Others
may not work correctly.
!iPod nano first generation; Ver. 1.3.1
!iPod nano second generation; Ver. 1.3.1
!iPod nano third generation; Ver. 1.1.3
!iPod nano fourth generation; Ver. 1.0.3
!iPod fifth generation; Ver. 1.3
!iPod classic; Ver. 2.0
!iPod touch first generation; Ver. 2.2
!iPod touch second generation; Ver. 2.2
!iPhone; Ver. 2.2
!iPhone 3G; Ver. 2.2
pIn this manual, iPod and iPhone will be re-
ferred to as iPod.
pWhen you use this navigation system with
a Pioneer USB interface cable for iPod (CD-
IU230V) (sold separately), you can control
an iPod compatible with this navigation
system.
pTo obtain maximum performance, we re-
commend that you use the latest software
for the iPod.
pOperation methods may vary depending on
the iPod models and the software version
of iPod.
pFor more details about iPod compatibility
with this navigation system, refer to the in-
formation on our website.
Map coverage
For more details about the map coverage of
this navigation system, refer to the information
on our website.
Protecting the LCD panel
and screen
pDo not allow direct sunlight to fall on the
LCD screen when this product is not being
used. Extended exposure to direct sunlight
can result in LCD screen malfunction due
to the resulting high temperatures.
pWhen using a mobile phone, keep the aer-
ial of the mobile phone away from the LCD
screen to prevent disruption of the video in
the form of spots, coloured stripes, etc.
pTo protect the LCD screen from damage, be
sure to touch the touch panel keys with
your finger and gently touch the screen.
Introduction
Engb 9
Chapter
01
Introduction

Notes on internal memory
Before removing the vehicle
battery
If the battery is disconnected or discharged,
the memory will be erased and must be repro-
grammed.
pSome data remains. Read Returning the na-
vigation system to the default or factory set-
tings before you operate this function.
=For more detailed information about the
items which would be erased, refer to
Returning the navigation system to the
default or factory settings on page 131.
Data subject to erasure
The information is erased by pressing the
RESET button or disconnecting the yellow lead
from the battery (or removing the battery it-
self). However, some items remain.
pSome data remains. Read Returning the na-
vigation system to the default or factory set-
tings before you operate this function.
=For more detailed information about the
items which would be erased, refer to
Returning the navigation system to the
default or factory settings on page 131.
Resetting the microprocessor
CAUTION
Pressing the RESET button clears the settings for
the AV source without clearing all the navigation
function items. Please refer to the related section
before clearing.
=For more detailed information about the items
which would be erased, refer to Returning the
navigation system to the default or factory set-
tings on page 131.
The microprocessor must be reset under the
following conditions:
!Prior to using this product for the first time
after installation.
!If the product fails to operate properly.
!If there appear to be problems with the op-
eration of the system.
!When changing the combination of equip-
ment.
!When adding/removing additional pro-
ducts that connect to the navigation sys-
tem.
!If your vehicle position is shown on the
map with a significant positioning error.
1 Turn the ignition switch OFF.
2 Press the RESET button with a pen tip
or other pointed implement.
RESET button
Introduction
Engb
10
Chapter
01

Checking part names and functions
This chapter gives information about the
names of the parts and the main features
using the buttons.
1Disc loading slot
Insert a disc to play.
=For details concerning operations, refer
to Inserting and ejecting a disc on the
next page.
2LCD screen
3EJECT button
4RESET button
=For details concerning operations, refer
to Resetting the microprocessor on the
previous page.
5MENU button
Press the MENU button to display the “Top
Menu”.
Press and hold the button when the “Top
Menu”is displayed. The “Screen Calibra-
tion”screen appears.
=For details concerning operations, refer
to Adjusting the response positions of the
touch panel (touch panel calibration) on
page 120.
6MAP button
Press to view the map screen.
Press and hold to display the “Picture Ad-
justment”screen.
=For details concerning operations, refer
to Adjusting the screen brightness on
page 120.
7MULTI-CONTROL
Rotating;
Adjusts the AV (Audio and Video) source vo-
lume.
Moving upward or downward once;
Changes the map scale one step at a time.
1234
5
6
7
8
9
a
Basic operation
Engb 11
Chapter
02
Basic operation

Keep moving upward or downward;
Changes the map scale continuously.
pThis operation is available only while the
map screen is displayed.
Moving MULTI-CONTROL to the left or
right;
Allows you to change the frequency one
step at a time; operates track search con-
trols.
Keep moving MULTI-CONTROL to the
left or right;
Allows you to perform manual seek tuning,
fast forward or reverse.
Pressing the centre of MULTI-CONTROL;
Allows you to hear the previous route gui-
dance.
pWhen your phone is paired to the naviga-
tion system, press the centre of MULTI-
CONTROL to answer an incoming call or
end the phone call.
Keep pressing the centre of MULTI-CON-
TROL;
Mutes the AV (Audio and Video) source. To
cancel the muting, press and hold it again.
8Bluetooth connection status indicator
Lights up when your phone is paired to the
navigation system by Bluetooth wireless
technology.
9“AV2”input jack
This is the “AV2”input terminal. Use the
CD-RM10 (sold separately) to connect the
external video component.
pTo connect your iPod by using USB inter-
face cable for iPod (CD-IU230V), use
“AV1”input (RCA) on the back of the
unit.
aSD card slot
=For more detailed information, refer to In-
serting and ejecting an SD memory card
on this page.
Inserting and ejecting a disc
Inserting a disc
%Insert a disc into the disc loading slot.
pDo not insert anything other than a disc
into the disc loading slot.
Ejecting a disc
%Press the EJECT button.
The disc is ejected.
Inserting and ejecting an
SD memory card
CAUTION
!Keep the dummy SD card out of the reach of
small children to prevent them from acciden-
tally swallowing it.
!To prevent data loss and damage to the sto-
rage device, never remove it from this naviga-
tion system while data is being transferred.
!If data loss or corruption occurs on the sto-
rage device for any reason, it is usually not
possible to recover the data. Pioneer accepts
no liability for damages, costs or expenses
arising from data loss or corruption.
Basic operation
Engb
12
Chapter
02

Inserting an SD memory card
%Insert an SD memory card into the SD
card slot.
Insert it with the contact surface facing to the
left and press the card until it clicks and com-
pletely locks.
pThis system is not compatible with Multi
Media Card (MMC).
pCompatibility with all SD memory cards is
not guaranteed.
pThis unit may not achieve optimum perfor-
mance with some SD memory cards.
pDo not insert anything other than SD mem-
ory cards or dummy SD cards into the SD
card slot.
Ejecting an SD memory card
1 Press the SD memory card until it clicks.
The SD memory card is ejected.
2 Pull out the SD memory card.
pInsert the dummy SD card to keep the SD
card slot free of dust when the SD memory
card is not inserted.
Plugging and unplugging a
USB storage device
CAUTION
!To prevent data loss and damage to the sto-
rage device, never remove it from this naviga-
tion system while data is being transferred.
!If data loss or corruption occurs on the sto-
rage device for any reason, it is usually not
possible to recover the data. Pioneer accepts
no liability for damages, costs or expenses
arising from data loss or corruption.
!Never remove the USB storage device immedi-
ately after plugging it. It may cause that the
navigation system cannot recognise the exter-
nal storage device (USB, SD).
Plugging in a USB storage device
%Plug a USB storage device into the USB
connector.
USB connector
USB storage device
pCompatibility with all USB storage device is
not guaranteed.
This navigation system may not achieve op-
timum performance with some USB sto-
rage devices.
pConnection via USB hub is not possible.
Unplugging a USB storage device
%Pull out the USB storage device after
checking that no data is being accessed.
Basic operation
Engb 13
Chapter
02
Basic operation

Connecting and
disconnecting an iPod
CAUTION
!To prevent data loss and damage to the sto-
rage device, never remove it from this naviga-
tion system while data is being transferred.
!If data loss or corruption occurs on the sto-
rage device for any reason, it is usually not
possible to recover the data. Pioneer accepts
no liability for damages, costs or expenses
arising from data loss or corruption.
Connecting your iPod
Using the USB interface cable for iPod en-
ables you to connect your iPod to the naviga-
tion system.
pA USB interface cable for iPod (CD-IU230V)
(sold separately) is required for connection.
1 Pull out the USB storage device after
checking that no data is being accessed.
To AV input on the back of the navigation system
USB connector USB interface cable for
iPod
pFor more details about iPod compatibility
with this navigation system, refer to the in-
formation on our website.
pConnection via USB hub is not possible.
2 Connect your iPod.
Disconnecting your iPod
%Pull out the USB interface cable for iPod
after checking that no data is being ac-
cessed.
Flow from startup to
termination
CAUTION
For safety reasons, the rear view camera function
is not available until the navigation system boots
up completely.
1 Start the engine to boot up the system.
After a short pause, the navigation splash
screen comes on for a few seconds.
2 Turn off the vehicle engine to termi-
nate the system.
The navigation system is also turned off.
On first-time startup
When you use the navigation system for the
first time, select the language that you want to
use.
1 Start the engine to boot up the system.
After a short pause, the navigation splash
screen comes on for a few seconds.
2 Touch the language that you want to
use on the screen.
Basic operation
Engb
14
Chapter
02

3 Touch the language that you want to
use for the voice guidance.
The navigation system will now restart.
4 Touch [Destination] to display Destina-
tion menu.
The disclaimer appears. Read the disclaimer
carefully, checking its details, and then touch
[OK] if you agree to the conditions.
The “Destination Menu”appears.
pWhen the system boots up, the vehicle’s an-
tenna may extend or turn on depending on
the setting. To retract the antenna, turn the
ignition switch off.
=For details, refer to Switching the auto aerial
setting on page 127.
Regular startup
CAUTION
For safety reasons, the rear view camera function
is not available until the navigation system boots
up completely.
%Start the engine to boot up the system.
After a short pause, the navigation splash
screen comes on for a few seconds.
pThe screen shown will differ depending on
the previous conditions.
pIf the navigation screen was shown pre-
viously, the disclaimer appears.
Read the disclaimer carefully, checking its
details, and then touch [OK] if you agree to
the conditions.
pIf other screens were shown previously, the
disclaimer screen will be skipped.
pIf the anti-theft function is activated, you
must enter your password. After unlocking
the navigation system, the “Top Menu”ap-
pears. If you enter the navigation screen
first, the disclaimer screen will appear.
Read the disclaimer carefully, checking its
details, and then touch [OK] if you agree to
the conditions.
Basic operation
Engb 15
Chapter
02
Basic operation

How to use the navigation menu screens
Screen switching overview
2
5
78
6
1
34
Basic operation
Engb
16
Chapter
02

What you can do on each menu
1Top Menu
Press the MENU button to display the “Top
Menu”.
This is the starting menu to access the desired
screens and operate the various functions.
2Destination Menu
You can search for your destination on this
menu. You can also check or cancel your set
route from this menu.
3Contacts screen
You can access the list of contacts to call up
an entry.
=For details, refer to Using hands-free
phoning.
4AV Source menu
You can access the screen for selecting the
audio and visual source to play.
5Phone Menu
You can access the screen that is related to
hands-free phoning to see call histories and
change the settings on the Bluetooth wireless
technology connection.
6Settings Menu
You can access the screen to customise set-
tings.
7Map screen
Press the MAP button to display the naviga-
tion map screen.
8AV operation screen
This is the screen that normally appears when
you play the AV source. Touching the icon on
the top left corner displays the “AV Source”
menu.
pTo return to the previous screen, touch
.
Displaying the rear view
camera image
[RearView] can be displayed the full-screen
rear view camera image. [RearView] is useful
if you want to monitor an attached trailer, etc.
=For details, refer to Setting the rear view
camera on page 119.
1 Press the MENU button to display the
“Top Menu”, and then touch [Settings].
2 Touch [System Settings] and then touch
[Back Camera].
3 Touch [On] next to “Camera”to acti-
vate the camera setting.
4 Press the MENU button to display the
“Top Menu”and then touch [AV Source].
5 Touch [RearView] on the “AV Source”
menu.
Basic operation
Engb 17
Chapter
02
Basic operation

How to use the map
Most of the information provided by your navigation system can be seen on the map. You need to be-
come familiar with how information appears on the map.
How to read the map screen
This example shows an example of a 2D map screen.
pInformation with the mark (*) appears only
when the route is set.
pDepending on the conditions and settings,
some items may not be displayed.
1Next direction of travel*
When you approach a guidance point, this ap-
pears in green. Touching this item enables
you to hear the previous guidance again.
pFor more information about the direc-
tion symbol, refer to Supplemental infor-
mation about directions on page 146.
2Distance to the guidance point*
Shows the distance to the next guidance
point.
3Name of the street to be used (or next gui-
dance point)*
4Current time
5Compass
The red arrow indicates north.
6Map mode selector
=For details, refer to Switching the map
mode on page 20.
7Shortcut to the
“Map Confirmation Screen”
Touching this shortcut enables the screen to
switch to the “Map Confirmation Screen”di-
rectly with the current position or the cursor
position centred.
=For details, refer to What you can do with
the “Map Confirmation Screen”on page
35.
8Stop key for the dummy run
Basic operation
Engb
18
Chapter
02

This key will be displayed while you activate
the dummy run (“Fly over”or “Demo
Mode”). Touch the key to cancel the dummy
run.
=For details, refer to Demo Mode on
page 112.
=For details, refer to Playing simulated tra-
vel at high speed on page 42.
9Album artwork on iPod
If you connect your iPod to this navigation sys-
tem, the artwork for the album that is playing
appears.
aShortcut to the AV operation screen
The AV Source currently selected is shown.
Touching the indicator displays the AV opera-
tion screen of the current source directly.
bExtension tab for the AV information bar
Touching this tab opens the AV information
bar and enables you to briefly view the current
status on the AV source. Touching it again re-
tracts the bar.
cCurrent route*
The route currently set is highlighted in bright
colour on the map. If a waypoint is set on the
route, the route after the next waypoint is
highlighted in another colour.
dCurrent position
Indicates the current location of your vehicle.
The apex of the triangular mark indicates your
orientation and the display moves automati-
cally as you drive.
pThe apex of the triangular mark is the
proper current position.
eStreet name (or city name) that your vehi-
cle is travelling along
fMulti-Info window
Shows the value on the items selected on
“Displayed Info”. Touching this area allows
you to display the “Route Information”
screen.
=For details, refer to Displayed Info on
page 109.
=For details, refer to Checking the current
route conditions on page 41.
pThis item is not shown when “Full
Screen Map”is set to “On”.
=For details, refer to Map Settings on
page 108.
pThe estimated time of arrival is an ideal
value that the navigation system com-
putes internally as the route is calcu-
lated. The estimated time of arrival
should be read just as a reference value,
and does not guarantee arrival at the
time indicated.
gMap scale
The scale of the map is indicated by distance.
hSecond Manoeuvre Arrow*
Shows the turning direction after next and the
distance to there.
pThis item is not shown when “Full
Screen Map”is set to “On”.
=For details, refer to Map Settings on
page 108.
Meaning of guidance flags
: Destination
The checkered flag indicates your
destination.
: Waypoint
The yellow flags indicate your way-
points.
: Start point
The bright green flag indicates
your start point.
Signpost and recommended lane
Signposts will appear together with the recom-
mended lane where multi-lane roads exist
when you are driving on your route. The high-
lighted lane indicates the recommended lane.
Basic operation
Engb 19
Chapter
02
Basic operation

pThis information is based on the map data-
base. Thus, the information may differ from
actual conditions. Use it as just a direc-
tional reference for your driving.
Note regarding the route highlighted
in purple
pA route highlighted in purple on the map
indicates that your route includes a road
not matching your preference on the fol-
lowing settings in “Route”;“Unpaved
Roads”,“Motorways”,“Ferries”,“U-
turns”,“Permit Needed”,“Toll Roads”.
For your safety, please review and obey all
local traffic rules along the highlighted
route.
Switching the map mode
There are a number of map displays.
Touching the map mode selector allows you to
change the map display.
Map mode selector
2D map screen (Heading up mode)
The map display always shows the vehicle’s di-
rection as proceeding toward the top of the
screen.
When “Heading up”mode is selected, is
displayed.
2D map screen (North up mode)
The map display always has north at the top of
the screen.
When “North up”mode is selected, is dis-
played.
3D map screen
When the 3D map screen is selected, is
displayed.
1 Press the MAP button to display the na-
vigation map screen.
2 Touch the map mode selector to switch
the map display.
Each touch of the map mode selector changes
the map display as follows:
2D map screen (Heading up mode) —2D map
screen (North up mode) —3D map screen
Changing the scale of the map
1 Press the MAP button to display the na-
vigation map screen.
Basic operation
Engb
20
Chapter
02
