Pioneer AVIC-Z1000D11-CHU User manual

Installation guide for :
- AVIC-Z1000D11-CHU
- AVIC-Z1000D12-C
- AVIC-Z1000D16-C
Installation kit - metal brackets, plastic facia
and rotary command keys
Interface
Depending on the kit, the interface may look different
Original dashboard setup
Remove the two storage pockets
Remove four screws using a T20 screwdriver
Keep them a side for later
Remove the original frame from the dashboard
Remove the airvents left an right by pulling
They are attached with two pins
Pioneer installation manual - Fiat Ducato 8 - v1.03
Fiat Ducato model year ’21 - Open dash only





Slide the Pioneer unit into the facia panel Mount the left and right metal bracket to the
Pioneer unit and plastic trim
Remove two screws at the bottom of
the tacho visor
Remove the tacho visor
It is still secured with clips
Remove two screws from the tachometer Remove the connector by sliding the red tab
away from the cables
Pioneer installation manual - Fiat Ducato 8 - v1.03






! Steps 7 to 18 are only for AVIC-Z1000D11-CHU kits with a head up display !

Cut the cable tie and slide the cables out
towards the bottom
Remove the blue and white cable from the
connector by pressing with a small screwdriver
Insert the two pins in the supplied plug
Press the cover to lock the pins
Install the blue and white cable from the
interface in the tacho connector (pos. 4 & 5)
Slide the cables back into the main housing
and secure with new cable tie or electric tape
Connect back to the tacho and to the interface
Pioneer installation manual - Fiat Ducato 8 - v1.03








Install and connect the head up display
onto the new tacho visor
Install the visor with head up display and
secure with the orignal screws
Open the fusebox underneath
the steering column
Locate the green and black connector and
remove them
Open the green connector and
slide the cables out
Connect the violet/white cable (reverse signal)
to the white/blue cable in pin seventeen.
Pioneer installation manual - Fiat Ducato 8 - v1.03






! Steps 19 to 24 are only for AVIC-Z1000D12-C & AVIC-Z1000D16-C kits !

Open the black connector and
slide the cables out
Insert the pink cable pin (speedpulse)
to the open position twenty-two (22)
Connect the main harness
Make sure to use the GREY connector
!Use top plug for steering wheel controls (W/R)!
DO NOT USE THE ORANGE CONNECTOR
See the warning label on the interface
Connect battery and accessory power to the
main harness of the unit
Put the cable for the rotary commander
through the side opening of the panel
Pioneer installation manual - Fiat Ducato 8 - v1.03






! Steps 25 & 26 are only for AVIC-Z1000D12-C & AVIC-Z1000D11-CHU kits !
! Step 27 is only for AVIC-Z100016-C !

Slide the unit in the dashboard and
secure with the originals screws
Reinstall the airvents with the rotary
command cable still outside
Connect the rotary command and slide
it upwards into the panel
Secure with small screw in
the opening on the side
Put the plastic cover over in the screw opening Final result
