Pioneer DV-K101 User manual

ORDER NO.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER ELECTRONIC CORPORATION 1999
c
DV-K101 (1)
RRV2088
T – IZE JAN. 1999 Printed in Japan
DVD PLAYER
1. SAFETY INFORMATION...................................... 2
2. EXPLODED VIEWS AND PARTS LIST................ 3
3. SCHEMATIC DIAGRAM ..................................... 10
4. PCB CONNECTION DIAGRAM.......................... 25
5. PCB PARTS LIST ............................................... 35
6. ADJUSTMENT .................................................... 40
CONTENTS 7. GENERAL INFORMATION ................................ 42
7.1 IC .................................................................. 42
7.2 DISASSEMBLY ............................................ 46
7.3 BLOCK DIAGRAM........................................ 47
8. PANEL FACILITIES AND SPECIFICATIONS.... 48
Refer to the service guide RRV2004 for DV-515.
DVDPLAYER
DV-K101
1 2 3 4 5 6 7 8 9 0 +
10
PLAYBACK ONE-TOUCH KARAOKE
CONTROL KARAOKE MODE
ON/OFF
OPEN/CLOSE
STANDBY
MIN MAX MIN MAX MIN MAX MICCONTROL PREVIOUS NEXT
RETURN SELECT
STOP PLAY PAUSE
STANDBY/ON
LOW CONTROL HIGH
KEY
ECHO MIC1 MIC2 MIC 1 MIC2
DIGITALVIDEO
MC
Type Model Power Requirement Region No.
DV-K101 (1)
RL/2 AC110-127V / 220-240V Automatic select 3
RAM/2 AC110-127V / 220-240V Automatic select 6
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
The Voltage can be converted by the
following method.
DV-K101 has two models which specifications are different.
Each distinction will be confirmed with the indication of
the rear panel. Refer to the following service manuals.
Indication of Rear Panel Service Manual No.
DV-K101 RRV1942
DV-K101 (1) RRV2088 (this manual)

2
DV-K101 (1)
LABEL CHECK
IMPORTANT
THIS PIONEER APPARATUS CONTAINS
LASER OF CLASS 1.
SERVICING OPERATION OF THE APPARATUS
SHOULD BE DONE BY A SPECIALLY
INSTRUCTED PERSON.
LASER DIODE CHARACTERISTICS
MAXIMUM OUTPUT POWER : 7 mW
WAVELENGTH : 650 nm
Additional Laser Caution
1. Inside detection switch (S201 on the INSB assy) and loading-
status detection switch (S301 on the LOSB assy) are detected
by the microprocessor (IC501 in the DVDM assy).
• To permit the laser diode to oscillate, it is required to set the
inside detection switch for the inside position (S201 : ON) and to
set the loading-status detection switch for the clamp position (the
center terminal of S301 is shorted to +5V). The laser diode
oscillation will continue if pin 13 of IC101 is shorted to +5V (fault
condition) in the DVDM assy.
In the test mode ∗, the laser diode oscillates when microproces-
sor detects a PLAY signal, or when the PLAY key is pressed
(S106 ON in the FLKY assy), with the above requirements satis-
fied.
2. When the cover is open, close viewing through the objective lens
with the naked eye will cause exposure to the laser beam.
∗: Refer to the service guide RRV2004.
(Printed on the Rear Panel)
1. SAFETY INFORMATION
This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to cause
cancer, birth defects or other reproductive harm. Health & Safety Code Section 25249.6 – Proposition 65

DV-K101 (1)
3
Mark No. Symbol and Description Part No. Remarks
RL/2 Type RAM/2 Type
1 Power Cord ADG1127 ADG7017
6 Operating Instructions (Trad-Chinese) VRC1087 Not used
6 Operating Instructions (Simp-Chinese) Not used VRC1086
NSP 7 Regular User’s Card Not used VRY1112
14 Packing Case VHG1751 VHG1741
NSP 15 Warranty Card PJ Not used ARY7029
(1) PACKING PARTS LIST
1 Power Cord See Contrast table (2)
2 Video Cord (L=1.5m) VDE1048
3 Audio Cord (L=1.5m) VDE1033
NSP 4 Dry Cell Battery (R6P, AA) VEM-013
5 Operating Instructions VRB1213
(English)
6 Operating Instructions See Contrast table (2)
NSP 7 Regular User’s Card See Contrast table (2)
8 Polyethylene Bag Z21-038
(230×340×0.03)
9 Remote Control Unit VXX2576
(CU-DV020)
10 Battery Cover VNK3703
11 Pad F VHA1220
12 Pad R VHA1221
13 Mirror Mat Sheet Z23-007
(750×600×0.5)
14 Packing Case See Contrast table (2)
NSP 15 Warranty Card PJ See Contrast table (2)
2.1 PACKING
2. EXPLODED VIEWS AND PARTS LIST
NOTES: •Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
•The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
•Screws adjacent to mark on the product are used for disassembly.
Mark No. Description Part No.
FRONT
8
7
6
5
RAM/2 Type Only
15
8
10
9
3
14
4
2
1
11 12
13
(2) CONTRAST TABLE
DV-K101/RL/2 and RAM/2 are constructed the same except for the following :

DV-K101 (1)
4
25
4
3
10
11
Refer to
"2.3 FRONT PANEL SECTION".
10
8
9
7
6
11
14 13
12
15
16
1
18
17
RL/2 Type
Only
2.2 EXTERIOR SECTION
1 Bonnet Case S VXX2620
2 Tray Panel VNK4158
3 DVD Plate VAM1080
4 Tray Panel Plate VNK4273
NSP 5 Getter VRW1730
6 Tray VNL1731
7 Tray Stopper VNL1739
8 Spring VBH1277
9 Tray Label VRW1628
10 Screw IBZ30P080FMC
11 Screw BCZ40P060FNI
12 Clamper Plate VNE2068
13 Bridge VNE2069
14 Clamper VNL1738
15 Screw BPZ26P080FZK
16 Screw BBZ30P080FMC
17 Power Button See Contrast table (2)
18 Power Button Joint See Contrast table (2)
(1) EXTERIOR SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
Mark No. Symbol and Description Part No. Remarks
RL/2 Type RAM/2 Type
17 Power Button VNK4159 Not used
18 Power Button Joint VNK4267 Not used
(2) CONTRAST TABLE
DV-K101/RL/2 and RAM/2 are constructed the same except for the following :

DV-K101 (1)
5
2.3 FRONT PANEL SECTION
1 FLKY Assy See Contrast table (2)
NSP 2 PWSB Assy See Contrast table (2)
3 KYLB Assy VWG2019
4 Front Panel See Contrast table (2)
5 FL Lens VNK4272
6 Name Plate VAM1067
7 LED Lens PNW2019
8 Main Key VNK4269
9 11 Key VNK4271
10 MICB Assy VWV1664
11 FL Filter VEC1643
12 Illumination Lens VNK4264
13 Illumination Filter VEC1983
14 Illumination Holder VNK4265
15 Flexible Cable (14P) VDA1646
(FLKY CN101 ↔DVDM CN602)
16 Screw BBZ30P080FMC
17 • • • • •
18 Volume Knob VNK4279
19 3 Key VNK4270
20 Light Key VNK4261
21 Earth Plate VBK1075
22 Power Button See Contrast table (2)
23 Lens Holder VNK4266
(1) FRONT PANEL SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
Mark No. Symbol and Description Part No. Remarks
RL/2 Type RAM/2 Type
1 FLKY Assy VWG2024 VWG2023
NSP 2 PWSB Assy VWG2021 VWG2020
4 Front Panel VNK4257 VNK4255
22 Power Button Not used VNK4059
(2) CONTRAST TABLE
DV-K101/RL/2 and RAM/2 are constructed the same except for the following :
6
47
23
19(1/2)
8
15
3
1
16
10
14
11
13
12
5
16
216
918
20
16
22
RAM/2 Type Only
21
19(2/2)

DV-K101 (1)
6
2.4 BOTTOM VIEW SECTION
2
24
45
1
611
12
418
710
10
8
13
23
4
3
21
20
19
15
14
16
Refer to
"2.5 LOADING MECHANISM ASSY".
444
4
44
4
94
9
4
4
4
22
25
4
27
26
7
RAM/2 Type
Only
RL/2 Type Only
28

DV-K101 (1)
7
NSP 1 Base Chassis See Contrast table (2)
2 Insulator PNW2766
3 Insulator Assy (F) VXA1680
4 Screw BBZ30P080FMC
5 Screw BBZ30P180FMC
6 POWER SUPPLY Assy VWR1306
NSP 7 PCB Holder PNW2100
8 Flat Cable Clip VEC2018
NSP 9 Cord Stopper ZCB-069Z
NSP 10 PCB Holder VNE2122
11 DVDM Assy VWS1368
12 KGJB Assy See Contrast table (2)
13 Rear Panel See Contrast table (2)
NSP 14 Loading Mechanism Assy VWT1157
15 Screw BBZ30P100FMC
16 Flexible Cable (12P) VDA1692
(LOSB CN301 ↔DVDM CN1030)
17 • • • • •
18 Flexible Cable (26P) VDA1689
(POWER SUPPLY CN103 ↔DVDM CN110)
19 Flexible Cable (26P) VDA1695
(KGJB CN901 ↔DVDM CN9020)
20 Flexible Cable (18P) VDA1709
(KGJB CN501 ↔DVDM CN9032)
21 Flexible Cable (9P) VDA1714
(KGJB CN401 ↔MICB CN402)
22 Rivet AEC-525
NSP 23 Card Spacer DEC1770
NSP 24 Filter Cushion VEC1287
25 Sheet VEC2000
26 MSWB Assy See Contrast table (2)
NSP 27 Housing Assy See Contrast table (2)
NSp 28 Housing Assy See Contrast table (2)
(1) BOTTOM VIEW SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
Mark No. Symbol and Description Part No. Remarks
RL/2 Type RAM/2 Type
NSP 1 Base Chassis VNA1998 VNA1981
12 KGJB Assy VWV1657 VWV1649
13 Rear Panel VNA2048 VNA2036
26 MSWB Assy VWG2001 Not used
NSP 27 Housing Assy VKP2160 Not used
NSP 28 Housing Assy Not used VKP2189
(2) CONTRAST TABLE
DV-K101/RL/2 and RAM/2 are constructed the same except for the following :

DV-K101 (1)
8
LOADING MECHANISM ASSY PARTS LIST
2.5 LOADING MECHANISM ASSY
11
13
12 14
15
16
8
7
17
9
10
18
2
3
4
5
6
1
•Top View •Bottom View
Refer to
"2.6 SERVO MECHANISM
ASSY"
19
20
1 Servo Mechanism Assy-S VXX2606
2 Screw DBA1006
3 Drive Cam VNL1736
4 Drive Gear VNL1735
5 Lock Plate VNL1820
6 Loading Base VNL1730
7 Belt VEB1260
8 Gear Pulley VNL1733
NSP 9 LOSB Assy VWG1885
10 Loading Gear VNL1734
11 Loading Motor Assy VXX2505
12 DC Motor / 0.3W PXM1027
13 Motor Pulley PNW1634
NSP 14 LOMB Assy VWG1886
15 Connector Assy VKP2198
(LOMB CN401 ↔LOSB CN306)
16 Screw VBA1055
17 Screw Z39-019
18 Flexible Cable (08P) VDA1698
(LOSB CN303 ↔SMEB CN202)
19 Float Base VNL1815
20 Floating Rubber VEB1286
Mark No. Description Part No. Mark No. Description Part No.

DV-K101 (1)
9
NSP 1 SMEB Assy VWG1968
NSP 2 FGSB Assy VWG2009
3 Motor VXM1074
4 Motor VXM1075
5 Pickup Assy VWY1050
6 Table Sheet DEC2040
7 Screw VBA1058
8 Centering Spring VBH1278
9 Hook Spring VBH1291
10 Skew Spring VBH1303
11 Gear Spring VBH1308
NSP 12 Reflected Sheet VEC1959
13 Guide Bar VLL1504
14 Sub-guide Bar VLL1505
15 Hold Spring VNC1017
NSP 16 Magnet Holder VNE2070
NSP 17 Motor Base VNE2154
NSP 18 Cover VNE2155
19 Centering Ring VNL1746
NSP 20 Disc Table VNL1747
2.6 SERVO MECHANISM ASSY
21 Hook VNL1770
22 FFC Holder VNL1802
23 Mechanism Base VNL1806
24 FG Holder VNL1807
25 Gear A VNL1808
26 Gear B VNL1809
27 Gear C VNL1810
28 Slider VNL1811
29 Gear D VNL1814
NSP 30 Magnet VYM1024
31 Screw JFZ17P025FZK
32 Screw JGZ17P028FMC
33 Screw VBA1051
34 Magnet Holder Assy VXX2507
35 Spindle Motor Assy VXX2604
36 Carriage Motor Assy VXX2605
37 Precision Screw PBA1069
38 Flexible Cable (24P) VDA1701
(DVDM CN120 ↔Pickup Assy)
•Top View
30
16 34
19
8
15 10
10
22
33
23
5
14 10
37
18 32
13
10
38
37
18
26
25
27
29
7
7
73
1
11
28
33
6
35
20
12
21
4
9
31
37
17
24
37
36
2
SERVO MECHANISM ASSY PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.

DV-K101 (1)
10
A
B
C
D
1234
1234
1/2, 2/2
KGJB ASSY
(RL/2 TYPE : VWV1657)
(RAM/2 TYPE : VWV1649)
J J J
E
HMICB ASSY
(VWV1664)
FRPB ASSY
(RL/2 TYPE : VWM1891)
(RAM/2 TYPE : VWM1890)
TV SYSTEM
AUTO
PAL
NTSC
FLKY ASSY
(RL/2 TYPE : VWG2024)
(RAM/2 TYPE : VWG2023)
G
KYLB ASSY
(VWG2019)
F
PWSB ASSY
(RL/2 TYPE : VWG2021)
(RAM/2 TYPE : VWG2020)
JA601
3. SCHEMATIC DIAGRAM
3.1 OVERALL CONNECTION DIAGRAM, LOMB, LOSB, SMEB and FGSB
ASSEMBLIES

DV-K101 (1)
11
A
B
C
D
5678
5678
D
Note :When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST".
1/3 3/3
DVDM ASSY
(VWS1368)
I
I I
LOMB ASSY
(VWG1886)
A
LOSB ASSY
(VWG1885)
BSMEB ASSY
(VWG1968)
C
LOADING MOTOR
ASSY :VXX2505
SPINDLE MOTOR
ASSY : VXX2604
CARRIAGE
MOTOR ASSY :
VXX2605
CN401
B2B-PH-K-S
CN303
B2B-PH-K-S
S301 S201
VKN1272
CN301 VKN1268 VKN1212
(S)
(S)
(S)
(S)
(S)
(S)
CN302
FGSB ASSY
(VWG2009)
D
PC101
TLP910(O)
R101
680
CN201
52044-0345
PICKUP ASSY
(VWY1050)
: RF SIGNAL ROUTE
: FOCUS SERVO LOOP LINE
: TRACKING SERVO LOOP LINE
(F)
(T)
: SLIDER SERVO LOOP LINE
(S)
(F)
(F)
(F)
(F)
(F)
(F)
(T)
(T)
(T)
(T)
POWER SUPPLY
ASSY
(VWR1306)
K
MSWB ASSY
(VWG2001)
L
AC110-127V/220-240V
50/60Hz
CN2
CN10
RL/2 TYPE ONLY
RAM/2 TYPE ONLY
AC POWER CORD
RL/2 TYPE : ADG7021
RAM/2 TYPE : ADG7017
FOR RS232C
CBA

DV-K101 (1)
12
A
B
C
D
1234
1234
3.2 FLKY, PWSB, KYLB and MICB ASSEMBLIES
E
FLKY ASSY
(RL/2 TYPE : VWG2024)
(RAM/2 TYPE : VWG2023)
G
H
KYLB ASSY
(VWG2019)
MICB ASSY
(VWV1664)
CN401
1/2
J
CN602
2/3
I
[LAMP]
(GNDB:CHASSIS)
FLKY ASSY
S101 : OPEN/CLOSE (0)
S102 : PLAYBACK CONTROL
S103 : ONE-TOUCH KARAOKE
S104 : KARAOKE MODE
S105 : PAUSE (8)
S106 : PLAY (3) /SELECT
S107 : STOP (7) /RETURN
S108 : (¡ ¢) NEXT
S109 : (4 1) PREV
S201 : +10
S202 : 0
S203 : 9
S204 : 8
S205 : 7
S206 : 6
S207 : 5
S208 : 4
S209 : 3
S210 : 2
S211 : 1
EG H

DV-K101 (1)
13
A
B
C
D
5678
5678
FL TUBE
F
PWSB ASSY
(RL/2 TYPE : VWG2021)
(RAM/2 TYPE : VWG2020)
RED
5MHz
68k27k
GREEN
GREEN
ORANGE
PWSB ASSY
S301 : KEY CONTROL ( )
S302 : KEY CONTROL ( )
S303 : STANDBY / ON (RAM/2 TYPE ONLY)
RAM/2 TYPE
ONLY
RL/2
TYPE
ONLY
RAM/2
TYPE
ONLY
FE

DV-K101 (1)
14
A
B
C
D
1234
1234
3.3 DVDM ASSY (1/3)
CN103
K
CN301 PICKUP ASSY
B
2/3
I
2/3
I
to IC501
to CN120
ADC1175CIJMX
1/2
2/2
from IC261
to IC701
(6/6)
(5/6)
(1/6)
(3/6)
(2/6)
(4/6)
to IC501
to IC501
to
IC501
2/3
I
(F)
(T)
(F) (F)
(F)
(T)
(F)
(F) (F)
(T)
(CD)
(CD)
(DVD)
(DVD)
(DVD)
(DVD)
(DVD)
(T)
(T)
(F)
(F) (F)
(T)
(T) (T)
(S)
(S)
(F)
(F)
(T)
(T)
(S)
(S)
1
2
4
3
2/2
1/2
1/3
I

DV-K101 (1)
15
A
B
C
D
5678
5678
1/3 DVDM ASSY(1/3) (VWS1368)
: RF SIGNAL ROUTE
: ROM DATA SIGNAL ROUTE
: FOCUS SERVO LOOP LINE
: TRACKING SERVO LOOP LINE
: SLIDER SERVO LOOP LINE
2/3
I
2/3
I
3/3
I
I
from Q107,Q108
to CN120
to IC101
to IC101
to IC302
to IC701
to IC601
2/3
I
(CD)
(CD)
(CD)
(CD)
(CD)
(F)
(F)
(T)
(T) (F)
(S)
(S)
(T)
(F)
(T)
5
7
98
1110
6
(F)
(T)
(S)
IC507
TC74VHCT245AFT
1/2 2/2
(1/2)
(2/2)
1/2
2/2
LEVEL SHIFT
1/3
I

DV-K101 (1)
16
A
B
C
D
1234
1234
3.4 DVDM ASSY (2/3)
2/3 DVDM ASSY(2/3)
(VWS1368)
1/3
I
I
1/3
I
VYW1589
3/3
I
3/3
I
ADDRESS
3/3
I
DATA
A2–A10
XCSDOLV,XCS6,XWRL,XWRH,XLT3,
XAMUTE,XDACK1,XDREQ1,IR,SEL-IR,
48/44,XDVRST1,XAVIRQ0,NSP-SW,
SSCK,SSO,XRESET
IC605(1/2)
TC74VHC139FT
IC605(2/2)
TC74VHC139FT
20MHz
2/3
I

DV-K101 (1)
17
A
B
C
D
5678
5678
CN101
to IC801 from IC201
E
3/3
I
3/3
I
1/3
I
3/3
I
3/3
I
3/3
I
3/3
I
3/3
I
1/3
I
1/3
I
1/3
I
1/3
I
1/3
I
1/3
I
1/3
I
1/3
I
3/3
I
to IC801
from IC301
from IC301
from IC801
from IC701
SDATA
: AUDIO SIGNAL ROUTE
: ROM DATA SIGNAL ROUTE
(DVD)
(DVD)
(CD)
(DVD)
(DVD)
IC703
TC74VHCT541AFT
MONITOR OUTPUT
SERVO
SBCK
R753
0
2/3
I

DV-K101 (1)
18
A
B
C
D
1234
1234
3.5 DVDM ASSY (3/3)
from IC701
2/3
I
from IC701
2/3
I
2/3
I
2/3
I
2/3
I
2/3
I
2/3
I
from IC701
2/3
I
IC810(1/4)
TC74VHC00FT
IC810(2/4)
TC74VHC00FT
IC810(4/4)
TC74VHC00FT
IC810(3/4)
TC74VHC00FT
(DVD)
(DVD)
(C)
(V/CB)
(Y)
(C)
(V/CB)
(Y)
(C)
(V/CB)
(Y)
1714 1512
1613
IC801
MB86371C
3/3
I

DV-K101 (1)
19
A
B
C
D
5678
5678
3/3 DVDM ASSY(3/3)
(VWS1368)
CN501
2/2
2/3
J
I
2/3
I
2/3
I
1/3
I
I
CN901
1/2
J
for IC801
for IC801
for IC701
for IC201
2/3
I
IC906 :
TC7WU04F
IC903 :
TC7WU04F
IC906(1/3)
IC903(1/3)
IC906(3/3)
IC903(3/3)
IC906(2/3)
IC903(2/3)
IC904 :
TC7WU04F
IC904(1/3)
IC904(3/3)
IC904(2/3)
CLOCK GENERATOR SECTION
: AUDIO SIGNAL ROUTE
: V/CB SIGNAL ROUTE
: Y SIGNAL ROUTE
: C SIGNAL ROUTE
: ROM DATA SIGNAL ROUTE
(C)
(V/CB)
(Y)
(C)
(V/CB)
(Y)
(C)
(V/CB)
(Y)
(V/CB)
(Y)
(C)
CN9032
VKN1476
3/3
I

DV-K101 (1)
20
A
B
C
D
1234
1234
3.6 KGJB ASSY (1/2)
1/2
J
KARAOKE
DSP
IC301:
AUDIO DAC
1/2 KGJB ASSY
(RL/2 TYPE : VWV1657)
(RAM/2 TYPE : VWV1649)
J
2/2
I
CN9020
3/3
I
CN402
NAP_SW
H
