Pioneer Elite KURO PRO 150FD User manual
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
ARP3463
PLASMA DISPLAY SYSTEM
PRO-150FD
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
This service manual should be used together with the following manual(s).
CONTENTS
1. CONTRAST OF MISCELLANEOUS PARTS ...................................................................... 2
1.1 CONTRAST TABLE ....................................................................................................... 2
1.2 CONTRAST OF PCB ASSEMBLIES............................................................................. 9
2. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ............................................................ 12
2.1 OVERALL CONNECTION DIAGRAM (1/2) ................................................................. 12
2.2 OVERALL CONNECTION DIAGRAM (2/2) ................................................................. 14
2.3 HNM BLOCK DIAGRAM.............................................................................................. 16
2.4 CONNECTOR PIN DESCRIPTION ............................................................................. 17
2.5 HN MODULE ASSY (1/6) [8620 BLOCK].................................................................... 18
2.6 HN MODULE ASSY (2/6) [8620_DDR BLOCK] .......................................................... 22
2.7 HN MODULE ASSY (3/6) [ETHERNET BLOCK]......................................................... 24
2.8 HN MODULE ASSY (4/6) [HNM_USB BLOCK] .......................................................... 26
2.9 HN MODULE ASSY (5/6) [HNM_IO BLOCK] .............................................................. 28
2.10 HN MODULE ASSY (6/6) [HNM_POWER BLOCK] .................................................. 30
3. PCB CONNECTION DIAGRAM........................................................................................ 32
3.1 HN MODULE ASSY..................................................................................................... 32
4. DIAGNOSIS ...................................................................................................................... 34
4.1 DIAGNOSIS FLOWCHART ......................................................................................... 34
5. SERVICE MODE............................................................................................................... 37
5.1 DETAILS OF FACTORY MENU ................................................................................... 37
6. DISASSEMBLY ................................................................................................................. 38
6.1 DISASSEMBLY AND REASSEMBLY PRECAUTIONS FOR SPEAKER SYSTEM ..... 38
Model Type Power Requirement Remarks
PRO-150FD KUCXC AC 120 V
Model No. Order No. Remarks
PDP-6010FD ARP3453 EXPLODED VIEWS, BLOCK DIAGRAM, ADJUSTMENT, etc
T-ZZS-001 AUG. 2007 Printed in Japan
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
PRO-150FD
2
1234
1 234
C
D
F
A
B
E
1. CONTRAST OF MISCELLANEOUS PARTS
1.1 CONTRAST TABLE
PDP-6010FD/KUCXC and PRO-150FD/KUCXC are constructed the same except for the following:
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
56 1
4 7 3
R 5 0
1R 0
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 101
47 x 103
R50
1R0
561
473
RN1/4PC F562 x 1015621 5 26 1
Mark No. Symbol and Description PDP-6010FD/KUCXC PRO-150FD/KUCXC Remarks
<PCB ASSEMBLIES>
P181-1 MAIN Assy (US FHD R) AWV2457 Not Used
P181-1 MAIN Assy (US FHD E) Not Used AWV2458
NSP 1..FUKUGO Assy(60FR) AWV2473 Not Used
P169-2 2..SIDE IO Assty(US R) AWW1274 Not Used
P181-2 2..TANSHI Assy(50/60FR) AWW1334 Not Used
NSP 1..FUKUGO Assy(60FE) Not Used AWV2475
P169-2 2..SIDE IO Assy(US E) Not Used AWW1285
P181-2 2..TANSHI Assy(50/60FE) Not Used AWW1335
HN MODULE Assy Not Used AWV2497 No.1
<PACKING SECTION>
P167-2 Remote Contorol Unit AXD1550 AXD1549
P167-3 Battery Cover(Gray) AZN2680 Not Used
P167-3 Battery Cover(Black) Not Used AZN2681
P167-4 Operating Instructions ARE1472 Not Used
(English, French, Spanish)
P167-4 Operating Instructions Not Used ARB1576
(English)
P167-5 Parental Caution ARM1371 Not Used
P167-6 HDMI Caution ARM1373 Not Used
P167-12 Label C(U) AAX3501 Not Used
P167-12 Label C(UE) Not Used AAX3505
NSP P167-18 Warranty Card KUC ARY1196 Not Used
NSP P167-18 Warranty Card EL Not Used ARY1123
P167-23 Upper Carton(608U) AHD3580 Not Used
P167-23 Upper Carton(608EL) Not Used AHD3581
P167-31 Stand Pipe L Ass'y AXY1186 AXY1188
P167-32 Stand Pipe R Ass'y AXY1187 AXY1189
P167-33 Base Cover Ass'y AXY1198 AXY1199
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
PRO-150FD 3
5678
5678
C
D
F
A
B
E
Note: For PCB ASSEMBLIES, Refer to “1.2 CONTRAST OF PCB ASSEMBLIES”.
: The numbers in the remarks column correspond to the numbers on the “EXPLODED VIEWS”.
Shading Bord Assy Not Used AMR3722 No.10
P167-39 Speaker System SMW1986 Not Used
P167-39 Speaker System Not Used SMW1980
<REAR SECTION>
NSP P169-4 Name Label(608REG) AAL2931 Not Used
NSP P169-4 Name Label(608EL) Not Used AAL2932
P169-6 Label A(U) AAX3478 Not Used
P169-6 Label A(UE) Not Used AAX3481
P169-29 Label B50(U) AAX3540 Not Used
P169-29 Label B50(UE) Not Used AAX3544
P169-8 Function Button Sheet (8U) AAK2919 Not Used
P169-8 Function Button Sheet (8U/E) Not Used AAK2920
P169-23 Input Cover Label 8U AAX3509 Not Used
P169-23 Input Cover Label 8UE Not Used AAX3512
<FRONT SECTION>
P171-6 1..Front Case Assy (608U) AMB3035 Not Used
P171-10 2..Power Button AAD4157 Not Used
P171-6 1..Front Case Assy (608EL) Not Used AMB3036
P171-10 2..Power Button B Not Used AAD4151
<PANEL CHASSIS SECTION>
NSP P179-1 Panel Chassis (608F) Assy AWU1238 Not Used
NSP P179-1 Panel Chassis (608FE) Assy Not Used AWU1258
<MULTI BASE SECTION>
P181-24 Terminal Panel A(U) ANC2440 Not Used
P181-24 Terminal Panel A(UE) Not Used ANC2444
P181-25 POD Stay A ANG2933 Not Used
P181-25 POD Stay B Not Used ANG2934
DLNA Stay Not Used ANG2932 No.2
Wire Saddle Not Used AEC1751 No.3
Card Spacer Not Used AEC2098 No.4
4P Housing Wire(J128) Not Used ADX3547 No.5
Flexible Cable(J216) Not Used ADD1474 No.6
Screw Not Used BMZ30P060FTB No.7
Screw Not Used AMZ30P060FTB No.8
Screw Not Used PMB30P080FNI No.9
<PDP SERVICE ASSY>
P18 PDP Service Assy 608F AWU1274 Not Used
P18 PDP Service Assy 608FE Not Used AWU1275
NSP P184-1 Panel Chassis (608F) Assy AWU1238 Not Used
NSP P184-1 Panel Chassis (608FE) Assy Not Used AWU1258
Mark No. Symbol and Description PDP-6010FD/KUCXC PRO-150FD/KUCXC Remarks
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
PRO-150FD
4
1234
1 234
C
D
F
A
B
E
EXPLODED VIEWS
No.5
No.5
No.4
No.4
No.5
No.5
No.2
No.2
No.5
No.5
No.3
No.3
No.5
No.5
No.6
No.6
No.5
No.5
No.5
No.5
No.5
No.3
No.5
No.5
No.4
No.5
No.5
No.6
POD Stay B
No.9
No.8
No.2
No.1
No.7
No.7
USB Cable(J301)
ADF1034
No.10
Base Cover Assy
Rear
<PACKING SECTION>
<MULTI BASE SECTION>
Pad Pad
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
PRO-150FD 5
5678
5678
C
D
F
A
B
E
SPEAKER SYSTEM (PACKING)
PACKING parts List
Ta p e
Ta p e
Ta p e
Mark No. Description Part No.
NSP 1 1..Accessory Set SME3784
2 2..Speaker Wire SDS1204
3 2..Polyethylene Bag S1 SHL1439
NSP 4 2..Screws Set SME3687
5 3..Screw BMZ50P100FTB
6 3..Polyethylene Bag S0 SHL1438
NSP 7 Bracket Top Set SME3787
NSP 8 Bracket Bottom Set SME3788
9 Protector SHA2586
10 Protection Sheet S4 SHC1865
11 Packing Case SHG2783
NSP 12 Inner Carton Board SHB1178
NSP 13 Label Serial SRW1112
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
PRO-150FD
6
1234
1 234
C
D
F
A
B
E
SPEAKER SYSTEM (BRACKET TOP SET and BRACKET BOTTOM SET)
BRACKET TOP SET Parts List BRACKET BOTTOM SET Parts List
BRACKET BOTTOM SET (SME3788)
BRACKET TOP SET (SME3787)
Tape
Tape
Mark No. Description Part No.
1 Polyethylene Bag S0 SHL1466
2 1..Bracket Assy(L-Top) SXG1141
NSP 3 2..Label(L-Top) SAK6005
4 2..Gasket SED1172
5 2..Gasket SED1173
NSP 6 2..Bracket Top SNA1485
7 1..Bracket Assy(R-Top) SXG1143
NSP 8 2..Label(R-Top) SAK6007
9 2..Gasket SED1176
10 2..Gasket SED1172
NSP 11 2..Bracket Top SNA1485
1 Polyethylene Bag S0 SHL1466
2 1..Bracket Assy(L-Bottom) SXG1142
NSP 3 2..Label(L-Bottom) SAK6004
4 2..Gasket SED1174
5 2..Gasket SED1175
NSP 6 2..Bracket Bottom SNA1486
7 1..Bracket Assy(R-Bottom) SXG1144
NSP 8 2..Label(R-Bottom) SAK6006
9 2..Gasket SED1177
10 2..Gasket SED1174
NSP 11 2..Bracket Bottom SNA1486
Mark No. Description Part No.
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
PRO-150FD 7
5678
5678
C
D
F
A
B
E
SPEAKER SYSTEM (CS ASSY)
Lch is symmetrical to center line.
*This product appearance shows Rch.
Grille (Back Side)
Baffle (Back Side)
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
PRO-150FD
8
1234
1 234
C
D
F
A
B
E
BAFFLE
CS ASSY parts List
Mark No. Description Part No.
NSP 1 Baffle (L) SNK2987
NSP 2 Baffle (R) SNK2988
NSP 3 1..Cabinet Assy L SXG1137
NSP 2..Insert Nut M5 SBN1073
NSP 2..Cabinet (L) SNK2989
NSP 4 1..Cabinet Assy R SXG1138
NSP 2..Insert Nut M5 SBN1073
NSP 2..Cabinet (R) SNK2990
5 1..Grille (L) SMG1890
NSP 2..Grille Cloth SAS1622
NSP 2..Grille Frame (L) SEH1127
6 1..Grille (R) SMG1891
NSP 2..Grille Cloth SAS1622
NSP 2..Grille Frame (R) SMH1128
7 Network Assy SWN1789
NSP 8 Model Label (L) SAN3959
NSP 9 Model Label (R) SAN3960
NSP 10 Gasket SEB1299
NSP 11 Gasket SEB1300
NSP 12 Blinder (L) SEB1306
13 Packing SEB1317
NSP 14 Blinder (R) SEB1319
15 • • • • •
NSP 16 Gasket SEC2074
NSP 17 Gasket SEC2123
NSP 18 Gasket SEC2126
NSP 19 Gasket SEC2127
NSP 20 Gasket SEC2145
21 Gasket (Tweeter) SEC6099
22 Gasket (Woofer) SEC6100
NSP 23 Gasket SEC6101
NSP 24 Gasket SEB1323
25 Tape SEH1100
26 Tape SEH1107
27 Tape SEH1115
28 Tape SEH1117
29 Tape SEH1122
NSP 30 MDF Bar SLX1165
NSP 31 Paper Port Tube SMR6013
NSP 32 Acoustic Absorbent SMT1363
NSP 33 Acoustic Absorbent SMT1370
NSP 34 Acoustic Absorbent SMT1371
NSP 35 Acoustic Absorbent SMT1364
NSP 36 Acoustic Absorbent SMT1374
37 1..Input Terminal SKX1098
NSP 2..Spring SBH1003
NSP 2..Terminal SKF1064
NSP 2..Terminal SKF1065
NSP 2..Case SNK2909
NSP 2..Lever (Black) SNK2910
NSP 2..Lever (Red) SNK2911
NSP 38 Acoustic Absorbent SMT1378
NSP 39 Label Serial SRW1111
40 Speaker A101EC65-51D
41 Speaker FK26AP32-56H
42 Screw BPZ35P080FTB
43 Screw (for input terminal) BPZ35P120FTC
44 Screw BPZ35P140FTB
45 Screw BPZ40P350FTC
NSP 46 Gasket SEC2163
NSP 47 Gasket SEC2171
NSP 48 Gasket SEC2172
NSP 49 Gasket SEC2174
Mark No. Description Part No.
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
PRO-150FD 9
5678
5678
C
D
F
A
B
E
1.2 CONTRAST OF PCB ASSEMBLIES
MAIN Assy
AWV2457 and AWV2458 are constructed the same except for the following:
FUKUGO Assy
AWV2473 and AWV2475 are constructed the same except for the following:
SIDE IO Assy
AWW1274 and AWW1285 are constructed the same except for the following:
Mark Symbol and Description AWV2457 AWV2458 Remarks
R4033 Not used RS1/10S0R0J
R4035 RS1/10S0R0J Not used
R4345 RS1/16SS103J Not used
R4382 Not used RS1/16SS103J
<BOARD IF 0 BLOCK(U)>
CN4002 FFC CONNECTOR 20P Not used AKM1380
<BOARD IF 1 BLOCK(U)>
D4101 Not used 1SS352
Q4107, Q4108 Not used RT1N241M
Q4109 Not used 2SA1602A
Q4111, Q4115 Not used RT1N241M
R4121 Not used RS1/16SS472J
R4123 Not used RS1/16SS471J
R4124 Not used RS1/16SS102J
R4127, R4128 Not used RS1/10S561J
R4151 Not used RS1/10S750J
R4152 Not used RS1/16SS222J
C4144 Not used CKSSYB104K10
CN4110 AKM1276 Not used
CN4111 PLUG(4P) Not used KM200NA4
<AV SW BLOCK(U)>
C4613 Not used CKSRYB105K10
<RGB SW BLOCK(U)
R4709, R4710, R4711 Not used RS1/16SS220J
C4732, C4733, C4734 Not used CKSRYB105K10
<7038 0 BLOCK(U)>
IC6402 R5523N001B Not used
L6402, L6403 BTX1042 Not used
R6419 RS1/10S0R0J Not used
R6433 RS1/16SS0R0J Not used
C6457 ACH1421 Not used
C6469, C6470 CKSSYB104K10 Not used
<IF UCOM BLOCK(U)>
R8329 RS1/16SS473J Not used
R8330 RS1/16SS103J Not used
R8313 Not used RS1/16SS103J
Mark Symbol and Description AWV2473 AWV2475 Remarks
R8895 RS1/16S0R0J Not used
R8896 Not used RS1/16S0R0J
Mark Symbol and Description AWW1274 AWW1285 Remarks
R9370 RS1/16S0R0J Not used
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
PRO-150FD
10
1234
1 234
C
D
F
A
B
E
TANSHI Assy
AWW1334 and AWW1335 are constructed the same except for the following:
HN MODULE Assy (AWV2497)
R9371 Not used RS1/16S0R0J
JA9351 AKB1303 AKB1304
JA9352 AKB1305 AKB1306
Mark Symbol and Description AWW1274 AWW1285 Remarks
Mark Symbol and Description AWW1334 AWW1335 Remarks
R9075 RS1/16S0R0J Not used
R9076 Not used RS1/16S0R0J
<IO_1 BLOCK>
C8903 Not used CKSSYB471K50
F8901 Not used CTF1557
F8902 Not used CTF1557
JA8901 Not used VKN1449
JA8902 AKB1348 AKB1350
Mark No. Description Part No.
Block Name: 8620 BLOCK(U)
SEMICONDUCTORS
IC7601 EM8620L-LFC
MISCELLANEOUS
F7601,7602CHIP FERRITE BEAD ATX1066
X7601CRYSTAL (27MHZ) ASS1218
RESISTORS
R7646,7647 RS1/16SS1400F
R7649-7651 RAB4CQ330J
R7652-7654 RAB4CQ103J
Other Resistors RS1/16SS###J
CAPACITORS
C7601-7609 DCH1201
C7610,7611 CCSSCH7R0D50
C7612,7613,7615-7639 CKSSYF104Z16
Block Name: 8620 DDR BLOCK(U)
SEMICONDUCTORS
IC7701,7702 HY5DU561622ETPJC
IC7703 AGC1063
MISCELLANEOUS
F7701 CHIP SOLID INDUCTOR ATL7002
RESISTORS
R7709,7710 RS1/16SS1001F
R7711-7718 RAB4CQ560J
Other Resistors RS1/16SS###J
CAPACITORS
C7701-7717 CKSSYF104Z16
C7722-7726 DCH1201
Block Name: ETHERNET BLOCK(U)
SEMICONDUCTORS
IC7751 TC74LCX125FTS1
IC7753 BR93L46RFJ-W
IC7754 RTL8100CL-LF
Q7751 2SB1197K
MISCELLANEOUS
F7751-7753 CHIP SOLID INDUCTOR ATL7002
JA7752 RJ45 CONNECTOR TRNS AKP1307
X7751 CRYSTAL(25MHZ) ASS1219
7752,7753 SCREW TERMINAL VNE1949
RESISTORS
R7753 RS1/16SS5601F
R7754,7755,7757,7758 RS1/16SS49R9F
Other Resistors RS1/16SS###J
CAPACITORS
C7751 BCG1059
C7754,7755 CCSSCH7R0D50
C7756,7757 CKSSYB103K25
C7758,7759,7762 CKSSYF104Z16
C7764-7779 CKSSYF104Z16
Block Name: HNM USB BLOCK(U)
SEMICONDUCTORS
IC7801 VT6212L-G
IC7803 R5523N001B
MISCELLANEOUS
L7801 CHOKE COIL ATH1160
F7801-7804 CHIP SOLID INDUCTOR ATL7002
F7806 CHIP SOLID INDUCTOR ATL7002
X7801 CRYSTAL (24MHZ) ASS1221
CN7801 L-PLUG (5P) KM200NA5L
RESISTORS
R7803 RS1/16SS5111F
R7806 RS1/16SS1021F
R7831,7832 RS1/16S0R0J
Other Resistors RS1/16SS###J
CAPACITORS
C7801-7803 DCH1201
C7806,7807 CCSSCH200J50
C7808 CEHVKW221M10
Mark No. Description Part No.
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
PRO-150FD 11
5678
5678
C
D
F
A
B
E
C7809-7823 CKSSYF104Z16
C7824 CEHVKW100M16
Block Name: HNM IO BLOCK(U)
SEMICONDUCTORS
IC7852,7855 TC74LCX04FTS1
IC7857 TC74LCX125FTS1
Q7852-7854 2SA1586
MISCELLANEOUS
F7852-7855 CHIP FERRITE BEAD ATX1066
F7857 CHIP FERRITE BEAD ATX1066
X7851 CRYSTAL (33MHZ) ASS1216
CN7851 FFC CONNECTOR 20P RA AKM1383
RESISTORS
R7851 RS1/16SS37R4F
R7859,7861,7875 RS1/16SS75R0F
R7870 RAB4CQ330J
R7895-7897 RS1/16SS75R0F
Other Resistors RS1/16SS###J
CAPACITORS
C7851,7853,7855,7863 CKSSYF104Z16
C7852 DCH1201
C7865 CKSSYF104Z16
C7871,7872,7874 CCSSCH220J50
C7875 CKSSYB103K25
Block Name: HNM POWER BLOCK(U)
SEMICONDUCTORS
IC7902 NJM2846DL3-25
IC7903,7904 LTC3412EFE
D7901,7902 RB051L-40
MISCELLANEOUS
L7901 INDUCTOR ATH1206
L7902 INDUCTOR ATH1207
F7901 CHIP BEEDS FILTER ATX1059
CN7901 CONNECTOR AKM1290
RESISTORS
R7903,7909 RS1/16SS3093F
R7904 RS1/16SS6202D
R7906 RS1/16SS2003D
R7910 RS1/16SS1503D
R7912 RS1/16SS7502D
R7917,7919 RS1/10S0R0J
Other Resistors RS1/16SS###J
CAPACITORS
C7901 CKSRYB334K10
C7902 CKSQYF475Z10
C7903,7906 BCG1059
C7904 CCSRCH471J50
C7905,7907 CCSRCH102J50
C7908 CCSRCH222J50
C7909 CEHVKW101M6R3
C7910,7920,7923 CKSSYF104Z16
C7911,7918,7924 CCSSCH101J50
C7912,7919 BCG1050
C7925 CCSSCH220J50
C7926 DCH1201
Mark No. Description Part No.
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
PRO-150FD 13
5678
5678
C
D
F
A
B
E
When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS
LIST" or "PCB PARTS LIST".
The mark found on some component parts indicates the importance of the safety
factor of the part. Therefore, when replacing, be sure to use parts of identical
designation.
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
PRO-150FD
16
1234
1 234
C
D
F
A
B
E
2.3 HNM BLOCK DIAGRAM
AWV2497- (HNM Ass'y) Block Diagram
Classification of each component
IC, memory, regulator and so on Differential signal Bus signal
Connector to outside of the ass'y Host controll signal Other digital signal
X'tal or oscillator Power supply
Power supply block
Ethernet block
DDR block
USB block
8620 block
I/O block
PCI clock
block
IC xxxx
IC7701
HY5DU561622ETPJ
[DDR-SDRAM (256Mbit)]
IC7703
AGC1063-A-PI
(S29GL128N90TFIR2)
[Flash Memory (128Mbit)]
IC7702
HY5DU561622ETPJ
[DDR-SDRAM (256Mbit)]
Connector to Main Ass'y
+5V for Power supply
Memory bus
Peripheral bus
PCI bus
PCI clock
X7851
ASS1216-
[33MHz OSC]
IC7855
TC74LCX04
[Inverter
(as Buffer)]
L7801
ATH1160-
[C. mode filter]
IC7803
R5523N001B
[USB High-side
Switch]
to USB Receptacle Connector
USB Differencial
signal
+5V
IC7753
BR93L46RFJ-W
[EEPROM (1kbit)]
IC7751
TC74LCX125
[3-state Buffer]
TxRx
Tx / Rx
IC7857
TC74LCX125
[3-state Buffer]
Reset
Reset
Reset
Reset
IC7852
TC74LCX04
[Inverter
(as Buffer)]
Reset
+3.3V +2.5V +1.2V+5.0V
IC7902
NJM2846DL3-25
[Regulator IC]
IC7903
LTC3412EFE
[SW Reg. IC]
IC7904
LTC3412EFE
[SW Reg. IC]
RJ-45 Ethernet Connector
IC7801
VT6212L-G
[USB Controller]
IC7754
RTL8100CL-LF
[Ethernet Controller]
IC7601
EM8620L-LFC
[Digital Media Processor]
27MHz
X'tal
24MHz
X'tal
25MHz
X'tal
CN7901
CN7851
CN7801 JA7752
AKP1307-
CN (JA) xxxx
xx MHz
X'tal
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
PRO-150FD 17
5678
5678
C
D
F
A
B
E
2.4 CONNECTOR PIN DESCRIPTION
AWV2497- (HNM Ass'y) Voltage at each connecter.
y'ssANIAMBTMy'ssAMNH
[HN1] CN7851 [M35] CN4002
nip)V(egatlovnoitpircsedO/Iemannipnip
1 TXD_HNM I UART signal with Main ass'y, Main => HNM +3.3 / 0 1
2 RXD_HNM O UART signal with Main ass'y, HNM => Main +3.3 / 0 2
3 RST_HNM I Reset signal for HNM ass'y, Active low +3.3 / 0 3
20 20
y'ssANIAMBTMy'ssAMNH
[HN2] CN7901 [M31] CN4111
nip)V(egatlovnoitpircsedO/Iemannipnip
10.5+ylppusrewopV5+IMNH_V5+V1
2 +USB I +5V power supply for USB bus-power +5.0 2
30-DNG3
4GND - 0 4
elbacBSUy'ssAMNH
[HN3] CN7801
)V(egatlovnoitpircsedO/Iemannipnip
0.5+rewop-subBSUrofV5+OV5+1
2 D- I/O USB differential signal minus +3.3 / 0
3 D+ I/O USB differential signal plus +3.3 / 0
0-DNG4
5 Sheild - 0
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
