Owner’s Manual
DVD RDS AV RECEIVER
AVH-2350DVD
English

Thank you for purchasing this PIONEER product.
To ensure proper use, please read through this manual before using this product. It
is especially important that you read and observe WARNINGs and CAUTIONsin
this manual. Please keep the manual in a safe and accessible place for future refer-
ence.
Be sure to read this
!DVD video disc region numbers 6
!Handling guidelines 64
Precautions
IMPORTANT SAFEGUARDS 4
To ensure safe driving 4
To avoid battery exhaustion 5
Before you start
About this unit 6
About this manual 6
Operating environment 6
In case of trouble 6
Resetting the microprocessor 6
Demo mode 7
Adjusting the response positions of the
touch panels (Touch Panel Calibration) 7
Use and care of the remote control 7
What’s what
Head unit 9
Remote control 10
Basic operations
Basic operations 11
Operating the scroll bar and the scrubber
bar 11
Activating the touch panel keys 12
Common operations for menu settings/
lists 13
Ejecting a disc 13
Setting the clock 13
Tuner
Introduction of tuner operations 14
Playing moving images
Introduction of video playback
operations 15
Playing audio
Introduction of sound playback
operations 18
Playing still images
Introduction of still image playback
operations 20
Introduction of still image playback as a
slideshow operations 21
Detailed instructions
Storing and recalling stations 22
Storing the strongest stations 22
Tuning in to strong signals 22
Switching the media file type 22
Operating the DVD menu 22
Operating this unit’s iPod function from your
iPod 23
Random play (shuffle) 24
Playing all songs in random order (shuffle
all) 24
Repeating playback 24
Playing videos from your iPod 24
Browsing for a video/music on the iPod 25
Resume playback (Bookmark) 25
Frame-by-frame playback 26
Slow motion playback 26
Searching for the part you want to play 26
Changing audio language during playback
(Multi-audio) 26
Changing the subtitle language during
playback (Multi-subtitle) 26
Changing the viewing angle during playback
(Multi-angle) 27
Return to the specified scene 27
Selecting audio output 27
Contents
En
2

PBC playback 27
Selecting tracks from the track title list 27
Selecting files from the file name list 28
Using advanced sound retriever 28
Changing audiobook speed 28
Displaying lists related to the currently
playing song (Link Search) 28
Playing DivXâVOD content 29
Capture an image in JPEG files 29
Changing the wide screen mode 29
Menu operations
Introduction of menu operations 31
Audio Adjustments 32
Setting up the DVD player 34
System settings 38
Entertainment settings 42
Customizing menus 43
Other Functions
Changing the picture adjustment 44
Adjusting the response positions of the
touch panels (Touch Panel
Calibration) 44
Using an AUX source 45
Installation
Connecting the units 46
Installation 54
Additional Information
Troubleshooting 58
Error messages 60
Understanding messages 62
Indicator list 63
Handling guidelines 64
Compressed audio compatibility (disc,
USB) 66
iPod compatibility 67
Sequence of audio files 67
Using the display correctly 68
Copyright and trademark 69
Language code chart for DVD 71
Specifications 72
En 3
Contents

IMPORTANT SAFEGUARDS
Please read all of these instructions regarding
your display and retain them for future refer-
ence.
1Read this manual fully and carefully be-
fore operating your display.
2Keep this manual handy as a reference for
operating procedures and safety informa-
tion.
3Pay close attention to all warnings in this
manual and follow the instructions care-
fully.
4Do not allow other persons to use this sys-
tem until they have read and understood
the operating instructions.
5Do not install the display where it may (i)
obstruct the driver’s vision, (ii) impair the
performance of any of the vehicle’s oper-
ating systems or safety features, includ-
ing air bags, hazard lamp buttons or (iii)
impair the driver’s ability to safely oper-
ate the vehicle.
6Do not operate this display if doing so in
any way will divert your attention from
the safe operation of your vehicle. Always
observe safe driving rules and follow all
existing traffic regulations. If you experi-
ence difficulty in operating the system or
reading the display, park your vehicle in a
safe location and make necessary adjust-
ments.
7Please remember to wear your seat belt at
all times while operating your vehicle. If
you are ever in an accident, your injuries
can be considerably more severe if your
seat belt is not properly buckled.
8Never use headphones while driving.
9To promote safety, certain functions are
disabled unless the parking brake is on,
and the vehicle is not in motion.
10 Never set the volume of your display so
high that you cannot hear outside traffic
and emergency vehicles.
WARNING
!Do not attempt to install or service your
display by yourself. Installation or servi-
cing of the display by persons without
training and experience in electronic
equipment and automotive accessories
may be dangerous and could expose you
to the risk of electric shock or other
hazards.
To ensure safe driving
WARNING
!LIGHT GREEN LEAD AT POWER CON-
NECTOR IS DESIGNED TO DETECT
PARKED STATUS AND MUST BE CON-
NECTED TO THE POWER SUPPLY SIDE
OF THE PARKING BRAKE SWITCH. IM-
PROPER CONNECTION OR USE OF
THIS LEAD MAY VIOLATE APPLICABLE
LAW AND MAY RESULT IN SERIOUS IN-
JURY OR DAMAGE.
!To avoid the risk of damage and injury and the
potential violation of applicable laws, this unit
is not for use with a video screen that is visible
to the driver.
!To avoid the risk of accident and the potential
violation of applicable laws, no viewing of
front seat video should ever occur while the
vehicle is being driven. Also, rear displays
should not be in a location where they are visi-
bly distracting to the driver.
!In some countries or states the viewing of
images on a display inside a vehicle even by
persons other than the driver may be illegal.
Where such regulations apply, they must be
obeyed and this unit’s DVD features should
not be used.
When you attempt to watch a video image
while driving, the warning Viewing of front
seat video source while driving is strictly
prohibited. will appear on the front display.
En
4
Section
01 Precautions

To watch a video image on the front display,
park your vehicle in a safe place and apply the
parking brake.
When using a display
connected to V OUT
Passengers in the rear seat can also watch
DVDs or the TV if you connect this unit to a
display using the V OUT.
WARNING
NEVER install the rear display in a location
where the driver can watch a DVD or TV while
driving.
When using the rear view camera
With an optional rear view camera, this unit
can be used as an aid to keep an eye on trai-
lers, or when backing into a tight parking spot.
WARNING
!SCREEN IMAGE MAY APPEAR RE-
VERSED.
!USE INPUT ONLY FOR REVERSE OR
MIRROR IMAGE REAR VIEW CAMERA.
OTHER USE MAY RESULT IN INJURY
OR DAMAGE.
CAUTION
!The rear view camera function is to be used
as an aid to keep an eye on trailers, or while
backing up. Do not use for entertainment pur-
poses.
!Please note that the edges of the rear view
camera images may differ slightly according
to whether full screen images are displayed
when backing up, and whether the images are
used for checking the rear when the vehicle is
moving forward.
To avoid battery exhaustion
Keep the vehicle engine running when using
this unit to avoid draining the battery power.
!When no power is supplied to this unit,
such as when the vehicle battery is being
replaced, the microcomputer of this unit re-
turns to its initial condition. We recom-
mend that you transcribe the audio
adjustment data.
WARNING
Do not use with vehicles that do not feature an
ACC position.
En 5
Section
01
Precautions
Precautions

About this unit
CAUTION
This product is a class 1 laser product classi-
fied under the Safety of laser products, IEC
60825-1:2007, and contains a class 1M laser
module. To ensure continued safety, do not re-
move any covers or attempt to gain access to
the inside of the product. Refer all servicing to
qualified personnel.
CAUTION—CLASS 1M VISIBLE AND INVISIBLE
LASER RADIATION WHEN OPEN, DO NOT VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS.
CAUTION:
USE OF CONTROL OR ADJUSTMENT OR
PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE.
CAUTION:
THE USE OF OPTICAL INSTRUMENTS
WITH THIS PRODUCT WILL INCREASE
EYE HAZARD.
CAUTION
!Do not allow this unit to come into contact
with liquids. Electrical shock could result.
Also, damage to this unit, smoke, and over-
heating could result from contact with liquids.
!Keep this manual handy for future reference.
!Always keep the volume low enough to hear
outside sounds.
!Avoid exposure to moisture.
!If the battery is disconnected or discharged,
any preset memory will be erased.
DVD video disc region numbers
Only DVD video discs with compatible region
numbers can be played on this player. You can
find the region number of the player on the
bottom of this unit and in this manual (refer to
Specifications on page 72).
About this manual
This unit features a number of sophisticated
functions to ensure superior reception and op-
eration. All the functions have been designed
for the easiest possible use, but many are not
self-explanatory. This operation manual will
help you benefit fully from this unit’s potential
and to maximize your listening enjoyment.
We recommend that you familiarize yourself
with the functions and their operation by read-
ing through the manual before you begin
using this unit. It is especially important that
you read and observe WARNINGs and CAU-
TIONs in this manual.
Operating environment
This unit should be used within the tempera-
ture ranges shown below.
Operating temperature range: –10 °C to +60
°C
EN300328 ETC test temperature: –20 °C and
+55 °C
In case of trouble
Should this product fail to operate properly,
please contact your dealer or nearest author-
ized Pioneer Service Station.
Resetting the microprocessor
By pressing RESET, you can reset the micro-
processor to its initial settings without chan-
ging the bookmark information.
En
6
Section
02 Before you start

The microprocessor must be reset in the fol-
lowing situations:
!Before using this unit for the first time after
installation
!If the unit fails to operate properly
!When strange or incorrect messages ap-
pear on the display
1 Turn the ignition switch OFF.
2 Press RESET with a pen tip or other
pointed instrument.
RESET button
Note
Switch your engine ON or set the ignition switch
to ACC ON before pressing RESET in the follow-
ing situations:
!After completing connections
!When erasing all stored settings
!When resetting the unit to its initial (factory)
settings
Demo mode
The feature demo automatically starts when
you select Source Off for the source and con-
tinues while the ignition switch is set to ACC
or ON. To cancel the feature demo, press and
hold MUTE. Press and hold MUTE again to re-
start. Operating the feature demo while the
car engine is turned off it may drain the bat-
tery power.
Important
Failure to connect the red lead (ACC) of this unit
to a terminal coupled with ignition switch on/off
operations may lead to battery drain.
Adjusting the response
positions of the touch panels
(Touch Panel Calibration)
If you feel that the touch panel keys on the
screen deviate from the actual positions that
respond to your touch, adjust the response po-
sitions of the touch panel. Refer to Adjusting
the response positions of the touch panels
(Touch Panel Calibration) on page 44.
Use and care of the remote
control
Installing the battery
Slide the tray on the back of the remote con-
trol out and insert the battery with the plus (+)
and minus (–) poles aligned properly.
!When using for the first time, pull out the
film protruding from the tray.
WARNING
!Keep the battery out of the reach of children.
Should the battery be swallowed, consult a
doctor immediately.
!Batteries (battery pack or batteries installed)
must not be exposed to excessive heat such
as sunshine, fire or the like.
CAUTION
!Use one CR2025 (3 V) lithium battery.
!Remove the battery if the remote control is not
used for a month or longer.
!There is a danger of explosion if the battery is
incorrectly replaced. Replace only with the
same or equivalent type.
!Do not handle the battery with metallic tools.
En 7
Section
02
Before you start
Before you start

!Do not store the battery with metallic objects.
!If the battery leaks, wipe the remote control
completely clean and install a new battery.
!When disposing of used batteries, comply
with governmental regulations or environmen-
tal public institutions’rules that apply in your
country/area.
Using the remote control
Point the remote control in the direction of the
front panel to operate.
Important
!Do not store the remote control in high tem-
peratures or direct sunlight.
!The remote control may not function properly
in direct sunlight.
!Do not let the remote control fall onto the
floor, where it may become jammed under the
brake or accelerator pedal.
En
8
Section
02 Before you start

Head unit
23
4
56
9
a
7
8
b
1
Part Part
1RESET 7MUTE
2h(eject) 8
MODE
Turning the infor-
mation display off.
3Disc loading slot 9
MENU
Displaying the
menu.
Returning to the
normal display.
4+/–(VOLUME/
VOL)a
USB port
When connecting,
open the USB con-
nector lid.
5c/d(TRACK/
SEEK)b
AUX input jack
(3.5 mm stereo/
video jack)
Use to connect an
auxiliary device.
6SRC/OFF
CAUTION
!Use an optional Pioneer USB cable (CD-U50E)
to connect the USB audio player/USB mem-
ory as any device connected directly to the
unit will protrude out from the unit and may
be dangerous.
!Do not use unauthorized products.
En 9
Section
03
What’s what
What’s what

Remote control
4
5
6
7
c
d
e
i
f
g
jh
Part Operation
cThumb pad Use to select a menu
on the DVD menu.
dRETURN
Press to display the
PBC (playback con-
trol) menu during PBC
playback.
e
fPress to pause or re-
sume playback.
o
Press to return to the
previous track (chap-
ter).
pPress to go to the next
track (chapter).
gPress to stop play-
back.
fa/b(FOLDER/P.CH)
Press to select the
next/previous disc/
folder.
Press to recall radio
station frequencies as-
signed to preset tun-
ing keys.
Part Operation
gBAND/ESC
Press to select the
tuner band when
tuner is selected as a
source. Also used to
cancel the control
mode of functions.
Press to switch be-
tween modes when
playing discs with
compressed audio
and audio data (CD-
DA) such as CD-
EXTRA and MIXED-
MODE CDs.
h
MENU
Press to display the
DVD menu during
DVD playback.
TOP MENU
Press to return to the
top menu during DVD
playback.
i
AUDIO
Press to change the
audio language during
DVD playback.
Press to switch audio
output for Video CD/
DivX.
SUBTITLE
Press to change the
subtitle language dur-
ing DVD playback.
ANGLE
Press to change the
viewing angle during
DVD playback.
jREAR SRC Not used.
En
10
Section
03 What’s what

Basic operations
Wed 28 May
12:45 PM
1 2
Radio
Disc
iPod
AUX
Rear
View
3 4 5
!Touch panel keys
1Displaying the source menu.
2Wed 28 may
12:45 PM
Switching to clock adjust-
ment display.
Refer to Setting the clock on
page 13.
3
Radio
Source icon
Selecting a favorite source.
When the source icon is not
displayed, it can be displayed
by touching the screen.
4Rear
View
Switching the rear view
image on or off.
5Turning the unit off.
Turning the unit on using the buttons
1Press SRC/OFF to turn the unit on.
Turning the unit off using the buttons
1Press SRC/OFF and hold until the unit turns off.
Selecting a source using the buttons
1Press SRC/OFF to cycle through the sources
listed below:
Selecting a source using the touch panel keys
1Touch the source icon and then touch the desired
source name.
!Radio –Radio
!AV –AV input
!Disc –Built-in DVD player
!USB/iPod –USB/iPod
!AUX –AUX
!When the source icon is not displayed, it can be
displayed by touching the screen.
Adjusting the volume
1Press +/–(VOLUME/VOL) to adjust the volume.
Notes
!In this manual, iPod and iPhone will be re-
ferred to as “iPod”.
!The USB/iPod icon will change as follows:
—USB is displayed when a USB storage de-
vice is connected.
—iPod is displayed when an iPod is con-
nected.
—USB/iPod is displayed when no device is
connected.
!When appropriately set up, the image from
the rear view camera can be displayed auto-
matically. For details, refer to Setting the rear
view camera (back up camera) on page 40.
Operating the scroll bar
and the scrubber bar
Audio
Fader/Balance F/R 0 L/R 0
Super BassGraphic EQ
High
0
Off
Off
Loudness
Subwoofer
Bass Booster
High Pass Filter
1
1
2
En 11
Section
04
Basic operations
Basic operations

Abcdeabcdeabcdeabcdeab
Wed 28 may
12:45 PM
101
812
01:45 -02:45
1L+R
2
1Scroll icon
Appears when selectable items are hidden.
2Scrubber bar
Appears when the playback point can be spe-
cified or set by dragging.
Viewing the hidden items
1Touch the scroll icon or drag the scrubber bar to
view any hidden items.
Specifying the playback point
1Drag the scrubber bar on the screen.
(Not available when the scrubber bar is grayed
out.)
Activating the touch panel
keys
Abcdeabcdeabcdeabcdeab
Wed 28 may
12:45 PM
101
812
01:45 -02:45
1L+R
1
1
1
12
2
22
Return
3
1Touch panel keys
Perform various operations by touching the
panel.
2Open/close keys
Control the touch panel key area by touching
these keys.
1
Turning the display to simpli-
fied display.
Returning to the normal dis-
play by touching the screen
when playing moving
images.
Returning to the normal dis-
play by touching same posi-
tion when playing audio.
2Viewing the hidden touch
panel keys.
3Shorten the touch panel
area.
En
12
Section
04 Basic operations

Common operations for
menu settings/lists
Displaying the list menu.
Starting the search function.
Displaying the menu.
Refer to Introduction of menu opera-
tions on page 31.
Displaying still images as a slide
show when listening to another
source.
Viewing slide shows.
Refer to Introduction of still image
playback operations on page 20.
Returning to the previous display.
Returning to the previous list/cate-
gory (the folder/category one level
higher.)
!Press and hold MENU to display
Picture Adjustment.
Refer to Changing the picture adjustment
on page 44.
Ejecting a disc
%Press h(eject).
Setting the clock
1 Switch to Clock Adjustment display.
Refer to Basic operations on page 11.
2 Select the item to set.
3 Touch aor bto set the correct date
and time.
En 13
Section
04
Basic operations
Basic operations

Introduction of tuner
operations
Wed 28 may
12:45 PM
P.CH 2
MHz
Band:
FM1
Local
Radio
87.50
87.50 MHz
Abcdeabc
123
45
!Touch panel keys
1
Turning local seek tuning on
and off.
Refer to Tuning in to strong
signals on page 22.
2
Displaying the EQ (Audio
function menu).
Refer to Using the equalizer
on page 32.
3
Displaying the preset channel
list.
Refer to Storing and recalling
stations on page 22.
Refer to Storing the strongest
stations on page 22.
4Band: Selecting a band (FM1, FM2,
FM3 for FM or AM).
5
Recalling radio station fre-
quencies assigned to preset
tuning keys.
Manual tuning (step by step) using the buttons
1Press cor d(TRACK/SEEK).
Seek tuning using the buttons
1Press and hold cor d(TRACK/SEEK).
Note
Listening AM radio while an iPod is charged from
this unit may generate noise. In this case, discon-
nect the iPod from this unit.
En
14
Section
05 Tuner

Introduction of video
playback operations
You can view DVD/DVD-R/DVD-RW/CD/CD-R/
CD-RW/USB/iPod.
DVD video
Return
Abcdeabcdeabcdeabcdeab
Wed 28 may
12:45 PM
101
812
01:45 -02:45
1L+R
Video CD
Return
DivX
iPod video
Abcdeabcdeabcdeabcdeab
Wed 28 may
12:45 PM
01:45
ALL Songs
S.Rtrv
-02:45
Abcdeabcdeabcdeabcdeab
Abcdeabcdeabcdeabcdeab
2067/12345
iPod
When playing a disc containing a mixture
of various media file types
01:45 -02:45
!If an iPod with video capabilities is con-
nected to this unit using an interface cable
such as the CD-IU50V (sold separately), you
can enjoy the video contents of the iPod as
an iPod source.
!Touch panel keys
1
Selecting the repeat range.
Refer to Repeating playback
on page 24.
2
During playback, touch the
point at which you want to re-
sume playback the next time
the disc is loaded.
Refer to Resume playback
(Bookmark) on page 25.
3
Changing the screen mode.
Refer to Changing the wide
screen mode on page 29.
4
Switching the equalizer
curves.
Refer to Using the equalizer
on page 32.
5
Switching between audio
languages during playback.
Refer to Changing audio lan-
guage during playback (Multi-
audio) on page 26.
6
Switching between subtitle
languages during playback.
Refer to Changing the subti-
tle language during playback
(Multi-subtitle) on page 26.
7
Switching among viewing
angles during playback.
Refer to Changing the view-
ing angle during playback
(Multi-angle) on page 27.
8
Switching the audio output,
when playing video discs re-
corded with LPCM audio.
Refer to Selecting audio out-
put on page 27.
Switching between stereo
and monaural audio output,
when playing Video CD
discs.
En 15
Section
06
Playing moving images
Playing moving images

9
Starting the search function.
Refer to Searching for the part
you want to play on page 26.
Refer to Selecting files from
the file name list on page 28.
Displaying iPod menus.
Refer to Playing videos from
your iPod on page 24 and
Browsing for a video/music
on the iPod on page 25.
a
Pausing playback
Returning to normal play-
back during paused, slow
motion, or frame-by-frame
playback.
b
Displaying the DVD menu
during DVD playback.
Refer to Operating the DVD
menu on page 22.
cReturning to the top menu
during DVD playback.
d
Stopping playback.
Stopping playback at the
point set in Resume play-
back.
Touch one more time to stop
playback completely when
playing DivX.
Refer to Resume playback
(Bookmark) on page 25.
e
Displaying arrow keys to op-
erate the DVD menu.
Refer to Using the arrow keys
on page 22.
f
Skipping to another title.
Selecting a folder during
DivX file playback.
g
Speeding down the playback
speed in four steps, during
slow motion playback on
Video CD.
h
Moving ahead one frame at a
time during playback.
Refer to Frame-by-frame play-
back on page 26.
Touch and hold for more
than two seconds to slow
down playback speed.
Speeding up the playback
speed in four steps during
slow motion playback on
DVD video/Video CD.
iReturn
Returning to the specified
scene to which the DVD cur-
rently being played has been
preprogrammed to return.
Refer to Return to the speci-
fied scene on page 27.
j
Playing the video on your
iPod in a random order.
Refer to Random play (shuf-
fle) on page 24.
k
Switching the Advanced
sound retriever function set-
ting when playing a video on
your iPod.
Refer to Using advanced
sound retriever on page 28.
l
Conducting operation from
your iPod and listening to it
using your car’s speakers.
Refer to Operating this unit’s
iPod function from your iPod
on page 23.
m
Switching between media
file types to play on DVD/CD/
USB.
Refer to Switching the media
file type on page 22.
En
16
Section
06 Playing moving images

Playing back videos
1Insert the disc into the disc loading slot with the
label side up.
Playback will automatically start.
!If you are playing a DVD or Video CD, a menu
may appear. Refer to Operating the DVD menu on
page 22 and PBC playback on page 27.
!When the automatic playback function is on, the
unit will skip the DVD menu and automatically
start playback from the first chapter of the first
title. Refer to Automatic playback of DVDs on page
37.
!While an iPod is connected to this unit, PIONEER,
OK to disconnect or (check mark) is displayed
on the iPod.
!When the source icon is not displayed, it can be
displayed by touching the screen.
!Disconnect headphones from the iPod before
connecting it to this unit.
!Depending on the iPod model and the amount of
data stored in the iPod, it may take some time for
playback to begin.
!Use the touch panel keys to select the iPod after
connecting it to this unit.
!No Device is displayed when disconnecting the
iPod.
!If a message is displayed after loading a disc con-
taining DivX VOD content, touch Play.
Refer to Playing DivXâVOD content on page 29.
Ejecting a disc
Refer to Ejecting a disc on page 13.
Selecting a chapter using the buttons
1Press cor d(TRACK/SEEK).
Fast forwarding or reversing using the buttons
1Press and hold cor d(TRACK/SEEK).
!Fast forward/fast rewind may not always be possi-
ble on some discs. In such cases, normal play-
back will automatically resume.
Notes
!This DVD player can play back a DivX file re-
corded on CD-R/RW or DVD-R/RW. (Please
see the following section for files that can be
played back. Refer to page 65.)
!Do not insert anything other than a DVD (-R/-
RW) or CD (-R/-RW) into the disc loading slot.
!If the bookmark function is on, DVD playback
resumes from the selected point. For more de-
tails, refer to Resume playback (Bookmark) on
page 25.
!Some operations may not be available while
watching a DVD due to the programming of
the disc. In such cases, the icon appears
on the screen.
!To ensure proper operation, connect the dock
connector cable from the iPod directly to this
unit.
!While the iPod is connected to this unit, the
iPod cannot be turned on or off.
En 17
Section
06
Playing moving images
Playing moving images

Introduction of sound
playback operations
You can listen to DVD-R/DVD-RW/CD/CD-R/
CD-RW/USB/iPod sound files.
CD
Abcdeabcdeabcdeabcdeab
Wed 28 may
12:45 PM
125
01:45
ROM Disc On
S.Rtrv
-02:45
Abcdeabcdeabcdeabcdeab
Abcdeabcdeabcdeabcdeab
87
6
1 2 3 4
97
5
8
iPod audio
Abcdeabcdeabcdeabcdea
Wed 28 may
12:45 PM
01:45
ALL Songs
S.Rtrv
-02:45
Abcdeabcdeabcdeabcdea
Abcdeabcdeabcdeabcdea
2067/12345
iPod
6h
c d e
1 a b 3 4 5
g
f i
You can control an iPod with this unit by using
a cable such as the CD-IU50V (sold sepa-
rately).
!Touch panel keys
1
Selecting the repeat
range.
Refer to Repeating play-
back on page 24.
2
Playing songs in random
order.
Refer to Random play
(shuffle) on page 24.
3
Switching the Advanced
sound retriever function
setting when playing
audio.
Refer to Using advanced
sound retriever on page
28.
4
Switching the equalizer
curves.
Refer to Using the equali-
zer on page 32.
5
Displaying a list of track
titles/file names to select
songs on a CD.
Refer to Selecting tracks
from the track title list on
page 27.
Displaying the file name
list to select the files.
Refer to Selecting files
from the file name list on
page 28.
Displaying iPod menus.
Refer to Browsing for a
video/music on the iPod
on page 25.
6Pausing and starting
playback.
7
Switching the text infor-
mation to display on this
unit when playing MP3/
WMA/AAC files.
8Selecting a folder.
9
Switching between
media file types on a
DVD/CD/USB.
Refer to Switching the
media file type on page
22.
a
Playing songs on the
iPod in random order.
Refer to Random play
(shuffle) on page 24.
b
Changing the speed of
audiobook playback on
the iPod.
Refer to Changing audio-
book speed on page 28.
En
18
Section
07 Playing audio

c
Switching to Link Search
mode to play songs re-
lated to the currently
playing song on the iPod.
Refer to Displaying lists
related to the currently
playing song (Link Search)
on page 28.
d
Playing all songs on the
iPod in random order.
Refer to Playing all songs
in random order (shuffle
all) on page 24.
e
Conducting operation
from your iPod and listen-
ing to it using your car’s
speakers.
Refer to Operating this
unit’s iPod function from
your iPod on page 23.
!Text information
f
Displaying the Songs list
on the iPod.
Refer to Searching for a
video/music by category
on page 25.
g
Displaying the Artists list
on the iPod.
Refer to Searching for a
video/music by category
on page 25.
h
Displaying the Albums
list on the iPod.
Refer to Searching for a
video/music by category
on page 25.
!Artwork display
i
Starting Album Link Search on your iPod
when you touch the artwork display.
Refer to Displaying lists related to the cur-
rently playing song (Link Search) on page 28.
Playing back sound
1Insert the disc into the disc loading slot with the
label side up.
Playback will automatically start.
!While an iPod is connected to this unit, PIONEER,
OK to disconnect or (check mark) is displayed
on the iPod.
!When the source icon is not displayed, it can be
displayed by touching the screen.
!Disconnect headphones from the iPod before
connecting it to this unit.
!Depending on the iPod model and the amount of
data stored in the iPod, it may take some time for
playback to begin.
!Use the touch panel keys to select the iPod after
connecting it to this unit.
!No Device is displayed when disconnecting the
iPod.
Ejecting a disc
Refer to Ejecting a disc on page 13.
Selecting a track using the buttons
1Press cor d(TRACK/SEEK).
Fast forwarding or reversing using the buttons
1Press and hold cor d(TRACK/SEEK).
Notes
!When playing back files recorded as VBR
(variable bit rate) files, the play time will not be
correctly displayed if fast forward or reverse
operations are used.
!To ensure proper operation, connect the dock
connector cable from the iPod directly to this
unit.
!While the iPod is connected to this unit, the
iPod cannot be turned on or off.
!If the characters recorded on the disc are not
compatible with this unit, those characters
will not be displayed.
!Text information may not be correctly dis-
played depending on the recorded environ-
ment.
!Disconnect the USB portable audio player/
USB memory when you are done using it.
!When you select Clock on Selecting the back-
ground display on page 42, the artwork is not
displayed.
En 19
Section
07
Playing audio
Playing audio

Introduction of still image
playback operations
You can view still images saved in CD-R/CD-
RW/USB.
CD
Capture
Photo Wed 28 may
12:45 PM
Abcdeabcdeabcde
Abcdeabcdeabcde
Full
Off
2 2
5
1 2 34
76 8
When playing a disc containing a mixture
of various media file types
01:45 -02:45
When loading a CD-R/CD-RW/USB containing
JPEG picture files, this unit starts a slideshow
from the first folder/picture on the disc/device.
The player displays the pictures in each folder
on the CD-R/CD-RW in alphabetical order by
file name.
The table below shows the controls for viewing
a slideshow.
!Touch panel keys
Touch any of the following touch panel keys
to select the function to be adjusted.
1
Selecting the repeat range.
Refer to Repeating playback
on page 24.
2
Playing files in a random
order.
Refer to Random play (shuf-
fle) on page 24.
3
Changing the screen mode
Refer to Changing the wide
screen mode on page 29.
4
Displaying the file name
list to select the files.
Refer to Selecting files from
the file name list on page
28.
5Starting or pausing the sli-
deshow.
6Rotating the displayed pic-
ture 90° clockwise
7
Capturing an image in
JPEG files.
Refer to Capture an image
in JPEG files on page 29.
8Selecting a folder.
9
Switching between media
file types.
Refer to Switching the
media file type on page 22.
Playing still images
1Insert the disc into the disc loading slot with the
label side up.
Playback will automatically start.
!When the source icon is not displayed, it can be
displayed by touching the screen.
Ejecting a disc
Refer to Ejecting a disc on page 13.
Selecting a file using the buttons
1Press cor d(TRACK/SEEK).
Fast file searching
1Press and hold cor d(TRACK/SEEK).
!You can search 10 JPEG files at a time.
Notes
!This unit can play back a JPEG file recorded
on CD-R/CD-RW/USB storage device. (Please
see the following section for files that can be
played back. Refer to JPEG picture files on
page 65.)
En
20
Section
08 Playing still images
