Pioneer R1 User manual

Instruction Manual
R1
7” Ta b l e t

Contents
Contents…………………………………………………..........…
1 Introduction…………………………………………………...1
1.1 Congratulations…..………………………………….….1
1.2 Precautions……………………………………………...1
1.3 Safety Notice…………………………………………....1
1.4 Abbreviation/term………………………………………3
2 Brief introduction for MID product………………….……….3
2.1 Diagram for MID complete machine…………….……..3
2.2 Introduction to accessories of MID………………..……4
2.3 Use and preparation of MID………………………..…...5
2.4 MID state and notice……………………………….………....5
3 Quick start……………………………………………..…..….7
3.1 Key function……….……………...……..…………..….7
3.2 Starting up and turning off….………...…………….…...7
3.3 Unlocking and closing of the screen…….…………........7
3.4 Use of touch screen……………………….………....…..7
3.5 Homepage interface……………………….……..…….10
3.6 Access to application program…………….………...…12
3.7 USB connection…………………………….………….13
3.8 Memory card……………………………….…………..15
3.9 Character input…………….……………….………….15
3.10 Application Technique…….……………….…………..17
4 Connection Establishment……………………………….......18
4.1 WiFi Connection……….………………….…………..18
5 Communication………………………………….………..…20
5.1 E-mail……………….……………………….………....20
6 Multi-media………………………………………………….21
6.1 Supported File Format…………………….………...…23
6.2 Music……………………………………….………….24
6.3 Camera…………………………………….…………...25
6.4 HDMI……………………………………….………….26
6.5 Media Browser…….……………………….………….27
7 Internet………………………………………….…………...29
7.1 Browser…………….…………………………………..29
8 Other Applications…………………………………………..33
8.1 Alarm clock………………………………………….…33

8.2 Calculator……………………………………………....34
8.3 File Management……………………...…………….…34
9 Basic Settings………………………………………..………37
9.1 Sound and Display……………………………………..37
9.2 Security and Location……………………...….……….38
9.3 Storage…………………………………………………39
9.4 Date and Time………………………………………….39
9.5 Language and Input Method………….………………..40
9.6 About Tablet PC…………………………….………….40
10 Installation and Management of Program …………………..41
10.1 Installation……………………………………………..41
10.2 Management and Uninstall…………………………….42
10.3 Update Approach………………………………………42
11 System Upgrade………………………………..……………42
11.1 System Upgrade Preparation……….………………….42
11.2 Restore Factory Settings…………….…………………42
11.3 System Upgrade………………….………………….…43
12 Troubleshooting……………………….……………..………44
13 Open Source Licenses…......................................................45
14 Warranty ………………….…...……………..……………...47

1
1 Introduction
1.1 Congratulations
Thank you for purchasing the Pioneer R1 Tablet / MID.
1.2 Precautions
Maintenance and Trouble Shooting
•Please keep the device dry. Please don’t let the device,
battery or charger contact water or water vapor. Do not
operate device or charger with wet hand, so as not to short
circuit of the device, or cause breakdown by corrosion.
This will also prevent electric shock.
•Please do not let the device, battery or charger receive
strong impact or shock, for fear of breakdown, catching
fire or explosion of device, battery and charger.
•Please do not place the device, battery or charger in
regions with too high or too low temperature, this may
lead to breakdown, fire or explosion of device.
•Please do not strike, throw or puncture the MID, and
dropping, puncturing, or bending of MID must be avoided.
•Please do not dismantle the device and its accessories on
your own, otherwise, the device and its accessories will be
out of the warranty scope by our company.
1.3 Safety Notice
Before using MID, please read information in this section, and
make sure your children understand this information, as well.
•Please do not use MID when you are driving, for fear of
hindering safe driving.

2
•In medical places, please observe relevant stipulations and
regulations. And in regions near the medical devices,
please shut down MID.
•Please shut down MID or enable the airplane mode when
boarding, so that the wireless signals will not interfere
control signal of the airplane.
•Please shut down MID neighboring electronic equipment
with high accuracy, otherwise, breakdown of electronic
equipment may be brought about.
•Please don’t dismantle the MID and its accessories on
yourself, and only the authorized agency can maintain this
MID.
•Please keep MID far away from magnetic equipment,
radiation from MID will erase information stored on the
magnetic equipment.
•Please don’t use MID in places with high temperature and
inflammable gas (such as nearby gas station).
•Please put MID and its accessories in places beyond
children’s touch, please don’t let children use MID without
supervision.
•During using of this MID, please observe related laws and
regulations, respect privacy and legitimate rights of others.
•Please strictly abide by relevant explanations in this
manual when using USB data line, otherwise, MID or
personal computer may be damaged.
•Please don’t use the MID in humid environment such as
bathroom, etc., and the MID being soaked or rinsed by
liquid must be avoided.

3
1.4Abbreviation/Term
2 Brief Introduction for MID product
2.1 Diagram for MID complete machine

4

5
2.3 Introduction to accessories of the MID
Included Items
The following Items are included in your packing box of MID:
•MID/ Tablet
•AC Power adaptor
•Micro USB Cable
•Instruction Manual
•Screen Protection Film
2.3 Use and preparation of MID
Battery charging
•Before using MID for the first time, the battery must be
charged firstly.
•Use power adaptor to charge MID.
•In order to guarantee full battery, please charge for over 4
hours.
2.4 MID State and Notice
Iconography for Notification
When a prompt message shows on your notice panel, please click
the column box and slide on the screen with your finger to open the
notice list. Click options needing to check to see detailed
information. Then you may click the message box and slide
upwards to close the message window. The following are
iconography for icons in status bar:
-

6
Notice panel
Notice iconography will show when receiving new message, setting
the alarm clock and odometer as well as inserting SD card, you can
open the notice panel to check detailed information.
Unlock notice panel
When new notice iconography shows on the notice column, please
press the notice column with your finger, then slide downwards to
unlock the notice panel.

7
3 Quick Start
3.1 Key function
Descriptions for key functions:
Power key
•Press this key for a long time to start up
•Under starting up state, press this key for a long
time to pop up shutdown option
•Under starting up state, press this key to close the
screen
•Under starting up state or when breakdown
appears, press the power key for 7 seconds to
make your device enter into shutdown state
3.2 Starting up and turning off
Starting up
Press the power key for 3 seconds, you can see the starting up
picture. After the system is started, the machine enters into screen
lock state, please unlock according to direction indication of sliding
icon on the interface.
Turning off
1. After pressing the power key for a long time, the
shutdown option will pop up.
2. Click OK.
3.3 Unlocking and closing of the screen
The machine will close automatically when the screen is left unused
1. After the screen being left unused for a period of time, the
machine will close screen automatically, so as to save
battery power.

8
2. Under screen on state, press the power key, the screen will
close immediately.
Prompt: if you want to inquire how to set turn-off time of screen,
please refer to chapter 9.1.
Turning on under screen off state
If the screen is off, you can unlock the screen by pressing power
key for a short time or the return key for a long time. After opening,
the screen will enter lock state, press “lock” icon by your finger and
slide rightwards, the screen will be unlocked, press “lock” icon and
slide leftwards, you can enter the camera function.
Figure 3-1
3.4 Use of touch screen
Operating mode in MID
There are various ways to skim the main screen, menu and
application program, etc. on your MID.

9
Click to select
When you want to use screen keyboard entry, and you want to
select items on the homepage interface such as application program,
you only use your finger to click.
Press on
If you want to unlock the available option of a certain item (such as
textbox or interlinkage in the webpage), or move shortcut on the
homepage interface and menu of main program, only press the
item.
Slide quickly or slide
Quick sliding or sliding means doing rapid vertical or horizontal
drag movement by using finger on the picture.
Drag
Before you starting to drag, you must press it with your finger and
impose a certain pressure, and don’t loosen the finger before
dragging to the wanted position.
Rotate
Aiming at most of pictures, only turn the MID in side direction, the
screen direction can be shifted from cross direction to vertical
direction. For example, when you input characters, watch cinema,
etc.
Homepage interface
All application programs on the machine will be displayed on the
main menu screen. You may use application program, shortcut and
user-defined mode to set wallpaper of your homepage interface.

10
Note: in any application program, you can press the homepage key
to return the homepage interface.
Outstretched homepage interface
Homepage interface may extend beyond the width of screen, so as
to provide more space, so that you can place the newly increased
shortcut, widget, etc. Press blank of homepage interface, then slide
around quickly in vertical direction by finger to jump to left side or
right side outside the screen. There are more than 2 stretched
pictures on the homepage interface.

11
Custom homepage interface
Change desktop wallpaper
1. Press the blank region on the homepage interface to pop
up the menu.
2. When the menu pops up, choose source of homepage
interface wallpaper you want to change.
3. After clicking source of wallpaper, click picture you want,
and then select “setting wallpaper”.
Add widgets
1. Please click the application program menu. As shown in
Figure 3-5.
2. After entering the application program menu, click the
“WIDGETS” button on the top left of the interface.
4. After pressing the desktop widgets you want, the system
will return back to the main interface, put the selected
widget to the desired place, then release.

12
3.6Access to application program
How to visit application program of MID:
1. Click the application program menu. As shown in Figure
3-5.
2. Select the application program you want to visit.
3. If you want to exit the program interface, press the return
key to the last interface, or press the homepage key to
return to the homepage interface directly.

13
3.7 USB Connection
Storage setting of MID
Before transmitting a document, you must first set the storage mode
for your MID:
1. Connect your MID with your computer by using USB
transmission line. The Notice bar will show the notice
prompt.
2. Click the status bar, options of the status bar as shown.
3. Among the options of the status bar, click to choose USB
connected, then click to open USB storage device.
4. At this time, USB has already been connected.
Copy the document to storage card
•Connect the MID and your computer together with USB
cable.
•After setting according to storage of MID, connect with
computer successfully.
•Open your computer, in my computer; examine content in
“removable disk (x)”.

14
•Find the document you want to copy, copy it to
“removable disk(x)”.
•After completion of copying, click “safely remove
hardware” in taskbar of your computer to unload.
Content of MID storage device
1. NAND FLASH storage device, space for MID to store
document itself.
2. TF removable memory card.
3. The two above-mentioned storage devices both can be
visited through connection with your computer with USB.
Attention: When your MID is connected with the USB cable, if you
start up USB storage device, you will not be able to visit the
memory card through MID, if you want to visit memory card in
MID, disconnect USB cable.
3.8 Memory card
Copy the document to storage card
You can transmit documents between you MID and computer, such
as music and picture, etc. If you want to see documents in MID,
only click the file browser to look through content in the SD card.
Delete documents on the storage card of MID
1. Find the document you want to delete.
2. Press the document name you need to delete; a file menu
will pop up.
3. Click delete.
Removing storage card when the MID is in starting up state
If you need to the remove storage card under starting up state of
MID, you must unload the storage card firstly, for fear of failure or
damage of the storage card.
1. In the homepage interface, press the menu key, and then
click setting.
2. Pull the setting menu downwards, and then click storage.
3. Click SD card setting.
4. Click to uninstall the SD card.

15
3.9 Character input
Use screen keyboard
When you start the program or select text edit box needing to input
characters or numbers, screen keyboard will show. The following
input methods are provided for the keyboard to select.
1. Android keyboard
2. Input method of a third party (user can install them by
himself).
Select the input method you need to use
According to presetting, the MID will display Android keyboard
when you want to input characters.
1. Press menu key in homepage interface, then click setting.
2. Click language and keyboard.
3. All of the input methods already installed on your MID
will be listed in the text setting region.
4. Select the input method you want.
Use and switch input method
1. In the character input interface, click keyboard icon under
the status bar, until popping up of editing text menu.
2. Select input method you need.

16
1 Switch input capital and small letters
2 Switch character input mode and symbol/figure input mode
3 Click to insert space
4 Click to execute carriage return
5 Click and press on to delete characters on the left of the cursor
6 Click here to switch input method
3.10Application Technique
Open the application procedure that is employed. Click the third
button under the lower left side at any procedure interface, pop up
the procedure windows on the screen, the application procedure that
is used recently can appear in the windows, referring to Figure 3-9.

17
Add the small tool on the desktop
On the application procedure menu, click the “WIDGETS” button
and enter into the interface of small parts, the icon and name for
added small parts can appear on this interface, such as: music,
photo frame, clock and searching.
Switch the Input Language
Click the keyboard icon at the lower right corner of interface for
input box; after clicking, pop up all input methods installed on this
equipment by you, click and select the Input method.
Rapid Procedure Shutoff
Click the Back Key to return to the superior interface, or click the
Homepage key to return to homepage interface.
Factory Default
When your MID produces the major error or the unlocking
password is forgotten, the Factory Default can be employed to
return to the ex-factory status. There are two kinds of methods to
reset to Factory Default:
1. On the homepage interface, click the menu key and pop up
the setting menu.
2. Click and select the Setting
3. Click and select the Backup and Reset
4. Click and select the Factory Default
5. Click and select the Tablet Computer Resetting
6. Wait for system resetting
Rapid Screenshot
When you are located on such any interface as Game or Movies and
intend to serve the wonderful picture as the commemoration, the
desired pictures can be reserved only by pressing Volume Down
key and Power key simultaneously.
