Pioneer XV-DV940 User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2004
RRV2913
DVD/CD TUNER
XV-DV940
T – ZZV MAR. 2004 Printed in Japan
This service manual should be used together with the following manual(s):
RemarksOrder No.
XV-DV830/ZUCXJ
RRV2817
Model
¶For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
This product is a system(s) component.
This product does not function properly when it is independent ; to avoid malfunctions, be
sure to connect it to the prescribed system component(s), otherwise damage may result.
Please connect it to the POWERED SUBWOOFER S-DV940SW , for adujustment and ope-
ration inspection.
Model Type Power Requirement Region No. Remarks
XV-DV940 ZUCXJ DC power is supplied from other system component. 1
XV-DV940 RRV2913(RRV2817)
S-DV940SW
RRV2887
RRV2912
S-DV940ST
DVD/CD TUNER
POWERED SUBWOOFER
SPEAKER SYSTEM
This manual
Component System Service Manual Remarks

2
1234
1234
C
D
F
A
B
E
XV-DV940
1. CONTRAST OF MISCELLANEOUS PARTS
jpfy
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
•When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560 Ω→56 × 101→561 ........................................................ RD1/4PU 56
1
J
47k Ω→47 × 103→473 ........................................................ RD1/4PU 47
3
J
0.5 Ω→R50 ..................................................................................... RN2H
R 5
0K
1 Ω→1R0 ..................................................................................... RS1P 1
R 0
K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Ω→ 562 × 101→5621 ...................................................... RN1/4PC
5 6
2
1
F
CONTRAST TABLE
XV-DV940/ZUCXJ and XV-DV830/ZUCXJ are constructed the same except for the following:
PACKING
P9-12 Setup Guide (English, French) ARE7337 ARE7336
P9-19 Packing Case AHD8224 AHD8225
EXTERIOR SECTION
P11-22 Rear Panel ANC8211 ANC8218
P11-34 Bottom Base AMA7030 AMA7031
P11-35 Top Panel AMB7850 AMB7890
P11-39 NSP Name Label AAL7338 AAL7339
P11-40 65 Label ARW7050 Not used
P11-44 NSP Energy Star Label AAX7876 AAX8022
Ref.
No. Remarks
XV-DV830/ZUCXJ XV-DV940/ZUCXJ
Part No.
Mark Symbol and Description

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2003
TIMER STANDBY/ON OPEN/CLOSE
0
XV-DV830
RRV2817
DVD/CDTUNER
XV-DV830
THIS MANUAL IS APPLICABLETOTHE FOLLOWING MODEL(S) ANDTYPE(S).
This product is a system(s) component.
This product does not function properly when independent ; to avoid malfunctions, be
sure to connect it to the prescribed system component(s), otherwise damage may result.
Please connect it to the POWERED SUBWOOFER S-DV830SW, for adjustment and opera-
tion inspection.
Model Type Power Requirement Regional restriction
codes (Region No.) Remarks
XV-DV830 ZUCXJ DC power supplied from other system component 1
XV-DV830 RRV2817
S-DV830
S-DV830SW RRV2807
S-DV830ST
DVD/CD TUNER
SPEAKER SYSTEM
POWERED SUBWOOFER
SPEAKER SYSTEM
This manual
Component System Service Manual Remarks
For details, refer to "Important symbols for good services" .
T-ZZV JULY 2003 printed in Japan

XV-DV830
2
1234
1234
C
D
F
A
B
E
SAFETY INFORMATION
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 – Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement
parts must be of identical designation.
REMARQUE
(POUR MODÈLE CANADIEN SEULEMENT)
Les symboles de fusible (fusible de type rapide) et/ou (fusible de type lent) sur CCI indiquent que
les pièces de remplacement doivent avoir la même désignation.
ANY MEASUREMENTS NOT WITHIN THE
LIMITS OUTLINED ABOVE ARE INDICATIVE
OF A POTENTIAL SHOCK HAZARD AND
MUST BE CORRECTED BEFORE RETURN-
ING THE APPLIANCETOTHE CUSTOMER.
2. PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in the appliance
have special safety related characteristics. These are
often not evident from visual inspection nor the
protection afforded by them necessarily can be obtained
by using replacement components rated for voltage,
wattage, etc. Replacement parts which have these
special safety characteristics are identified in this
Service Manual.
Electrical components having such features are
identified by marking with a on the schematics and
on the parts list in this Service Manual.
The use of a substitute replacement component which
does not have the same safety characteristics as the
PIONEER recommended replacement one, shown in the
parts list in this Service Manual, may create shock, fire,
or other hazards.
Product Safety is continuously under review and new
instructions are issued from time to time. For the latest
information, always consult the current PIONEER
Service Manual. A subscription to, or additional copies
of, PIONEER Service Manual may be obtained at a
nominal charge from PIONEER.
(FOR USA MODEL ONLY)
1. SAFETY PRECAUTIONS
The following check should be performed for the
continued protection of the customer and service
technician.
LEAKAGE CURRENT CHECK
Measure leakage current to a known earth ground
(water pipe, conduit, etc.) by connecting a leakage
current tester such as Simpson Model 229-2 or
equivalent between the earth ground and all exposed
metal parts of the appliance (input/output terminals,
screwheads, metal overlays, control shaft, etc.). Plug
the AC line cord of the appliance directly into a 120V
AC 60 Hz outlet and turn the AC power switch on. Any
current measured must not exceed 0.5 mA.
Device
under
test
Leakage
current
tester
Earth
ground
Reading should
not be above
0.5 mA
Also test with
plug reversed
(Using AC adapter
plug as required)
Test all
exposed metal
surfaces
AC Leakage Test

XV-DV830 3
5678
5678
C
D
F
A
B
E
[ Important symbols for good services ]
In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely.
When you find the procedures bearing any of the symbols, be sure to fulfill them:
2. Adjustments
To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable.
In accordance with the procedures or instructions described in this manual, adjustments should be performed.
3. Cleaning
For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning,
proper cleaning should be performed to restore their performances.
5. Lubricants, glues, and replacement parts
Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying
glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the
prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed
ones should be used.
4. Shipping mode and shipping screws
To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or
the shipping screws should be installed before shipping out in accordance with this manual, if necessary.
1. Product safety
You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during servicing by following the safety instructions described in this manual.
* When the FFC cable between the VIDEO ASSY-CN8301 and DVDM ASSY-CN 943 is off from
the connector and then the power is turned on, the parts below on the DVDM ASSY may be
destroyed.
Be sure to take care when diagnosing the ASSYS. Refer to P.106.
IC851 DSD1791DBR (AUDIO DAC)
IC861, IC871 DSD1702EG (AUDIO DAC)

XV-DV830
4
1234
1234
C
D
F
A
B
E
CONTENTS
SAFETY INFORMATION.....................................................................................................................................2
1. SPECIFICATIONS ............................................................................................................................................ 5
2. EXPLODED VIEWS AND PARTS LIST............................................................................................................8
2.1 PACKING ...................................................................................................................................................8
2.2 EXTERIOR SECTION.............................................................................................................................. 10
2.3 LOADING MECHA ASSY ........................................................................................................................12
2.4 TRAVERSE MECHA ASSY-S ..................................................................................................................14
2.5 DISPLAY UNIT.........................................................................................................................................15
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM..........................................................................................16
3.1 BLOCK DIAGRAM...................................................................................................................................16
3.2 LOAB ASSY and OVERALL WIRING DIAGRAM..................................................................................... 18
3.3 DVDM ASSY(1/4).....................................................................................................................................20
3.4 DVDM ASSY(2/4).....................................................................................................................................22
3.5 DVDM ASSY(3/4).....................................................................................................................................24
3.6 DVDM ASSY(4/4).....................................................................................................................................26
3.7 VIDEO, DSP TRADE and COMPONENT ASSYS ...................................................................................28
3.8 DSP ASSY(1/2)........................................................................................................................................ 30
3.9 DSP ASSY(2/2)........................................................................................................................................ 32
3.10 FM/AM TUNER MODULE......................................................................................................................34
3.11 TATRADE and CONTROL(1/3) ASSYS .................................................................................................36
3.12 CONTROL(2/3) and HP ASSYS............................................................................................................38
3.13 CONTROL ASSY(3/3)............................................................................................................................40
3.14 LCDCONT, CONNECT, KEY RTOP, KEY R, KEY L and KEY LTOP ASSYS ........................................42
3.15 WAVEFORMS........................................................................................................................................44
4. PCB CONNECTION DIAGRAM ..................................................................................................................... 45
4.1 LOAB ASSY.............................................................................................................................................45
4.2 DVDM ASSY............................................................................................................................................46
4.3 VIDEO, DSP TRADE and COMPONENT ASSYS ...................................................................................48
4.4 DSP ASSY...............................................................................................................................................52
4.5 FM/AM TUNER MODULE........................................................................................................................54
4.6 KEY RTOP, KEY R, KEY L and KEY LTOP ASSYS................................................................................. 55
4.7 TXTRADE, CONTROL and HP ASSYS...................................................................................................56
4.8 LCDCONT and CONNECT ASSYS.........................................................................................................60
5. PCB PARTS LIST ........................................................................................................................................... 62
6. ADJUSTMENT ............................................................................................................................................... 68
6.1 TUNER SECTION....................................................................................................................................68
6.2 ADJUSTMENT ITEMS AND LOCATION .................................................................................................69
6.3 JIGS AND MEASURING INSTRUMENTS...............................................................................................69
6.4 NECESSARY ADJUSTMENT POINTS ................................................................................................... 70
6.5 TEST MODE ............................................................................................................................................71
6.6 MECHANISM ADJUSTMENT.................................................................................................................. 72
7. GENERAL INFORMATION............................................................................................................................. 74
7.1 DIAGNOSIS.............................................................................................................................................74
7.1.1 TEST MODE .........................................................................................................................................74
7.1.2 DISPLAY SPECIFICATIONS OF THE TEST MODE............................................................................. 76
7.1.3 FUNCTIONAL SPECIFICATION OF THE SHORTCUT KEY................................................................ 77
7.1.4 SPECIFICATION OF MODEL INFORMATION .....................................................................................78
7.1.5 FUNCTIONAL SPECIFICATION OF THE SERVICE MODE.................................................................79
7.1.6 MECHANICAL ERROR HISTORY........................................................................................................80
7.1.7 ID NUMBER AND DATA SETTING.......................................................................................................85
7.1.8 TROUBLE SHOOTING .........................................................................................................................88
7.1.9 DSP TROUBLE SHOOTING.................................................................................................................91
7.1.10 SEQUENCE AFTER POWER ON...................................................................................................... 95
7.1.11 SINGLE OPERATION METHOD.......................................................................................................100
7.1.12 PROTECTION CIRCUIT...................................................................................................................101
7.1.13 DISASSEMBLY.................................................................................................................................105
7.2 IC ...........................................................................................................................................................114
7.3 DISC/CONTENT FORMAT ....................................................................................................................137
7.4 CLEANING............................................................................................................................................. 139
8. PANEL FACILITIES ......................................................................................................................................140

XV-DV830 5
5678
5678
C
D
F
A
B
E
1. SPECIFICATIONS
Amplifier Section
Continuous Power (RMS). . . . .75W/channel
. . . . . . . . . . . . . . . . . . . .(1 kHz, THD 10%, 6Ω)
Disc section
Digital audio
characteristics . . . . . . . DVD fs: 96 kHz, 24-bit
Type. . . . . .DVD system, Video CD system and
Compact Disc digital audio system
Frequency response
48 kHz sampling. . . . . . . . . . 4 Hz – 22 kHz
96 kHz sampling. . . . . . . . . . 4 Hz – 44 kHz
192 kHz sampling. . . . . . . . . 4 Hz – 88 kHz
S/N ratio. . . . . . . . . . . . . . . . . . . . . . . . 108dB
Dynamic range . . . . . . . . . . . . . . . . . . . 95dB
Total harmonic distortion . . . . . . . . . . .0.005 %
Wow and Flutter. . . . . . .Limit of measurement
(±0.001 % W.PEAK) or less (JEITA)
FM tuner section
Frequency Range. . . . . . . . . . . . .87.5 - 108MHz
Antenna . . . . . . . . . . . . . . . .75Ω, unbalanced
AM tuner section
Frequency Range
Antenna . . . . . . . . . . . . . . . . . . .Loop antenna
Miscellaneous
Power Requirements . . . . . . AC 120V, 60 Hz
Power Consumption. . . . . . . . . . . . . . . .178 W
Power Consumption
in standby mode . . . . . . . . . . . . . . . . . . .0.48 W
Dimensions:
DVD/CD Tuner. .360 (W) x 74 (H) x 270 (D) mm
Display Unit . . . . 274 (W) x 44 (H) x 35 (D) mm
Weight:
DVD/CD Tuner. . . . . . . . . . . . . . . . . . . . 3.2 kg / 7 lb
Display Unit . . . . . . . . . . . . . . . . . . . . . . 0.2 kg / 7 oz
Accessories
Operating Instructions. . . . . . . . . . . . . . . . . . 1
Setup guide. . . . . . . . . . . . . . . . . . . . . . . . . . 1
Display unit. . . . . . . . . . . . . . . . . . . . . . . . . . 1
Remote control unit . . . . . . . . . . . . . . . . . . . . 1
Power cord . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Video Cord (yellow plugs). . . . . . . . . . . . . . . 1
Display cable (gray plugs). . . . . . . . . . . . . . . 1
Control cable A (blue plugs). . . . . . . . . . . . . 1
Control cable B (black plugs) . . . . . . . . . . . . .1
FM antenna . . . . . . . . . . . . . . . . . . . . . . . . . . .1
AM loop antenna . . . . . . . . . . . . . . . . . . . . . .1
Dry cell batteries (AA/R6) . . . . . . . . . . . . . . . 2
Speaker cords (5 m). . . . . . . . . . . . . . . . . . . . 3
Speaker cords (10 m). . . . . . . . . . . . . . . . . . . 2
Non-skid pads (center speaker). . . . . . . . . . .3
Non-skid pads (subwoofer). . . . . . . . . . . . . . 4
Speaker stands. . . . . . . . . . . . . . . . . . . . . . . 4
Warranty Card. . . . . . . . . . . . . . . . . . . . . . . . 1
Satellite Speaker System
(S-DV830ST)
Type Sealed, antimagnetic
Speaker. . . . . . . . . . . . . . . . .8.7 cm (cone type)
. . . . . . . . . . . . . . . . . . . . . . . .5.2 cm (cone type)
Nominal impedence. . . . . . . . . . . . . . . . . . 6Ω
Frequency range. . . . . . . . . . . .80 – 20,000 Hz
Max. input . . . . . . . . . . . . . . . . . . 75 W (JEITA)
Front / Surround speakers
Dimensions. . . . .110 (W) x 59 (D) x 284 (H) cm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . 0.7 kg
Center speaker
Dimensions. . . . .284 (W) x 58 (D) x 110 (H) cm
Weight . . . . . . . . . . . . . . . . . . . 0.7 kg /1 lb. 9 oz
With 9kHz step . . . . . . 530 kHz to 1,700 kHz
With 10kHz step . . . . . 531 kHz to 1,602 kHz
14 (W) x 2 (H) x 10 (D) in.
29/32 5/8
3/16
4 (W) x 2 (H) x 10 (D) in.
5/16 3/16
11/32
11 (W) x 2 (H) x 11 (D) in.
9/32 3/16
3/16
10 (W) x 1 (H) x 1 (D) in.
23/32 3/8
25/32
Powered subwoofer
(S-DV830SW)
Type. . . . . .Bass reflex floor type, antimagnetic
Speaker. . . . . . . . . . . . . . . . 18 cm (cone type)
Nominal impedence. . . . . . . . . . . . . . . . . . 6Ω
Frequency range. . . . . . . . . . . . . . .28 – 250 Hz
Max. input . . . . . . . . . . . . . . . . . . 75 W (JEITA)
Dimensions. . . .192 (W) x 436 (D) x 395 (H) cm
Weight . . . . . . . . . . . . . . . . . 12.5 kg / 27 lb. 9 0z
7 (W) x 17 (H) x 15 (D) in.
5/32 9/16
9/16

XV-DV830
6
1234
1234
C
D
F
A
B
E
• Specifications and design subject to
possible modification without notice, due
to improvements.
accessories
Remote control unit Dry cell batteries
(sizeAA/R6P)x2 Display unit(AXX7163) AM loop antenna FM antenna
Control cable A Control cable B Display cable Video cord
Gray plugs Yellow plugs Blue plugs Black plugs
(ATB7009) (ADH7004)
(VDE1065)(ADE7077) L=1.5m(ADE7078) L=3m(ADE7063) L=3m
(XXD3058)
• Power cord
(ADG7021)
ST+
TUNE+
ENTER
TUNE–
MASTER
VOLUME
ST–
STANDBY/ON
CD
TRAY
OPENCLOSE
DOOR
OPENCLOSE
DVD FM/AM TV VIDEO
V1/V2/V3
0
1
4
4
¡
8
3
7
0
DVDMENU
RETURN
SOUND
TVCONTROL
PVOL
INPUT
MUTE
PROGRAM REPEAT RANDOM
AUTO
ROOMSETUP
TESTTONE
123
DVDSYSTEM
CHLEVELTCPMENUSYSMENU
DIMMERDVDDISPSYSDISP
SETUP
SURROUND
ANGLE
AUDIO SUBTITLE
ZOOM
ADVANCED
456
789
0
LANGUAGE
MAIN
AX0000
SUB
PCM
TELETEXTON/OFF
TIMER
(CLOCKADJ)
FOLDER–
CLR
ENTER
/
–––
FOLDER+
This product includes FontAvenue®
fonts licenced by NEC corporation.
FontAvenue is a registered trademark
of NEC Corporation.

XV-DV830 7
5678
5678
C
D
F
A
B
E

XV-DV830
8
1234
1234
C
D
F
A
B
E
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
NOTES:
Top
Front
ST+
TUNE+
ENTER
TUNE–
MASTER
VOLUME
ST–
STANDBY/ON
CD FM/AM
OPEN/CLOSEDISPLAY
DVD TUNER TV LINE
L1/L2
DVDMENU
RETURN
SOUND
TV CONTROL
PVOL
INPUT
MUTE
TESTTONE
123
ZOOM TOPMENU
CHLEVEL
DIMMER
REPEAT
AUDIO ANGLE
RANDOM
SUBTITLE
PROGRAM
456
789
0
FOLDER–
ROOMSETUP
CLR
ENTER
FOLDER+
MENU
HOME
SETUP
SYSTEM
MIDNIGHT
QUIET/ CLOCK
TIMER/
BASSMODE DIALOGUE VIRTUALSB
AUTO SURROUND ADVANCED
/
–––
MAIN SUB PDP
0
8
7
3¡1
4¢
19
20
16
17
21
15
14
5,6
1,2,3,4,7,10
15
11
18
21 8
13
12
9
Display Unit

XV-DV830 9
5678
5678
C
D
F
A
B
E
PACKING parts List
Mark No. Description Part No.
> 1Power Cord ADG7021
2 FM Antenna ADH7004
3 AM Loop Antenna ATB7009
4 Video Cord VDE1065
5 Control Cable A (Blue Pugs) ADE7063
6 Control Cable B (Black Plugs) ADE7078
7 Display Cable (Gray Plugs) ADE7077
8 Remote Control Unit XXD3058
9 Battery Cover XZN3130
NSP 10 Dry Cell Batteries (R6P,AA) VEM1031
11 Operating Instructions ARE7335
(English, French)
12 Setup Guide ARE7337
(English, French)
NSP 13 Warranty Card ARY7045
NSP 14 Polyethylene Bag AHG7098
NSP 15 Polyethylene Bag Z21-038
16 Front Pad AHA7420
17 Rear Pad AHA7421
18 Spacer AHB7087
19 Packing Case AHD8224
20 Packing Sheet AHG7015
21 Protection Bag AHG7109

XV-DV830
10
1234
1234
C
D
F
A
B
E
2.2 EXTERIOR SECTION
C
H
I
K
M
A
A
C
B
B
D
E
D
J
J
M
KL
G
F
E
L
I
GH
F
39
34
29
41
42
42
42
19
8
23
29
29
29
18
9
12 11
16
10
42
42
42
50
47
50
50
48
49
41
41
41 45
41
24
41
40 31
36
32
30
41
41 38
41
22
41
18
41
41
41
41
41
42
42
42
42
42
27
26
25
2
4
3
43
43
19
17
7
17
13
20
5
6
32
44
28
28
35
36
40
14
47
16
46
1
42
42
42
37
33
CONTACT SIDE
NON-CONTACT
SIDE
I
L
M
N
O
B
FP
GH
C
DE
Refer to
"2.3 LOADING
MECHA ASSY".

XV-DV830 11
5678
5678
C
D
F
A
B
E
EXTERIOR SECTION parts List
Mark No. Description Part No.
1DVDM Assy AWM7813
2 VIDEO Assy AWU8104
3 DSP Assy AWX8325
4 DSP TRADE Assy AWU8101
5 FM/AM TUNER Module AXQ7228
6 TX TRADE Assy AWU8115
7 CONTROL Assy AWU8103
8 HP Assy AWU8102
9 KEY R TOP Assy AWU8113
10 KEY R Assy AWU8112
11 KEY L Assy AWU8110
12 KEY L TOP Assy AWU8111
13 COMPONENT Assy AWU8116
NSP 14 LOADING MECHA Assy VWT1208
15 • • • • • •
16 30P FFC/30V ADD7436
17 30P FFC/30V ADD7437
18 5P FFC/30V ADD7438
19 13P FFC/30V ADD7439
20 19P FFC/30V ADD7440
21 • • • • • •
22 Rear Panel ANC8211
NSP 23 Bottom Plate ANF7035
NSP 24 Top Plate ANF7036
25 Angle DSP ANG7467
26 Angle PCB S ANG7468
27 Angle PCB M ANG7475
28 Screw Plate ANG7470
29 Leg AEB7090
30 Tuner Spacer AEB7320
31 Top Spacer AEB7321
32 Side Plate AAK8135
33 Tray Panel AAN7223
34 Bottom Base ZUC AMA7030
35 Top Panel AMB7850
36 Button Assy T AXG7205
37 Button Assy F AXG7206
NSP 38 ID Label Assy VXW1003
NSP 39 Name Label R AAL7338
40 65 Label ARW7050
41 Screw BBZ30P080FMC
42 Screw BPZ30P080FZK
43 Screw PSC30P080FNI
NSP 44 Energy Star Label AAX7876
NSP 45 DVD Assy AXA7126
46 Connector Assy PG05KK-E25
47 Cushion AEB7267
48 Adapter02 L ANW7267
49 Adapter02 R ANW7268
50 Screw BPZ30P080FMC
Mark No. Description Part No.

XV-DV830
12
1234
1234
C
D
F
A
B
E
2.3 LOADING MECHA ASSY
LOADING MECHA ASSY parts List
A
A
2
3
5
4
12
23 13
17
21
16
22
15
14
22
22
22
20
18
19
91
7
10
11
6
8
8
8
8
A
Refer to
"2.4 TRAVERSE MECHA. ASSY-S".
Lubricating Oil
GYA1001
Daifree
GEM1036
Refer to
" Application of Lubricant".
Note :
Lubricating Oil
GYA1001
To DVDM CN101 (Pickup Assy-S)
To DVDM CN104 (Stepping Motor)
To DVDM CN105 (Spindle Motor)
Mark No. Description Part No.
NSP 1 LOAB Assy VWG2346
2Traverse Mechanism Assy-S VXX2871
3 Loading Motor Assy VXX2872
4 Motor Pulley PNW1634
5 Motor VXM1105
6 Flexible Cable (24P) VDA1947
7 Connector Assy 2P VKP2253
8 Floating Rubber VEB1351
9 Belt VEB1330
10 Stabilizer VNE2253
11 Loading Base VNL1917
12 Float Base DVD VNL1918
13 Drive Cam VNL1919
14 Gear Pulley VNL1921
15 Loading Gear VNL1922
16 Drive Gear VNL1923
17 SW Lever VNL1925
18 Clamper Plate VNE2251
19 Bridge VNE2252
20 Clamper VNL1924
21 Screw JGZ17P028FMC
22 Screw Z39-019
23 Tray VNL1920
Mark No. Description Part No.

XV-DV830 13
5678
5678
C
D
F
A
B
E
Application of Lubricant
Lubricating Oil
GYA1001
Around the shaft
No. 11
Loading Base
No. 23
Tray
No. 13
Drive Cam
No. 13
Drive Cam
No. 23
Tray
Front View Rear View
Daifree
GEM1036
Inner side of a ditch
Concave of unevenness
Top View Bottom View
Daifree
GEM1036
Daifree
GEM1036
Side of the rib
Lubricating Oil
GYA1001
Concave of unevenness
Daifree
GEM1036 Concave of unevenness
Daifree
GEM1036
Lubricating Oil
GYA1001
Lubricating Oil
GYA1001 Lubricating Oil GYA1001
Inner side of a ditch
Lubricating Oil
GYA1001 Inner side of a ditch
Lubricating Oil
GYA1001

XV-DV830
14
1234
1234
C
D
F
A
B
E
2.4 TRAVERSE MECHA ASSY-S
TRAVERSE MECHA ASSY-S parts List
To
DVDM CN104
(Stepping Motor)
To DVDM CN105
(Spindle Motor)
To
DVDM CN101
(Pickup Assy)
CONTACT SIDE
NON-CONTACT
SIDE
12
3
7
8
1
17
16
17
10
13
17
10
6
11
14
16
2
9
15 (Torque : 0.15 ±0.01 N•m)
15 (Torque : 0.15 ±0.01 N•m)
4 (Adjustment screw)
5
(Adjustment
spring)
Screw Tight
GYL1001
Silicone Adhesive
GEM1037
Silicone Adhesive
GEM1037
Mark No. Description Part No.
1 Spindle Motor VXM1099
2 Stepping Motor VXM1101
>
3 Pickup Assy-S OXX8005
4Skew Screw VBA1080
5Skew Spring VBH1335
6 Guide Bar VLL1514
7 Sub Guide Bar VLL1515
8 Leaf Spring VNC1023
9 Joint Spring VNC1019
10 Support Spring VNC1020
NSP 11 Mechanism Chassis VNE2248
12 Damper Sheet VEB1335
13 Spacer VNL1913
14 Joint 03 VNL1949
15 Tapping Screw OBA8021
16 Screw BBZ20P050FZK
17 Screw PMA26P100FMC
Mark No. Description Part No.

XV-DV830 15
5678
5678
C
D
F
A
B
E
2.5 DISPLAY UNIT
DISPLAY UNIT parts List
K
J
1
8
9
7
7
13
12
18
14
7
2
4
3
6
510
11
16
16
17 16
15
Mark No. Description Part No.
1 LCD CONT Assy AWU8119
2 CONNECT Assy AWU8118
3 LCD AAV7098
4 LED (White) NSPW510BS-1064
5 Diffusion Sheet AAK8144
6 Earth Spring ABH7233
7 Leg AEB7090
8 Back Light Case AMR7463
9 REF Plate A AMR7464
10 REF Plate B AMR7465
11 Optical Plate AMR7466
12 Display Window AAK8137
13 Display AL AAP7094
14 Display Panel AMB7851
15 Display Cover AMC7051
16 Screw BPZ30P080FZK
17 Screw PSC30P080FNI
18 Display Unit AXX7163

XV-DV830
16
1234
1234
C
D
F
A
B
E
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM
3.1 BLOCK DIAGRAM
- 6dB - 10dB
system control
MPEG Video Decoder
Video Encoder
(withPictureControl)
Video DAC
(Progressive: 54MHz)
Audeo Decoder
-DD MPEG
JPEG Viewer
WMA Playback
RW Playback
(VRmode with CPRM)
3.3V, 1.8V
208pin, PQFP
IC802
64M SDRAM
IC603
16M
FLASH ROM
SPINDLE
Motor
03SD PU
PlCK UP
ASSY
DVD MODULE
FTS&SPDL DRlVER
Steppingtor M
+ -
VlDEO AMP
DRlVER
6IN-6OUT
M63018FP
IC101
MM1623
L
20MHz
IC601
IC801
IC802
IC851
DSD
DAC
IC871
DSD
DAC
IC861
DSD
DAC
SAA7893
HL/C2
IC501
STI5588CVB
BACK END IC
27MHz
IC301
STM6316ATXXA
FRONT END IC
LoadMotor M
+ -
*single disc mecha
DOUT
FL/FR
SW
Center
SL/SR
V
C
Y
B/PB
R/PR
G/Y
DolbyDigital Decoder
Dolby PrologicII
DTS Decoder
IC8501
DSPD56367
DSP
IC8201
DIR
AK4114
IC8001
INPUT
SELECTOR
IC8401
AK4529
8ch
CODEC
LINE 1
IN
LINE 2
IN
TV IN
DIGITAL
OPT IN1
DIGITAL
OPT IN2
DIGITAL
OPT OUT
JA8251
BUFFER
IC8003
ATTENUATOR
JA8252
JA8253
IIC
EMI SACD LSI
64M SDRAM
IC8251
DVDM ASSY
B
DSP ASSY
F
VIDEO ASSY(2/2)
FM/AM
TUNER
MODULE
F
Traverse Mechanism Assy
VWT1199
CN201
CN5605
CN5502
CN8908
CN8011
CN8003
CN8907
(1/2)
CN8906(2/3)
CN8906(1/3)
CN8007(1/2)
CN8302(1/2)
CN8401(1/2)
CN8007(2/2)
CN943(2/2)
CN8301(2/2)
CN101
CN1013
CN103
CN105
CN104
CN943(1/2)CN901
CN5604
CN8301(1/2)
C 2/2

XV-DV830 17
5678
5678
C
D
F
A
B
E
V
C
Y
B/PB
R/PR
G/Y
LPF
LPF
LPF
LPF 6ch E-vol
IC3001
IC3901 IC3902
IC8402
IC8651
IC8401
IC8381
IC8382
IC3101
IC3102
IC3103
IC3104
M62446AFP
E-VOL
IC3301
IC3401
STK402- 270
STK402- 270
3ch Power
Amp
3ch Power
Amp
E-VOL
LC75344
COMPOSITE
VIDEO OUT
COMPONENT
VIDEO OUT
S-VIDEO OUT
SW
Center
HEADPHONE
OUT
FL/FR
OUT
SW
OUT
CENTRE
OUT
SL/SR
OUT
micro
Processoer
LINE
OUT
ANDREW
IR
SENSOR
PDC110B
IC5501
SPEAKER
RELAY
-
+
SW MIX/GAIN
FL/FR
SL/SR
REC
OUT
REC OUT
SELECT
LCD
KEY
CONTROL ASSY
H
VIDEO ASSY(1/2)
C 1/2
LCDCONT ASSY
DISPLAY UNIT
J
KEY R ASSY
MKEY L ASSY
NKEY LTOP ASSY
O
KEY RTOP ASSY
L
CONNECT ASSY
K
POWERED SUBWOOFER
HP ASSY
I
COMPONENT
ASSY
P
CN8906(3/3)
CN8907(2/2)
JA3901
CN3901 CN3701
CN8501
CN8401(2/2)
CN8302(2/2)
CN3902
CN5201
CN5101
CN8811
CN8951
CN5001
CN5601
CN1902
CN5102

XV-DV830
18
1234
1234
C
D
F
A
B
E
3.2 LOAB ASSY and OVERALL WIRING DIAGRAM
PICKUP ASSY-S (OXX8005)
STEPPING
MOTOR
: VXM1102
LOADING MOTOR
ASSY : VXX2505
SPINDLE MOTOR
: VXM1098
A
LOAB ASSY
(VWG2346)
A
VIDEO ASSY (AWU8104)
C
KEY LTOP
ASSY
(AWU8111)
O
KEY L ASSY
(AWU8110)
N
DSP TRADE ASSY (AWU8101)
E
B1/4 - B4/4
DVDM ASSY (AWM7813)
B
D1/2 - D2/2
DSP ASSY (AWX8325)
D
CN8011
CN8007
CN8003
CN943
COMPONENT ASSY
(AWU8116)
P
