Pioneer X-SMC1-K User manual

Operating Instructions
Mode d’emploi
Manual de instrucciones
Register your product at:
http://www.pioneerelectronics.com (US)
http://www.pioneerelectronics.ca (Canada)
http://www.pioneerelectronics.com (États-Unis)
http://www.pioneerelectronics.ca (Canada)
• Protect your new investment
The details of your purchase will be on file for reference in the event of an insurance claim such as loss or theft.
• Improve product development
Your input helps us continue to design products that meet your needs.
• Receive a free Pioneer newsletter
Registered customers can opt in to receive a monthly newsletter.
• Receive free tips, updates and service bulletins on your new product
X-SMC1-K
Slim AV Micro System
Système AV Compact
Sistema Micro Slim AV
X-SMC1_CUXZTSM_En.book 1 ページ ２０１１年７月８日 金曜日 午後１２時５４分

NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
D8-10-1-2_A1_En
This Class B digital apparatus complies with
Canadian ICES-003.
D8-10-1-3_A1_En
Information to User
Alterations or modifications carried out without
appropriate authorization may invalidate the user’s
right to operate the equipment.
D8-10-2_A1_En
WARNING: Handling the cord on this product or
cords associated with accessories sold with the
product may expose you to chemicals listed on
proposition 65 known to the State of California and
other governmental entities to cause cancer and
birth defect or other reproductive harm.
Wash hands after handling.
D36-P5_B1_En
WARNING
Before plugging in for the first time, read the following
section carefully.
The voltage of the available power supply differs
according to country or region. Be sure that the
power supply voltage of the area where this unit
will be used meets the required voltage (e.g., 230 V
or 120 V) written on the AC adapter label.
D3-4-2-1-4*_A1_En
VENTILATION CAUTION
When installing this unit, make sure to leave space
around the unit for ventilation to improve heat radiation
(at least 10 cm at top, 10 cm at rear, and 10 cm at each
side).
WARNING
Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the product,
and to protect it from overheating. To prevent fire
hazard, the openings should never be blocked or
covered with items (such as newspapers, table-cloths,
curtains) or by operating the equipment on thick carpet
or a bed.
D3-4-2-1-7b*_A1_En
Operating Environment
Operating environment temperature and humidity:
+5 °C to +35 °C (+41 °F to +95 °F); less than 85 %RH
(cooling vents not blocked)
Do not install this unit in a poorly ventilated area, or in
locations exposed to high humidity or direct sunlight (or
strong artificial light)
D3-4-2-1-7c*_A1_En
IMPORTANT NOTICE
THE MODEL NUMBER AND SERIAL NUMBER OF THIS EQUIPMENT ARE ON THE REAR OR BOTTOM.
RECORD THESE NUMBERS ON YOUR ENCLOSED WARRANTY CARD AND KEEP IN A SAFE PLACE FOR FUTURE
REFERENCE.
D36-AP9-1_A1_En
WARNING
This equipment is not waterproof. To prevent a fire or
shock hazard, do not place any container filled with
liquid near this equipment (such as a vase or flower
pot) or expose it to dripping, splashing, rain or
moisture.
D3-4-2-1-3_A1_En
WARNING
To prevent a fire hazard, do not place any naked flame
sources (such as a lighted candle) on the equipment.
D3-4-2-1-7a_A1_En
X-SMC1_CUXZTSM_En.book 2 ページ ２０１１年７月８日 金曜日 午後１２時５４分

The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
IMPORTANT
D3-4-2-1-1_A1_En
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s
instructions.
Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
Only use attachments/accessories specified by
the manufacturer.
Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
Unplug this apparatus during lightning storms
or when unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
D3-7-13-69_En
11)
12)
13)
14)
CAUTION
The STANDBY/ON switch on this unit will not
completely shut off all power from the AC outlet.
Since the power cord serves as the main disconnect
device for the unit, you will need to unplug it from the
AC outlet to shut down all power. Therefore, make
sure the unit has been installed so that the power
cord can be easily unplugged from the AC outlet in
case of an accident. To avoid fire hazard, the power
cord should also be unplugged from the AC outlet
when left unused for a long period of time (for
example, when on vacation). D3-4-2-2-2a*_A1_En
If the AC plug of this unit does not match the AC
outlet you want to use, the plug must be removed
and appropriate one fitted. Replacement and
mounting of an AC plug on the power supply cord of
this unit should be performed only by qualified
service personnel. If connected to an AC outlet, the
cut-off plug can cause severe electrical shock. Make
sure it is properly disposed of after removal.
The equipment should be disconnected by removing
the mains plug from the wall socket when left unused
for a long period of time (for example, when on
vacation). D3-4-2-2-1a_A1_En
X-SMC1_CUXZTSM_En.book 3 ページ ２０１１年７月８日 金曜日 午後１２時５４分

POWER-CORD CAUTION
Handle the power cord by the plug. Do not pull out the
plug by tugging the cord and never touch the power
cord when your hands are wet as this could cause a
short circuit or electric shock. Do not place the unit, a
piece of furniture, etc., on the power cord, or pinch the
cord. Never make a knot in the cord or tie it with other
cords. The power cords should be routed such that they
are not likely to be stepped on. A damaged power cord
can cause a fire or give you an electrical shock. Check
the power cord once in a while. When you find it
damaged, ask your nearest PIONEER authorized
service center or your dealer for a replacement.
S002*_A1_En
AC adapter CAUTION
• Make sure to grasp the body of the AC adapter when
removing it from the power outlet. If you pull the
power cord, it may become damaged which could
lead to fire and/or electrocution.
• Do not attempt to plug in or remove the AC adapter
with wet hands. This may result in electrocution.
• Do not insert the power cord of AC adapter into a
power outlet where the connection remains loose
despite inserting the prongs all the way into the
outlet. Heat may be generated which could lead to
fire. Consult with the retailer or an electrician
regarding replacement of the power outlet.
When using this product, confirm the safety
information shown on the bottom of the unit and the
AC adapter label. D3-4-2-2-4_B1_En
WARNING
Store small parts out of the reach of children and
infants. If accidentally swallowed, contact a doctor
immediately.
This product is for general household purposes. Any
failure due to use for other than household purposes
(such as long-term use for business purposes in a
restaurant or use in a car or ship) and which requires
repair will be charged for even during the warranty
period. K041_A1_En
The Safety of Your Ears is in Your Hands
Get the most out of your equipment by playing it at a
safe level – a level that lets the sound come through
clearly without annoying blaring or distortion and, most
importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time, your hearing
“comfort level” adapts to higher volumes of sound, so
what sounds “normal” can actually be loud and
harmful to your hearing. Guard against this by setting
your equipment at a safe level BEFORE your hearing
adapts.
ESTABLISH A SAFE LEVEL:
• Set your volume control at a low setting.
• Slowly increase the sound until you can hear it
comfortably and clearly, without distortion.
• Once you have established a comfortable sound
level, set the dial and leave it there.
BE SURE TO OBSERVE THE FOLLOWING
GUIDELINES:
• Do not turn up the volume so high that you can’t
hear what’s around you.
• Use caution or temporarily discontinue use in
potentially hazardous situations.
• Do not use headphones while operating a motorized
vehicle; the use of headphones may create a traffic
hazard and is illegal in many areas.
S001a_A1_En
Store the AC adapter out of the reach of
children and infants.
The AC adapter cord may accidentally wind around the
neck and it may cause suffocation.
CAUTION
This product is a class 1 laser product classified
under the Safety of laser products, IEC 60825-1:2007.
CLASS 1 LASER PRODUCT
D58-5-2-2a_A1_En
X-SMC1_CUXZTSM_En.book 4 ページ ２０１１年７月８日 金曜日 午後１２時５４分

5
En
English Français Español
Thank you forbuying this Pioneerproduct.
Please read through these operating instructions so that you will know how to operate yourmodel properly. Afteryou
have finished reading the instructions, put them in a safe place forfuture reference.
Contents
01 Before you start
What’s in the box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Loading the batteries in the remote control . . . . . . . . . .6
Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 6
02 Connections
Connecting using a video cable. . . . . . . . . . . . . . . . . . . .7
Connecting using an HDMI cable . . . . . . . . . . . . . . . . . .7
Connecting to a TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting to an AV receiveroramplifier. . . . . . . . . . . . 8
Audio signals that can be output from this unit's HDMI
OUT terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting the FM antenna. . . . . . . . . . . . . . . . . . . . . . .8
Connecting optional Bluetooth® adapter
(optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Connecting USB storage devices . . . . . . . . . . . . . . . . . .9
Plugging in. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
03 Part names and functions
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Toppanel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
04 iPod/iPhone playback
Confirming what iPod/iPhone models are
supported . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Connecting youriPod/iPhone . . . . . . . . . . . . . . . . . . . .15
Connecting yourTV. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Playing youriPod/iPhone . . . . . . . . . . . . . . . . . . . . . . . .16
05 Disc playback
Playing discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Eject a disc from this unit. . . . . . . . . . . . . . . . . . . . . . . . . 17
Example of display on the front panel display. . . . . . . .17
Playing in the desired order(Programmed Play) . . . . .18
06 Bluetooth ® Audio playback (optional)
Music playback using Bluetooth wireless
technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Remote control operation. . . . . . . . . . . . . . . . . . . . . . . . . 19
Connecting optional Bluetooth® adapter. . . . . . . . . . .19
Setting the PIN code . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Pairing Bluetooth® adapterand Bluetooth wireless
technology device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Listening to Music Contents of Bluetooth wireless
technology device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
AIR JAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
07 USB playback
Playing files stored on USB storage devices. . . . . . . . .22
Playing in the desired order(Programmed Play) . . . . .22
08 Using the tuner
Connect the FM antenna . . . . . . . . . . . . . . . . . . . . . . . .23
Listening to the FM radio broadcasts . . . . . . . . . . . . . .23
Saving stations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Listening to station presets . . . . . . . . . . . . . . . . . . . . . .23
09 Other connections
Connecting auxiliary components . . . . . . . . . . . . . . . . .24
10 Changing the settings
Initial settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Setting the clock display . . . . . . . . . . . . . . . . . . . . . . . . . 25
Setting the time format . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Setting the volume limit . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Setting the PIN code. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Settings forDVD/CD and USB playback. . . . . . . . . . . .26
Closing the HOME MENU screen . . . . . . . . . . . . . . . . . . 26
Audio Settings parameters . . . . . . . . . . . . . . . . . . . . . . . 26
Video Adjust parameters . . . . . . . . . . . . . . . . . . . . . . . . . 26
Initial Settings parameters. . . . . . . . . . . . . . . . . . . . . . . . 26
Setting the HDMI Resolution settings back to their
defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Sound settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Using sound retriever. . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Using virtual surround . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Adjusting the bass and treble . . . . . . . . . . . . . . . . . . . . . 28
Restoring all the settings to the defaults . . . . . . . . . . .28
11 Using the timer
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Setting the wake-uptimer. . . . . . . . . . . . . . . . . . . . . . . .29
Turning the wake-uptimeron/off . . . . . . . . . . . . . . . . . . 29
Using the wake-uptimer. . . . . . . . . . . . . . . . . . . . . . . . . 29
Using the sleeptimer. . . . . . . . . . . . . . . . . . . . . . . . . . .29
12 Playable discs and files on discs or USB
storage devices
Playable discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Playable files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
13 Additional information
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Language Code Table and Country/Area Code
Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Cautions on use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Handling discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
About iPod/iPhone . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
X-SMC1_CUXZTSM_En.book 5 ページ ２０１１年７月８日 金曜日 午後１２時５４分

Before you start01
6
En
Chapter 1:
Before you start
What’s in the box
Please confirm that the following accessories are in the box
when you open it.
• Remote control
•Powercord
•ACadapter
•Videocable
•FMwire antenna
• AAA batteries (R03) x 2
•Operating instructions (this document)
Loading the batteries in the remote
control
1 Open the rear lid and load the batteries as
illustrated below.
2 Close the rear lid.
The batteries included with the unit have been provided to
allow you check product operation and may not last long. We
recommend using alkaline batteries that have a longerlife.
Caution
• When inserting the batteries, make sure not to damage
the springs on the battery’s terminals.
• Do not use any batteries otherthan the ones specified.
Also, do not use a new battery togetherwith an old one.
• When loading the batteries into the remote control, set
them in the properdirection, as indicated by the polarity
marks (and ).
• Do not heat batteries, disassemble them, orthrow them
into flames orwater.
•Batteries may have different voltages, even if they are the
same size and shape. Do not use different types of
batteries together.
•T
oprevent leakage of battery fluid, remove the batteries
if you do not plan to use the remote control fora long
period of time (1 month ormore). If the fluid should leak,
wipe it carefully off the inside of the case, then insert new
batteries. If a battery should leak and the fluid should get
on yourskin, flush it off with large quantities of water.
• When disposing of used batteries, please comply with
governmental regulations orenvironmental public
institution’s rules that apply in yourcountry/area.
•WARNING
Do not use orstore batteries in direct sunlight orother
excessively hot place, such as inside a carorneara
heater. This can cause batteries to leak, overheat,
explode orcatch fire. It can also reduce the life or
performance of batteries.
Using the remote control
The remote has a range of about 7 m at an angle of about 30º
from the remote sensor.
Keepin mind the following when using the remote control:
•Makesure that there are no obstacles between the
remote and the remote sensoron the unit.
• Remote operation may become unreliable if strong
sunlight orfluorescent light is shining on the unit’s
remote sensor.
• Remote controllers fordifferent devices can interfere
with each other. Avoid using remotes forother
equipment located close to this unit.
•Replace the batteries when you notice a fall off in the
operating range of the remote.
30°
7 m (23 ft.)
30°
X-SMC1_CUXZTSM_En.book 6 ページ ２０１１年７月８日 金曜日 午後１２時５４分

Connections 02
7
En
English Français Español
Chapter 2:
Connections
•Besure to turn off the powerand unplug the powercord
from the poweroutlet whenevermaking orchanging
connections.
• Connect the powercord afterall the connections
between devices have been completed.
Connecting using a video cable
• When an iPod/iPhone is connected to this unit, the TV
output setting of iPod/iPhone is automatically set to
‘ON’.1
• Do not connect the unit through a VCR. Video signals fed
through VCRs may be affected by copyright protection
systems and the picture will be distorted on the
television.
Connecting using an HDMI cable
By using an HDMI cable, digital signals can be transferred to
an HDMI-compatible TV on a single cable with no loss of
picture orsound quality.2Afterconnecting, adjust unit
resolution and HDMI colorsettings according to the HDMI-
compatible TV. Also referto the operating instructions with
the HDMI-compatible TV.
HDMI, the HDMI Logo and High-Definition Multimedia
Interface are trademarks orregistered trademarks of HDMI
Licensing, LLC in the United States and othercountries.
Connecting to a TV
• If you connect this unit to yourtelevision with the HDMI
cable, sound can not be transferred from yourtelevision
to this unit. To listen to sound, connect the front panel
AUX IN mini-plug jack to yourtelevision.
Note
1 • Some iPod allow the TV output setting to be changed while connected.
• When the iPod/iPhone is disconnected from this unit, the iPod/iPhone’s TV output setting returns to its original state.
2•TheHDMI OUT terminal does not output any audio signals except DVD/CD sound.
• When playing a disc orUSB storage device content, this unit can transferdigital signals by the HDMI OUT terminal. Use the video
cable forplaying othercontent.
• This unit’s interface is designed based on the High-Definition Multimedia Interface specification.
• When an HDMI-compatible device is connected, the resolution is displayed on the front panel display.
• The resolution of video signals output from this unit’s HDMI OUT terminal is changed manually. Change the HDMI Resolution setting
(page 27). Settings fortwo units can be stored in memory.
• This unit is designed forconnection to HDMI-compatible devices. It may not operate properly if connected to DVI devices.
ANTENNA VIDEO
OUT
DC IN
19 V
FM75
Yellow
TV
Video cable
(supplied)
To video input
terminals
This unit’s rearpanel
ANTENNA
AS-BT200
LABEL SIDE
VIDEO
OUT
DC IN
19 V
FM75
HDMI
OUT
Match the direction of
the plug to the
terminal and insert
straight. To HDMI input
terminal
HDMI cable
(commercially
available)
TV
This unit’s rearpanel
X-SMC1_CUXZTSM_En.book 7 ページ ２０１１年７月８日 金曜日 午後１２時５４分

Connections02
8
En
Connecting to an AV receiver or amplifier
Audio signals that can be output from this
unit's HDMI OUT terminal
• 44.1 kHz to 96 kHz, 16-bit/ 20-bit/ 24-bit 2-channel linear
PCM audio (including 2-channel downmixing)
• Dolby Digital 5.1-channel audio
• DTS 5.1-channel audio
• MPEG audio
•Manufactured underlicense from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of
Dolby Laboratories.
Connecting the FM antenna
Connect the FM antenna plug onto the centerpin of the FM
antenna socket.1
Connecting optional Bluetooth ® adapter
(optional)
Connect the Bluetooth
®
adapter(PioneerModel No.
AS-BT200) to AS-BT200 terminal on the rearpanel.
•Open the AS-BT200 terminal’s coverand connect the
Bluetooth
®
adapterwith the label side facing to the right,
then close the cover.
ANTENNA
AS-BT200
LABEL SIDE
VIDEO
OUT
DC IN
19 V
FM75
HDMI
OUT
Match the direction of
the plug to the
terminal and insert
straight. To HDMI input
terminal
HDMI cable
(commercially
available)
TV
This unit’s rearpanel
To HDMI input
terminal
From HDMI
output terminal
AV receiveror
amplifier
HDMI cable
(commercially
available)
Note
1Toensure optimum reception, make sure the FM antenna is fully extended and not coiled orhanging at the rearof the unit.
ANTENNA VIDEO
OUT
DC IN
19 V
FM75
FM wire antenna (supplied)
This unit’s rearpanel
Bluetooth® adapter
(commercially available)
This unit’s
rearpanel
Cover
X-SMC1_CUXZTSM_En.book 8 ページ ２０１１年７月８日 金曜日 午後１２時５４分

Connections 02
9
En
English Français Español
Connecting USB storage devices
Plugging in
Important
•Before making orchanging the connections, switch off
the powerand disconnect the powercord from the AC
outlet.
Afteryou’ve finished making all connections, plug the unit
into an AC outlet.
1 Plug the supplied AC adapter into the DC IN
socket on the back of the unit.
2 Plug the supplied power cord into the AC
adapter then plug the other end into an AC
outlet.
USB storage device
(commercially available)
This unit’s front panel
ANTENNA VIDEO
OUT
DC IN
19 V
FM75
To AC outlet
AC adapter
(supplied)
This unit’s rearpanel
Powercord (supplied)
X-SMC1_CUXZTSM_En.book 9 ページ ２０１１年７月８日 金曜日 午後１２時５４分

Part names and functions03
10
En
Chapter 3:
Part names and functions
Remote control
1 STANDBY/ON
Press to turn the poweron and off.
2 Number buttons (0 to 9)
Use these to specify and play the folder, track orfile you
want to view/listen to. Also use them to select the station
preset when using the tuner, etc.
AUDIO*
Fordiscs orfiles including multiple audio streams/
channels, the audio stream/ channel can be switched
during playback. Forfiles stored in iPod/iPhone, this
button is not available.
SUBTITLE*
On DVD-Video orDivX discs containing subtitles in
multiple languages, the subtitle can be switched during
playback.
ANGLE*
On DVD-Video discs containing multiple angles, the
angle can be switched during playback.
3 SET UP
Use this to change initial settings of the unit. (page 25)
4MENU
•Press to display the menu screen orDisc Navigator.
• Select and play the title, chapter, track orfile from the
Disc Navigator.
Ex.: DVD-Video Disc Navigator
STANDBY/ON
4
5
12
13
1
2
6
15
3
7
8
9
24
25
26
27
28
01
04
02
05
03
06
Disc Navigator:Title
01- 49: – –
X-SMC1_CUXZTSM_En.book 10 ページ ２０１１年７月８日 金曜日 午後１２時５４分

Part names and functions 03
11
En
English Français Español
5///
Use these to select items, change settings and move the
cursor.
ENTER
Use this to implement the selected item orentera
setting that you have changed.
PRESET +/–
Use these to select station presets.
TUNE +/–
Change the frequency one stepat a time. To search for
stations automatically, press and hold forabout a few
second.
6 SOUND
Turns Virtual Surround and Sound Retriever on and off
(page 28). Also use to adjust the Bass and Treble.
7 FUNCTION /
Use to change the input source. The source changes as
below.
iPod BT AUDIO1AIR JAM1 DVD/CDUSB 
FM AUX Return to the beginning (Undisplayed)
8  PLAY
Press to start playback.
9//
•Press during playback to fast-reverse.
•Press in the pause mode to move backward frame-by-
frame. (DVD-Video orDVD VR discs only)
•Press and hold in the pause mode forslow play in the
reverse direction. (DVD-Video orDVD VR discs only)
10 STOP
Press to stopplayback.
11 PREV
Press to return to the beginning of the currently playing track
orfile. Press twice to move back to the beginning of the
previous track orfile.
12 SHIFT
Press to access the ‘boxed’ commands (above the buttons)
on the remote. These buttons are marked with an asterisk (*)
in this section.
13 HOME MENU
When selecting a DVD/CD orUSB storage device input, press
to display/ hide the HOME MENU. When selecting another
input, this button is not available.
•Audio Settings (page 26)
•Video Adjust (page 26)
•Play Mode
The Play Mode function may not work forsome discs or
files.
A-B Repeat
The specified section within a single title ortrack is
played repeatedly.
Repeat
Plays titles, chapters, tracks orfiles repeatedly.
Random
Plays titles, chapters ortracks in random order.
Program (page 18)
Plays titles, chapters, tracks orfiles in the orderin which
youprogram them.
Search Mode
Plays the specified numberortime within the title,
chapter, track orfile.
•Disc Navigator (MENU on page 10)
•Initial Settings (page 26)
14 DISP OFF
Press to turn the front panel display off when you do not need
it.
15 SLEEP
Use to put the unit in the sleepmode and select the amount
of time before sleep(page 29).
16
Use to turn on and off the timer.
Note
1Optionally available. To use BT AUDIO and AIR JAM function, you need to connect the commercially available Bluetooth
®
adapter:
AS-BT200 to the unit. See page 19 fordetails.
Audio Settings
Play Mode Disc Navigator
Initial Settings
Video Adjust
HOME MENU
DVD
A-B Repeat
Repeat
Random
Program
Search Mode
A(Start Point)
B(End Point)
Off
Play Mode
X-SMC1_CUXZTSM_En.book 11 ページ ２０１１年７月８日 金曜日 午後１２時５４分

Part names and functions03
12
En
17 CLEAR
Press to clearthe selected item.
Use this forexample if you input the wrong number.
18 RETURN
When currently on the main unit’s setting menu, disc menu,
orDisc Navigator menu, pressing this button returns you to
the preceding menu.
19 MUTE
Press to temporarily silence the sound.
20 SHUFFLE
Perform shuffle play of tracks on the selected iPod/iPhone or
DVD/CD.
21 VOLUME +/–
Use to set the listening volume. (Default setting: 10)
22 REPEAT
Perform repeat play of tracks on the selected iPod/iPhone or
DVD/CD.
23 / /
•Press during playback to fast-forward.
•Press in the pause mode to move forward frame-by-
frame. (DVD-Video, DVD VR, Video CD orDivX discs only)
•Press and hold in the pause mode forslow play in the
forward direction. (DVD-Video, DVD VR, Video CD or
DivX discs only)
24  PAUSE
Press to stopplayback temporarily. Press again to resume.
25 ZOOM
Zooming on the image. Forimages stored in iPod/iPhone, this
button is not available.
26 NEXT
Press during playback to skipahead to the beginning of the
next track orfile.
27 DISPLAY
The elapsed time, amount remaining, etc., are displayed.
(When playing files stored in iPod/iPhone orplaying in FM or
AUX mode, they are not displayed.)
28 TOP MENU
Press to display the topmenu of the DVD-Video.
X-SMC1_CUXZTSM_En.book 12 ページ ２０１１年７月８日 金曜日 午後１２時５４分

Part names and functions 03
13
En
English Français Español
Front panel
1 POWER ON
When the poweris on, this indicatorlights.
BT AUDIO1
When BT AUDIO is selected as the input source, this
indicatorlights.
AIR JAM1
When AIR JAM is selected as the input source, this
indicatorlights
TIMER
When the wake-uptimeris set to ON, this indicator
lights.
TUNE
When the tunerreceives FM broadcasts, this indicator
lights.
HDMI
When this unit is recognized by anotherHDMI
compatible component, this indicatorlights.
2 Front panel display
3 Speaker units
4 USB terminal
5 AUX IN
Use to connect auxiliary components.
6PHONES
Use to connect headphones.
7 iPod/iPhone connector ports
33
2
4567
7
1
Note
1Optionally available. To use BT AUDIO and AIR JAM function, you need to connect the commercially available Bluetooth
®
adapter:
AS-BT200 to the unit. See page 19 fordetails.
X-SMC1_CUXZTSM_En.book 13 ページ ２０１１年７月８日 金曜日 午後１２時５４分

Part names and functions03
14
En
Top panel
1 Disc slot
2  EJECT
Eject the disc.
3 STANDBY/ON
Press to turn the poweron and off.
4FUNCTION
Use to change the input source. The source changes as
below.
iPod BT AUDIO1AIR JAM1 DVD/CD USB FM
AUX Return to the beginning (Undisplayed)
5 BT AUDIO1
Switches the input source to BT AUDIO.
6AIRJAM
1
Switches the input source to AIR JAM.
7
Press to start playback. During playback, pause/unpause
playback.
8
Press to stopplayback.
9 VOLUME –/+
Use to set the listening volume. (Default setting: 10)
3 6 7 8 9
7
2
1
4 5
Note
1Optionally available. To use BT AUDIO and AIR JAM function, you need to connect the commercially available Bluetooth
®
adapter:
AS-BT200 to the unit. See page 19 fordetails.
X-SMC1_CUXZTSM_En.book 14 ページ ２０１１年７月８日 金曜日 午後１２時５４分

iPod/iPhone playback 04
15
En
English Français Español
Chapter 4:
iPod/iPhone playback
Merely by connecting youriPod/iPhone to this unit, you can
enjoy high-quality sound from youriPod/iPhone. This unit
can also be connected to a television set, letting you view
videos and images from youriPod/iPhone. When connecting
to a television set, use the included video cable. This unit can
not transfermusic, movies and images from an iPod/iPhone
via the HDMI OUT terminal.
Playback setting foriPod/iPhone music and images can be
performed from this unit orthe iPod/iPhone itself. This unit
cannot be used to record CD, tunerorothercontent on an
iPod/iPhone.
Confirming what iPod/iPhone models are
supported
The iPod/iPhone playable on this unit are shown below.1
* The iPod nano 6G cannot play back video, but can play slide
shows only.
Tip
• This system has been developed and tested forthe
software version of iPod/iPhone indicated on the website
of Pioneer(http://pioneer.jp/homeav/support/ios/na/).
• Installing software versions otherthan indicated on the
website of Pioneerto youriPod/iPhone may result in
incompatibility with this system.
Connecting your iPod/iPhone
Caution
• When connecting iPod/iPhone devices, always use the
dock adapterprovided with iPod/iPhone devices, ora
commercially available adapterdesigned to support
iPod/iPhone. The iPod/iPhone cannot be connected
without a dock adapter; attempting to connect an iPod/
iPhone without it will cause damage ormalfunction.
• An iPod/iPhone universal dock adapteris not supplied
with this unit.
1 Open the iPod/iPhone connector port.
2
2 Attach the dock adapter to iPod/iPhone
connector port.
When attaching the dock adapter, be sure to orient the front-
back directions of the dock adaptercorrectly. To attach, first
place the protruding tabs on the front side of the adapterinto
the depressions on the iPod/iPhone connectorport and press
into position. When attaching the adapter, be careful not to
strike the connectors.
iPod/iPhone Audio Video
iPod nano 1/2G —
iPod nano 3/4/5/6G *
iPod classic 
iPod touch 1/2/3/4G 
iPhone 
iPhone 3G 
iPhone 3GS 
iPhone 4 
Note
1•Pioneerdoes not guarantee that this unit plays iPod/iPhone models otherthan the ones specified.
• Some functions may be restricted depending on the model orsoftware version.
• iPod/iPhone is licensed forreproduction of non-copyrighted materials ormaterials the useris legally permitted to reproduce.
• Features such as the equalizercannot be controlled using this system, and we recommend switching the equalizeroff before
connecting.
• Pioneercannot underany circumstances accept responsibility forany direct orindirect loss arising from any inconvenience orloss of
recorded material resulting from iPod/iPhone failure.
• Fordetailed instructions on using the iPod/iPhone, please referto the manual supplied with the iPod/iPhone.
2 When opening orclosing the iPod/iPhone connectorport, support the topof the unit with yourhand to prevent it from moving
Push
X-SMC1_CUXZTSM_En.book 15 ページ ２０１１年７月８日 金曜日 午後１２時５４分

iPod/iPhone playback04
16
En
3 Connect your iPod/iPhone.
• When youriPod/iPhone is not connected to the unit,
close the iPod/iPhone connectorport firmly.
Connecting your TV
1
To watch iPod/iPhone images on a television, connect it using
the included video cable. Fordetails, see Connecting using a
video cable on page 7.
• When an iPod/iPhone is connected to the unit, the TV
output setting of the iPod/iPhone is automatically set to
ON.2
Caution
•Before making orchanging the connections, switch off
the powerand disconnect the powercord from the
poweroutlet. Plugging in should be the final step.
Playing your iPod/iPhone
Caution
• When youriPod/iPhone is connected to this unit and you
wish to operate the iPod/iPhone directly, be sure to
steady the iPod/iPhone with the otherhand to prevent
malfunctions due to faulty contacts.
1 Connect your iPod/iPhone.
• If an iPod/iPhone is connected when this unit is on,
playback of the iPod/iPhone will not begin.
2 Press FUNCTION / to select iPod as the
input source.
is shown on the front panel display.
3 Press  PLAY .
• The available iPod/iPhone’s playback control by this unit
is , , , , , , .
•Inthefollowingcase,operate youriPod/iPhone directly3:
-Searching a file by artist name orgenre.
-Playingintherepeat orshuffle mode.
- Watching images stored in iPod/iPhone on your
television.
Important
If this unit can not play the iPod/iPhone when Err is displayed,
perform the following troubleshooting checks:
• Check whetherthe iPod/iPhone is supported by this unit.
• Reconnect the iPod/iPhone to the unit. If this doesn’t
seem to work, try resetting youriPod/iPhone.
If the iPod/iPhone cannot be operated, check the following
items:
• Is the iPod/iPhone connected correctly? Reconnect the
iPod/iPhone to the unit.
• Is the iPod/iPhone experiencing a hangup? Try resetting
the iPod/iPhone, and reconnect it to the unit.
Tip
• iPod/iPhone recharging occurs wheneveran iPod/
iPhone is connected to this unit. (This function is
supported in standby mode as well.)
• When input is switched from iPod to anotherfunction,
iPod/iPhone playback is temporarily stopped.
Note
1 Fordetailed instructions on using the iPod/iPhone, please referto the manual supplied with the iPod/iPhone.
2• Some iPods allow the TV output setting to be changed while connected.
• When the iPod/iPhone is disconnected from this unit, the iPod/iPhone’s TV output setting returns to its original state.
MENU


3
2
Push
3 Fordetailed instructions on using the iPod/iPhone, please referto the manual supplied with the iPod/iPhone.
X-SMC1_CUXZTSM_En.book 16 ページ ２０１１年７月８日 金曜日 午後１２時５４分

Disc playback 05
17
En
English Français Español
Chapter 5:
Disc playback
Playing discs
1 Press STANDBY/ON to turn the power on.
The selected input is displayed on the front panel display.
• When playing a DVD-Video orDivX discs, turn the TV on
and switch TV input before starting.
• You can change the screen display language of the unit
(OSD Language on page 27).
2 Press FUNCTION / to select DVD/CD as
the input source.
Please wait until the indicatorchanges from flashing
‘’to ‘ ’.
When a disc has been slotted in the disc slot already, press
EJECT to eject the disc.
3Slotadisc.
• By using the numberbuttons (0 to 9), you can specify
and play the title, chapter, track orfile you want to view/
listen to.
• Hold the disc as shown in the illustration, insert it in the
centerof the disc slot, and press in gently from above.
• The disc will then be automatically drawn into the slot.
• If the disc does not load smoothly, do not attempt to
force it. Remove it from the slot and try inserting it again.
Attempting to force a disc causes damage or
malfunction.
• Do not touch the recording surface of the disc, since the
disc may not play properly if it has fingerprints orother
soiling.
• 8 cm discs cannot be played. Also do not attempt to use
adapters for8 cm CD to play such discs, since
malfunction may result.
Eject a disc from this unit
• Press EJECT on the top panel.
Tip
• When no operation has done in DVD/CD mode formore
than 30 minutes, the powerwill automatically turn off.
Example of display on the front panel
display
When the poweris turned on (On)
When the poweris turned off (OFF)
When the disc is being loaded (LOAd)
When the title menu ormenu is displayed (titLE)
When the GUI is displayed oroperated (GUI)
When the disc is stopped (StOP)
When no disc is loaded
Slot a disc with
the label side
facing front.
X-SMC1_CUXZTSM_En.book 17 ページ ２０１１年７月８日 金曜日 午後１２時５４分

Disc playback05
18
En
Playing in the desired order
(Programmed Play)
1 Press HOME MENU .
The HOME MENU is displayed.
2Use  /  to select Play Mode , then press
ENTER.
The Play Mode screen is displayed.
3Use  /  to select Program , then press
ENTER or
 .
4Use
 /  to select Create/Edit , then press
ENTER .
The Create/Edit screen differs according to the disc orfile.
5Use  / // to select the title, chapter,
track or file, then press
ENTER .
• To add to a program, first select the place in the program
(the program step), next select the title, chapterortrack,
then press ENTER (files are added at the end of
program).
•Press RETURN to return to the previous screen. If you
return to the previous screen when inputting it, the
settings you have programmed are cleared.
•Todeleteastep, highlight it and press CLEAR.
6 Press PLAY to start playback.
•Toplay a program that has already been set, select
Playback Start from the program screen, then press
ENTER.
•Toresume normal playback, select Playback Stop from
the program screen, then press ENTER. The program
remains in memory.
• To cancel the entire program, select Program Delete
from the program screen, then press ENTER.
•Programs can be played repeatedly. Select Program
Repeat from Repeat on the Play Mode screen during
programmed playback.
•Programs cannot be played in random order(random
play is not possible during programmed play).
Program Step
01.
02.
03.
04.
05.
06.
07.
08.
Title 1-01
Title 01
Program
Chapter 1-015
Chapter 001
Chapter 002
Chapter 003
Chapter 004
Chapter 005
Chapter 006
Chapter 007
Chapter 008
X-SMC1_CUXZTSM_En.book 18 ページ ２０１１年７月８日 金曜日 午後１２時５４分

Bluetooth
®
Audio playback (optional) 06
19
En
English Français Español
Chapter 6:
Bluetooth
®
Audio playback (optional)
Music playback using Bluetooth wireless
technology
When the Bluetooth
®
adapter(PioneerModel No. AS-BT200)
is connected to this unit, a product equipped with Bluetooth
wireless technology (portable cell phone, digital music player,
etc.) can be used to listen to music wirelessly.1Also, by using
a commercially available transmittersupporting Bluetooth
wireless technology, you can listen to music on a device not
equipped with Bluetooth wireless technology. The AS-BT200
model supports SCMS-T contents protection, so music can
also be enjoyed on devices equipped with SCMS-T type
Bluetooth wireless technology.
Remote control operation
The remote control supplied with this unit allows you to play
and stopmedia, and perform otheroperations.2
Connecting optional Bluetooth
®
adapter
1 Connect the Bluetooth
®
adapter to the unit
when the unit is in standby mode.
• Remove the AS-BT200 terminal’s coverand connect the
Bluetooth
®
adapterwith the label side facing to the right,
then close the cover.
Remote control operation
This unit
Bluetooth®
adapter
Device not equipped with Bluetooth
wireless technology:
Digital music player
+
Bluetooth® audio transmitter
(commercially available)
Bluetooth wireless technology
enabled device:
Digital music player
Bluetooth wireless technology
enabled device:
Cell phone
Note
1•TheBluetooth wireless technology enabled device must support A2DP profiles.
• Pioneerdoes not guarantee properconnection and operation of this unit with all Bluetooth wireless technology enabled devices.
• The Bluetooth
®
word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by PIONEER
CORPORATION is underlicense. Othertrademarks and trade names are those of theirrespective owners.
2•TheBluetooth wireless technology enabled device must support AVRCP profiles.
• Remote control operations cannot be guaranteed forall Bluetooth wireless technology enabled devices.
Bluetooth® adapter
(commercially
available)
This unit’s
rearpanel
Cover
X-SMC1_CUXZTSM_En.book 19 ページ ２０１１年７月８日 金曜日 午後１２時５４分

Bluetooth
®
Audio playback (optional)
06
20
En
2 Press STANDBY/ON to turn the power on.
3 Press
FUNCTION / or BT AUDIO on the
top panel of the unit to select
BT AUDIO as the
input source.
1
The BT AUDIO indicatorlights and is shown on the
front panel display.
Setting the PIN code
Set this unit’s PIN code to the same setting as that forthe
Bluetooth wireless technology device used. Supported PIN
code setting values include 0000, 1234 or8888.
• Default setting: 0000
1 Press SET UP continuously to select
.
•EachtimeSET UP is pressed the item on the front panel
display changes accordingly.
2 Press ENTER continuously to select the PIN
code .
•Eachtime/ is pressed the item on the front panel
display changes accordingly.
• You can select the PIN numberfrom 0000/1234/8888.
3 Press ENTER .
The PIN code is stored.
4 Press SET UP .
The setting is completed.
Pairing Bluetooth
®
adapter and
Bluetooth wireless technology device
“Pairing” must be done before you start playback of Bluetooth
wireless technology content using Bluetooth
®
adapter. Make
sure to pairdevices the first time you operate the system or
any time pairing data is cleared. “Pairing” is the step
necessary to registerBluetooth wireless technology device to
enable Bluetooth communications.2Formore details, see
also the operating instructions of yourBluetooth wireless
technology device.
1 Press FUNCTION / or BT AUDIO on the
top panel of the unit to select
BT AUDIO as the
input source.
The BT AUDIO indicatorlights .
• When Bluetooth
®
adapterAS-BT200 is connected,
is shown on the front panel display for2
seconds, then is shown.
• When no Bluetooth
®
adapteris connected, is
shown on the front panel display for2 seconds, then
is shown.
2 Turn on the Bluetooth wireless technology
device that you want to pair, place it near the
system and set it into pairing mode.
Pairing starts.
3 Check to see that the Bluetooth
®
adapter is
detected by the
Bluetooth wireless technology
device.
•IftheBluetooth wireless technology device cannot be
connected to the unit, perform the connection operation
from the Bluetooth wireless technology device.
Note
1WhentheBluetooth
®
adapteris not connected and BT AUDIO is selected as the input source, the errormessage noAdP. will be shown
on the front panel display.
2•Pairing is required when you first use Bluetooth wireless technology device and Bluetooth
®
adapter.
• To enable Bluetooth communication, pairing should be done with both of yoursystem and Bluetooth wireless technology device.
• During pairing, the name of this unit appears as AS-BT200.
X-SMC1_CUXZTSM_En.book 20 ページ ２０１１年７月８日 金曜日 午後１２時５４分
