Pipishell PIMT4 User manual

PIMT4
Installation Instructions V1.0
Thank you for choosing our product! We strive to provide the best
quality and services for our customers. Would you kindly share your
experience on Amazon if you are satisfied? Should you have any issues,
please don't hesitate to contact us.
Telephone：[phone] Mon-Fri 10am - 6pm (PST) (USA) (CAN)
Email：[email protected] (US/CA/DE/UK/FR/IT/ES/AU)

1
Wall plate
01 x1 x1
Right TV
Bracket
0302 x1
Left TV
Bracket
Supplied Parts
Tools Needed (Not lncluded)
Stud Finder Tape Measure Pencil Drill
5mm
Wood Drill
10mm
Concrete Drill
1/2 in.(13mm)
Socket Wrench Screw Driver
Hammer
IMPORTANT SAFETY INFORMATION
•Check package contents against Supplied Parts and Hardware Lists to assure that all
components were received undamaged. Do not use damaged or defective parts. lf you
require replacement parts, contact customer service at [email protected]
•Not all parts and hardware included will be used.
•Carefully read all instructions before attempting installation. If you do not understand
the instructions or have any concerns or questions, please contact customer service at
[email protected]
•This product may contain moving parts. Use with caution.
•Do not use this product for any purpose or in any configuration not explicitly specified in
this instruction. We hereby disclaim any liability for injury or damage arising from
incorrect assembly, incorrect mounting, or incorrect use of this product.
•DO NOT INSTALL INTO DRYWALL ALONE.
Level

x8
10mm
x8
5mm
2
Supplied Hardware
Hardware for Attaching the Wall Plate to Wall
These anchors are for concrete
or brick walls ONLY. DO NOT use
them in drywall or wood studs.
CAUTION!
x4
B
Wall
Anchor
Lag Bolts
ST7X55
x4
A
Hardware for Attaching TV Bracket to TV
04 05
x4
M4/M6
M6 x 15mm x4 M6 x 30mm x4
M8 x 15mm x4 M8 x 45mm x4
M8
M6
M4 x 15mm x4 M4 x 30mm x4
M4
Washers
Spacers
TV Screws
06
[Only one size fits your TV]
[If necessary]
[M-G]
[M-A]
[M-C]
[M-E] [M-F]
[M-D]
[M-B]
[M-H] [M-I]

MAX:400mm/16 in.
MAX:400mm/
16 in.
3
Step 1 Check TV Hole Pattern and Select TV Screws
Step 2
Select Spacers (if needed)
Only one screw size fits your TV.
M6M4 M8
[For M4 M6 screws]
[For M4 M6 screws]
200 mm ≈ 7 7/8 in.
400 mm ≈ 15 3/4 in.
100 mm ≈ 4 in.
300 mm ≈ 11 3/4 in.
WITH SPACER
3
For Rounded TV
For Flat TV with:
Inset Holes Cable Interference
aLong Screw
Short Screw
Washer
Washer
Spacer
TV Bracket
TV Bracket
EXTRA
06
06
04
05
04
NO SPACER b
For Flat TV
Spacer not necessary
SPACE

● Any material covering the wall must not exceed 5/8 in. (16 mm)
● Nominal wood stud size: common 2 x 4 in. (51 x 102 mm) minimum 1½ x 3½ in.
(38 x 89 mm)
● Stud center must be verified
●Ensure the wall plate[01] is securely fastened to the wall before
continuing on to the next step.
●DONOT USE ANCHOR [B] FOR THIS STEP!
Too Short Too Long
Step 3 Attach the TV Brackets to [02] and [03] Your TV
WARNING:
Step 4
For wood stud installation, follow STEP 4A
For concrete installation, follow STEP 4B
Attach the Wall Plate [01] to Wall
Step 4A Wood Stud Option
X
4
Alternate Spacer
Setups
With Spacer
b
06 No Spacer
a
06 06
04
04
05
03
02
●Avoid potential personal injury or property damage! DO NOT over-tighten the lag
bolts [A]. Tighten the lag bolts [A] only until they are pulled firmly against the wall
plate [01].

ø5mm
55mm
5
4A-1
4A-2
4A-3
4A-4
13mm
Socket Wrench
16 in.(406mm)
Drill 4 pilot holes using a 4 mm
diameter drill bit. Make sure the
depth is not less than 55mm.
Use a stud finder(not included)to
locate wood studs. Mark the edge
and center locations.
Position the wall plate[01] at your
desired height and line up the holes with
your stud center line. Level the wall plate
and mark the holes.
Install the wall plate [01] using lag bolts
[A]. Tighten the lag bolts [A] only until
they are pulled firmly against the wall
plate.
A

WARNING:
●Ensure the wall plate[01] is securely fastened to the wall before
continuing on to the next step.
● Any material covering the wall must not exceed 5/8 in. (16 mm)
● Mount the wall plate directly onto the concrete surface
● Minimum solid concrete thickness: 203 mm (8 in.)
● Minimum concrete block size: 203 x 203 x 406 mm (8 x 8 x 16 in.)
Wall
Anchor
B
6ø10mm
60mm
Drill 4 pilot holes using a 10mm diameter
drill bit. Make sure the depth is not less
than 60mm. Never drill into the mortar
between blocks.
Step 4B Solid Concrete or Concrete Block Option
Position the wall plate[01] at your
desired height, level the wall plate and
mark the pilot hole locations.
4B-1
4B-2
● Avoid potential personal injury or property damage! DO NOT over-tighten the lag bolts
[A]. Tighten the lag bolts [A] only until they are pulled firmly against the wall plate [01].

T
Adjust the hooks [H] to your desired angle. Then tighten the 4 pcs tilt screws [T] in
both brackets [02]/[03] with a screwdriver (not included) to fix the tilting angle.
7
Step 5
Fix Tilting Angle
4B-3
B
A
13mm
Socket Wrench
Note: Do not over-tighten the screws.
T
T
Top of TV
Bottom of TV
T
TH
H
8mm
Wremch
02
03
Use the hammer to knock
anchors [B] into the wall.
Be sure the anchors [B]
are seated flush with the
concrete surface.
Install wall plate using lag bolts [A] and anchors [B]. Tighten the
lag bolts [A] only until they are pulled firmly against the wall plate.
DO NOT over-tighten the lag bolts [A].

8
Step 6
HEAVY! You may need
assistance with this step.
Hang TV to the Wall Plate [01].
Step 7
Secure TV
Press Locking
R
03
02
Pull down and hold both cords [R], press the bottom of the TV into the wall plate
[01] until the latches lock the TV in place.

9
HEAVY! You may need
assistance with this step.
R
Remove the TV
Unlocking
Disconnect all cables, pull down and hold both cords [R] while gently pulling the
bottom of the TV away from the wall.
CAUTION: Avoid potential personal injury or property damage!
To prevent breaking the locking latches: always pull and hold the cords [R] down
while pulling the TV away from the wall. Then lift the TV up and off of wall plate
[01] . Place the TV on cardbard or other protective surface to avoid damage.
NOTE: To rehang the TV, follow the procedures in Step 6 and 7 on PAGE 8.
