Pipishell PISM02 User manual

Soundbar Bracket
INSTRUCTION
MANUAL
Rev02(A)
PISM02
(US/CA) 1-800-556-9829
(UK) 44-808-196-3885
[email protected]
WWW. www.pipishellav.com

Before getting started,
let's make sure this mount is compatible.
22 lbs
（10kg）
Yes - Perfect!
No - This mount is NOT
compatible.
Yes - Perfect!
No -This mount is NOT compatible.
Is the VESA
pattern of your TV
75 x 75mm (3" x 3")
to 600 x 400mm
(23.6" x 15.7") ?
1
Does the equip-
ment you intend to use
weigh less than 22 lbs
(10kg) ?
2
Tools Needed
(NOT lncluded)
3
Important Safety
Information
4
· Avoid potential injuries and property damage!
· DO NOT use this product for any purpose that is NOT explicitly
specified in this manual. DO NOT exceed weight capacity. We are NOT
liable for damage or injury caused by improper mounting, incorrect
assembly or inappropriate use.
· Before starting assembly, verify all parts are included and undam-
aged. DO NOT use damaged or defective parts. lf you require replace-
ment parts, please contact our Technical Support line at
1-800-556-9829 (US/CA) / 44-808-196-3885 (UK) or Customer
Service at [email protected].
CAUTION
· This product contains small parts that may pose a choking hazard.
· This soundbar bracket is designed to be installed and utilized only as
specified in this manual.
· This soundbar bracket is ONLY designed to mount BELOW the
television.
WARNING
NOTE
· Please read and understand these directions.
· Refer to the documentation that came with your soundbar, your TV and
your TV wall mount for additional guidance.
· Carefull read all instructions before attempting installation. If you DO
NOT understand the instructions or have any questions or concerns, please
contact our Technical Support line at 1-800-556-9829 (US/CA) /
44-808-196-3885 (UK) or Customer Service at [email protected].
· Not all hardware included in this package will be used.
Phillips
Screwdriver
02
W
H

Contents
Hardware for Attaching the Brackets to the TV
M6
[B1] x 4
M8
[B2] x 4
L2.5mm
[F1] x 4
L22mm
[F2] x 4
Washers Spacers
M6
M4
M8
M8 x 30mm
[E1] x 4
M8 x 50mm
[E3] x 4
M8 x 65mm
[E4] x 4
M6 x 30mm
[D1] x 4
M4 x 30mm
[C1] x 4
M4 x 50mm
[C2] x 4
M6 x 50mm
[D2] x 4
M8 x 40mm
[E2] x 4
TV Bolts
03

Hardware for Attaching the Brackets to the Soundbar
Soundbar Bolts
Keyhole Screw
[g] x 2
Knob
[h] x 2
M6
[d] x 2
M8
[e] x 2
M8
[f] x 2
M4 M4 x 10mm
[a1] x 2
M5
M6
Washers
M5 x 16mm
[b] x 4
M6 x 16mm
[c] x 4
M4 x 16mm
[a2] x 4
Vertical Bracket
01 x 1
Bracket
04 x 2
Connecting Rod
03 x 2
Vertical Bracket
02 x 1
Clamp
05 x 2
04

CAUTION: Follow your TV mount’s manual for instructions on how to
safely remove your TV and TV bracket.
NOTE: Your TV wall mount may vary from the illustrations throughout
this manual — the procedure to install the soundbar is the same.
a. If your TV brackets fit inside the
vertical soundbar brackets, follow
Figure a.
b. If your TV brackets do not fit
inside the vertical soundbar
brackets, follow Figure b.
Step 1 Prepare your TV [If mounted]
a b
05
1 2
TOSS
3

2-2 Spacer and Bolt Configurations
2-1 Select TV Bolts
Hand thread bolts into the threaded inserts on the back of your TV to determine which
bolt (M4, M6 or M8) to use. A minimum of 4-5 turns into the threading is required. Do
not turn past the bottom of the hole.
Step 2 Attach the TV Brackets and Vertical Brackets to the TV
M6 M8
M4
06
Bump
See Option C
Curved TV
See Option B
Cables
See Option D
Recessed Holes
See Option E
Flat Back TV
See Option A

2-3 Attach the TV Brackets and Vertical Brackets to Your TV
Add spacers if needed to fit the bolt length and TV back.
07
Option A: For Flat Back TVs
D
O
N
O
T
o
v
e
r
t
i
g
h
t
e
n
(If needed)
B1/B2
F1/F2
C1/D1/E1
0102
Knob facing
outward
0201
Knob facing
outward
0201

Option C: For TVs with a Bump
Option B: For Curved TVs
Spacers must be tall enough so that the curved back of the TV
does not interfere with the mounting plate.
The TV brackets must be flush on the bump and leveled by spacers over the gap.
08
D
O
N
O
T
o
v
e
r
t
i
g
h
t
e
n
B1/B2
F1/F2
C2/D2/E2
/E3/E4
(If needed)
B1/B2
F1
C1/D1/E1
D
O
N
O
T
o
v
e
r
t
i
g
h
t
e
n
B1/B2
F1/F2
C2/D2/E2
/E3/E4

Option E: For TVs with Recessed Holes
Option D: For TVs with Protruding Cables
Spacers [F1], [F2] need to fill in the recessed holes on the back of the TV, while
keeping the TV brackets as close to the TV as possible.
Use spacers [F1] or [F2] to create extra space between the TV and TV brackets.
D
O
N
O
T
o
v
e
r
t
i
g
h
t
e
n
B1/B2
C2/D2/E2
/E3/E4
F1/F2
D
O
N
O
T
o
v
e
r
t
i
g
h
t
e
n
B1/B2
C2/D2/E2
/E3/E4
F1/F2
09

3-1 Slightly loosen the knobs on both vertical brackets.
3-2 Insert the connecting rods [03] into the vertical brackets, then slide the brackets
[04] onto the connecting rods. Do not secure them before choosing the soundbar
bracket configuration on Page 11.
Step 3 Assemble the Bottom Brackets
Phillips
Screwdriver
(Not lncluded)
10
04
04
03
03
