SXMLCR72 - Satellite Radio Compact Motorcycle Kit
Installaon Instrucons
Pixel Technologies, Inc. | www.pixelsatradio.com | contact[email protected]m | [phone] | Page 1
Package Includes
(1) SiriusXM™ PowerConnect™ Vehicle Cradle
(1) SiriusXM™ 5 Volt Hardwired Power Adapter
(1) Handlebar Clamp Mount
(1) RAM Ball Mount Adapter (25 MM)
(1) Weatherproof Protecve Case
(1) SiriusXM™ Antenna
(1) Auxiliary Cable
(1) L-Bracket with AMPS Plate & Lock Ring
(1) AMPS Plate (Male Dual Notch) with Screws
Loosen this screw
Loosen this screw
Rubber inserted here
Step 1 - Install Clamp Mount
Before geng started, it is important to select an installaon locaon for the protecve case with receiver.
Aer selecng the installaon locaon for the protecve case, loosen the two screws on the handlebar clamp mount
all the way out and separate it from the back side of the clamp mount. Place the clamp mount on the handlebars, line
up the screw holes and ghten the screws to mount the clamp. Use the supplied rubber strips to increase the grip of
the mount.

BACK PLATE ASSEMBLY
Locate the bag containing the parts shown below.
Step 2 - Place the parts as pictured below. Take the AMPS Socket Plate and place it on one side of the
L-bracket. Next place the Dual Male AMPS Plate on the opposite side as the AMPS Socket Plate and line up
the screw holes. Please note the posioning of the Dual Male AMPS Plate with the notches at the boom.
The dual notches must be posioned at the boom in order to properly seat into the back of the case.
Use the supplied screws and nuts to secure the plates to the L-bracket. The mount can be assembled with
the top plate of the L-bracket facing forward or backwards to fit your installaon needs. Next, slide the
L-bracket assembly onto the back of the protecve case. The case should slide down over the dual notches.
Oponal - RAM Mount Assembly
To install the kit onto a RAM mount, use the RAM Mount Adapter Plate located in the supplied parts bag.
Screw the RAM Mount Adapter Plate to the L-bracket with the Dual Male AMPS Plate on one side and the
RAM Mount Adapter Plate on the other side. The mount can be assembled with the top plate of the
L-bracket facing forward or backwards to fit your installaon needs. Next, slide the L-bracket assembly onto
the back of the protecve case. The case should slide down over the dual notches.
AMPS Socket Plate with Lock Ring
Dual Male AMPS Plate Metal L-bracket
RAM Mount Adapter
Pixel Technologies, Inc. | www.pixelsatradio.com | contact[email protected]m | [phone] | Page 2

Step 3 - Connect Mount to Back Plate and Mount Antenna
To connect the handlebar or strap mount to the back plate, insert the ball joint into the AMPS Female Socket
Plate with the Lock Ring having the wide end facing towards the socket plate. Push the mount into the socket
unl it clicks. Once the ball joint is firmly in place, screw the Lock Ring clockwise unl it ghtens all the way.
To change the angle of the case, loosen the ring and pivot the case then reghten the Lock Ring to secure.
Do not over ghten the Lock Ring to avoid damaging it. Next, place the antenna on the metal L-bracket and
run the antenna wire through the boom of the case connecng it to the antenna port on the dock.
Pixel Technologies, Inc. | www.pixelsatradio.com | contact[email protected]m | [phone] | Page 3
Step 4 - Connect Audio
Included in the kit is an auxiliary cable for audio. Connect the
auxiliary cable to the aux input on the motorcycle sound system,
headset or other audio system. Run the auxiliary cable to the
locaon of the mount and leave the cable loose.
Step 4 - Connect Power
Included in the package is a hardwired power adapter. Find a power source on the motorcycle, either in a
fuse box or an auxiliary power source on the motorcycle. The hardwired power adapter comes with two
interchangeable cables, one older Sirius and XM receivers and one for newer SiriusXM™ PowerConnect™
receivers. For installaons with an older 5 volt Sirius or XM receiver (non PowerConnect™), use the cable
with the smaller connector p. For installaons using the supplied PowerConnect™ docking cradle, you will
use the cable with the larger p.
Connect the cables
Adapter fully assembled
If you are installing a Bluetooth dock, FMDA25, or using wireless FM transmission, refer to that products user guide for installaon.

To learn more on how to operate your specific receiver refer to the SiriusXM Radio user manual that came with the receiver.
Audio Port Antenna Port Power Port FM Port
Pixel Technologies, Inc. | www.pixelsatradio.com | contact[email protected]m | [phone] | Page 4
Step 6 - Connecng Docking Cradle
Aer all cables have been run to the protecve case, feed the wires
up through the boom of the case shown in the image on the right.
Pull enough cable through to allow for extra play in the wire in case a
cable is pulled. If there is extra antenna wire, it is recommended to
wrap up the excess antenna wire inside the protecve case.
Next, connect each cable to the corresponding port on the dock.
(Some docks may have the connecons on the sides and not the
back as shown in the figure to the right)
Note: If installing a Bluetooth SiriusXM™ Dock, only power and
antenna are required. The FM port on the dock is not used unless
installing the FMDA25 Direct Wire Audio Adapter.
Aer all connecons have been made, slide the receiver down onto
the dock and power on the unit. If installing a new SiriusXM™
receiver, follow the instrucons on how to acvate the receiver
provided in the receivers user guide.
