PKP DV04 Series User manual

Instruction Manual
DV04
High precision gear wheel counter for viscous liquids
PKP Prozessmesstechnik GmbH
Borsigstraße 24
D-65205 Wiesbaden- ordenstadt
Tel.: ++49-(0)6122-7055-0
Fax: ++49-(0)6122-7055-50
Email: [e-mail] www pkp.de

Table of Contents
Safety Information..................................................................................................................2
Functional principle and construction....................................................................................3
Special Conditions.................................................................................................................4
Corrosion Protection..............................................................................................................4
Installation..............................................................................................................................5
Electrical connection..............................................................................................................7
Plug assignment.....................................................................................................................8
Operation start-up..................................................................................................................8
Maintenance and Cleaning....................................................................................................9
Failure table.........................................................................................................................11
Dimensions..........................................................................................................................12
Safet Information
General Instructions
To ensure safe operation, the device should only be operated according to the specifica -
tions in the instruction manual. The requisite Health & Safety regulations for a given
application must also be observed. This statement also applies to the use of accessories.
Every person who is commissioned with the initiation or operation of this device must have
read and understood the operating instructions and in particular the safety instructions!
The work safety instructions in this manual as well as the safety, accident prevention and
environmental protection regulations generally valid for the work area must be observed.
The liability of the manufacturer expires in the event of damage due to improper use, non-
observance of this operating manual, use of insufficiently qualified personnel and unau-
thorized modification of the device.
Proper Usage
The flow meters DV04 are designed to monitor continuous flow rates of liquids which do
not attack the device materials. All other usage is regarded as being improper and outside
the scope of the device.
In particular, applications in which shock loads occur (for example, pulsed operation)
should be discussed and checked in advance with our technical staff.
The series DV04 flow meter devices should not be deployed as the sole agents to prevent
dangerous conditions occurring in plant or machinery. Machinery and plant need to be
designed in such a manner that faulty conditions and malfunctions do not arise that could
pose a safety risk for operators.
DV04 Instruction manual 02/2021 page 2

Dangerous substances
For dangerous media such as e.g. Oxygen, Acetylene, flammable or toxic substances as
well as refrigeration systems, compressors, etc. must comply with the relevant regulations
beyond the general rules.
Qualified Personnel
The DV04 devices may only be installed by trained, qualified personnel who are able to
mount the devices correctly. Qualified personnel are persons, who are familiar with
assembling, installation, placing in service and operating these devices and who are suit-
ably trained and qualified.
Inward Monitoring
Please check directly after delivery the device for any transport damages and deficiencies.
Additional with reference to the accompanying delivery note the number of parts must be
checked.
Claims for replacement or goods which relate to transport damage can only be considered
valid if the delivery company is notified without delay.
Functional principle and construction
Within the DV04 there two gearwheels that are supported in low-friction bearings. During
operation, the gearwheels are driven by the flowing liquid. The movement of the gear-
wheels is sensed by two non-contact sensors located in the cover and converted into elec-
trical signals.
Between the sensor area and the measuring chamber there is a pressure-resistant anti-
magnetic separator. The signals are transmitted to the connected display device.
1: Cover
2: A-magenetic divider
3: Sensor
4: Equipment plug/socket
5: O-Ring
6: Housing
7: Measurement unit
8 Bearing jounal
9 Bearing
DV04 Instruction manual 02/2021 page 3

Special Conditions
Special conditions and/or limitations apply to the safe application of gearwheel flow meters
in the approved operating environment. These conditions and/or limitations must be met
by the customer and/or system operator by means of appropriate technical and/or
organizational measures.
•Gearwheel flow meters must only be operated in the specified environment and
under the specified ambient conditions.
•Gearwheel flow meters must only be used if the materials used in their construction
are resistant to mechanical and/or chemical influences or corrosion under the given
service conditions.
•The fluid must at least have minimum lubricating properties (lubricity).
•Gearwheel flow meters are intended for use with liquids. Dry operation is not
approved.
•Operation outside of the specified parameters is not allowed.
•If necessary, a filter must be installed to prevent the gearwheel from being blocked
by foreign objects.
•The specified installation, service and maintenance schedules must be strictly fol -
lowed.
•Gearwheel flow meters must only be used in closed operation and not be subject to
excessive vibration.
•Only genuine spare parts must be used for service and maintenance.
Corrosion Protection
All gearwheel flow meters are checked for proper function at the factory with mineral-
based hydraulic oil. Following testing, the connections are sealed with plugs so that the
internal parts are protected against corrosion for a moderate amount of time.
During transport and storage, gearwheel flow meters must not be exposed to the harmful
effects of ambient weather conditions and great variations in temperature. They must be
stored under dry conditions.
If a gearwheel flow meter is to be stored for a longer period of time, both its interior and
exterior must be protected by application of a suitable anti-corrosion oil. In addition, it must
be protected from humidity by means of a desiccant material.
If high humidity or other unfavorable (aggressive, polluted) ambient conditions are expec -
ted to be encountered during transport, appropriate steps must be taken to prevent corro -
sion of the gearwheel flow meter.
Attention:
When preserving, check whether the preservative is compatible with the materials and
elastomers used in the gearwheel flow meter. Furthermore, compatibility with the pumped
medium must be ensured.
DV04 Instruction manual 02/2021 page 4

Installation
This gearwheel flow meter was thoroughly tested and checked at the factory before ship -
ment. It will be fully functional and immediately ready for use after it has been installed in
position and the electrical lines have been connected. The space required by the installed
device is specified in the "Dimensions" section. Once installed, the measuring device
should also be accessible for safe, visual inspection at any time.
Caution:
To prevent possible damage to the gearwheel flow meter, a pressure regulating device
must be present in the installation to prevent the maximum permissible pressure from
being exceeded in the volume sensor or other parts of the installation (pressure-limiting
valves). During transport and installation, the gearwheel flow meter must only be held by
its housing; must never be suspended from the plugged-in connector!
Preparation:
1. Check the product for transport damage and contamination.
2. Remove any preservative present.
Only use cleaning agents that are compatible with the materials used.
Do not use cleaning wool.
3. Compare the environmental and ambient conditions at the place of use with the
permissible conditions.
Expose the product only to low vibrations, see IEC 60034-14.
Ensure sufficient accessibility for maintenance and repair.
Comply with the manufacturer's information.
Do not use any sealing materials such as hemp, Teflon tape or putty.
DV04 Instruction manual 02/2021 page 5

Installation with plate connection:
1. Before installing the device, check the connection faces of the device for dirt or
small parts and clean if necessary.
2. Attach the connection plate to the intended position in the system.
Attention: Make sure that the seals are seated correctly! The connection surface
must be free of dirt and paint residues, etc. when mounting!
3. Position the housing on the connection plate.
4. tighten all fastening screws crosswise to the prescribed torque.
Make sure that the product is not distorted.
Ensure sufficient screw-in depth of the fastening screws.
1: fastening screws
Installation on connection plates not supplied with the device or on valve manifolds
Be sure to observe the specified values for surface flatness and surface roughness.
Nominal Size DV04.2-6 DV04.7-8
Surface roughness Rt, 1/1000 mm 0,01 0,02
Surface flatness, 1/1000 mm 10 10
In this case, the gearwheel flow meter must also be installed as described above.
DV04 Instruction manual 02/2021 page 6

Installation on pipe
1. Clean all lines.
Do not use cleaning wool.
Pickle and flush welded pipes.
2. Remove the protective plugs.
3. Mount the lines.
Comply with the manufacturer's information.
Do not use any sealing materials such as hemp, Teflon tape or putty.
4. After the gearwheel flow meter is installed and the piping system is placed back in
service, check all connections for leakage.
Electrical connection
Preamplifier
A 24V (DC) line (± 20 %) must be provided to supply power to the pre-amplifier.
The terminal assignment for channel 1 or 2 has an influence on the displayed direction of
rotation of the gearwheels, and thus on the preceding sign (+ or -) that is used when dis -
playing the measured volumetric flow rate on the evaluation device.
umber of measuring channels 2
Operating voltage UB = 24 VDC +/- 20%, protected against
polarity reversal
Pulse amplitude UA >/= 0,8 UB
Pulse from with symmetric output signal Square-wave pulse, scanning ratio/channel
1:1 +/- 15 %
Pulse offset between both channels 90° +/- 30°
Power consumption Pb max = 0,9 W
Output power / channel Pa max = 0,3 W, short circuit proof
Protection type IP65 (DI 40500)
Attention:
Damage by overvoltage
Excessive voltage can cause damage and dysfunction to the product.
a) Use the product only with the correct voltage.
b) Please consult the manufacturer in cases of doubt.
The power supply line must match the used preamplifier.
DV04 Instruction manual 02/2021 page 7

Plug assignment
1: UB (brown)
2: Channel 1 (green)
3: Channel 2 (yellow)
4: 0 Volt (white)
H1: Transmitter channel 1 (red)
H2: transmitter channel 2 (red)
Circular plug connector M12x1 (for high temperature up to 220 °C)
1: UB (brown)
2: Channel 1 (white)
3: 0 Volt (blue)
4: Channel 2 (black)
Operation start-up
•Before starting the product, make sure that a sufficient quantity of the service fluid
is extant to avoid dry running. This must be taken into account especially with large
line volumes.
•Check all fastening screws on the product.
•Fill the unit with media.
•Open existing shut-off elements upstream and downstream of the device.
•Adjust pressure relief valves in the system installed for lowest opening pressure.
•Run the device for a few minutes depressurised or with low pressure.
•Vent the system at the highest possible point.
•Gradually increase the pressure load up to the desired operating pressure.
•Operate the system for so long until the final operating state is achieved.
•Check the operating data.
•Document the operating data of the initial start-up for later comparison.
•Check the level of the operating medium in the system.
•Check the device for leaks.
•Check all threaded connections for leaks and retighten if necessary.
During operation, the two LED displays in the equipment plug flash as long as there is a
continual flow of fluid through the measuring unit.
DV04 Instruction manual 02/2021 page 8

Maintenance and Cleaning
Gearwheel flow meters are generally maintenance-free. However, if fluids that can leave
deposits flow through the device, cleaning may be necessary. Otherwise, the device can
be cleaned with the rest of the system during the standard cleaning procedure. Indications
of wear may be evident by a change in measuring accuracy. It is recommended the device
be inspected regularly.
Caution:
If fluids harden in the gearwheel flow meter, it must be cleaned as quickly as possible with
suitable cleaning agents.
The mounting screws must be regularly checked for tightness. If necessary, retighten
them (in such case, observe the tightening torque specified in the section ”Installation”).
Caution:
Be sure to relieve the pressure in the piping before performing any work on the
gearwheel flow meter or removing it. The gaskets in the joints between the gearwheel
meter and the piping system must be checked regularly for leakage.
Removal:
1. Depressurise and de-energize the system.
2. Close existing shut-off elements upstream and downstream of the device.
3. Open existing drain elements and loosen connection lines. Collect and dispose of
discharging medium so that no hazard arises for persons or environment.
4. Dismantle the device.
Pull the plug off the housing.
late connection: Release the unit from the connection plate.
ipe connection: Loosen the pipe connections from the unit and, if applicable,
take the unit off the holding fixture.
5. Clean the device
6. Close the device connections and lines to prevent dirt penetration.
Cleaning:
Devices in series 1, 2, 6, and 8:
These devices must never be opened by the customer. They must only be opened by
trained service personnel because only such specialists can reassemble them properly so
that they will function correctly.
Devices in series 4 and 5:
If due care is used, these devices may be opened and cleaned by the customer.
DV04 Instruction manual 02/2021 page 9

Caution:
Be sure to relieve the pressure in the piping and ensure that the electrical supply is de-
energized before opening and cleaning the device. The device and the piping may still
contain the transported fluid or a cleaning agent. All guidelines governing the handling of
the fluid that was last sent through the system must be followed. Before opening the sys-
tem, make sure that containers of sufficient capacities are available to catch any escaping
fluid. If necessary, the work area must also be sufficiently ventilated.
•Removing the gearwheel flow meter
•Drain the measuring device.
•Loosen the screws that hold the two halves of the housing together bolts.
•The 4 or 8 internal hexagon drive screws ("Allen screws) are accessible from the
bottom of the housing.
Caution: When removing the upper half of the gearwheel flow meter, do not pry the
halves apart at the joint with screwdrivers or similar tools. The gearwheels must not
be removed from the housing with pliers or similar tools.
•Clean the interior of the housing, the gearwheels and the bearings with a suitable
cleaning agent.
•Insert both gearwheels with the bearings in the lower housing.
•Position the o-ring in the grooved seat in the housing.
•Place the upper part of the housing on the bottom part (insert the locating pins).
•Insert the screws and snug them down crossways. Then tighten them crossways to
the specified torque (see below).
Caution:
All parts being assembled must be free of dirt and deposits. During installation of the gear-
wheel flow meter, make sure that no foreign objects enter the assembly.
Tightening torques housing with thread connection:
Type DV04.2 DV04.4 DV04.5 DV04.6 DV04.7 DV04.8
Nominal size 0,025 0,2 0,4 1 3 5
Model 5 4, 5 4 4, 5 4, 5 4, 5
Tightening
torques MA
40 m 65 m 145 m
DV04 Instruction manual 02/2021 page 10

Failure table
Fault otential causes Mögliche Ursache ossible measures
LED display
Both LED displays flash
-however, false values are-
displayed in the overrid-ing
controller
Connection between the
devic eplug and the
overriding controller is
loose/defective
Check the connection and
re-place the cable or plug if
necessary
An LED display does not
illuminate
Wire break Repairs by manufacturer
Soldering point defective
Sensor defective
o LED display illuminates Power failure Check the supply cable
Check the fuses
Measuring unit is blocked Put the device out of
operation immediately!
Send devices of model 1, 2,
6 and 8 to manufacturer to
be repaired
Devices of model 4 and 5
can be cleaned by user
Seal failure / Leakage
Leakage O-Ring in the device is
defective
Send devices of model 1, 2,
6 and 8 to manufacturer to
be repaired
Devices of model 6 and 8:
Check seal compatibility, if
necessary consult the
manufacturer and install a
new seal set (obtain from the
manufacturer).
O-ring between housing and
connection plate defective
Replace O-ring.
Defective values in the overriding controller
Reduction of measuring
accuracy
Wear Check the measuring device
or send it to the
manufacturer for repair.
DV04 Instruction manual 02/2021 page 11

Dimensions
Models 1, 2, 4, measuring ranges 2 - 8
Cast iron version, mounting plate
Electronic-Version: Standard, high temperature up to 150 °C, ATEX
Type dimensions [mm] torque
[ m]
weight
A C D F G* J K L M P MA[kg]
DV04.2 85 10 60 50 101 - 70 40 20 6,7 M 6 14 1,8
DV04.3 85 9 60 56 107 - 70 40 20 6,7 M 6 14 2,0
DV04.4 85 13 60 57 108 - 70 40 20 9 M 6 14 2,0
DV04.5 100 17 90 63 114 - 80 38 34 16 M 8 35 3,7
DV04.6 120 13 95 72 123 15,5 84 72 35 16 M 8 35 5,2
DV04.7 170 18 120 89 140 46,5 46 95 50 25 M 12 120 9,0
DV04.8 170 22 120 105 156 46,5 46 95 50 25 M 12 120 13,0
* plus 12 mm for electronic version H1 (high temperature up to 150 °C)
plus 6 mm for electronic version X (ATEX)
DV04 Instruction manual 02/2021 page 12

Models 1, 2, 4, measuring ranges 9, 10
Cast iron version, mounting plate
Electronic-Version: Standard, high temperature up to 150 °C, ATEX
Type dimensions [mm] torque
[ m]
weight
A C D F G* J K L M P MA[kg]
DV04.9 - 44 249 168 219 78 120 140 70 38 M 20 400 53,5
DV04.10 - 38 249 184 235 78 120 140 70 38 M 20 400 57,4
* plus 12 mm for electronic version H1 (high temperature up to 150 °C)
plus 6 mm for electronic version X (ATEX)
DV04 Instruction manual 02/2021 page 13

Models 1, 2, 4
Cast iron version, mounting plate
Electronic-Version: High temperature up to 220 °C
Type dimensions [mm] torque
[ m]
weight
A C D F G J K L M P MA[kg]
DV04.2 85 10 60 50 87 - 70 40 20 6,7 M 6 14 1,8
DV04.3 85 9 60 56 93 - 70 40 20 6,7 M 6 14 2,0
DV04.4 85 13 60 57 94 - 70 40 20 9 M 6 14 2,0
DV04.5 100 17 90 63 100 - 80 38 34 16 M 8 35 3,7
DV04.6 120 13 95 72 109 18,5 84 72 35 16 M 8 35 5,2
DV04.7 170 18 120 89 126 11 46 95 50 25 M 12 120 9,0
DV04.8 170 22 120 105 142 11 46 95 50 25 M 12 120 13,0
DV04 Instruction manual 02/2021 page 14

Models 5, 6, 8
Stainless steel version, mounting plate
Electronic-Version: Standard, high temperature up to 150 °C, ATEX
Type dimensions [mm] torque
[ m]
weight
A C D F G* J K L M P MA[kg]
DV04.2 - 10 94 55 106 - 70 40 20 6,7 M 6 14 3
DV04.3 - 9 94 56 107 - 70 40 20 6,7 M 6 14 3
DV04.4 - 13 94 57 108 - 70 40 20 9 M 6 14 3,1
DV04.5 - 17 118 63 114 - 80 38 34 16 M 8 35 4,8
DV04.6 - 13 124 72 123 15,5 84 72 35 16 M 8 35 7
DV04.7 - 18 170 89 140 46,5 46 95 50 25 M 12 120 15,9
DV04.8 - 22 170 105 156 46,5 46 95 50 25 M 12 120 18,7
* plus 12 mm for electronic version H1 (high temperature up to 150 °C)
plus 6 mm for electronic version X (ATEX)
DV04 Instruction manual 02/2021 page 15

Models 5, 6, 8
Stainless steel version, pipe mounting version
Electronic-Version: Standard, high temperature up to 150 °C, ATEX
Type dimensions [mm] weight
A B C D E F G* H J K L R [kg]
DV04.2 G 1/8 9 17 94 90 55 106 15 - 70 40 6,7 3
DV04.3 G 1/4 13 21 94 90 56 107 15 - 70 40 6,7 3
DV04.4 G 3/8 13 25 94 90 57 108 16 - 70 40 6,5 3,1
DV04.5 G 1/2 15 29 118 114 63 114 17,5 - 80 38 9 4,8
DV04.6 G 1/2 15 29 124 120 72 123 22 15,5 84 72 9 7
DV04.7 G 1 19 51,5 170 162 89 140 30 46,5 46 95 13 15,9
DV04.8 G 1 19 42 170 162 105 156 30 46,5 46 95 13 18,7
* plus 12 mm for electronic version H1 (high temperature up to 150 °C)
plus 6 mm for electronic version X (ATEX)
DV04 Instruction manual 02/2021 page 16

Mounting plates (cast iron), thread connection on site
Type dimensions [mm] weight
e A B C E F G H J K L M P R c d f [kg]
DV04.2
DV04.3
DV04.4
G 3/8 85 90 35 65 76 7 11 7 70 40 20 6,5 M6 17 0,7 25 13 1,8
DV04.5 G 1/2 100 110 37 86 96 7 11 7 80 38 34 16 M8 18,5 0,7 29 15 2,7
DV04.6 G 1/2 100 120 37 80 106 7 11 7 84 72 35 12 M8 17,5 0,7 29 15 2,9
DV04.7 G 1 100 120 65 80 106 7 11 8 84 72 35 13 M8 32,5 1 42 19 4,9
DV04.8 G 1 160 165 80 140 145 9 15 9 46 95 50 25 M12 28 1 42 19 14
DV04 Instruction manual 02/2021 page 17

Flow Measurement and Monitoring
DV04
High Precision Gear Wheel
Counter for Viscous Liquids
•for media with iscosities starting from 20 cSt
•excellent price / performance ratio
•cast iron or stainless steel ersion
•accuracy better than 0,3 % of m. .
•high definition
•pressure resistant up to 400 bar
•small installation dimensions
•measuring ranges: 0,008...2 l/min bis 3...700 l/min
•Pmax: 480 bar, Tmax: 210 °C
Description:
The measuring mechanism of the flow meter DV04 consists of
a pair of gears which are driven by the liquid flow according to
the operating principle of a gear pump.
The movement bearing is designed as plain bearing or ball
bearing. The movement of the gears is scanned by two
magnetoresistive sensors, which are hermetically separated
from the measuring chamber and phase-shifted by 0°.
This two-channel scanning enables a higher measured value
resolution as well as the detection of the flow direction by
means of suitable electronics. As an option, all devices are
available in explosion-proof design with separate switching
amplifier. The gearwheel flow meter DV04 is characterized by
very low flow resistance and particularly low sound pressure
level.
Typical applications:
Due to the outstanding measuring accuracy, combined with
the high resolution, these devices are particularly suitable for
use in test benches for measuring small and very small flow
rates.
Further fields of application:
• consumption measuring
• control of filling processes
• dosage of oils and chemicals
• flow measurement of paints and varnishes
• ratio control of polyol and isocyanate
PKP Prozessmesstechnik GmbH
Borsigstr. 24 • D-65205 Wiesbaden
S [phone] • T [phone]
[email protected] • www.pkp.de
20210118

Model (table. 1):
Depending on the field of applications and media properties,
the DV04 available in 6 different models:
Model Material Min.
viscosity
[mm² s]
Accuracy [%
of measured
value]
Media properties
Viscosity Lubricating
properties
1GJS-
400/600
20 ± 0,3 low good
2GJS-400 50 ± 0,5 intermediate good
4GJS-400 100 ± 0,5 intermediate low
5st. steel
1.4404
100 ± 0,5
DV04.2: ± 3
intermediate low
6st. steel
1.4404
20 ± 0,3 low good
8st. steel
1.4404
20 ± 1 low low
Process connection (table. 2):
Model 1 2 4 5 6 8
MB-Code Ball
bearing
Ball
bearing
Carbide
plain
bearing
Carbide
plain
bearing
Ball
bearing
Hybrid
ball
bearing
DV04.2 G 3/8 - - G 1/8 G 1/8 G 1/8
DV04.3 G 3/8 - - - G 1/4 G 1/4
DV04.3A G 3/8 - G 3/8 - G 3/8 G 3/8
DV04.4 G 3/8 G 3/8 G 3/8 G 3/8 G 3/8 G 3/8
DV04.5 G 1/2 or
G 3/4
- G 1/2 or
G 3/4
- - -
DV04.6 G 1/2 or
G 3/4
G 1/2 or
G 3/4
G 1/2 or
G 3/4
G 1/2 G 1/2 G 1/2
DV04.7 G 1 G 1 G 1 G 1 G 1 -
DV04.8 G 1 G 1 G 1 G 1 G 1 -
DV04.9 SAE*)- - - - -
DV04.10 SAE*)- - - - -
*)SAE flange, d = 38 mm
Measuring ranges [l/min] (Tab. 3):
MB-
Code
Model
124568
DV04.2 0,008-2 - - 0,02-2 0,008-2 0,008-2
DV04.3 0,02-4 - - - 0,02-4 0,02-4
DV04.3A 0,04-8 - 0,04-8 - 0,04-8 0,04-8
DV04.4 0,16-16 0,16-16 0,16-16 0,16-16 0,16-16 0,16-16
DV04.5 0,2-40 - 0,2-30 - - -
DV04.6 0,4-80 0,4-80 0,3-60 0,3-60 0,4-80 0,4-80
DV04.7 0,6-160 - 0,6-100 0,6-100 0,6-160 -
DV04.8 1-250 1-250 1-160 1-160 1-250 -
DV04.9 2-600 - - - - -
DV04.10 3-700 - - - - -
Parameters (Tab. 4):
MB-Code Max. pressure [bar] Sound pressure
level [dB(A)]
Resolution [Imp. l]
DV04.2 480 < 65 40.000
DV04.3 480 < 65 25.000
DV04.3A 480 < 65 10.000
DV04.4 480 < 65 4.081,63
DV04.5 480 < 65 2.500
DV04.6 480 < 65 65,25
DV04.7 350 < 65 333,33
DV04.8 350 < 65 1 1,5
DV04.9 480 < 65 83,33
DV04.10 480 < 65 62,5
Order Code:
Order number: DV04.
Gear wheel counter
2. 1. F. PS. 10. S. 0. 0
Measuring ranges:
2…10 = see table 3
Model:
1…8 = see table 1
Gasket:
F = FKM (standard)
E = EPDM
P = FEP
K = FFKM
Connection type:
PS = with mounting plate, connection at side
(standard, not for models 5, 6, 8)
PU = with mounting plate, connection bottom
(not for models 5, 6, 8)
R = without mounting plate, connection at side
(models 5, 6, 8 only)
Process connection: (see table 2)
04 = G 1/8 female thread
06 = G 1/4 female thread
10 = G 3/8 female thread
15 = G 1/2 female thread
20 = G 3/4 female thread
25 = G 1 female thread
40 = SAE flange, d = 38 mm
Electronic version:
S = standard
H1 = high temperature version up to 150 °C
H2 = high temperature version up to 210 °C (FEP gasket
and terminal box)
X = intrinsically safe with separate switching amplifier
(EEx ia IIC)
Display:
0 = without display
DVA= prepared for plug-on display DVA
(date sheet on the following pages)
Options:
0 = without
1 = please specify in plain text
(*not for models 5, 6, 8)
Technical Data:
Viscosity range: 20…100.000 mm²/s
Pressure drop: depending on viscosity and
load of the devices
(exact values on request)
Medium temperature range:
standard version: −40 °C…+120 °C
high temp. version: −30 °C…+150 °C, (210 °C)
Materials:
models 1, 2, 4: housing GJS-400-15,
GJS-600 (DV04. , DV04.10)
measuring unit steel 1.713
models 5, 6, 8: housing st. steel 1.4404
measuring unit st. steel 1.4462
Electronic:
standard: 2 sensors, 0° phase-shifted
Ex-version: with separate switching amplifier
Power supply: 12…30 VDC,
protected against polarity reversal
Power consumption: 0, W
Output signal: square-wave pulses, min. 0,8 x UB,
duty cycle 1:1 (± 15 %)
Protection class: IP65
PKP Prozessmesstechnik GmbH
Borsigstr. 24 • D-65205 Wiesbaden
S [phone] • T [phone]
[email protected] • www.pkp.de
Flow
