Planar PX171M User manual

PX171M
LCD Monitor
USER’S GUIDE
www.planar.com

1
English
Usage Notice
Precautions ................................................................................. 2
Introduction
About the Product ....................................................................... 3
Package Overview ...................................................................... 4
Installation
Product Overview ........................................................................ 5
Connecting the Display ............................................................... 7
User Controls
Front Panel Controls ................................................................... 10
How to Use the OSD Menus........................................................ 11
On-Screen Display Menus .......................................................... 12
Appendices
Troubleshooting .......................................................................... 16
Warning Signal ........................................................................... 17
Product Dimensions .................................................................... 18
Compatibility Modes ................................................................... 19
Pivot Software Installation..............................................................20
Table of Contents

English 2
Usage Notice
Warning- To prevent the risk of fire or shock hazards, do not
expose this product to rain or moisture.
Warning- Please do not open or disassemble the product as this
may cause electric shock.
Precautions
Follow all warnings, precautions and maintenance as recommended
in this users manual to maximize the life of your unit.
Do:
qTurn off the product before cleaning.
qUse only a dry soft cloth or clean room wiper when cleaning the
LCD panel surface.
qUse a soft cloth moistened with mild detergent to clean the
display housing.
qUse only high quality and safety approved AC/DC power
adapter.
qDisconnect the power plug from AC outlet if the product is not
used for a long period of time.
Dont:
qDo not touch the LCD panel surface with sharp or hard objects.
qDo not use abrasive cleaners, waxes or solvents for your
cleaning.
qDo not operate the product under the following conditions:
- Extremely hot, cold or humid environment.
- Areas susceptible to excessive dust and dirt.
- Near any appliance generating a strong magnetic field.
- Place in direct sunlight.

3
English
Introduction
About the Product
Having a 17 flat panel screen with an active matrix, thin-film transistor
(TFT) liquid crystal display (LCD) , this product also demonstrates
following outstanding features:
qAnalog and Digital signal input
qActive matrix TFT LCD technology
q1280 x 1024 addressable pixels
q17 diagonal screen size
q31.5 ~ 80 kHz horizontal scan
q56 ~ 75 Hz refresh rate
qVESA wall mountable
qAuto-adjustment
qMultilingual OSD user controls
qAdjustment stand design brings users the conveniences for easy
storage and VESA Mounting applications
qVESA DPMS power saving
qBuilt-in speakers for multimedia application
qKensington lock capability

English 4
Package Overview
LCD Display
VGA Signal Cable
Power Adapter Power Cord
Audio-In Cable
DVI-D Cable
Users Manual Quick Start Guide Planar Product
Family CD
CD-ROM for
Pivot software

5
English
Installation
Product Overview
uFront View
uRear View
Connector Ports
Kensington Lock
Panel
Controls
Stand Speakers
LCDDisplay
VGA Input
DC
Power-In
Audio-In
Digital Port

English 6
Warning!
Please must select the proper screws!
The depth from plastic back cover to the bottom of the screw hole is 8mm.
The spec is M4 screw.
VESA Mount on your monitor
This monitor conforms to the VESA Flat Panel Mounting Physical
Mounting Interface Standard which defines a physical mounting interface
for flat panel monitors, and corresponding standards for flat panel
monitor mounting devices, such as wall and table arms.The VESA
mounting interface is located on the back of your monitor.
To mount the monitor on a swing arm or other mounting fixture,
follow the instruction included with the mounting fixture to be used.
VESA
Mounting
Interface
Slots
100mm
100mm

7
English
To setup this display, please refer to the following figure and procedures.
1. Be sure all equipments are off.
2. Connect the DC power cord to the power connector; plug one end of the
AC power cord into the power adapter, and then the other end into an
electrical outlet(u).
3. Connect the VGA signal cable from display VGA input connector to the
15-pin connector of your host computer and tighten the screws(v).
4. For the PC with DVI digital output: Connect the DVI signal cable to the
connector of the display card in your computer; connect the other side to
the DVI-D input port of your display. Tighten the screws(w).
5. Connect the Audio-In cable from audio input port of your display to the
Audio-out port of your computer(x).
6. Turn on your computer and display.
Note: To ensure the LCD display can work well with your computer, please
configure the display mode of your graphic card to make it less than or equal
to 1280 x 1024 resolution and make sure timing of the display mode is
compatible with the LCD display. We have listed the Compatibility Modes
of this LCD display in appendices for your reference.
ConnectingtheDisplay (Figure8.1)

English 8
Figure 8.1

VGA
Cable
Audio-In
Cable

Power Adapter
& Power Cord

DVI-D Cable

English 10
User Controls
Front Panel Controls
No. / Icon Control Function
M Menu Button Display the OSD menus.
SSelect /Auto 1. To select the adjustment
items from OSD menus.
2. To activate the Auto Adjust
ment function to obtain an
optimum image.
Power Switch on/off the power of the
LCD display.
Power LED 1. Green indicates the display is
turned on.
2. Amber indicates the display
is in power-saving mode.
1. Minus / 2. Brightness 1. Decrease value of the
adjusments items.
2. Adjust the brightness of
image.
1. Plus / 2. Mute On/Off 1. Increase value of the
adjusment items.
2. Make the volume function
Ineffective/effective.






11
English
How to Use the OSD Menus
1. Press the M button to pop up the on-screen menu and to select
between the four Main Menus.
2. Choose the adjustment items by pressing the S button.
3. Adjust the value of the adjustment items by pressing the - or +
button.
4. Once you dont operate the OSD menus after a pre-set time, the OSD
menus will automatically disappear.

English 12
On-Screen Display Menus
4
Auto-Adjustment
Chooses this function to obtain an optimum image.
4 Contrast
Adjusts the contrast of the display image.
4 Brightness
Adjusts the brightness of the display image.
4 Horizonta Position
Changes the horizontal position of the image.
4 Vertica Position
Changes the vertical position of the image.
4C ock
Changes the display data frequency to match the frequency of your
graphic card. When you are experiencing vertical flickering bar, use this
function to make an adjustment.
4 Phase
Synchronizes the signal timing of the display to that of the graphic card.
When you are experiencing unstable to flickering image, use this function to
make an adjustment.
First OSD Menu:

13
English
Second OSD Menu:
4Display Mode
Selects this function to demonstrate the display resolution, vertical refresh,
and horizontal scan of the current mode.
4OSD Off-Time
Adjusts the time period for OSD menu disappear.
4Language
Chooses the language you need.
4Sharpness
Adjust the sharpness of the image.
4Reset
Returns the display parameters of the current mode to its factory default
settings.

English 14
Third OSD Menu:
4Volume
It allows you to control the volume sound.
4Mute
It allows you to disable the sound immediately.
4Input Select
It allows you to select the type of signal.

15
English
Fourth OSD Menu:
4Color Setting
Adjusts the color temperature.
4Color Adjustment-Red
It allows you to adjust the red color of the display.
4Color Adjustment-Green
It allows you to adjust the green color of the display.
4Color Adjustment-Blue
It allows you to adjust the blue color of the display.

English 16
Troubleshooting
If you are experiencing trouble with the LCD display, refer to the
follows. If the problem persists, please contact your local dealer or
our service center.
Problem: No image appears on screen.
4Check that all the I/O and power connectors are correctly and
well connected as described in the  Installation  section.
4Make sure the pins of the connectors are not crooked or broken.
Problem: Partial image or incorrectly displayed the image.
4Check to see if the resolution of your computer is higher than that
of the LCD display.
4Reconfigure the resolution of your computer to make it less than
or equal to 1280 x 1024.
Problem: Image has vertical flickering line bars.
4Use  Frequency  to make an adjustment.
4Check and reconfigure the display mode of the vertical refresh
rate of your graphic card to make it compatible with the LCD
display.
Problem: Image is unstable and flickering
4Use  Tracking  to make an adjustment.
Problem: Image is scrolling
4Check and make sure the VGA signal cable (or adapter) is well
connected.
4Check and reconfigure the display mode of the vertical refresh
rate of your graphic card to make it compatible with the LCD
display.
Problem: Vague image (characters and graphics)
4Use  Frequency  to make an adjustment. If this problem still exists,
use Tracking to make an adjustment.
Appendices

17
English
Warning Signal
Sometimes you probably will see the warning messages from this
LCD screen. This means that the LCD display cannot exactly receive the
signal from the computer graphic card.
There are three kind of situations may happen.Please check with the
connected cables or contact your local dealer for more information.
4No Signal
This message means that the LCD display has been powered on but it
cannot receive any signal from the computer graphic card. Check all the
power switches, power cables, and VGA signal cable.
4Going to Sleep
This message means that the LCD display is under the power saving
mode. In addition, the LCD display will go to this sleeping mode when
experiencing a sudden signal disconnecting problem.
4Unsupport Mode
This message means that the signal of the computer graphic card is not
compatible with the LCD display. When the signal is not included in the
compatibility mode we have listed in the Appendices of this manual, the
LCD display will appear this message.

English 18
Product Dimensions
Front View
Side View
377.5mm/14.86
465.0mm/18.30
Top View
52mm/2.05
222mm/8.74

19
English
Compatibility Modes
edoMnoituloseR)zH(ycneuqerF)zHk(ycneuqerF.H
AGVMBI053x046075.13
AGVMBI004x046075.13
AGVMBI084x046065.13
AGVMBI004x027075.13
AGVASEV084x046279.73
AGVASEV084x046575.73
AGVSASEV006x008652.53
AGVSASEV006x008069.73
AGVSASEV006x008271.84
AGVSASEV006x008579.64
AGXASEV867x4201064.84
AGXASEV867x4201075.65
AGXASEV867x4201570.06
AGXSASEV4201x0821060.46
AGXSASEV4201x08215708
CLcaMelppA084x046769.43
IIcaMelppA084x046760.53
