Planet Audio Anarchy AC15D User manual

AC15D_0616_2
Congratulations on your purchase of the Planet Audio Anarchy Subwoofer.
Planet Audio takes great pride in producing products that sound and look great and stand up
to the daily rigors applied by audio enthusiasts around the world.

AC15D 15” Subwoofer
Dual 4 Ω Voice Coils
2100 W Peak Power Handling
Customizable Trim Ring
Enclosure
The AC15D is designed to work in a sealed or ported enclosure. Since the
woofer has pole-vent, it needs a minimum clearance from the rear wall
of the enclosure of 0.75” (19 mm).
Below you will nd the dimensions to make the enclosure to suit the
subwoofer, it has been designed for maximum output while retaining
great sound quality.
The dimensions have already accounted for the volume displacement of
the subwoofer, and using 3/4” (19mm) MDF.
All dimensions are external.
Enclosure Dimensions
External Sealed Dimensions:
Height (H) : 16” (406mm)
Depth (D) : 16” (406 mm)
Width (W) : 18” (457 mm)
Cutout Diameter: 13-7/8” (352 mm)
External Ported Dimensions:
Height (H) : 16-1/2” (419 mm)
Depth (D) : 18” (457 mm)
Width (W) : 26” (660 mm)
Slot Port Height: 15” (381 mm)
Slot Port Length: 30” (762 mm)
Slot Width: 2” (51 mm)
Tuning Freq: 35 Hz

8 Ω2 Ω
Parallel Series
Wiring Opons
Series
4 Ω
Parallel
1 Ω
Mulple Subwoofers
Parameters
Impedance Dual 4 Ω
Resonant Frequency 25 Hz
Qts 0.675
Qms 6.147
Qes 0.759
Vas 8 ³ (227 liters)
Xmax 13 mm
Sensivity (1 W/ 1 m) 89 dB
Peak Power Handling 2100 W
Mounng Depth 7” (178 mm)
Cutout Diameter 13-7/8” (352 mm)
