Planet Audio BBD12 User manual

TELEPHONE
888.990.1236
805.988.0215
FAX
805.988.0275
TECHNICAL SUPPORT
www.planetaudiousa.com/support
www.planetaudiousa.com
USER’S MANUAL
BBD12
BBD12 12.14
all specifications subject to change without notice
© 2014 Planet Audio
2500 WATTS
12" (305MM) HIGH POWER DVC SUBWOOFER

Technical Support
If you need technical support with your Planet Audio product or have
questions about its use, please contact us:
805.751.4853
www.PlanetAudioUSA.com
6
Due to ongoing technical advancements, specifications are subject to change without notice
BBD12_1214
1
Congratulations on your purchase of the Planet Audio Big Bang Subwoofer.
Planet Audio takes great pride in producing products that sound and look great,
but stand up to the daily rigors applied by audio enthusiasts around the world.

BBD12 12” (30.5cm) Subwoofer
 Dual 4 Ω Voice Coils
 2500 W Peak Power Handling
 Dual High Power Voice Coils
 Stitched Foam Surround
2
5
Enclosure
The BBD12 is designed to operate in two types of enclosures, sealed and
ported. Since the woofer has pole-vent, it needs a minimum clearance
from the rear wall of the enclosure of 0.75” (19 mm).
Below you will find the dimensions to make the enclosure to suit the
subwoofer, it has been designed for maximum output while retaining
great sound quality.
The dimensions have already accounted for the volume displacement of
the subwoofer, and using 3/4” (19mm) MDF.
All dimensions are external.
External Sealed Dimensions:
Length (L) : 15” (318 mm)
Width (W) : 10.5” (267 mm)
Height (H) : 15” (318 mm)
Min. Internal Volume: 0.65 ft³
Enclosure Dimensions
External Ported Dimensions:
Length (L) : 20” (508 mm)
Width (W) : 17” (432 mm)
Height (H) : 14” (356 mm)
Port Diameter: 4” (102 mm)
Port Length: 15” (381 mm)
Tuning Freq: 35Hz
Min. Internal Volume: 1.6 cu ft.

4
Multiple Subwoofers
8 Ω2 Ω
Wiring Options
Parallel Series
4 Ω
1 Ω
3
Product Specifications
Impedance
Dual 4 Ω
Resonant Frequency
28 Hz
Qts
0.599
Qms
4.68
Qes
0.687
Vas
1.35 ft³ (38.2 liters)
Xmax
14.3 mm
Sensitivity (1 W/ 1 m)
83 dB
Peak Power Handling
2500 W
Mounting Depth
7-7/8” (200 mm)
Cutout Diameter
11-1/4” (285mm)
