Planet Audio P8.2UAW User manual

Congratulations on your purchase of the Planet Audio P8.2UAW, amplified Under Seat
Subwoofer.
It has been designed, engineered and manufactured to bring you the highest level of
performance and quality, and will afford you years of listening pleasure.
Thank you for making a Planet Audio your choice for car audio entertainment!
P8.2UAW
8" Amplified Under Seat Subwoofer
High & Low Level Input
LED Status Indicator
Subwoofer Phase Control
Soft Remote Turn-0n
Subwoofer Remote Control
Variable Bass Boost
Low Pass Filter
Subsonic Filter
High Pass Filter
MAX Power @ 4Ω: (250 W x 2) + (800 W x 1)
Thermal, Short, Overload and Fuse Protection
Dimension: 14” (L) x 9-7/8” (W) x 3” (H)
Weight: 11.6 lbs.
Introduction
The P8.2UAW, introduces a low-profile active subwoofer, with an additional 2 channels
of amplified full-range output.
Its low enough to easily fit under the seat of your car, this system offers you a quick
and easy way to add a high-powered 2 Ch amplifier and subwoofer to your audio
system.
P8.2UAW contains a 2 Channel Full-Range Amplifier and an Amplified Subwoofer
Both high-level (speaker level) and low-level (RCA) inputs are present, making this a
universal solution for use with any head unit or other input sources.

What is included?
When first unpacking your new amplified system, please check that the package
contains all of the items below.
If something is missing, contact our Tech Dept.
Main Unit
P8.2UAW Amplified System
Accessories
Subwoofer Remote Control w/ Cable
High-Level Input Harness
Speaker Output Harness
Mounting Hardware
Mounting Feet
Mounting Feet Screws w/ Washers M3x10mm (x8)
Mounting Screws (x4)

Front Panel Controls and Features
① LED STATUS INDICATOR
Green –On
Red –Protection
②CH 1/2 GAIN CONTROL
Ch 1/2 Gain control should be first set. The volume control on the head unit should be turned up to ¾
of max.
Slowly adjust the Gain to where distortion is barely audible and then back off a bit of the adjustment.
③ HIGH PASS FILTER
The HP filter can be adjusted from 50 Hz to 150 Hz @ 12dB/Oct.
④SUBWOOFER GAIN CONTROL
Please note to use the same music track to set the Sub Gain as Ch 1/2.
The volume control on the head unit should be turned up to ¾ of max.
Slowly adjust the Gain to where distortion is barely audible and then back off a bit of the adjustment.
⑤SUBW00FER SUBSONIC FILTER
The subsonic filter can be adjusted 20-50Hz.
⑥BASS BOOST
The bass boost is centered at 45 Hz. Adjusting this setting will boost 45 Hz up to 12 dB
⑦LOW PASS FILTER
The LP filter is adjustable from 50 Hz to 150 Hz @ 12dB/Oct.
⑧SUB PHASE
The Sub Phase can be used to adjust for bass response. Each vehicle will be different and should be set
for your particular installation. If the bass response “disappears”, flipping the switch should fix and will
properly align the phase with the rest of the system.
⑨SUBWOOFER REMOTE CONTROL PORT
Attach the included remote control to control the level of the subwoofer independently. This should
be installed in a convenient location where you can adjust the level of subwoofer easily.

Rear Panel Controls and Features
①POWER TERMINALS
Planet Audio recommends the use of high quality 8 gauge wiring. The ground should be kept under
3ft (36”). Always scrape away any paint for the ground connection. Ground point should be clean with
the correct type of bolt to secure it.
The +12V wire should be fused (30 A) within 18” of the battery, keep away from any signal and/or
speaker lines to avoid noise in the system.
Remote Turn-On wire should be coming from the source unit, so the amplifier turns on/off with the
source.
②FUSES
Fuse rating is a total of 30 A. The unit is equipped with two 15 A fuses.
Always replace the fuses with the same type and value.
③HIGH-LEVEL (Speaker Level) INPUTS
If your source unit does not have Full-Range RCA Pre-Amp Outputs, you can use the speakeroutputs to
the P8.2UAW.
④CH1/2 SPEAKER OUTPUTS
Connect to the Front or Rear speakers in your vehicle. Always Observe Polarity!
⑤RCA INPUTS (LOW LEVEL)
Please note the inputs MUST be Full-Range from the source unit. Otherwise, CH 1/2 outputs will not
output correctly.
If the pre-amp of the source unit is not Full-Range, the speaker level input should be used.
Use the supplied harness and connect the outputs as shown in the connection diagram in this manual.
⑥ILLUMINATION
The unit is equipped with an illumination feature that can be turned ON/OFF via the switch.
The illumination if ON will turn on when the Remote terminal receives power.

RCA Inputs (Low Level)
RCA cables are preferred for best audio performance.
Installation lengths will vary due to sizes.
Always connect with the high-quality cables to avoid any induced noise.
NOTE: DO NOT USE/CONNECT BOTH HIGH-LEVEL AND RCA INPUTS AT THE SAME TIME
Speaker Input (High-Level)
The high-level input(s) should only be used when your receiver lacks Full-Range RCA
Outputs.
If the RCA outputs are not present, connect the speaker outputs from the receiver to
the high-level input connector of the amplifier. Be sure to observe polarity to avoid
audio phase problems.

High-Level Input & Speaker Output Wiring
The high-level input(s) should only be used when your receiver lacks Full-Range RCA
Outputs.
If the RCA outputs are not present, connect the speaker outputs from the receiver to
the high-level input connector of the amplifier. Be sure to observe polarity to avoid
audio phase problems.
Connect to the full-range front or rear speakers in your car.

Power Input Connections
Connect the ground terminal to the closest point on the chassis of the vehicle.
Keep this ground wire to less than 3 ft. (36”) in length.
Use a high quality OFC 8 gauge wire.
Connect the remote terminal to the remote output of the head unit to “REM” using
16 gauge wire.
Connect an empty fuse holder within 18”of the car battery, and run
8 gauge cable from this fuse to the amplifier location.
Then connect the fuse holder to the “+12V”
Subwoofer Level Control
Subwoofer Remote Control allows you raise or lower the level of the subwoofer
independently from the other two outputs channels.

Mounting the subwoofer
1. Find asuitable location in the vehicle in which to mount the amplifier. An
optional location is shown below:
2. Make sure there is sufficient air circulation around the intended mounting Location.
3. The mounting feet have multiple mounting locations.
4. Before drilling any holes or screws, double check you’re not about to drill into any
fuel lines, brake lines, cables, etc….

Troubleshooting
If you experience operation or performance problems with this product, compare
your installation with the electrical wiring diagrams on the previous pages. If problems
persist, read the following troubleshooting guide which may help.
If you have any further questions, please give our Tech Department a call.
Amplifier will not
power up
Check to make sure you have a good ground connection
Check that the remote input (turn-on) has at least 9VDC
Check that there is battery power on the (+)terminal
Check that there is at least 12v
Check all fuses, replace if necessary
Make sure that the protection led is not illuminated.
If it is lit,
Shut off the amplifier briefly, and then power it ON again
Protection LED
comes on when
Amplifier is
powered up
Turn down the volume control on the head until to prevent overdriving.
If it remains on, please contact our Tech Dept.
No output
Check that all fuses are ok
Check that unit is properly grounded.
Check that the remote input (turn-on)has at least 9VDC
Check that the RCA audio cables are plugged into the proper
Inputs.
Check all speaker wiring.
Low output
Reset the level control
Check the crossover control settings.
High hiss in the
sound
Disconnect all RCA inputs to the power sub’s control panel. If the hiss disappears,
then plug in the component driving the amplifier and unplug its inputs. If the hiss
disappears at this point ,go on
Until the faulty/noisy component is found.
It is best to set the amplifier’s input level control as low as
Possible
Squealing noise
is present
Check all cables
Distorted sound
Check that the input level control is set to match the signal level of the source unit.
Always try to set the input level as low as possible.
Check that all crossover frequencies are properly set.
Check for broken or damaged cable insulation on the speaker leads.
Amplifier gets
very hot
Check that there is good air circulation around the amp.
Adjust the input gain to properly match the source unit
Engine noise
This is usually caused by poor quality RCA cables, which can pick up radiated noise.
Use only the best quality cables, and route them away from any power cables.
Engine noise
(alternator
whine)
Check that the RCA grounds are not shorted to the vehicle chassis.
Check that the source unit is properly grounded.
Check the ground connection is clean and any paint is scraped away.

Specifications
Maximum Power 800 W + (250 W @ 2 Ohm)
THD < 0.1%
S/N Ratio >88db
Frequency Response 20 Hz - 150 Hz
Input Sensitivity 100 mV - 6 V
Low Pass Filter 50 Hz –150 Hz @ 12dB/Oct
Subsonic Filter 20 Hz –50 Hz @ 6dB/Oct
Bass Boost @ 45 Hz 0 to +12 dB
Fuse Rating15 A
Dimensions 14”x 9-7/8” x 3” (356x251x76mm)
