Planet Networking & Communication IPM-16120 User manual

IP-based 16-port Metered
Power Distribution Unit
IPM-16120

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 2-
Copyright
Copyright 2016 by PLANET Technology Corp. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with respect to the
contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular
purpose. Any software described in this manual is sold or licensed "as is". Should the programs prove
defective following their purchase, the buyer (and not PLANET, its distributor, or its dealer) assumes the
entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting
from any defect in the software. Further, PLANET reserves the right to revise this publication and to
make changes from time to time in the contents hereof without obligation to notify any person of such
revision or changes.
All brand and product names mentioned in this manual are trademarks and/or registered trademarks of
their respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
To assure continued compliance, use only shielded interface cables when connecting to computer or
peripheral devices. Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 3-
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In
order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to
the antenna shall not be less than 20 cm (8 inches) during normal operation.
Safety
This equipment is designed with the utmost care for the safety of those who install and use it. However,
special attention must be paid to the dangers of electric shock and static electricity when working with
electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed
at all times to ensure the safe use of the equipment.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.
WEEE Regulation
To avoid the potential effects on the environment and human health as a result of the
presence of hazardous substances in electrical and electronic equipment, end users of
electrical and electronic equipment should understand the meaning of the crossed-out
wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to collect such
WEEE separately.
Revision
User’s Manual of PLANET IP-based 16-port Metered Power Distribution Unit
Model: IPM-16120
Rev: 1.00 (June, 2016)
Part No. EM-IPM-16120_v1.0

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 4-
Table of Contents
Chapter 1. Product Introduction.............................................................................................6
1.1 Package Contents.........................................................................................................6
1.2 Overview .......................................................................................................................6
1.3 Features ........................................................................................................................9
1.4 Specifications ..............................................................................................................10
Chapter 2. Hardware Interface............................................................................................12
2.1 Physical Descriptions..................................................................................................12
2.2 Installation Precautions...............................................................................................14
2.3 Hardware Installation...................................................................................................14
2.4 Initial Utility Installation................................................................................................15
Chapter 3. Quick Setup .......................................................................................................17
3.1 Network connection.....................................................................................................17
3.2 Setup Wizard...............................................................................................................17
Chapter 4. Web-based Management ..................................................................................21
4.1 Monitor ........................................................................................................................21
4.2 System ........................................................................................................................22
4.2.1 Network setting .................................................................................................22
4.2.2 Email Server......................................................................................................24
4.2.3 SMS Server.......................................................................................................25
4.2.4 SNMP................................................................................................................26
4.2.5 Syslog ...............................................................................................................28
4.2.6 Peripheral Parameters......................................................................................29
4.2.7 Other .................................................................................................................30
4.3 Firewall........................................................................................................................31
4.3.1 IP Filter..............................................................................................................31
4.3.2 MAC filter ..........................................................................................................32
4.4 Account........................................................................................................................32
4.4.1 Basic Info ..........................................................................................................33
4.4.2 Email .................................................................................................................34
4.4.3 SMS ..................................................................................................................34
4.5 Time.............................................................................................................................36
4.6 Chart............................................................................................................................37
4.7 Event ...........................................................................................................................38
4.8 Upgrade.......................................................................................................................38

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 5-
Appendix A: Reset to Default via Navigation Button..............................................................40
Appendix B: HTTP Message API Example............................................................................41

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 6-
Chapter 1 Product Introduction
1.1 Package Contents
The package should contain the following:
Quick Installation Guide x 1
If any of the above items are missing, please contact your seller immediately.
1.2 Overview
High Voltage Power Distribution Unit with Digital Load Meter
PLANET IPM-16120 is a 16-port IP Power Management device that provides premium power
protection for your professional workstations and connected devices. With the innovative IP-based
technology, PLANET has made the traditional power management equipment into true networking
devices. The unit comes with a digital load meter to enable the PDU's load to be monitored on-site.

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 7-
Vertical Mounting
Any devices can be easily mounted vertically in racks or enclosures and occupy zero U of valuable rack
space, which allows more equipment in the rack.
Electric Current Monitored on Display
The aggregate current draw per rack PDU is displayed on the unit via a digital display. The local digital
display helps installers avoid overloaded circuits by providing a visible warning when the current draw is
close to the maximum amperage draw of the strip.
Remote Management Capabilities
Full-featured network management interfaces provide standards-based management via Web, SNMP

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 8-
and Telnet. They allow users to access, configure, and manage units from remote locations to save
valuable time.
Overload Protection
16-amp circuit breaker prevents dangerous circuit overloads that could damage equipment. The PDU
features a built-in circuit breaker and reset switch, ensuring dependable performance of vital
equipment.

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 9-
1.3 Features
Hardware
■Zero U rack-mount size design
■IEC outlet models
■16 power outlets that support real-time current image monitoring
■10ft (3m) power cord
■Hot-swap IP-module without power shutdown
■LCD panel displays current, max. alarm, device temperature and network information
Power Distribution
■Maximum Amps/Inlet: IEC 16A/1 inlet
■Maximum Amps for 16 Outlets: IEC 16A for 16 outlets
■Full Frequency Range: 50~60Hz
Remote Access
■Remote power control via TCP/IP and a built-in 10/100Mbps Ethernet port
■Multi browsers support (IE, Google, Firefox, Safari, Opera, Netscape)
Management
■Provides Install Wizard to ease users' setting of parameters
■Events notification by sending pop-up message, trap or e-mail
■Supports Management Information Base (MIB) files for SNMP
■24-hour power consumption and device temperature monitoring
■Sets over-current watchdog for power outlet
Security
■Web page supports 1024-bit SSL security encryption transmission
■Supports Secure Socket Layer V3 and Secure Shell V1 protocols
■Administrator and multiple users with password protection for double-layer security
■IP Filtering -- Address-specific IP security masks to prevent unauthorized access

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 10 -
1.4 Specifications
Product IPM-16120
Hardware Specifications
Output Power Port 16
Input Power Port 1
Buzzer 1
Breaker 1 x 16A
Network Connector 1 RJ45 port for 10/100BASE-TX
Button Five-sided button
LED
Alarm
Lights remaining lit: Alarm has occurred
Slow flashing: There was current overloading
Power Distribution
Input Power Output Power
Voltage 100~240V
Frequency 50~60Hz
Connection 1 x IEC320 C20 16 x IEC320 C13
Maximum Current 16A
Maximum Line Current - 10A
Cord Length 3 meters -
Management
User Account General/Manage/Administrator
Management Utility Web browser, SNMP software, Windows base utility, Telnet
Security IP filter/MAC filter/Secure 128-bit SSL encryption
Standards Conformance
Computer Interface IEEE 802.3 10BASE-T
IEEE 802.3u 10/100BASE-TX
Regulatory Compliance CE, FCC

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 11 -
System Unit
Operating Temperature -5 ~ 45 degrees C
Operating Humidity 5 ~ 95%
Operating Altitude 0 ~ 4500 meters
Dimensions (W x D x H) 748 x 43 x 43 mm
Weight 1.7kg
Installation Zero U

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 12 -
Chapter 2 Hardware Interface
2.1 Physical Descriptions
Dimensions (W x D x H) 748 x 43 x 43 mm
Weight 1.7kg (gross weight)
Front Panel
1 RJ45 Port Enable user to configure the IP Metered PDU through a LAN or WAN.
2 Alarm Lights remaining lit: Alarm has occurred.
Slow flashing: There was current overloading.
3 LCD Panel Display current information, max. alarm current, device temperature and
network information.
4 Five-sided Button Provides LCD switching panel info and setting parameters.
Please see below the Panel Operation for more understanding.
5 Power Outlet Connect a device to each power outlet to supply power to it.
Note: The max. output current is 16 amps.
6 Power Inlet Device power lead.
7 Circuit Breaker
Protection
Prevents power overload and damage to devices when circuit breaker
protection trips. Press the button on the breaker protection to return to
normal operation after eliminating abnormal device power supply.
8 Buzzer Buzzer will make a beep sound when alarm happens.
9 RJ45 LED
Link (Green): The port is successfully established.
Network Speed
(Yellow):
Blink: The port is running at a speed of 100Mbps.
Off: The port is running at a speed of 10Mbps.

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 13 -
Panel Operation
The first mode of LCD is total current, switching with the five-sided button down to show the regular
sequence of current info, max. current, inner temp.and network info as shown below:
When the LCD menu shows current info, hold the five-sided button in the middle for 3 seconds until
a long beep sounds to enter alarm current setting.
1. For modification of alarm current, press to increase the alarm current by 0.5A in
each press.
2. After increasing to the maximal alarm current, the value will return back to 0.5A
again, and this will cycle.
3. Once the alarm current reaches the wanted value, hold the five-sided button in
the middle for 3 seconds until a "beep" soundsto end the setting.
When the LCD shows the maximum total current record, hold the five-sided button in the middle
for 3 seconds until a long beep sounds to adjust it to a zero point.

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 14 -
When the LCD menu shows network info, hold the five-sided button for 10 seconds until two
beeps sound to enter reset mode.
2.2 Installation Precautions
Please set the maximum power-off protection allowed by power circuit as per the rated current
information indicated on the device with reference to the local state rules, safety procedures and
disconnector deviation.
The unit can only be connected to a grounded power outlet or system.
Make sure the total current output of all the connected systems is within the rated current indicated
on the device.
The test results of this device may be inaccurate giving unstable power supply.
Avoid using this device in places near water or moisture environments.
In order to avoid a fire hazard or risk of electric shock, do not expose the product to
rain or moisture.
Use the attachments/accessories specified by the manufacturer only.
Please avoid any items or liquids entering the device because their contact with dangerous voltage
points or short-circuit parts may cause a fire or electric shock.
2.3 Hardware Installation
IP Metered PDU provides standard 0U rack for the installation of devices; for the installation of the
device on the rack, you can install it on the top or bottom of the rack.

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 15 -
Please make sure all the units connected are powered off before the installation of the
device and take other necessary precautions during the installation.
2.4 Initial Utility Installation
PLANET “IP Search” is a software utility used to search the IP Metered PDU product on a network
quickly and with ease.
Step 1: Please download the IP Search tool from PLANET Download Center:

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 16 -
Step 2: Please press the “Refresh” button to find out your IP Metered PDU.
1. Before searching the IP, please make sure your PC is in the same IP segment
as control gateway.
2. Do not set double IP addresses on the same LAN card.
Step 3: Enter the IP address and login to the homepage of IP Metered PDU.

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 17 -
Chapter 3 Quick Setup
In this section users can learn how to query device IP and how to set language, account password,
network and time zone through daemon.
3.1 Network Connection
After the device connects to the network, IP can be acquired automatically through DHCP server (The
device IP will be preset to 192.168.0.10 if there is no DHCP server.). The acquired IP can be displayed
on the LCD panel or device IP can be searched by IP Search Utility.
Default DHCP Client On
Default IP Address 192.168.0.10 – if no DHCP existed in the network
Default Port 80
Default Login User Name Set itself
Default Login Password Set itself
Search Tools ip_search
3.2 Setup Wizard
When you use the IPM-16120 for the first time, after it is connected to the Internet, browser would pop
up Setup Wizard asking you to provide language, account, password, network and time zone.
Step 1: Language Selection
Select your language currently available in English, Traditional Chinese and Simplified Chinese, and
press Next to continue.

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 18 -
Step 2: Account Setting
This menu is for setting the admin account and password of the device. Press Next to continue.
Step 3: Host Setting
The product is assigned dynamically (DHCP). To specify a fixed IP address, please fill in IP Address,
Subnet Mask and Gateway. Press Next to continue.
Step 4: DNS Setting
Key in the DNS server, provided by ISP providers, and then you can set up two DNS servers. Press
Next to continue.

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 19 -
Step 5: Web Server
Https can help protect streaming data transmission over the internal on the higher security level. You
can select the connection type. "Https" means user cannot connect the camera via Http protocol. The
Https path will be: "https://(IP address)/". If you select "Http & Https", both the Http and Https path can
be used to access the device. Press Next to continue.
Step 6: Time Format
Select the time format to show in the system. Press Next to continue.
Step 7: Time Server Setting
User can set up device time synchronized with Time Server. Press Next to continue.
Step 8: Time Zone
Please fill in the time zone where the device is. The system is based on Greenwich Mean Time, and
thus, an accuracy setting to time zone may affect the time record of events and chart. Press Next to
continue.

IP-based 16-port Metered Power Distribution Unit
IPM-16120
- 20 -
Step 9: Daylight Saving Time
Set the Daylight saving time from Sunday to Saturday. Press Next to continue.
Step 10: General Setting
You may set up operational overtime in this section. Press Finish to save all settings.
