Planet Networking & Communication IGS-5225-8T2S2X User manual

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
1

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
2
Trademarks
Copyright © PLANET Technology Corp. 2018.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no
warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for
a particular purpose. PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability
for any inaccuracies or omissions that may have occurred.
Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of
PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANET makes
no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to
this User's Manual and/or to the products described in this User's Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your comments and
suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
CE Mark Warning
This is a ClassA product. In a domestic environment, this product may cause radio interference, in which case the user may be
required to take adequate measures.
Energy Saving Note of the Device
This power required device does not support Standby mode operation. For energy saving, please remove the power cable to
disconnect the device from the power circuit. In view of saving the energy and reducing the unnecessary power consumption, it
is strongly suggested to remove the power connection for the device if this device is not intended to be active.
WEEE Warning
To avoid the potential effects on the environment and human health as a result of the presence of
hazardous substances in electrical and electronic equipment, end users of electrical and electronic
equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of
WEEE as unsorted municipal waste and have to collect such WEEE separately.
Revision
User's Manual of PLANET Industrial L3 Multi-port Full Gigabit Industrial Industrial Managed Switch
FOR MODEL: IGS-5225--8T2S2X/IGS-5225-8P2S2X
REVISION: 3.0 (April, 2018)
Part No: EM-IGS-5225-8T2S2X & 8P2S2X_v3.0

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
3
TABLE OF CONTENTS
1. INTRODUCTION ....................................................................................................... 11
1.1 Packet Contents .........................................................................................................................................11
1.2 Product Description...................................................................................................................................12
1.3 How to Use This Manual............................................................................................................................16
1.4 Product Features........................................................................................................................................17
1.5 Product Specifications ..............................................................................................................................21
2. INSTALLATION ...................................................................................................................25
2.1 Hardware Description................................................................................................................................25
2.1.1 Physical Dimensions ...........................................................................................................................................25
2.1.2 Front Panel..........................................................................................................................................................27
2.1.3 LED Indications ...................................................................................................................................................29
2.1.4 Switch Rear Panel...............................................................................................................................................31
2.1.5 Wiring the Fault Alarm Contact............................................................................................................................32
2.1.6 Wiring the Digital Input/Output.............................................................................................................................33
2.2 Installing the Industrial Managed Switch.................................................................................................35
2.2.1 Installation Steps.................................................................................................................................................35
2.2.2 DIN-rail Mounting.................................................................................................................................................36
2.2.3 Wall Mount Plate Mounting..................................................................................................................................38
2.3 Cabling ........................................................................................................................................................39
2.3.1 Installing the SFP/SFP+ Transceiver...................................................................................................................40
2.3.2 Removing the SFP/SFP+ Transceiver.................................................................................................................43
3. SWITCH MANAGEMENT....................................................................................................43
3.1 Requirements .............................................................................................................................................44
3.2 Management Access Overview.................................................................................................................45
3.3 Administration Console.............................................................................................................................46
3.4 Web Management.......................................................................................................................................48
3.5 SNMP-based Network Management.........................................................................................................49
3.6 PLANET Smart Discovery Utility ..............................................................................................................50

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
4
4. WEB CONFIGURATION...................................................................................................... 52
4.1 Main Web Page ...........................................................................................................................................55
4.2 System.........................................................................................................................................................57
4.2.1 Management........................................................................................................................................................58
4.2.1.1 System Information....................................................................................................................................58
4.2.1.2 IP Configuration.........................................................................................................................................59
4.2.1.3 IP Status....................................................................................................................................................62
4.2.1.4 Users Configuration...................................................................................................................................63
4.2.1.5 Privilege Levels.........................................................................................................................................66
4.2.1.6 NTP Configuration.....................................................................................................................................67
4.2.1.6.1 System Time Correction Manually..........................................................................................................69
4.2.1.7 Time Configuration ....................................................................................................................................70
4.2.1.8 UPnP.........................................................................................................................................................72
4.2.1.9 DHCP Relay..............................................................................................................................................73
4.2.1.10 DHCP Relay Statistics.............................................................................................................................75
4.2.1.11 CPU Load................................................................................................................................................77
4.2.1.12 System Log .............................................................................................................................................78
4.2.1.13 Detailed Log............................................................................................................................................79
4.2.1.14 Remote Syslog........................................................................................................................................80
4.2.1.15 SMTP Configuration................................................................................................................................81
4.2.1.16 Fault Alarm..............................................................................................................................................82
4.2.1.17 Digital Input/Output..................................................................................................................................83
4.2.2 Simple Network Management Protocol ...............................................................................................................85
4.2.2.1 SNMP Overview........................................................................................................................................85
4.2.2.2 SNMP System Configuration.....................................................................................................................86
4.2.2.3 SNMP Trap Configuration..........................................................................................................................88
4.2.2.4 SNMP System Information........................................................................................................................90
4.2.2.5 SNMPv3 Communities..............................................................................................................................91
4.2.2.6 SNMPv3 Users..........................................................................................................................................92
4.2.2.7 SNMPv3 Groups........................................................................................................................................93
4.2.2.8 SNMPv3 Views..........................................................................................................................................94
4.2.2.9 SNMPv3 Access........................................................................................................................................95
4.2.3 RMON..................................................................................................................................................................97
4.2.3.1 RMON Alarm Configuration.......................................................................................................................97
4.2.3.2 RMON Alarm Status..................................................................................................................................99
4.2.3.3 RMON Event Configuration.....................................................................................................................100
4.2.3.4 RMON Event Status................................................................................................................................101
4.2.3.5 RMON History Configuration...................................................................................................................102
4.2.3.6 RMON History Status..............................................................................................................................103

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
5
4.2.3.7 RMON Statistics Configuration................................................................................................................104
4.2.3.8 RMON Statistics Status...........................................................................................................................105
4.2.4 DHCP server .....................................................................................................................................................107
4.2.4.1 DHCP Server Mode Configuration...........................................................................................................107
4.2.4.2 DHCP Server excluded IP Configuration.................................................................................................108
4.2.4.3 DHCP Server pool Configuration.............................................................................................................109
4.2.4.4 DHCP Server pool Configuration.............................................................................................................110
4.2.4.5 DHCP Server Binding IP Configuration................................................................................................... 111
4.2.4.6 DHCP Server Declined IP .......................................................................................................................112
4.2.4.7 DHCP Detail Statistics.............................................................................................................................113
4.2.5 Industrial Protocol..............................................................................................................................................115
4.2.5.1 Protocol Configuration.............................................................................................................................115
4.3 Switching...................................................................................................................................................116
4.3.1 Port Management..............................................................................................................................................116
4.3.1.1 Port Configuration....................................................................................................................................116
4.3.1.2 Port Statistics Overview...........................................................................................................................118
4.3.1.3 Port Statistics Details...............................................................................................................................118
4.3.1.4 SFP Module Information..........................................................................................................................120
4.3.1.5 Port Mirror ...............................................................................................................................................122
4.3.2 Link Aggregation................................................................................................................................................126
4.3.2.1 Static Aggregation ...................................................................................................................................128
4.3.2.2 Static Aggregation Status........................................................................................................................129
4.3.2.3 LACP Configuration.................................................................................................................................130
4.3.2.4 LACP System Status...............................................................................................................................132
4.3.2.5 LACP Port Status ....................................................................................................................................133
4.3.2.6 LACP Port Statistics................................................................................................................................134
4.3.3 VLAN.................................................................................................................................................................135
4.3.3.1 VLAN Overview.......................................................................................................................................135
4.3.3.2 IEEE 802.1Q VLAN.................................................................................................................................136
4.3.3.3 VLAN Port Configuration.........................................................................................................................139
4.3.3.4 VLAN Membership Status.......................................................................................................................145
4.3.3.5 VLAN Port Status ....................................................................................................................................146
4.3.3.6 Private VLAN...........................................................................................................................................147
4.3.3.7 Port Isolation ...........................................................................................................................................149
4.3.3.8 VLAN setting example:............................................................................................................................151
4.3.3.8.1 Two Separate 802.1Q VLANs...............................................................................................................151
4.3.3.8.2 VLAN Trunking between two 802.1Q aware switches..........................................................................153
4.3.3.8.3 Port Isolate...........................................................................................................................................156
4.3.3.9 MAC-based VLAN...................................................................................................................................157
4.3.3.10 IP Subnet-based VLAN Membership Configuration...............................................................................158

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
6
4.3.3.11 Protocol-based VLAN............................................................................................................................159
4.3.3.12 Protocol-based VLAN Membership .......................................................................................................161
4.3.4 Spanning Tree Protocol.....................................................................................................................................163
4.3.4.1 Theory.....................................................................................................................................................163
4.3.4.2 STP System Configuration......................................................................................................................169
4.3.4.3 Bridge Status...........................................................................................................................................171
4.3.4.4 CIST Port Configuration ..........................................................................................................................172
4.3.4.5 MSTI Priorities.........................................................................................................................................175
4.3.4.6 MSTI Configuration..................................................................................................................................176
4.3.4.7 MSTI Ports Configuration........................................................................................................................177
4.3.4.8 Port Status...............................................................................................................................................179
4.3.4.9 Port Statistics ..........................................................................................................................................180
4.3.5 Multicast ............................................................................................................................................................181
4.3.5.1 IGMP Snooping.......................................................................................................................................181
4.3.5.2 Profile Table.............................................................................................................................................184
4.3.5.3 Address Entry..........................................................................................................................................186
4.3.5.4 IGMP Snooping Configuration.................................................................................................................187
4.3.5.5 IGMP Snooping VLAN Configuration.......................................................................................................188
4.3.5.6 IGMP Snooping Port Group Filtering.......................................................................................................190
4.3.5.7 IGMP Snooping Status............................................................................................................................192
4.3.5.8 IGMP Group Information..........................................................................................................................193
4.3.6 MLD Snooping...................................................................................................................................................194
4.3.6.1 MLD Snooping Configuration ..................................................................................................................194
4.3.6.2 MLD Snooping VLAN Configuration........................................................................................................195
4.3.6.3 MLD Snooping Port Group Filtering.........................................................................................................197
4.3.6.4 MLD Snooping Status..............................................................................................................................198
4.3.6.5 MLD Group Information...........................................................................................................................199
4.3.6.6 MLDv2 Information..................................................................................................................................200
4.3.7 MVR (Multicast VLAN Registration)...................................................................................................................202
4.3.7.1 MVR Configuration..................................................................................................................................202
4.3.7.2 MVR Status.............................................................................................................................................205
4.3.7.3 MVR Groups Information.........................................................................................................................206
4.3.7.4 MVR SFM Information.............................................................................................................................206
4.3.8 LLDP..................................................................................................................................................................208
4.3.8.1 Link Layer Discovery Protocol.................................................................................................................208
4.3.8.2 LLDP Configuration.................................................................................................................................208
4.3.8.3 LLDP Neighbor........................................................................................................................................211
4.3.8.4 LLDP MED Configuration........................................................................................................................212
4.3.8.5 LLDP-MED Neighbor...............................................................................................................................219
4.3.8.6 Port Statistics ..........................................................................................................................................223

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
7
4.3.9 MAC Address Table...........................................................................................................................................225
4.3.9.1 MAC Table Configuration.........................................................................................................................225
4.3.9.2 MAC Address Table Status......................................................................................................................227
4.3.10 Loop Protection ...............................................................................................................................................229
4.3.10.1 Configuration.........................................................................................................................................229
4.3.10.2 Loop Protection Status..........................................................................................................................230
4.3.11 UDLD...............................................................................................................................................................232
4.3.11.1 UDLD Port Configuration.......................................................................................................................232
4.3.11.2 UDLD Status..........................................................................................................................................233
4.3.12 GVRP ..............................................................................................................................................................235
4.3.12.1 GVRP Configuration..............................................................................................................................235
4.3.12.2 GVRP Port Configuration ......................................................................................................................236
4.3.13 PTP..................................................................................................................................................................238
4.3.13.1 PTP Configuration.................................................................................................................................238
4.4 Quality of Service.....................................................................................................................................243
4.4.1 General..............................................................................................................................................................243
4.4.1.1 QoS Port Classification............................................................................................................................244
4.4.1.2 Queue Policing........................................................................................................................................246
4.4.1.3 Port Tag Remarking.................................................................................................................................247
4.4.1.4 WERD .....................................................................................................................................................247
4.4.1.5 Statistics..................................................................................................................................................249
4.4.2 Bandwidth Control.............................................................................................................................................250
4.4.2.1 Port Policing............................................................................................................................................250
4.4.2.2 Port Schedule..........................................................................................................................................251
4.4.2.3 Port Shaping............................................................................................................................................252
4.4.3 Storm Control ....................................................................................................................................................255
4.4.3.1 Storm Policing Configuration...................................................................................................................255
4.4.4 Differentiated Service........................................................................................................................................257
4.4.4.1 Port DSCP...............................................................................................................................................257
4.4.4.2 DSCP-based QoS...................................................................................................................................258
4.4.4.3 DSCP Translation....................................................................................................................................259
4.4.4.4 DSCP Classification ................................................................................................................................260
4.4.5 QCL...................................................................................................................................................................262
4.4.5.1 QoS Control List......................................................................................................................................262
4.4.5.2 QoS Control Entry Configuration.............................................................................................................263
4.4.5.3 QCL Status..............................................................................................................................................266
4.4.5.4 Voice VLAN Configuration.......................................................................................................................267
4.4.5.5 Voice VLAN OUI Table ............................................................................................................................270
4.5 Security .....................................................................................................................................................271

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
8
4.5.1 Access Security.................................................................................................................................................271
4.5.1.1 Access Management...............................................................................................................................271
4.5.1.2 Access Management Statistics................................................................................................................272
4.5.1.3 SSH.........................................................................................................................................................273
4.5.1.4 HTTPs.....................................................................................................................................................273
4.5.2 AAA ...................................................................................................................................................................276
4.5.2.1 Authentication Configuration....................................................................................................................280
4.5.2.2 RADIUS...................................................................................................................................................283
4.5.2.3 TACACS+................................................................................................................................................285
4.5.2.4 RADIUS Overview...................................................................................................................................286
4.5.2.5 RADIUS Details.......................................................................................................................................288
4.5.3 Port Authentication ............................................................................................................................................295
4.5.3.1 Network Access Server Configuration.....................................................................................................295
4.5.3.2 Network Access Overview.......................................................................................................................298
4.5.3.3 Network Access Statistics........................................................................................................................300
4.5.4 Port Security......................................................................................................................................................305
4.5.4.1 Port Limit Control.....................................................................................................................................305
4.5.4.2 Port Security Status.................................................................................................................................308
4.5.4.3 Port Security Detail..................................................................................................................................310
4.5.5 Access Control Lists ..........................................................................................................................................312
4.5.5.1 Access Control List Status.......................................................................................................................312
4.5.5.2 Access Control List Configuration............................................................................................................313
4.5.5.3 ACE Configuration...................................................................................................................................315
4.5.5.4 ACL Ports Configuration..........................................................................................................................325
4.5.5.5 ACL Rate Limiters....................................................................................................................................327
4.5.6 DHCP Snooping................................................................................................................................................329
4.5.6.1 DHCP Snooping Configuration................................................................................................................329
4.5.6.2 Snooping Table........................................................................................................................................331
4.5.7 IP Source Guard................................................................................................................................................332
4.5.7.1 IP Source Guard Configuration................................................................................................................332
4.5.7.2 Static IP Source Guard Table ..................................................................................................................333
4.5.7.3 Dynamic IP Source Guard Table .............................................................................................................334
4.5.8 ARP Inspection..................................................................................................................................................335
4.5.8.1 ARP Inspection........................................................................................................................................335
4.5.8.2 ARP Inspection Static Table.....................................................................................................................336
4.5.8.3 Dynamic ARP Inspection Table................................................................................................................337
4.6 Power over Ethernet (IGS-5225-8P2S2X)...............................................................................................339
4.6.1 PoE....................................................................................................................................................................339
4.6.1.1 Power over Ethernet Powered Device.....................................................................................................340
4.6.1.2 System Configuration..............................................................................................................................340

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
9
4.6.1.3 Power over Ethernet Configuration..........................................................................................................341
4.6.1.4 Port Configuration....................................................................................................................................343
4.6.1.5 PoE Status ..............................................................................................................................................345
4.6.1.6 Port Sequential........................................................................................................................................346
4.6.1.7 PoE Schedule..........................................................................................................................................347
4.6.1.8 PoEAlive Check Configuration................................................................................................................350
4.6.1.9 LLDP PoE Neighbors ..............................................................................................................................351
4.7 Ring............................................................................................................................................................353
4.7.1 Ring...................................................................................................................................................................353
4.7.1.1 MEP Configuration ..................................................................................................................................354
4.7.1.2 Detailed MEP Configuration....................................................................................................................355
4.7.1.3 Ethernet Ring Protocol Switch.................................................................................................................359
4.7.1.4 Ethernet Ring Protocol Switch Configuration...........................................................................................360
4.7.1.5 Ethernet Ring Protocol Switch.................................................................................................................363
4.7.1.6 Ring Wizard Example..............................................................................................................................365
4.8 ONVIF.........................................................................................................................................................368
4.8.1 ONVIF................................................................................................................................................................368
4.8.1.1 ONVIF Device Search.............................................................................................................................368
4.8.1.2 ONVIF Device List...................................................................................................................................369
4.8.1.3 MAP Upload / Edit...................................................................................................................................370
4.8.1.4 Floor Map................................................................................................................................................371
4.9 Maintenance..............................................................................................................................................373
4.9.1 Switch Maintenance ..........................................................................................................................................373
4.9.1.1 Web Firmware Upgrade ..........................................................................................................................373
4.9.1.2 Save Startup Config ................................................................................................................................374
4.9.1.3 Configuration Download..........................................................................................................................374
4.9.1.4 Configuration Upload...............................................................................................................................375
4.9.1.5 Configuration Activate..............................................................................................................................376
4.9.1.6 Configuration Delete................................................................................................................................376
4.9.1.7 Image Select ...........................................................................................................................................376
4.9.1.8 Factory Default........................................................................................................................................377
4.9.1.9 Configuration Download..........................................................................................................................378
4.9.2 Diagnostics........................................................................................................................................................379
4.9.2.1 Ping.........................................................................................................................................................379
4.9.2.2 IPv6 Ping.................................................................................................................................................380
4.9.2.3 Remote IP Ping Test................................................................................................................................381
4.9.2.4 Cable Diagnostics....................................................................................................................................382
5. SWITCH OPERATION....................................................................................................... 385

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
10
5.1 Address Table...........................................................................................................................................385
5.2 Learning ....................................................................................................................................................385
5.3 Forwarding & Filtering.............................................................................................................................385
5.4 Store-and-Forward ...................................................................................................................................385
5.5 Auto-Negotiation ......................................................................................................................................386
6. TROUBLESHOOTING....................................................................................................... 387
APPENDIX A: Networking Connection............................................................................... 388
A.1 Switch's Data RJ45 Pin Assignments - 1000Mbps, 1000BASE-T .......................................................388
A.2 10/100Mbps, 10/100BASE-TX .................................................................................................................388
APPENDIX B : GLOSSARY.................................................................................................. 390

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
11
1. INTRODUCTION
The descriptions of PLANET L3 Industrial Managed Switch series, such as IGS-5225-8T2S2X and IGS-5225-8P2S2X, is as
follows:
IGS-5225-8T2S2X Industrial L3 8-Port 10/100/1000T Managed Ethernet Switch with 2-Port 100/1000X SFP + 2-Port
10G SFP+
IGS-5225-8P2S2X Industrial L3 8-Port 10/100/1000T 802.3at PoE Managed Ethernet Switch with 2-Port 100/1000X
SFP + 2-Port 10G SFP+
“Industrial Managed Switch” is used as an alternative name for the above models in this user’s manual.
1.1 Packet Contents
Open the box of the Industrial Managed Switch and carefully unpack it. The box should contain the following items:
Model Name
Item IGS-5225-8T2S2X IGS-5225-8P2S2X
The Industrial Managed Switch ■■
Quick Installation Guide ■■
RS232 to RJ45 Console Cable ■■
DIN-rail Kit ■■
Wall Mounting Kit ■■
SFP Dust Caps 4 4
RJ45 Dust Caps 9 9
If any of these are missing or damaged, please contact your dealer immediately; if possible, retain the carton including the
original packing material, and use them again to repack the product in case there is a need to return it to us for repair.

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
12
1.2 Product Description
PLANET Industrial Managed Switch is specially designed to build a full Gigabit backbone to transmit reliable and high-speed
data in heavy industrial demanding environments and forward data to remote network through fiber optic cabling. It comes with
an IP30 rugged case and redundant power system. Besides support for 60Gbps switch fabric to handle extremely large
amounts of video, voice and important data in a secure topology, the Industrial Managed Switch provides user-friendly but
advanced IPv6/ IPv4 management interfaces and abundant L2/L4 switching functions. It is the best investment for expanding
industrial business or upgrading its network infrastructure.
Redundant Ring, Fast Recovery for Critical Network Applications
The Industrial Managed Switch supports redundant ring technology and features strong, rapid self-recovery capability to prevent
interruptions and external intrusions. It incorporates advanced ITU-T G.8032 ERPS (Ethernet Ring Protection Switching)
technology, Spanning Tree Protocol (802.1s MSTP), and redundant power input system into customer’s industrial automation
network to enhance system reliability and uptime in harsh factory environments. In a certain simple Ring network, the recovery
time of data link can be as fast as 20ms.
Environmentally Hardened Design
With IP30 aluminum case, the Industrial Managed Switch provides a high level of immunity against electromagnetic interference
and heavy electrical surges which are usually found on plant floors or in curb-side traffic control cabinets. It also possesses an
integrated power supply source with a wide range of voltages for worldwide high availability applications requiring dual or
backup power inputs. Being able to operate under the temperature range from -40 to 75 degrees C, the Industrial Managed
Switch can be placed in almost any difficult environment.
Digital Input and Digital Output for External Alarm
The Industrial Managed Switch supports Digital Input and Digital Output on its upper panel. The external alarm enables users to
use Digital Input to detect external device’s status (such as door intrusion detector), and send event alarm to the administrators.
The Digital Output could be used to alarm the administrators if the Industrial Managed Switch port is link-down, link-up or
power-dead.

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
13
Intelligent Powered Device Alive Check (IGS-5225-8P2S2X)
The Industrial Managed PoE Switch can be configured to monitor connected PD (powered device) status in real-time via ping
action. Once the PD stops working and responding, the Industrial Managed PoE Switch will recycle the PoE port power and
bring the PD back to work. It will greatly enhance the network reliability through the PoE port resetting the PD’s power source
and reduce administrator management burden.

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
14
PoE Schedule for Energy Saving (IGS-5225-8P2S2X)
Under the trend of energy saving worldwide and contributing to environment protection on the Earth, the Industrial Managed
PoE Switch can effectively control the power supply along with its capability of giving high watts power over Ethernet. The “PoE
schedule” function enables you to activate or inactivate PoE power feeding for each PoE port during specified time intervals,
which is a powerful function to help SMBs or enterprises save power and money.
Robust Layer2 Features
The Industrial Managed Switch can be programmed for advanced switch management function, such as dynamic port link
aggregation, Q-in-Q VLAN, Multiple Spanning Tree Protocol (MSTP), Layer 2/4 QoS, bandwidth control and IGMP/MLD
snooping. The Industrial Managed Switch allows the operation of a high-speed trunk combining multiple ports.
IPv6/IPv4 Full-function Secure Switch for Building Automation Networking
The Industrial Managed Switch is the ideal solution to fulfilling the demand of IPv6 management Gigabit Ethernet Switch,
especially in the Industrial hardened environment. It supports both IPv4 and IPv6 protocols, advanced Layer 2 to Layer 4 data
switching and redundancy, QoS traffic control, network access control and authentication, and Secure Management features to
protect customer’s industrial and building automation network connectivity with reliable switching recovery capability that is
suitable for implementing fault tolerant and mesh network architectures.
IPv4 and IPv6 VLAN Routing for Secure and Flexible Management
The Industrial Managed Switch offers IPv4/IPv6 VLAN routing feature which allows to crossover different VLANs and different IP
addresses for the purpose of having a highly-secured, flexible management and simpler networking application.
User-friendly Management Interfaces
For efficient management, the Industrial Managed Switch is equipped with console, Web and SNMP management interfaces.
With the built-in web-based management interface, the Industrial Managed Switch offers an easy-to-use, platform independent
management and configuration facility. The Industrial Managed Switch supports SNMP which can be managed via any
management software based on standard SNMP v1 or v2. For reducing product learning time, the Industrial Managed Switch
offers Cisco-like command via Telnet or console port and customer doesn’t need to learn new command from these switches.
Moreover, the Industrial Managed Switch offers remote secure management by supporting SSH, SSL and SNMPv3 connection
which can encrypt the packet content at each session.

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
15
Intelligent SFP Diagnosis Mechanism
The Industrial Managed Switch supports SFP-DDM (Digital Diagnostic Monitor) function that can easily monitor real-time
parameters of the SFP for network administrator, such as optical output power, optical input power, temperature, laser bias
current, and transceiver supply voltage.
Flexible and Extendable 10Gb Ethernet Solution
10G Ethernet is a big leap in the evolution of Ethernet. Each of the 10G SFP+ slots in the IGS-5225-8T2S2X/IGS-5225-8P2S2X
supports dual speed and 10GBASE-SR/LR or 1000BASE-SX/LX, providing broad bandwidth and powerful processing
capacity. With its 2-port, 10G Ethernet link capability, the administrator now can flexibly choose the suitable SFP/SFP+
transceiver according to the transmission distance or the transmission speed required to extend the network efficiently.
Flexible and Extendable Solution
It features 100BASE-FX and 1000BASE-SX/LX SFP (Small Form-factor Pluggable) fiber-optic modules, meaning the
administrator now can flexibly choose the suitable SFP transceiver according to the transmission distance or the transmission
speed required to extend the network efficiently.
1588 Precision Time Protocol for Industrial Computing Networks
The Industrial Managed Switch is intended for telecom and carrier Ethernet applications, supporting MEF service delivery and
timing over packet solutions for the IEEE 1588 Precision Time Protocol and synchronous Ethernet.

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
16
1.3 How to Use This Manual
This User’s Manual is structured as follows:
Section 2, INSTALLATION
The section explains the functions of the Industrial Managed Switch and how to physically install the Industrial
Managed Switch.
Section 3, SWITCH MANAGEMENT
The section contains the information about the software function of the Industrial Managed Switch.
Section 4, WEB CONFIGURATION
The section explains how to manage the Industrial Managed Switch by Web interface.
Section 5,SWITCH OPERATION
The chapter explains how to do the switch operation of the Industrial Managed Switch.
Section 6,TROUBLESHOOTING
The chapter explains how to do troubleshooting of the Industrial Managed Switch.
Appendix A
The section contains cable information of the Industrial Managed Switch.
Appendix B
The section contains glossary information of the Industrial Managed Switch.

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
17
1.4 Product Features
Physical Port
8 10/100/1000BASE-T Gigabit Ethernet RJ45 ports
2 100/1000BASE-X mini-GBIC/SFP slots for SFP type auto detection
2 10GBASE-SR/LR SFP+ slots, backward compatible with 1000BASE-SX/LX/BX SFP
One RJ45 console interface for basic management and setup
Power over Ethernet (IGS-5225-8P2S2X)
Complies with IEEE 802.3at Power over Ethernet Plus/end-span PSE
Up to 8 IEEE 802.3af/802.3at devices powered
Supports PoE power up to 36 watts for each PoE port
240-watt PoE budget
Auto detects powered device (PD)
Circuit protection prevents power interference between ports
Remote power feeding up to 100m
PoE management features
−Total PoE power budget control
−Per port PoE function enable/disable
−PoE admin-mode control
−PoE port power feeding priority
−Per PoE port power limit
−PD classification detection
Intelligent PoE features
−Temperature threshold control
−PoE usage threshold control
−PD alive check
−PoE schedule
Industrial Case & Installation
IP30 aluminum case
DIN-rail and wall-mount design
Redundant power design (IGS-5225-8T2S2X)
−12~48V DC, redundant power with polarity reverse protect function
−24V AC power input acceptable
Redundant power design (IGS-5225-8P2S2X)
−48~56V DC, redundant power with polarity reverse protect function
Supports 6000V DC Ethernet ESD protection
-40 to 75 degrees C operating temperature
Digital Input & Digital Output
2 Digital Input (DI)
2 Digital Output (DO)

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
18
Integrate sensors into auto alarm system
Transfer alarm to IP network via email and SNMP trap
Layer 2 Features
Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex)
High performance of Store-and-Forward architecture, and runt/CRC filtering that eliminates erroneous packets to
optimize the network bandwidth
Storm Control support
−Broadcast/Multicast/Unicast
Supports VLAN
−IEEE 802.1Q tagged VLAN
−Up to 255 VLANs groups, out of 4095 VLAN IDs
−Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
−Private VLAN Edge (PVE)
−Protocol-based VLAN
−MAC-based VLAN
−Voice VLAN
Supports Spanning Tree Protocol
−IEEE 802.1D Spanning Tree Protocol (STP)
−IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
−IEEE 802.1s Multiple Spanning Tree Protocol (MSTP), spanning tree by VLAN
−BPDU Guard
Supports Link Aggregation
−802.3ad Link Aggregation Control Protocol (LACP)
−Cisco ether-channel (static trunk)
−Maximum 6 trunk groups with 8 ports per trunk group
−Up to 16Gbps bandwidth (duplex mode)
Provides port mirror (many-to-1)
Port mirroring to monitor the incoming or outgoing traffic on a particular port
Loop protection to avoid broadcast loops
Layer 3 IP Routing Features
IP interfaces (Max. 128 VLAN interfaces)
Routing table (Max. 128 routing entries)
Routing Protocols (IPv4/IPv6 hardware static routing)
Quality of Service
Ingress Shaper and Egress Rate Limit per port bandwidth control
8 priority queues on all switch ports
Traffic classification
- IEEE 802.1p CoS
- TOS/DSCP/IP precedence of IPv4/IPv6 packets

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
19
- IP TCP/UDP port number
- Typical network application
Strict priority and Weighted Round Robin (WRR) CoS policies
Supports QoS and In/Out bandwidth control on each port
Traffic-policing policies on the switch port
DSCP remarking
Multicast
Supports IGMP snooping v1, v2 and v3
Supports MLD snooping v1 and v2
Querier mode support
IGMP snooping port filtering
MLD snooping port filtering
Multicast VLAN Registration (MVR) support
Security
IEEE 802.1x Port-based/MAC-based network access authentication
Built-in RADIUS client to cooperate with the RADIUS servers
TACACS+ login users access authentication
RADIUS/TACACS+ users access authentication
Access Control List
- IP-based Access Control List (ACL)
- MAC-based Access Control List
Source MAC/IP address binding
DHCP snooping to filter un-trusted DHCP messages
DynamicARP Inspection discards ARP packets with invalid MAC address to IP address binding
IP Source Guard prevents IP spoofing attacks
Auto DoS rule to defend DoS attacks
IP address access management to prevent unauthorized intruder
Management
IPv4 and IPv6 dual stack management
Switch Management Interfaces
- Console/Telnet Command Line Interface
- Web switch management
- SNMP v1, v2c and v3 switch management
- SSH/SSL secure access
Four RMON groups (history, statistics, alarms, and events)
IPv6 IP address/NTP/DNS management
Built-in Trivial File Transfer Protocol (TFTP) client
BOOTP and DHCP for IP address assignment

User’s Manual of IGS-5225-8T2S2X & 8P2S2X series
20
System Maintenance
- Firmware upload/download via HTTP/TFTP
- Reset button for system reboot or reset to factory default
- Dual Images
DHCP Server
DHCP Relay
DHCP Option 82
User Privilege levels control
Network Time Protocol (NTP)
Link Layer Discovery Protocol (LLDP) and LLDP-MED
Network Diagnostic
- ICMPv6/ICMPv4 Remote Ping
- Cable Diagnostic technology provides the mechanism to detect and report potential cabling issues
SMTP/Syslog remote alarm
System Log
SNMP trap for interface Link up and Link down notification
SFP-DDM (Digital Diagnostic Monitor)
Reset button for system reboot or reset to factory default
ONVIF Supports
Precision Time Protocol(PTP) Clock transparent PLANET
Smart Discovery Utility for deployment management
