Product Specification of ICA-4500V
1. PRODUCT DESCRIPTION
Exceptional surveillance with outdoor-ready 5
Mega-Pixel camera
The PLANET ICA-4500V Network Camera with IR
Illuminator is a high resolution camera for round-the-clock
surveillance over IP networks. This camera supports H.264,
MPEG-4, and JPEG compression formats and delivers
excellent picture quality in 3 Mega-Pixel resolutions at 30
frames per second (fps) and Full HD resolutions at 30
frames per second (fps It is perfect for remote and discreet
monitoring of indoor areas such as stores, banks, hotels,
office lobbies, and warehouses.
Vari-Focal Offer the Best Recording Flexibility
The ICA-4500V incorporates the Mega-Pixel Vari-Focal
Lens from TAMRON, which has the option of selecting a high millimeter setting for narrow
viewing fields or a low millimeter setting for wider viewing fields. The ICA-4500V provides high
quality images under all lighting conditions.
Day & Night functionality
To adapt to constantly changing lighting conditions, the ICA-4500V comes with a removable
IR-cut filter and built-in IR illuminators, which enables the camera to provide color video when
there is sufficient light, and black/white video in dark conditions. The camera is able to maintain
clear images 24 hours a day.
Exceptional Image quality
Together with powerful image processing attributes like Wide Dynamic Range and 3D Digital
Noise Reduction (3DNR) technology, the camera is able to filter the intense backlight
surrounding a subject and remove noises from video signal. The result is that an extremely clear
and exquisite picture quality can be produced even under any challenging lighting conditions.
Passive InfraRed (PIR) Sensor
When people pass by or in an emergency situation, the built-in PIR motion detection sensor will
“detect” and start recording automatically, which is able to detect movement up to 6 meters
away. When motion is detected at the specified regions, the additional function of alarm
notification can send an E-mail alert or send captured images via FTP upload to a designated
storage server.
Camera tampering and audio detection
Provided with three individually configurable motion detection zones, the camera can record
video or trigger alarms or alerts when motion is detected in user-specified areas of the camera
image. Also, the camera's built-in microphone enables it to hear what the video cannot see and
to trigger the audio detection alarm when sounds like screams, glass breaking, etc., are
detected.
Advanced event management
The ICA-4500V also supports a number of advanced features that give the camera increased
flexibility and capabilities, including Auto-iris for improve the image quality to avoid over
exposure, AV out for perform the two-way audio function, RS485 for connectivity to an optional
pan/tilt enclosure which effectively adds pan/tilt functionality and inputs/outputs for connecting
external devices such as door sensors and relays to activate light or close doors.
Flexible installation and Power functionality
The ICA-4500V incorporates Power over Ethernet supplies power to the camera via the network,
eliminating the need for power cables and reducing installation costs. With other advanced

Networking & Communication
Confidential
Filename: PS-ICA4500V_v1.doc Page 3 of 9 Printed on 3/1/2013
Product Specification of ICA-4500V
features such as the Gigabit Ethernet Transmission, giving a user the utmost in bandwidth
flexibility and storage efficiency. The ICA-4500V is ONVIF-compliant and therefore
interoperable with other manufacturer’s products, it’s also included 64-CH central management
software; the ICA-4500V is indisputably the top choice for reliable and high performance
surveillance.
2. PRODUCT FEATURES
Camera
1/3" type 5MP CMOS sensor
3.3~12.0 mm Vari-focal, DC Auto-iris Lens
0.5 lux Minimum Illumination at F1.4
Maximum resolution 2592 x1944
Removable IR-cut Filter for Day & Night Function
Built-in PIR sensor (6m/120 degree coverage) for thermal / motion detection
Video / Audio
H.264 / MPEG-4 and M-JPEG video compression simultaneously
Simultaneous multi-stream support
H.264 high profile, main profile and baseline
Max. Resolution 5 Mega-Pixel at 15fps and 1080P at 30fps
3DNR to improve picture quality at low Lux
WDR Enhancement for enhance visibility under extremely bright or dark environments
Two-way audio support with enhanced audio quality
Tamper and audio detection for unauthorized changes
Network and Configuration
Compliant with IEEE 802.3af PoE interface for flexible deployment
Equipped with Gigabit Ethernet port
Auto MDI/MDI-X supported
Support for IPv6 in addition to the standard IP protocol version 4
RTSP / UPnP / 3GPP / HTTPS protocols selectable
Easy Installation & Management
Onvif compliant for interoperability
Built-in 12 IR Illuminators, effective up to 20 Meters
Built-in Samba client for NAS
3GPP for 3G mobile remote applications
Micro SD card local video recording supported
RS485 interface for P/T scanner control
Digital Input/Outputs for integration with sensors and alarms
Cam Viewer 3 Central management software supported

Networking & Communication
Confidential
Filename: PS-ICA4500V_v1.doc Page 4 of 9 Printed on 3/1/2013
Product Specification of ICA-4500V
Analog video (BNC) output, works with conventional video devices such as TV Monitors, analog
DVRs
3. PRODUCT SPECIFICATION
3.1 COMPOMENT SPECIFICATIONS
CPU: Cortex A9 based SoC
RAM: 256MB
Flash: 16MB
LAN Chipset: RTL8211
Audio Chipset: SoC built-in
2 FUNCTIONAL SPECIFICATIONS
Model ICA-4500V
5 Mega-Pixel 20M IR Vari-Focal Dome IP Camera
Camera
Image device 1/3" type progressive scan CMOS sensor
Lens
Vari-Focal 3.3~12.0mm, DCAuto-Iris
Mechanical IR Cut Filter
Angle of view : horizontal: 27 ~ 82 Degree / vertical: 19 ~ 64 Degree
Min Illumination 0.5 Lux (Color) @ F1.4
0.1 Lux (B/W)
IR Illuminations IR LED x 12, 850nm
Built-in IR illuminators, effective up to 20 meters
Effective Pixels 2592x1944 pixels
PIR Sensor Built-in 6m/120 Degree Coverage
Video Compression H.264 / MPEG-4 / M-JPEG
Video Resolution
5M mode
H.264: 2592 x 1944 / 1280 x 960 / 640 x 480 / 320 x 240
2M mode
H.264: 1080P / 1280 x 720 / 640 x 360 / 320 x 180
MPEG4: 1280 x 720 / 640 x 360 / 320 x 180
M-JPEG: 1080P / 1280 x 720 / 640 x 360 / 320 x 180
Frame Rate Up to 30fps for Full HD resolution
Up to 15fps for 5 Mega-Pixel resolution
Image Setting
AE, AWB
3D Noise reduction
WDR
Color, brightness, sharpness, contrast
Mirror/Flip
10 Privacy Masks
Text, time and date overlay
Overlay image on video
Streaming Simultaneously multi-profile streaming

Networking & Communicatio
n
Confidential
Filename: PS-ICA4500V_v1.doc Page 5 of 9 Printed on 3/1/2013
Product Specification of ICA-4500V
Streaming over UDP, TCP, HTTP, or HTTPS
M-JPEG streaming over HTTP (server push)
Supports 3GPP mobile surveillance (MPEG4)
Controllable frame rate and bandwidth
Constant and variable bit rate (MPEG4/H.264)
ROI
Audio
Audio Streaming Two-Way Audio
Audio Compression RTSP: G.711 64kbps, G.726 32kbps
3GPP: AMR
Microphone External microphone input
Audio Output Adjustable audio output gain
Network and Configuration
Standard
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3ab 1000Base-T
Protocol IPv4, IPv6, TCP/IP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, DDNS, DHCP,
ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP, PPPoE, 3GPP, ICMP, Samba
Security Password protection, IP address filtering, HTTPS encrypted data transmission,
user access log
Users 20 clients on-line monitoring at the same time
System Integration
Application Pro
g
rammin
g
Interface
Open API for software integration
ONVIF Compliant
Alarm Triggers Intelligent Motion / Tampering / Audio detection and external input
Alarm Events
File upload via FTP, Samba to NAS, SD card or email
Notification via email, HTTP, and TCP
External output activation
Audio alerting output
Go to PTZ preset position
Video Buffer Pre- and post-alarm buffering
General
Power Requirement 12V DC, 1A
IEEE 802.3af Class 3
Power Consumption 8W max.
Operating Temperature -10 ~ 40 Degree C
Operating Humidity 20 ~ 80% (non-condensing)
Weight 635g
Dimension (Φx L) 152 x 109 mm
Emission CE, FCC
Connectors
10/100/1000 Mbps Gigabit Ethernet, RJ-45
DC power jack
Terminal block for 1 alarm input and 1 output
RS-485 interface for scanners, pan/tilts
External MIC input
Audio out
Composited video out (Max. resolution: D1 720 x 480 pixel))
Micro SD/SDHC card (Max 32GB, Class 6)
Factory default reset

Networking & Communicatio
n
Confidential
Filename: PS-ICA4500V_v1.doc Page 6 of 9 Printed on 3/1/2013
Product Specification of ICA-4500V
3.2 PHYSICAL SPECIFICATION
Dimension
Φ152mm x 109mm (Φx L)
Weight
635g
Item Description
Lens Lens set. Keep this area clean to keep excellent video quality.
IR LED Emits infrared light to provide light source in dark places
Light sensor
Detects the illumination level or the place where this IP camera is
installed, and switches IR LEDs on when it’s required.
NOTE:
When IR LEDs are switched on, this IP camera will switch
to black and white video mode to enhance video quality.
Do not cover light sensor or this IP camera will work in
black and white mode only.
PIR PIR sensor is used to sense motion or detect whether a human has
moved in or out of the sensors range.
I/O Control Instruction:
20M IR LED x 12
F3.3~12mm
Vari-Focal Lens Light Sensor
PIR

Networking & Communicatio
n
Confidential
Filename: PS-ICA4500V_v1.doc Page 7 of 9 Printed on 3/1/2013
Product Specification of ICA-4500V
Descriptions for I/O cable set:
Interface Description
DC Power The input power is DC 12V, 1A.
Note：ONLY use package power adapter supplied with the internet.
Otherwise, the product may be damaged.
RJ-45
(LAN socket, PoE )
Connect to PC or Hub/Switch.
For connect to 10Base-T Ethernet or 100Base-TX or 1000Base-TX
Fast Ethernet cabling. This Ethernet port built auto-negotiation
protocol can detect or negotiate the transmission speed of the
network automatically. Please use CAT-5 cable to connect the
Network Camera to a 1000Mbps Fast Ethernet network switch or
hub.
Note：ONLY use one power source, either from DC or from 802.3af
Power over Ethernet.
Audio Output
(Green, Line Out)
Connect a loud speaker to the IP Camera. This is for voice alerting
and two-way audio.
Microphone Input
(Pink, Audio In) Connect a microphone to the IP Camera.
Video Output
(BNC)
The Network Camera also provides composite video output. The
video output function is only for easy installation to check view angle
and focus. The output is not a Mega-pixel resolution. Furthermore,
the video output is off by default. Please turn on video.
Reset
(Factory Default) This button is used to restore the all factory default settings.
DI/DO, RS-485 The 6 pin terminal block includes 1 input ports and 1 output ports,
and RS-485 D+ and D-.

Networking & Communicatio
n
Confidential
Filename: PS-ICA4500V_v1.doc Page 8 of 9 Printed on 3/1/2013
Product Specification of ICA-4500V
Terminal block for I/O connectors:
Name Cable Color Function
12VDC Brown/White DC 12V (50mA maximum)
GND Blue/White GND
D+ Purple/White RS485 data +
D- Gray RS485 data -
DI Green/White Digital signal input
DO Orange/White Digital signal output
3.3 ENVIRONMENTAL SPECIFICATION
Operating Temperature
-10 ~ 40 degree C
Operating Humidity
20 ~ 80% (non-condensing)
3.4 REGULATORY COMPLIANCE
FCC, CE
3.5 BASIC PACKAGING
Camera unit x 1
Power Adapter x 1
Screw Kit x 1
User’s Manual CD x 1
Quick Installation Guide x 1
3.6 PACKAGE INFORMATION
Dimension
252 x 192 X 140 mm (W x D x H)
Weight
1.6kg

Networking & Communicatio
n
Confidential
Filename: PS-ICA4500V_v1.doc Page 9 of 9 Printed on 3/1/2013
Product Specification of ICA-4500V
APPENDIX A: DEFAULT SETTING
Default DHCP Client On
Default IP Address 192.168.0.20 – if no DHCP existed in the network
Default Login User Name admin
Default Login Password admin
